Priorit PRIOBOX User instructions

1
Assembly and operating manual
PRIOBOX
EP.A.11144
Last updated 01/2022

2
Contents
Introduction .............................................................................................................................. 4
Assembly manual ..................................................................................................................... 6
1. Setup .................................................................................................................................. 6
2. Connecting the elements .................................................................................................... 6
3. Installing the entilation duct ............................................................................................... 7
4. Installing the doors .............................................................................................................. 7
5. Shutoff de ice installation ................................................................................................... 8
Warranty/transfer declaration .................................................................................................. 9

3
Dear customer,
Thank you for purchasing a high-quality PRIORIT product.
To ensure we can guarantee that the entire system will function free from errors, please obser e the
following operating manual.
Failure to obser e this manual will oid any warranty guarantees.
We expressly reser e the right to make technical modifications for the purpose of impro ing our product
or as required due to changes in the law, e en without pro iding separate notification of said modifications.
This operating manual may only be reprinted or copied in whole or in part with the written appro al of
PRIORIT AG.
PRIORIT AG
3457 Hanau
Tel.: [phone], Fax: [phone],
E-mail : [e-mail] , www.priorit.de

4
Transportation, assembly, operating
and maintenance manual
Always read in full before transportation and assembly!
Fire-resistant barrel container (PRIOBOX PB):
 in CPL laminate decor (not flammable according to EN 13501-1)
 Exterior dimensions: 2650x1500x1000mm, base with ground clearance
Tested in accordance with European and German standards
 Fire-resistant, tested wall in accordance with EN 13501-2 EI90, European test report
 Fire-resistant, tested top, base in accordance with EN 13501-2 EI90, European test report
 Fire-resistant, tested door(s) in accordance with EN 13501-2 EI90, European test report
 Smoke-tightness in accordance with DIN 18095
 O erall assessment by the Official Material Testing Institute for Construction, MPA Dresden
Permitted set-up location
 Subsurface must be flat
 Indoors, frost-free, dry
 Subsurface must be suitable (load-bearing capacity, classification)
Special features
 Panels and door leaf same area on both sides – no offset
 Cable, pipe, and entilation bulkheads can be inserted into the walls from the top and bottom on site.
 Storage for hazardous materials/laboratory materials
Information in this manual
 This manual is not a manufacturer's declaration, nor is it considered a usability certificate under building appro al
regulations.
 The information in this manual applies to a wide range of different products. For binding technical and
appro al information, please see the building appro al usability certificates, the manufacturer declarations
submitted by the installing company, and our order confirmation, which is considered part of the purchasing
agreement upon signing

5
Transportation
 If the packaging is damaged, then such damage must always be reported on the deli ery slip to the freight carrier
– a “simple acknowledgement” to the deli ering freight company excludes the recognition of any damage in
transit. The same applies if any packages are missing according to the deli ery slip.
 The pallet must always be picked up from the narrow side with forks inserted fully to the end of the pallet.
 Our panels weigh approx. 65 kg per m² of area. Warning: Risk of injury!
 Only open the pallet at the installation site, in order to pre ent damage during transportation to the site.
 Do not use pointed or sharp objects such as kni es when opening the pallet, as these could damage the
panels/doors. Please use caution!
 Dispose of packaging materials in an en ironmentally appropriate manner, or reuse them.
 If the material is not used or installed immediately, it must be stored at a suitable location; please ensure that no
water spray can form or penetrate the rack
-> do not store outdoors.
General information
 Do not install damaged components – this will immediately oid the warranty and usability certificate.
 Always obser e building law regulations and guidelines, as well as instructions from the responsible building
authority and the responsible commissioned fire protection expert.
 As the installing technician, you should only issue an unrestricted manufacturer's declaration of compliance with
the building appro al if installation was completed in a compliant manner, and if all necessary fittings ha e been
installed. Note any necessary de iations on the declaration, if these are significant in scope.
Assembly / scope of deli ery
 Our deli ery is shipped with a scope of deli ery required for installation by our own technicians or certified
contracting companies.
 Setup in compliance with alid appro als requires a le el of technical expertise which cannot be con eyed fully in
an assembly manual. We train technicians on request, and certify them for professional installation of our
products.
General safety information
 This operating / assembly manual must always be stored at the location where the barrel container will be used.
 Legally required safety information must be posted in an area isible to users.
 All safety and hazard notices and the type plate must be kept in legible condition.
Functional test, safety technology inspection,
care and maintenance
 The container should be maintained at least once annually and checked for proper function. We recommend that
you complete a functional check ( isual inspection) each month. The safety technology inspection can only be
completed with the necessary le el of care by one of our authorised employees, since sufficient experience and
comprehensi e expertise are essential for this inspection.
 Commonly a ailable, mild household cleaners can be used for external cleaning of the container.
 The door locking mechanism should be oiled 2 x per year.
 The container must be protected against water, moisture penetration, or water spray.
 If rele ant damage to the safety technology is found, then the containers must be repaired with original parts
before further use.

