PRODIS XD701S User manual

XD SERIES
REFRIGERATION
USER MANUAL
XD080818UM Rev 1.4
COLDER BY NATURE
XD1NW - XD2NW - XD260C - XD701 - XD701S - XD1201 - XD1201S
XDMANUAL.indd 1 16/07/2021 11:19:51

PART I - WARNINGS
PART II - INSTALLATION
PART III - OPERATING INSTRUCTIONS
PART IV - MAINTENANCE AND CLEANING
PART V - SPECIFICATION
PART VI - TROUBLESHOOTING
TABLE OF CONTENTS
XD080818UM Rev 1.4
XDMANUAL.indd 2 16/07/2021 11:19:51

PART I
01. PROPER INSTALLATION, USE AND
MAINTENANCE OF THIS MACHINE ARE ALL
IMPORTANT FOR MAINTAINING EFFICIENCY
AND USER SAFETY. IN ORDER TO REDUCE
THE FAILURE RATE PLEASE READ THESE
INSTRUCTIONS CAREFULLY. IMPROPER USE
COULD RESULT IN EQUIPMENT DAMAGE,
PERSONAL INJURY OR EVEN DEATH.
02. DO NOT LET CHILDREN PLAY WITH THE
CABINET OR ITS PACKAGING MATERIALS.
03. AT LEAST TWO PEOPLE ARE REQUIRED
TO POSITION AND UNPACK THE CABINET
OR IT IS RECOMMENDED THAT A LIFTING
DEVICE IS USED TO AVOID INJURY.
04. A QUALIFIED ENGINEER MUST PERFORM
THE INSTALLATION AND ONGOING
MAINTENANCE OF THE REFRIGERATOR.
05. WHEN OPERATING ALL PROCEDURES
MUST BE FOLLOWED IN ACCORDANCE WITH
THESE INSTRUCTIONS TO ENSURE NO DAMAGE
OCCURS TO THE REFRIGERATION SYSTEM.
06. DO NOT OPERATE THE UNIT IF THERE
ARE ANY UNAUTHORISED CHANGES
TO THE ORIGINAL MANUFACTURERS
SPECIFICATIONS OR IF THE MACHINE HAS
BEEN MISUSED, ABUSED OR NEGLECTED.
07. DO NOT COVER THE FRONT VENTS,
THERE MUST BE A MINIMUM CLEARANCE
OF 100MM AROUND THE REFRIGERATOR AT
ALL TIMES DURING OPERATION.
08. DO NOT STORE FLAMMABLE GASES OR
LIQUIDS IN OR NEAR TO THIS CABINET.
09. DO NOT USE HIGH-PRESSURE
WATER CLEANING DEVICES
TO CLEAN THE REFRIGERATOR.
10. IT IS THE USERS RESPONSIBILITY TO TAKE
APPROPRIATE MEASURES TO ENSURE THE SAFETY
OF STAFF OPERATING REFRIGERATOR.
11. IT IS THE USERS RESPONSIBILITY TO
ENSURE THE ONGOING MAINTENANCE OF THE
REFRIGERATOR IS COMPLETED IN ACCORDANCE
WITH THE MANUFACTURERS INSTRUCTIONS LAID
OUT IN THIS MANUAL.
12. TO PREVENT ACCIDENTAL INJURIES
KEEP THE AREA SURROUNDING THE
REFRIGERATOR CLEAN AND TIDY
AND FREE FROM OBSTRUCTIONS.
13. ALWAYS USE A DEDICATED ELECTRICAL
OUTLET FOR INSTALLATION. DO NOT
USE EXTENSION CABLES OR MULTI-PLUG
ADAPTORS AS THIS COULD CAUSE ELECTRICAL
SHOCK, OVERHEATING OR FIRE.
14. NEVER OPERATE THE REFRIGERATOR
WITH A DAMAGED POWER CABLE
AS THIS COULD CAUSE ELECTRICAL
SHOCK, OVERHEATING OR FIRE.
15. NEVER TWIST, BUNDLE, STRAIN OR
EXCESSIVELY BEND THE POWER CABLE
AS THIS COULD CAUSE ELECTRICAL
SHOCK, OVERHEATING OR FIRE.
