INSTRUCTION MANUAL
ProDevice OMS130 Shredder
V.OMS130.2023.1.EN
Manufactured by: DISKUS Polska Sp. z o. o., ul. Kościuszki 1, 32-020 Wieliczka

Instruction manual ProDevice OMS130
CONTENTS
1. Features 04
2. Packaging removal 04
3. Overview 05
4. Operation 08
5. Destruction of storage media 09
6. Safety precautions 10
7. Maintenance
8. Possible faults and ways to fix them
12
13
2
www.pro-device.com

Thank you for purchasing the ProDevice OMS130 –the medium office media shredder for
physical destruction / disintegration of storage media which may include: solid state drives
(SSD), mobile phones and tablets (with the battery packs removed), floppy disks, and more.
This user manual is integral to the shredder. Read and understand the manual before
operating the shredder. Keep the manual for future reference. The company Diskus Polska
sp. z o. o., as the manufacturer is not responsible for the partial or total failure to comply with
this manual.
Strictly follow the operating guidance specified in the user manual. Any deviation from it is
against the intended use of the shredder. The manufacturer will not be liable for any damage
caused by non-intended use of the shredder.
Never attempt to modify the shredder. The manufacturer will not be liable for the
performance or operating safety if the device is modified.
The manufacturer reserves the right to introduce changes to the design of devices, deemed
necessary by the manufacturer to improve them.
Refer to Instruction manual. Wear eye protection. Not for hard disks. Do not put hands inside.
3
www.pro-device.com
Instruction manual ProDevice OMS130

1. FEATURES
•ProDevice OMS130 shredder
•Plastic container for shredded data carriers
•Sprayer with oil for cutting knives
•Pendrive with manual instructions
2. PACKAGING REMOVAL
The shredder is delivered to the buyer on a pallet in a box. The weight of the shredder
requires a pallet truck or a forklift to remove it from the pallet. Carefully remove all packaging
materials and verify that the contents are complete as listed in the product features above.
Having removed the packaging materials, immediately inspect the shredder for any evidence
of damage in transport. If the shredder or any of its dedicated accessories are damaged,
report this to the shipment forwarder and the manufacturer.
With all packaging materials removed, place the shredder on a firm surface at the
designated, sheltered installation site. Secure the shredder in position to prevent movement.
It is recommended to apply oil to the cutting blades before every use to extend the life span
of the cutting blades greatly.
4
www.pro-device.com
Instruction manual ProDevice OMS130

3. OVERVIEW
3D view
1. Main switch.
3. Media input.
3. Operator control panel.
4. Shredded scrap bin compartment.
5
www.pro-device.com
Instruction manual ProDevice OMS130

6
www.pro-device.com
Instrukcja obsługi ProDevice OMS130
Operator control panel
1. START A/M BUTTON: starts a 60 second shredder cycle. When pressed again, it switches
the operating mode between automatic/manual.
2. STOP BUTTON: stops the shredder while running.
3. REVERSE BUTTON: switches over the sense of rotation of the shredding blades.
4. OVERLOAD BAR: displays the current engine load while running.
5. AUTO ICON: lights up after pressing the START button, after entering the automatic
operating mode.
6. MANUAL ICON: illuminates after entering the manual mode of operation and after the
knife cleaning function is activated - after holding the REVERSE button for 6 seconds.
7. STOP ICON: lights up when the STOP button is pressed.
8. REVERSE ICON: lights up when the REVERSE button is pressed.
9. FULL ICON: lights up when the shredded scrap bin is full.
10. DOOR OPEN ICON: lights up when the door of the waste bin or media compartment
is open.