6
Assembly manual
Assembly of fire-resistant barrel container:
1. Setup
 The subsurface must be flat and must be capable of bearing the weight of the container when loaded.
 Align the base strips to the floor.
2. Connecting the elements
 Always add a thin seam of silicone to the connecting joints, and glue the enclosed Roku
strip in the groo es pro ided for this purpose before connecting the panel elements together.
 Align the floor elements to the baseboards and install.
 The wall, base, and co er elements ha e cup holes, assemble using
carriage bolts and nuts. Start assembly with the rear wall, the corner plate joints are
connected using hanger bolts and nuts.
 Mount wall elements in a clockwise direction, starting with the rear wall elements.
 Once all wall and co er elements are mounted, attach the top panel as a door lintel.
Fasten using brackets with hexagonal screws. Holes are pre-drilled in the side elements.

7
3. Installing the ventilation duct
 Pre-assemble the elements included for this purpose as a box, and screw to the
point on the co er marked with pre-drilled holes. Screw on the longitudinal rails and the co er plate.
4. Installing the doors
 Screw the enclosed hinges on the doors. Holes are pre-drilled for this purpose. Lift the door lea es with
the hinges onto the cabinet and screw the hinges into the holes drilled in the side elements.
 Check closure function.
 Install the door handles.
 Install the door closer and slide rails based on the manufacturer’s instructions. Holes are pre-drilled for this
purpose.

8
 Insert the shelf at the desired position in the cabinet. There is a grid of holes a ailable for this purpose.
 Shelf supports included.
 Insert the collection tray with grate on the base.
 The barrel container can be filled.
5. Installing the shut-off device:
 The position is specified in the co er elements by the drill holes.
 The dimensions of the enclosed doubling panels must be obser ed, and appropriate edge spacing must be
obser ed.
 Use suitable tools.
 Complete the pre-drilled holes to fasten the doubling panels on site

9
Warranty, transfer declaration
In order to ensure the optimal function of our products, the
assembly instructions must always be obser ed.
PRIORIT's warranty applies to the deli ered products.
Modifications or changes to the design may be carried out only following consultation with
PRIORIT AG; otherwise the appro al/warranty
will be null and oid.
The installer/setup technician must pro ide a guarantee for all assembly
work.
Warranty and liability claims for personal injury and property damage
are excluded if they are caused by one or more of the following:
 Container is not used according to its intended purpose.
 Improper assembly, commissioning, operation, and maintenance.
 Failure to obser e the instructions on transportation, storage, operation, and assembly.
 Unauthorised structural modifications to the containers.
 Failure to monitor the safety equipment to be installed.
 Improper repairs.
 Catastrophes caused by third parties or force majeure.
Intellectual property rights
In order to protect inno ations and the design, utility model
specifications ha e been submitted to the German Patent Office.