16. THIS UNIT IS DESIGNED FOR USE
INDOORS ONLY USING THE CABINET OUTSIDE
OR IN AN AREA SUBJECT TO MOISTURE
COULD CAUSE DAMAGE, ELECTRICAL
SHOCK, OVERHEATING OR FIRE.
17. THIS UNIT MUST BE INSTALLED ON
A LEVEL FLOOR WHICH IS CAPABLE OF
SUPPORTING THE WEIGHT OF THE UNIT
WHEN FULLY LOADED. INSTALLATION
ON AN UNEVEN SURFACE COULD CAUSE
DAMAGE, INJURY AND BREAKDOWNS.
18. NEVER INSERT FINGERS OR OBJECTS INTO
THE FANS AS THEY ROTATE AT HIGH SPEED.
19. NEVER PLACE HEAVY OBJECTS OR
ITEMS CONTAINING WATER ON TOP OF
THE UNIT AS THIS COULD CAUSE INJURY,
OR DAMAGE TO THE CABINET.
20. THIS REFRIGERATOR MUST BE INSTALLED
AWAY FROM HEAT SOURCES AND OUT OF DIRECT
SUNLIGHT. INSTALLATION IN A HOT ENVIRONMENT
OR IN DIRECT SUNLIGHT COULD CAUSE
BREAK DOWNS AND WILL ADVERSELY AFFECT
COOLING EFFICIENCY AND PERFORMANCE.
1 XD080818UM Rev 1.4
XDMANUAL.indd 3 16/07/2021 11:19:51

PART II
01. THIS MANUAL IS AN INTEGRAL PART OF
THE REFRIGERATOR AND SHOULD BE KEPT
AND PRESERVED BY THE USER FOR FUTURE
REFERENCE. PLEASE READ THE INSTRUCTIONS
CAREFULLY FOR THE CORRECT INSTALLATION
METHOD, SAFETY WARNINGS AND MAINTENANCE
INFORMATION FOR THIS REFRIGERATOR.
02. THIS REFRIGERATOR IS DESIGNED FOR
COMMERCIAL USE AND SHOULD BE USED
FOR THE PURPOSE FOR WHICH IT HAS BEEN
EXPRESSLY DESIGNED. ANY OTHER USE SHOULD
BE CONSIDERED IMPROPER AND THEREFORE
DANGEROUS. THE MANUFACTURER WILL
NOT BE LIABLE OR RESPONSIBLE FOR ANY
DAMAGE CAUSED BY IMPROPER, INCORRECT OR
UNREASONABLE USE.
iv. REMOVE THE PROTECTIVE PLASTIC FILM
(IF PRESENT) FROM THE EXTERIOR BEFORE
INSTALLATION. IF THE REFRIGERATOR HAS
BEEN EXPOSED TO SUN OR HEAT ALLOW
THE REFRIGERATOR TO COOL DOWN
BEFORE REMOVING THE PROTECTIVE FILM.
iv. REMOVE THE ACCESSORY PACK AND CHECK
THE CONTENTS, IT SHOULD CONTAIN
1 x SET OF KEYS (IF LOCK FITTED)
1 x INSTRUCTION MANUAL
1 x DIGITAL CONTROLLER MANUAL
IMPORTANT
WARNING
THEINSTALLATIONOFTHISREFRIGERATOR MUST
BE CARRIED OUT BY QUALIFIED PERSONNEL IN
ACCORDANCE WITH CURRENT REGULATIONS
AND AS PER THE MANUFACTURERS
INSTRUCTIONS. FAILURETO CORRECTLY INSTALL
THIS REFRIGERATOR COULD RESULT IN DAMAGE
OR INJURY AND WILL VOID THE WARRANTY.
INSTALLATION
01. UNPACKING
WARNING
KEEP ALL PACKAGING MATERIALS INCLUDING
BOXES, PLASTIC BAGS AND POLYTHENE OUT OF
REACH OF CHILDREN
IMPORTANT
i. REMOVE ALL SHIPPING MATERIALS, TAPE
AND PACKAGING FROM THE BOTH OUTSIDE
AND INSIDE THE REFRIGERATOR. IF PACKAGING
MATERIAL IS LEFT INSIDE THE REFRIGERATOR
IT WILL NOT FUNCTION CORRECTLY
ii. AFTER REMOVING THE PACKAGING MAKE
SURE THE REFRIGERATOR IS IN GOOD CONDITION.
