Princeton EO710F User manual

EO710f
17” FLAT COLOR MONITOR
REFERENCE MANUAL

FRONT COVER

EO710f
Table of Contents
FCC Information
Safety Information
Installation
Controls & Functions
Preset Timing
Input Pin Assignment
Technical Specifications
Troubleshooting
1
2
3
4
8
8
9
10
Reference Manual

FCC Information
This equipment has been tested and found to comply with limits
for a class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protec-
tion against harmful interference in a residential installation.
This equipment can generates, uses, and radiate radio fre-
quency energy, and if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. If this equipment does cause unacceptable
interference to radio and television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of
the following measures.
Caution:
To comply with the limits for an FCC Class B computing device,
always use the shielded signal cord and shielded power cord
supplied with this unit.
Caution to the User:
The Federal Communications Commission warns the user that
changes or modifications to the unit not expressly approved
by the party responsible for compliance could void the user’s
authority to operate the equipment. if necessary, the user should
contact the dealer or an experienced radio/television technician
for additional suggestions.
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced Radio/TV technician
for help.
1

Safety Information
Provided with this monitor is a detachable power supply cord
with IEC320 style terminations. It may be suitable for con-
nection to any UL listed personal computer with similar con-
figuration. Before making the connection, ensure that the
voltage rating of the computer convenience outlet is the same
as the monitor and that the ampere rating of the computer
convenience outlet is equal to or exceeds the monitor current
rating.
For 120V applications use only UL listed detachable power
cord with NEMA configuration 5-15P type (parallel blades)
plug cap.
For 240V applications use only UL listed detachable power
cord with NEMA configuration 6-15P type (tandem blades)
plug cap.
Use only a power source and connection appropriate for the
monitor as indicated on the marking label.
Slots and openings in the cabinet are provided for ventilation;
these openings must not be blocked or covered. Never push
objects of any kind into cabinet slots or other openings.
Never insert anything metallic into the monitor openings.
Doing so may create a danger of electric shock.
To avoid electric shock, never touch the inside of the monitor.
Only a qualified technician should open the monitor’s case.
Unplug the monitor from the wall outlet before cleaning. Do
not use liquid cleaners or aerosol cleaners. use a damp, lint-
free cloth for cleaning.
Install the monitor near an outlet that you can reach easily.
Disconnect the product by grasping the plug firmly and pull-
ing in from the outlet. Never disconnect it by pulling the
cord.
2

Installation
No tools are required to install the EO710f. Simply follow the
instructions outlined in the next few pages.
Connect Power Cord
Connect the female end of the power cable to the power input
receptacle on the back panel of the EO710f. Then, plug the
male end of the power cable into an AC outlet.
Connect Signal Cable
Attach the loose end of the signal cable to the graphics card.
Be cautious in inserting the cable properly into the graphics
card. If the cable does not seem to fit, it may be facing
the wrong direction. Turn the cable over and try to match
the shape of the connector with that of the graphics card.
Power On
Switch ON the power to both the EO710f and your computer.
There will be a short delay before the display appears.
Adjust the Picture
Adjust the controls, if necessary, to obtain the best display.
Instructions on how to use the On-Screen Display controls and
the Auto Setup button may be found in the next section, “Con-
trols and Functions.”
3

Controls & Functions
Base of Unit
Assemble the tilt/swivel base onto the bottom of the monitor.
Turn the monitor for a comfortable viewing angle within 80
degrees horizontally and 20 degrees vertically.
Signal Cable (VGA Cable)
Connect the end of the signal cable to your graphics card on
your computer.
Power Input (AC)
Connect the AC outlet with the supplied power cord as shown
on page 3.
Power Button
Press this button to turn the power ON or OFF. There will be a
short delay before the display appears.
Control & Functions Buttons
Press “MENU” button to activate OSD menu.
Press “Up/Down” buttons to scroll through the selection.
Press “Enter” button to execute the selection.
Adjustment Buttons
Pressing the “Up/Down” buttons are used to adjust picture
adjustment or to highlight a selection.
4
From left to right:
“MENU” button
“UP” button
“DOWN” button
“ENTER” button
CLOSER LOOK