7
Technical specification
Power supply 230 V ~ 50 Hz
Rated current 3.5 A
Maximum current 10 A
Motor power 0.75 kW (1.0 HP)
Security level (DIN 66399) E-3, O-3
Ambient temperature 5°C –45°C (41°F − 104°F)
Ambient humidity 10% − 70% (no condensation)
Sound intensity at idle 55 dB
Dimensions 550 mm x 550 mm x 983 mm
(21.7 in x 21.65 in x 38.7 in)
Weight 130 kg (286.6 lb)
Waste container capacity 30 l (7.9 gal)
www.pro-device.com
Instruction manual ProDevice OMS130

4. OPERATION
1. Place the shredder on a hard surface in the designated, sheltered installation area.
2. Secure the shredder in position to prevent movement.
3. Make sure the shredded scrap bin is in the compartment and that the compartment
door is closed.
4. Open the media input compartment.
5. Apply the oil for cutting knives.
6. Extend the power cord and plug it into a power outlet.
7. Turn on the shredder with the main switch.
8. Start the cleaning function by holding down the REVERSE button for 6 seconds.
9. After cleaning, the shredder is ready for use. Place the storage device in the media input
compartment and close it.
10. Start the shredder by pressing the START button.
11. The shredding cycle takes 60 seconds in the automatic mode (3 min in manual mode),
during which time the carrier will be completely shredded.
12. Stop the shredder by pressing the STOP button or by opening the input media drawer.
13. Place another media in the media input drawer and press the START button to restart
the device.
14. In the event of overloading the device, the work of the shredding knives will be stopped.
To restart the shredder, lift up the main switch. Then start the shredder operation by
pressing the START button.
15. To properly shut down the device, after the shredding cycle is complete, press the STOP
button and use the main switch.
16. Disconnect the power cord from the power outlet and wind it up.
8
www.pro-device.com
Instrukcja obsługi ProDevice OMS130

5. DESTRUCTION OF STORAGE MEDIA
The OMS130 shredder is designed to destroy data carriers that are available on the market.
By placing the media in the media input, you can shred various types of media as well as
media of various sizes.
A maximum of two carriers can be shredded in one cycle.
This device is not intended for hard drives.
The ProDevice OMS130 shredder can be used for continuous operation.
30 minutes break in the operation of the device should be done after 3 hours of continuous
operation.
9
DANGER!
It is prohibited to open device housing!
Removing the housing causes risk of electric shock, injury, serious injury
and / or death.
MANDATORY!
Wear safety glasses at all times when working with the device.
CAUTION!
The shredder can always be stopped by operating:
•The STOP button.
•The MAIN switch.
www.pro-device.com
Instruction manual ProDevice OMS130

10
6. SAFETY PRECAUTIONS
Please read the operating manual before initial start-up, operation and maintenance of the
machine and keep it for later use or for passing on to any subsequent users.
•Service may be performed by authorized personnel only.
•Before using the device, check if all elements are installed accordingly to the manual
instructions.
•Never attempt to open and / or modify the device.
•If a malfunction is detected in the device, it must be reported immediately to the person
responsible. This is important for your own safety and that of others.
•This device may be used by people with inexperience and knowledge of the equipment,
if supervision or instruction regarding the use of the equipment is provided in a safe way,
so that the threats were understandable. Children should not play with the device.
•Before attempting any adjustment, maintenance or inspection, always isolate the shredder
from the supply voltage by unplugging the power cord from the mains and wait until the
shredder cools down.
•If power is disconnected, the operator must see that the machine is disconnected (power
cord disconnected and unplugged) from every point to which he has access. If this is not
possible due to the design or installation of the machine, disconnect with the locking
system in the disconnected position from the power supply.
•Do not store / use the device in places where it may be exposed to moisture
or temperature exceeding the allowed.
•If the device will not be used for an extended period of time, disconnect the power cord
from the mains.
•Disconnect the device from the local power grid during an electrical storm.
•Do not allow any liquids to enter the device.
www.pro-device.com
Instruction manual ProDevice OMS130