IF IN DOUBT PLEASE DO NOT INSTALL OR USE THE
REFRIGERATOR AND CONTACT YOUR SUPPLIER
IMMEDIATELY.
iii. REMOVE THE SHIPPING TAPE WHICH IS
HOLDING THE DOOR CLOSED.
WARNING
THIS REFRIGERATOR IS NOT INTENDED
FOR OUTDOOR USE. NORMAL OPERATING
TEMPERATURES FOR THIS REFRIGERATOR
ARE BETWEEN 10°C AND 30°C. USE OF THIS
REFRIGERATOR OUTSIDE OF THE DEFINED
OPERATING PARAMETERS WILL AFFECT
COOLING AND MAY DAMAGE THE UNIT.
01. ENSURE THERE IS A FREE FLOW
OF CLEAN AIR AVAILABLE ALL
AROUND THE REFRIGERATOR.
02. THIS REFRIGERATOR SHOULD NOT
BE INSTALLED CLOSE TO A HEAT SOURCE
(RADIATOR, STOVE OR HEATER) OR
EXPOSED TO DIRECT SUNLIGHT.
03. THE INSTALLATION LOCATION
SHOULD BE FIRM AND LEVEL AND ABLE
TO SUPPORT THE FULL WEIGHT OF THE
REFRIGERATOR WHEN FULLY LOADED.
04. ALLOW AT LEAST 100MM CLEARANCE
AT THE REAR, BOTH SIDES AND TOP OF THE
REFRIGERATOR FOR PROPER AIR CIRCULATION
AND EASE OF MAINTENANCE.
05. THIS REFRIGERATOR IS NOT SUITABLE
FOR INSTALLATION IN AREAS WHERE
WATER IS FREE FLOWING OR HIGH
PRESSURE WATER JETS ARE USED.
LOCATION
2
XD080818UM Rev 1.4
XDMANUAL.indd 4 16/07/2021 11:19:51

01. CARE SHOULD BE TAKEN TO ENSURE THE
REFRIGERATOR IS PERFECTLY LEVEL FOR CORRECT
OPERATION. A SPIRIT LEVEL SHOULD BE USED TO
CHECK THE UNIT IS PERFECTLY LEVEL, IF THE UNIT
IS NOT LEVEL WATER LEAKS MAY OCCUR.
LEVELLING THE REFRIGERATOR
WARNING
ALL WIRING AND ELECTRICAL CONNECTIONS
MUST CONFORM TO NATIONAL REGULATIONS.
ALL ELECTRICAL CONNECTIONS MUST BE
UNDERTAKEN BY A COMPETENT ENGINEER OR A
QUALIFIED ELECTRICIAN.
ELECTRICAL CONNECTION
01. THIS REFRIGERATOR MUST BE PLUGGED
IN TO AN INDEPENDENT POWER SOURCE OR
AN ELECTRICAL SOCKET OF VOLTAGE AND
FREQUENCY SPECIFIED. ELECTRICAL RATING
INFORMATION CAN BE FOUND ON THE DATA
PLATE OF THE REFRIGERATOR.
02. THIS REFRIGERATOR MUST BE CONNECTED
TO AN INDEPENDENT CIRCUIT BREAKER OR FUSE.
03. DUE TO POTENTIAL SAFETY HAZARDS THIS
REFRIGERATOR IS NOT RECOMMENDED FOR USE
WITH AN EXTENSION LEAD
PART II
WARNING
IF THE POWER SUPPLY CABLE IS DAMAGED,
DO NOT INSTALL OR OPERATE THE MACHINE
UNTIL THE CABLE HAS BEEN REPLACED BY
AN AUTHORISED SERVICE PARTNER OR A
QUALIFIED ENGINEER.
WARNING
ALL ELECTRICAL CONNECTIONS MUST
CONFORM TO LOCAL REGULATIONS AND BE
CARRIED OUT BY A QUALIFIED ENGINEER
XD080818UM Rev 1.43
ALL REFRIGERATORS HAVE BEEN FACTORY
PRESET BEFORE SHIPMENT. ADJUSTMENTS TO
THE PROGRAM OR SETTINGS ARE NOT REQUIRED
FOR A NEW REFRIGERATOR INSTALLATION. IN
ORDER TO ENSURE NORMAL OPERATION OF THE
REFRIGERATOR PLEASE REFER TO PART III OF THIS
MANUAL. ALWAYS REMEMBER THAT CHECKING
AND MONITORING OF THE REFRIGERATOR IS THE
RESPONSIBILITY OF THE OPERATOR.
