Princeton LCD1516 Installation instructions

15" LCD
0.297mm x 0.297mm
1024 x 768 @ 60Hz
1024 x 768 @ 75Hz
16 ms typical
400:1
250 cd/m²
Horizontal: 120° (CR=5)
Vertical: 100° (CR=5)
16 Million Colors by dithering
11.98" x 8.98" (304.1mm x 228.1mm)
4:3
Video: 0.7Vpp/75 Ohm,
Sync: Separate TTL Level, composite Sync ,
Horizontal: 24kHz~82kHz, Vertical: 55~76Hz
D-Sub x 15-pin (Analog RGB Input)
Audio in 3.5mm head phone jack
N/A
1W x 2 Stereo Speaker
VESA 1024 x 768 @ 75/70/60Hz
VESA 800 x 600 @ 75/72/60/56Hz
VESA 640 x 480 @ 75/72/60Hz, Super VGA, VGA,
Standard 1280 x 768/60Hz,
N/A
Back Panel Side Controls: Power ON/OFF, Power LED
3 button OSD Controls: Contrast, Brightness, Volume, Auto Adjust, H-V Position, Language,
Frequency, Phase, Color, Recall, Exit
VESA DDC2B
Optional wall mount kit VESA 100mm
Tilt, 5° Forward, 20° Backward,
338mm x 343mm x 165mm with Stand ;13.3" x 13.5" x 5.5" with Stand
404mm x 470mm x 101mm ; 15.9" x 18.5" x 3.9"
Net: 2.9 kg, 6.4lbs
Gross: 3.3kg, 8.2lbs
Power Input: AC: 100 ~ 240 V, 60/50Hz,
On: <25W; Active Off: <1W
EPA Energy Star® Compliant
FCC(B), UL, C-UL,
Operating Temperature: 41° to 95° (5°C to 35°C)
Operating Humidity: 20% to 90% (no condensation)
3 Year Warranty
Panel Size/Type
Pixel Dimension
Native/Optimum Resolution
Maximum Resolution
Response Time
Contrast Ratio
Brightness
Viewing Angles
Display Colors
Active Display Area (H x V)
Aspect ratio
Input Signal
Input PC Module
Input Video Module
Audio
Compatible Signals
HD Compatible
Controls
Plug & Play
Wall/Arm Mount
Base/Stand
Dimensions (W x H x D)
Dimensions Box(W x H x D)
Weight
Power Supply
Power Consumption
Power Management
Agency Approvals
Environmental Conditions
Warranty
GRAPHICS SYSTEMS
For Product Information: 1-888-668-7655
Visit us on the web: www.princetongraphics.com
Product Specifications
3300 Irvine Ave, Suite 120
Newport Beach, California 92660
Tel: [phone]
Fax: [phone]
www.princetongraphics.com
UPC: 663555007704
PN: 14AP1516A00
LCD1516
Continental U.S. Only. Additional terms and conditions may apply. * May vary based on panel generation
© 2003-2004 Princeton Digital (USA) Corp. All rights reserved. Product designs & specifications are subject to change without notice. Rev a
*663555007704*
Mid Level, 3 Year Warranty, Exceptional Image Quality
Available Thru: Systems Builders,Value Added Resellers
Ideal for: End-Users, Small/Medium Businesses,
Education, Government, Dental or Doctor's Offices
LCD Series
