Prima LPR 9022 Operating and installation instructions

SERVICE Whirlpool EMEA
Customer Services LPR 9022
PRIMA Service Information
Built-in Oven
LPR 9022
8579 208 15510
Last Modification: 08/28/10
Spare Part List 2
Exploded View 3
Dimensional Sketch 4
Technical Data 5
Wiring Diagram 6
Service Bulletin 4812 715 40304 9
Service Bulletin 4812 715 40185 10
Service Bulletin 4812 715 40332 12
This document is only intended for qualified technicans who are aware of the
respective safety regulations.
Subject to modifications
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8579 208 15510, 08/28/10
page 2 of 14
Spare Part List
Pos 12NC Description
040 0 4812 417 19339 Hinge
047 0 4812 417 19137 Hinge run.mech.
110 0 4819 498 58588 Handle door
110 1 4819 462 48443 Rubber
121 3 4812 460 58418 Exhaust fume Venturi
141 0 4812 450 59964 Oven glass + supports
142 0 4812 450 59576 Inner glass
143 1 4812 404 49841 Support glass
191 0 4812 466 88874 Gasket door
201 0 4812 442 69486 Panel rear
245 0 4812 458 19334 Oven shelf
245 2 4819 458 19538 Grid
247 1 4819 395 48003 Plier grid
247 2 4812 418 38149 Fat pan enameled
301 0 4812 452 40223 Panel control
334 0 4812 412 79476 Knob
351 0 4801 310 00099 Kit pilot lamp
354 0 4819 462 79749 Lens red
440 0 4812 361 18604 Motor fan
441 0 4812 361 18527 Ventilator cooling
443 0 4819 515 48065 Fan wheel
451 0 4812 259 98405 Heating element forced-air 240 V
452 0 4819 259 28817 Heating element upper/grill
490 1 4812 290 68255 Clamp cable
490 2 4812 316 18036 Cover cable
491 0 4812 290 68329 Connectionblock
503 0 4819 349 48019 Timer
554 0 4812 282 08669 Thermostat
557 0 4812 282 28209 Temper.limiter
557 1 4812 282 28329 Temper.limiter 3-way
557 2 4812 282 28282 Temper.limiter
620 0 4812 273 18113 Switch,oven
651 0 4819 134 88153 Lamp,oven
652 0 4819 255 18237 Holder lamp rear
656 0 4812 450 28007 Lamp screen rear
915 0 4819 505 18145 Nut
993 0 4812 310 39061 Spacer
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8579 208 15510, 08/28/10
page 3 of 14
Exploded View
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8579 208 15510, 08/28/10
page 4 of 14
Dimensional Sketch
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8579 208 15510, 08/28/10
page 5 of 14
Technical Data
Electrical base data
Ratedvoltage ...........................................................................................230 V~
Mainconnection ...............................................................................230V1N~50Hz
Power Consumption
Totalconnectedload ...................................................................................2300W
Grill heating element ...................................................................................2250W
Forcedair ..............................................................................................1840W
Electrical components
Auto timer
Minute minder
Accessories
Pan set enameled ............................................................................... 415 x 318 mm
Grid chrome ...................................................................................446,5x340mm
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8579 208 15510, 08/28/10
page 6 of 14
Wiring Diagram
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8579 208 15510, 08/28/10
page 7 of 14
Wiring Diagram
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8579 208 15510, 08/28/10
page 8 of 14
Legend
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8579 208 15510, 08/28/10
page 9 of 14
Service Bulletin 4812 715 40304
AUTHOR: Sabine Wilky
Last Update: 05/04/10
VERSION: 1.0
TITLE: spontaneous glass break, outer door glass
SUBJECT: Under certain circumstances it can happen, that the outer door glass breaks. This can happen every time e.g.
during heating up, opening the door, cooling down.
CAUSE
As cause it was detected a too small gap between hinge mechanism and inner side of the outer door glass. This gap results
from bad tolerances. That means not all oven doors will consequently break.
By moving the door mechanism during opening and closing the door, the round edge of the lever pushes against the glass
surface. This causes aging cracks.
From week 26/2008 production changed the hinges.
REMEDIAL ACTION
Replace the outer door glass and replace the hinges of the oven with the ones mentioned in the list of codes attached below.
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8579 208 15510, 08/28/10
page 10 of 14
Service Bulletin 4812 715 40185
AUTHOR: Jochen Hohl
Last Update: 07/01/09
VERSION: 1.0
TITLE: Spring used to fix the thermostat on the back of the cavity
CAUSE
If part breaks or is lost
REMEDIAL ACTION
Exchange with spare part
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8579 208 15510, 08/28/10
page 11 of 14
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8579 208 15510, 08/28/10
page 12 of 14
Service Bulletin 4812 715 40332
AUTHOR: Pasquale Lattuca
Last Update: 07/01/09
VERSION: 1.0
TITLE: Sharp edges.
SUBJECT: Due to the gap between Door frame & Door, can it happen that customers cut their finger.
REMEDIAL ACTION
Fill the gap with heatresistant silicon.
Please follow below mentioned instructions!
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8579 208 15510, 08/28/10
page 13 of 14
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8579 208 15510, 08/28/10
page 14 of 14
© Whirlpool EMEA www.scc-service.com