PRE-INSTALLATION CHECK LIST
IS THE REFRIGERATOR INSTALLED ON A
SOLID AND LEVEL FLOOR
HAS ALL OF THE INNER AND OUTER
PACKAGING BEEN REMOVED FROM THE
UNIT?
IS THERE PROPER VENTILATION AROUND
ALL SIDES OF THE REFRIGERATOR?
HAS THE REFRIGERATOR BEEN CLEANED
INSIDE AND OUT?
IS THE MACHINE CORRECTLY EARTHED?
IS THE POWER TO THE MACHINE SWITCHED
ON?
IS THE REFRIGERATOR LOCATED IN A ROOM
WITH AN AMBIENT TEMPERATURE BETWEEN
10°C AND 30°C?
HAVE ALL USERS BEEN FULLY TRAINED IN
THE OPERATION OF THE REFRIGERATOR?
HAS THE REFRIGERATOR BEEN ALLOWED TO
STAND FOR A MINIMUM OF 2 HOURS?
XDMANUAL.indd 5 16/07/2021 11:19:51

OPERATING INSTRUCTIONS
WARNING
AFTER TURNING OFF YOUR REFRIGERATOR
YOU MUST WAIT AT LEAST 5 MINUTES BEFORE
RESTARTING TO AVOID DAMAGE TO THE
COMPRESSOR
XD080818UM Rev 1.4 4
ALTERING THE TEMPERATURE (FREEZERS WITH
SF-820T DIGITAL TEMPERATURE CONTROL)
PART III
YOUR FREEZER FEATURES A DIGITAL CONTROLLER.
ALL PARAMETERS ARE PRESET AT THE FACTORY
FOR OPTIMUM COOLING PERFORMANCE AND
EFFICIENCY. ALTERING THE PARAMETERS OF THE
DIGITAL CONTROLLER WILL ADVERSELY AFFECT
THE COOLING EFFICIENCY AND PERFORMANCE
OF THE FREEZER.
TO CHANGE THE SET POINT OF YOUR COOLER
PRESS AND HOLD THE SET BUTTON, THE DISPLAY
WILL FLASH ANDTHE CURRENT SETTEMPERATURE
WILL BE DISPLAYED. USE THE UP AND DOWN
ARROWS TO ADJUST THE TEMPERATURE
ACCORDING TO YOUR NEEDS AND PRESS THE SET
BUTTON AGAIN TO STORE THE NEW SET POINT.
CHANGING THE SET POINT WILL AFFECT
THE PERFORMANCE AND EFFICIENCY OF
THE REFRIGERATOR AND SHOULD ONLY BE
UNDERTAKEN BY A QUALIFIED REFRIGERATION
ENGINEER.
ALTERING THE TEMPERATURE (REFRIGERATORS
FITTED WITH AN SF-101 CONTROLLER)
TO CHANGE THE SET POINT OF YOUR COOLER
PRESS AND HOLD THE SET BUTTON, THE DISPLAY
WILL FLASH ANDTHE CURRENT SETTEMPERATURE
WILL BE DISPLAYED. USE THE UP AND DOWN
ARROWS TO ADJUST THE TEMPERATURE
ACCORDING TO YOUR NEEDS AND PRESS THE SET
BUTTON AGAIN TO STORE THE NEW SET POINT.
CHANGING THE SET POINT WILL AFFECT THE
PERFORMANCE AND EFFICIENCY OF THE COOLER
AND SHOULD ONLY BE UNDERTAKEN BY A
QUALIFIED REFRIGERATION ENGINEER.