Controls & Functions
The OSD menu activates when you press the “MENU” button. Use either the
“Up” button to move your selection up or “Down” button to move your selection
down. After making your selection, Press the “Enter” button and you will be able
to move your selection in the sub-menu to the right.
Use either the “Up” or “Down” buttons to select the function you would like to
modify. Use the “Enter” button and you will see a status bar indicating adjust-
ment values. Press either the “UP” or “DOWN” to perform the adjustment.
Below are the descriptions of what each function will do:
5
Contrast
Selecting this function allows you to make adjustments to
the luminosity level of the display screen.
Brightness
Selecting this function allows you to make adjustments to
the black level of the display screen.
Input Level
Selecting this function allows you to choose input of 0.7V
or 1.0V video input voltage levels. (Expert Only)
Reset
Selecting this function will reset the Contrast and Bright-
ness levels, Size, Position, Geometry to factory preset
values.
Zoom
Selecting this function allows you to enlarge your image
proportionally.
H-Position (Horizontal Position)
Select this function, then use the “UP/DOWN buttons to
center the image horizontally on the display screen.
H-Size (Horizontal Size)
Select this function, then use the “UP/DOWN” buttons to
increase or decrease the image width to horizontally fill
the display screen.
V-Position (Vertical Position)
Select this function, then use the “UP/DOWN” buttons to
center the image vertically on the display screen.
V-Size (Vertical Size)
Select this function, then use the “UP/DOWN” buttons to
increase or decrease the image height to vertically fill the

Controls & Functions
6
Pincushion (Side-Pin)
Select this function, then use the “UP/DOWN” buttons
to straighten the sides of the image by pulling them in
opposing directions.
Pin Balance
Select this function, then use the “UP/DOWN” buttons to
straighten the sides of the image by pulling them in the
coressponding direction.
Trapezoid
Select this function, then use the “UP/DOWN” buttons
to even the widths of the top and bottom of the display
(pulling the sides in opposing directions).
Parallel
Select this function, then use the “UP/DOWN” buttons to
center the top and bottom of the display (pulling the sides
in the corresponding direction).
Rotation
Select this function, then use the “UP/DOWN” buttons to
rotate the image until the sides of the image are parallel
to the edge of the bezel.
9300K
Select this to select your color temperature to 9300°
Kelvin. (Cool White Point)
6500K
Select this to select your color temperature to 6500°
Kelvin. (Warm White Point)
User (custom color temperature settings)
Select this to customize your white point settings. You
will be given the Red, Green, and Blue adjustments.
(Changes to the “User” is not recommended).

Controls & Functions
7
English
Selecting this will change your OSD to English.
Deutsch
Selecting this will change your OSD to German.
Francais
Selecting this will change your OSD to French.
Espanol
Selecting this will change your OSD to Spanish.
Italic
Selecting this will change your OSD to Italian.
H-Moire (Horizontal Moire)
Select this function, then use the “UP/DOWN” buttons
to decrease the moire, a Finger Print Pattern that causes
some dithered colors to appear uneven.
V-Moire (Vertical Moire)
Select this function, then use the “UP/DOWN” buttons to
decrease the moire, an interference pattern that causes
some dithered colors to “vertical shimmer” or appear
uneven.
OSD H-Position
Select this function, then use the “UP/DOWN” buttons to
move the OSD menu horizontally.
OSD V-Position
Select this function, then use the “UP/DOWN” buttons to
move the OSD menu vertically.
Degauss
Selecting this function will demagnetize the CRT when the
display becomes discolored or washed out in appear-
ance. The monitor will automatically degauss on startup
if the monitor has been shut-off.

Preset Timing
H. Frequency V. Frequency SYNC. Polarity
31.47KHz 70Hz - / +
31.47KHz 60Hz - / -
37.50KHz 75Hz - / -
43.30KHz 85Hz - / -
46.88KHz 75Hz + / +
53.67KHz 85Hz + / +
60.02KHz 75Hz + / +
68.68KHz 85Hz + / +
63.97KHz 60Hz + / +
8
Resolution
720 x 400
640 x 480
640 x 480
640 x 480
800 x 600
800 x 600
1024 x 768
1024 x 768
1280 x 1024
Input Pin Assignment
1
6
5
10
11 15
Pin Signal Pin Signal
1. Red Video 9. No Pin
2. Green Video 10. Ground
3. Blue Video 11. Ground
4. Ground 12. SDA (DDC1/2B Data)
5. Ground 13. Horizontal Sync
6. Red Video Return 14. Vertical Sync
7. Green Video Return 15. SCL (DDC1/2B Clock)
8. Blue Video Return