•If you notice overheating of the device, turn off the shredder and wait 30 minutes.
•The weight of the device requires a pallet truck or a forklift to remove it from the palette.
•The device should be secured during transport with transport belts or other means
ensuring mechanical stability.
•Never tamper with the shredder’s blades by placing any part of the body or any foreign
objects into the media input.
•Do not place any objects which might cause a risk of explosion in the feeder tray: this
applies to batteries (rechargeable and non-rechargeable ones), capacitors,
and pressurized containers.
•Press the MAIN SWITCH if there is a risk to the operator or the device.
Safe operation of the shredder requires proper connection to the electrical network, which
must be performed under applicable regulations. The electric shock protection system in the
shredder must comply with the standards in force at the place of destination. The shredder
should be connected to the mains by a qualified specialist.
Oil for cutting blades:
•May be fatal if swallowed and / or enter airways.
•IF SWALLOWED: Immediately call a POISON CENTER or a doctor. Do NOT induce vomiting
•Store locked up, away from children.
11
www.pro-device.com
Instruction manual ProDevice OMS130

7. MAINTENANCE
CAUTION!
Improper handling of the machine can
lead to an electric shock.
Disconnect the plug from the power supply before relocation, cleaning or maintenance.
Before carrying out maintenance, wait 30 seconds after disconnecting the power plug.
Mechanical and electrical maintenance may only be performed by the manufacturer's
authorized service.
The device requires an inspection by an authorized service of the manufacturer at least every
10,000 work cycles.
In the event of a failure or interruption in operation due to damage to the device or any of its
components, contact the authorized service of the manufacturer.
Applying oil to the cutting blades (before every use):
•Turn off the device.
•Open the media input.
•Apply a small amount of oil.
•Close the media input.
•Turn on the device.
•Initiate the cleaning function by holding REVERSE button for 6 s.
•Operate the shredder.
12
www.pro-device.com
Instruction manual ProDevice OMS130

13
www.pro-device.com
8. POSSIBLE FAULTS AND WAYS TO FIX THEM
Below are the fault descriptions and the required user responses:
Fault Possible cause Way to remove the fault
The device does not turn on There is no power at the wall socket Check that there is power in the outlet
by plugging in another electrical device
or by using a meter
The plug is not properly inserted in the
wall socket
Insert the plug into the wall socket
correctly
The device does not turn on - socket ok Lowered circuit breaker in the
installation
Lift the fuse or, if it is damaged, replace
it with a new one with the parameters
recommended by the manufacturer
The main switch in the device is
lowered.
Lift the main switch
The device does not turn on - socket,
main switch ok
Damaged power cord Replace the power cord with a new one
having the same specifications. THIS
OPERATION CAN ONLY BE
PERFORMED BY AN ELECTRICIAN
WITH VALID LICENSE!
The device does not turn on - socket,
main switch, power cord ok
- Contact service
The device does not start operation START button disabled Turn on the device by pressing the
START button
Defective control panel Contact service
The door of the media input or waste
bin is not closed
The LED "Door open" is on
Close the door and try again
Bad microswitch on media input door
and / or waste bin
Contact service
Switching off the device operation while
destroying the medium
Motor overload Lift the main switch, press START
button
"Full" LED on Full waste bin Empty the waste bin and put it back into
the machine.
Damaged cutting knife Operation of the device Contact service
Instruction manual ProDevice OMS130

INTERNATIONAL HOTLINE: [phone]
CONTACT
ProDevice Spółka z ograniczoną odpowiedzialnością
ul. Kościuszki 1, 32-020 Wieliczka, Poland
tel. [phone]
e-mail: [email protected]
service: [e-mail]
If you have an improvement idea or suggestion, write to [e-mail]
[email protected]
www.pro-device.com
MANUFACTURER'S ADDRESS DETAILS
DISKUS Polska Spółka z ograniczoną odpowiedzialnością
ul. Kościuszki 1, 32-020 Wieliczka, Polska
service: [e-mail]