ALTERING THE TEMPERATURE (REFRIGERATORS
WITH ANALOGUE/DIAL THERMOSTATS)
YOUR REFRIGERATOR IS FITTED WITH AN
ANALOGUE/DIAL THERMOSTAT WHICH RANGES
FROM 0 TO 6. 0 IS OFF, 1 IS WARMEST THROUGH
TO 6 THE COLDEST SETTING. FOR OPTIMUM
EFFICIENCY AND PERFORMANCE YOUR
REFRIGERATOR IS FACTORY PRESET BETWEEN
POSITION 4-5, TO DECREASE THE TEMPERATURE
INSIDETHE REFRIGERATORTURNTHETHERMOSTAT
TO RIGHT (INCREASE THE NUMBER).
SF-101
SET
SF-101
SET
YOUR COOLER FEATURES A DIGITAL CONTROLLER.
ALL PARAMETERS ARE PRESET AT THE FACTORY
FOR OPTIMUM COOLING PERFORMANCE AND
EFFICIENCY. ALTERING THE PARAMETERS OF THE
DIGITAL CONTROLLER WILL ADVERSELY AFFECT
THE COOLING EFFICIENCY AND PERFORMANCE
OF THE COOLER.
0/OFF
1
2
3 4
5
6
C
O
L
D
E
R
XDMANUAL.indd 6 16/07/2021 11:19:52

PART III
DEFROSTING
THIS REFRIGERATOR IS FITTED WITH AN
AUTOMATIC DEFROST SYSTEM. MANUALLY
DEFROSTING IS NOT REQUIRED UNDER NORMAL
CIRCUMSTANCES.
IN HUMID CONDITIONS MOISTURE IN THE AIR
MAY CAUSE AN EXCESS BUILD UP ON FROST ON
THE INSIDE OF THE UNIT.
MANUAL THERMOSTAT MODELS: UNLOAD THE
CABINET AND TURN OFF UNTIL ALL FROST AND
ICE BUILD UP HAS NATURALLY MELTED. A TOWEL
MAY NEED TO BE PLACED UNDER THE CABINET
TO SOAK UP ANY EXCESS MOISTURE GENERATED
DURING DEFROST. IF FROST BUILD UP REOCCURS
ANDTHE CABINETISWITHIN ITSNORMAL AMBIENT
OPERATING TEMPERATURE THE THERMOSTAT MAY
BE SET TOO HIGH, REDUCE THE NUMBER THAT THE
THERMOSTAT IS SET TO.
NEVER TOUCH THE EVAPORATOR SURFACE
WHEN THE MACHINE IS RUNNING AS THIS MAY
CAUSE INJURY TO THE USER
NEVER REMOVE FROST OR ICE BUILD UP WITH
A SHARP IMPLEMENT OR TOOL AS THIS WILL
DAMAGE THE REFRIGERATION SYSTEM AND
WILL VOID YOUR WARRANTY
XD080818UM Rev 1.4
5
ADJUSTING THE SHELVES
THIS REFRIGERATOR IS FITTED WITH ADJUSTABLE
SHELVES WHICH CAN BE MOVED TO SUIT
DIFFERENT SIZE PRODUCTS. TO ADJUST THE
SHELVES REMOVE THE SHELF COMPLETELY FROM
THE UNIT TO REVEAL THE SHELF CLIPS. LIGHTLY
SQUEEZE THE CLIPS TOGETHER BY HAND AND
LIFT THEM UPWARDS TO REMOVE THEM FROM
THE SUPPORT LADDER.
IMPORTANT: DO NOT USE PLIERS OR TOOLS
TO SQUEEZE THE SHELF CLIPS TOGETHER AS
THIS WILL DEFORM THEM AND THEY WILL NO
LONGER SUPPORT THE WEIGHT OF THE SHELF.
TO REINSTALL THE CLIPS INTO THE CORRECT
LOCATION PLACE THE BOTTOM LUG OF THE CLIP
INTO THE SUPPORT LADDER, SQUEEZE TOGETHER
BY HAND AND INSERT THE TOP LUG INTO THE
LADDER SUPPORT.
LOADING YOUR CABINET
ALLOW YOUR CABINET TO RUN FOR 2 HOURS
AFTER INSTALLATION BEFORE LOADING
PRODUCTS INTO THE REFRIGERATOR.
ALWAYS LOAD YOUR REFRIGERATOR IN BATCHES,
FULLY LOADING YOUR CABINET WITH WARM
PRODUCT WILL INCREASE THE CABINET
TEMPERATURE AND MAY CAUSE LOSS OF
PRODUCT.