Technical Specifications
EO710f
17” Diagonal (16” Viewable)
90 Degrees
0.25mm
Shadow Mask, Anti-Static, Non-Glare
NON-INTERLACED 1280 x 1024 (SXGA), 1024 x 768 (XGA),
800 x 600 (SVGA), 640 x 480 (VGA)
1280 x 1024 @ 60Hz
110Mhz
30 ~ 70KHz
50 ~ 160Hz
RGB Analog 0.7Vp-p / 75 Ohms Positive
TTL Separate/Composite (+/+)
Unlimited
310mm x 235mm (Default)
325mm x 240mm (Overscan)
90-264Vac
90W
Less than 5W
15pin Mini D-SUB
425mm / 16.75in. (D) x 408mm / 16.07in. (W) x 427mm / 16.82in. (H)
with Stand
Net Weight: 10.0kg (35.27lbs), Gross Weight: 18.5kg (40.79lbs)
Power Switch, Brightness, Contrast, Input Level, H-size, H-position, V-size,
V-position, Pincushion, Trapezoid, Parallel, Rotation, 9300K, 6500K, User
Color, Zoom, Pin-Balance, Corner, Language, H-moire, V-moire, OSD V-posi-
tion, OSD H-position, Degauss, Reset.
0°C to 40°C (32°F to 104°F)
10% to 80%
MPR II
DDC1/2B
9
Model
CRT Size
Deflection Angel
Dot Pitch
Screen Type
Graphics Standards
Compatibility
Video Bandwidth
Horizontal Sync.
Vertical Sync.
Input Video
Input Sync.
Display Colors
Display Area
Power Source
Power Consumption
Active Off
Input Connector
Dimensions
Weight
User Controls
Operating Temperature
Operating Humidity
Nordic Standard
Plug & Play

The monitor is switched ON, but the Power LED indicator is
not lit and there is no display on the screen.
Check all the power connections and make sure they are
secure. If the monitor is plugged into a surge protector, make
sure that the surge protector is switched on.
Why do I hear a “humming” sound when I first switch on the
monitor?
The sound you hear indicates that the degauss function is
activated. Every time the monitor is switched on, it will go
through the degaussing process which helps eliminate any
purity problems.
How do I change the resolution the monitor displays?
The frequency and resolution displayed on a monitor is con-
trolled by the video card and operating system. The monitor
simply responds to the signal it receives from the video card
and is not able to change the resolution on its own. Most
video card manufacturers provide software drivers and utili-
ties that allow you to use different resolutions for different
applications. Please consult your video card manual or
dealer for more information.
The monitor is “plug and play,” why do I still need to run the
graphics card utility to make adjustments on refresh rate in
different resolutions?
In order to fully utilize the plug and play feature, the com-
puter must be equipped with a plug and play (DDC2B) video
card and running with a Plug and Play capable operating
system (i.e., Windows® 98) or a separate utility program that
enables the plug and play function automatically.
Troubleshooting
10

How do I change the frequency or refresh rate the monitor
uses?
The refresh rate is controlled by the video card. In your
“Display Properties,” press the “Advanced” button. Select the
Adapters tab. There should be a list of refresh rates.
Why do the characters in the corner of the screen look fuzzier
than the center?
One of the limitations of a CRT screen is that the focus is
impossible to be uniform across the entire area. In general, a
monitor is adjusted so that the focus is best in an area around
the center, in which case the overall focus is optimized. How-
ever, the image in the corner should always be readable.
I see what appears to be a second image or “Ghost” on the
screen. How can I correct this?
The ghosting effect may be due to a reflection in the signal.
This usually occurs if an extension signal cable is installed or if
the signal cable is not fastened to the back of the video card.
I turned on both the monitor and computer, but there is still
no display on my monitor. How can I tell if the monitor is
defective?
The monitor has a self test screen to troubleshoot this kind
of problem. You can activate the self test screen by turning
off the monitor, detaching the signal cable from the computer
and then turning the monitor back on (with the signal cable
unattached). If you can see the self test screen, the monitor is
functioning properly.
Troubleshooting
11

© 2001 Princeton Graphic Systems, Inc. All rights reserved. This manual may not be copied in whole or in part without
the written consent of Princeton Graphic Systems. Princeton Graphic Systems is not responsible for printing or clerical
errors. Product specifications is subject to change without notice. Windows® is a registered trademarks of Microsoft
Corporation. Apple® and Macintosh™ is a registered trademark of Apple Computer, Inc. Sun® SPARCStation™
is a registered trademark of Sun Microsystems Inc. ENERGY STAR® is U.S. registered mark. As an ENERGY
STAR® Partner, Princeton Graphic Systems, has determined that this product meets the ENERGY STAR® guidelines
for energy efficiency.

Princeton Graphic Systems
2801 South Yale Street
Santa Ana, CA 92704
[phone]
[phone] fax
www.princetongraphics.com
Copyright © 2001 Princeton Graphic Systems, Inc. Ref No.: 00300000295
Part No.: 11/14EO1701A04