WHEN LOADING YOUR REFRIGERATOR ALWAYS
ALLOW ADEQUATE SPACE FOR FLOW OF AIR INSIDE
THE CABINET. NEVER LOAD PRODUCTSTOUCHING
THE INTERIOR WALLS OF THE UNIT. NEVER LOAD
PRODUCTS SO THAT THEY ARE OVERHANGING
THE SHELVES. THE SPACE BETWEEN THE FRONT
OF THE SHELF AND THE DOOR IS DESIGNED TO
ASSIST AIR FLOW, NEVER BLOCK THIS SPACE.
ALWAYS LOAD YOUR REFRIGERATOR WITH CARE,
NEVER THROW OR DROP ITEMS ON TO THE
SHELVES AS THIS COULD CAUSE DAMAGE TO THE
INSIDE OF THE CABINET OR DISLOCATE THE SHELF
CAUSING DAMAGE OR INJURY.
OPERATING THE INTERIOR AND CANOPY LIGHTS
THE INTERIOR AND CANOPY LIGHTING (WHERE
FITTED) CAN BE SWITCHED OFF AT NIGHT OR
WHEN THE CABINET IS NOT IN USE TO SAVE
ELECTRICITY AND REDUCE RUNNING COSTS.
OPERATING THE LIGHTS (ALL CABINETS)
YOUR REFRIGERATOR IS FITTED WITH
AN EXTERNAL LIGHT SWITCH. TO TURN THE
LIGHTING ON AND OFF SIMPLY PRESSTHIS SWITCH
WHEN REQUIRED.
WARNING
WARNING
XDMANUAL.indd 7 16/07/2021 11:19:52

PART III
6
EFFICIENT USE
TO PREVENT COLD AIR FROM ESCAPING OPEN
AND CLOSE THE DOOR QUICKLY.
ALWAYS LOAD YOUR CABINET TO ALLOW FOR
SUFFICIENT AIRFLOW BETWEEN PRODUCTS.
ALWAYS TRY TO KEEP YOUR CABINET AS FULLY
LOADED WITH COLD PRODUCE AS POSSIBLE.
INSTALL THE UNIT IN A WELL VENTILATED AREA
WHERE THE AMBIENT TEMPERATURE WILL NOT
RISE ABOVE 30°C.
THE CABINET IS SUITABLE FOR USE IN CONDITIONS
UP TO 55% RELATIVE HUMIDITY. CONDITIONS
ABOVE THE RATED VALUE WILL CAUSE EXCESS
FROST AND ICE BUILD UP WHICH WILL AFFECT
THE PERFORMANCE AND EFFICIENCY OR THE
REFRIGERATION SYSTEM
DEFROST YOUR CABINET REGULARLY TO KEEP ICE
BUILD UP AND FROST TO A MINIMUM TO INCREASE
EFFICIENCY
EXTERIOR CLEANING
ALWAYS CLEAN THE EXTERIOR OF THE
REFRIGERATOR WITH A MICRO-FIBRE CLOTH AND
OR A SPONGE.
DO NOT USE ABRASIVE OR METALLIC PRODUCTS
(WIRE WOOL) WHICH COULD SCRATCH AND
DAMAGE THE FINISH OF THE REFRIGERATOR
PERMANENTLY.
GLASS CLEANING
CLEAN THE GLASS DOORS OF THE FRIDGE WITH
GLASS CLEANING CHEMICALS AND WIPE DRY
WITH PAPER TOWELS TO AVOID SMEARS.
INTERIOR CLEANING
CLEAN THE INTERIOR OF THE REFRIGERATOR AND
ALL REMOVABLE PARTS BY WASHING THEM WITH
A SOLUTION OF LUKEWARM WATER AND A SMALL
AMOUNT OF DISH-WASHING LIQUID. RINSE AND
DRY IMMEDIATELY.
XD080818UM Rev 1.4
PART IV
WARNING
DISCONNECT THE MACHINE FROM THE MAINS
ELECTRICITY BEFORE PERFORMING ANY
CLEANING OR MAINTENANCE.
CONDENSER CLEANING
A DIRTY OR CLOGGED CONDENSER WILL
PREVENT PROPER AIR FLOW. THIS WILL LEAD
TO REDUCED EFFICIENCY AND AN INCREASE IN
OPERATING TEMPERATURE WHICH MAY LEAD TO
COMPONENT FAILURE. WE RECOMMEND THE
CONDENSER IS CLEANED EVERY SIX MONTHS BY A
QUALIFIED ENGINEER. TO CLEANTHE CONDENSER
DISCONNECT THE REFRIGERATOR FROM THE
MAINS ELECTRICITY. REMOVE THE
SCREWS FROM THE BOTTOM PANEL
AND GENTLY REMOVE THE GRILL.
REMOVE DIRT AND DUST FROM THE CONDENSER
FINS WITH A SOFT BRUSH AND VACUUM CLEANER.
REATTACH THE FRONT GRILL AND RECONNECT
POWER TO THE MACHINE.
FREEZER MODELS FEATURE A CONDENSER
CLEAN REMINDER ON THE DIGITAL
CONTROLLER. AFTER 30 DAYS OF CONTINUOS
OPERATION CL WILL DISPLAY ON THE CONTROL
PANEL AND AN ALARM WILL SOUND. THIS
IS A REMINDER TO CLEAN THE CONDENSER,
FOLLOW THE ABOVE PROCEDURE AND PRESS
ANY BUTTON ON THE CONTROL PANEL TO
RESET THE ALARM
WARNING
ALTHOUGH THE REFRIGERATOR HAS BEEN
TESTED AND CLEANED AT THE FACTORY
DIRT AND PARTICLES MAY OF ENTERED THE
CABINET DURING TRANSIT, UNPACKING AND
INSTALLATION. DUE TO THIS IT IS IMPORTANT
THAT YOUR REFRIGERATOR IS CLEANED INSIDE
AND OUT BEFORE OPERATION.
WARNING
NEVER CLEAN THE REFRIGERATOR WITH A
PRESSURE WASHER OR BY SPRAYING WATER.
WARNING
NEVER USE ACIDIC OR ABRASIVE DETERGENTS,
THESE TYPES OF CLEANERS MAY DAMAGE THE
INTERIORANDEXTERIOROFTHEREFRIGERATOR
AND MAY LEAD TO DISCOLOURATION.
XDMANUAL.indd 8 16/07/2021 11:19:52

PART IV
7
PREPARING YOUR REFRIGERATOR FOR LONG
TERM STORAGE OR MOVING
IF THE REFRIGERATOR NEEDS TO BE STORED FOR A
LONG PERIOD OF TIME OR IT NEEDS TO BE MOVED
TO A NEW LOCATION THE FOLLOWING STEPS
MUST BE TAKEN
DISCONNECT THE UNIT FROM THE MAINS
ELECTRICITY.
REMOVE ALL REMAINING PRODUCT FROM THE
CABINET.
CLEAN THE INSIDE OF THE REFRIGERATOR AND
THOROUGHLY DRY THE INSIDE WITH PAPER
TOWELS.
FOR TRANSPORTING TO A NEW LOCATION
TAPE THE DOOR SHUT WITH A LOW TACK TAPE
(MASKING TAPE) OR LOCK THE DOORS (WHERE
LOCKS ARE FITTED)
FOR LONG TERM STORAGE LEAVE THE DOOR OPEN
AT LEAST 50MM TO ALLOW FOR AIR FLOW INTO
THE REFRIGERATOR. THIS WILL PREVENT MOLD
AND MILDEW FORMING.
NEVER STORE THE REFRIGERATOR IN AN AREA
WHERE CHILDREN COULD CLIMB INSIDE AND
BECOME TRAPPED.
ALWAYS TRANSPORT YOUR CABINET IN AN
UPRIGHT POSITION AND NEVER TILT PAST A 45°
ANGLE.
WARNING
AFTER LONG TERM STORAGE OR TRANSPORT
YOU NEED TO FOLLOW ALL INSTRUCTIONS IN
PART II OF THIS INSTRUCTION MANUAL WHEN
REINSTALLING THE MACHINE.
WARNING
ALWAYS TRANSPORT YOUR REFRIGERATOR IN
AN UPRIGHT POSITION AND NEVER TILT PAST
A 45° ANGLE.
XD080818UM Rev 1.4
WARNING
CONDENSER CLEANING SHOULD ONLY BE
UNDERTAKEN BY A QUALIFIED ENGINEER OR
SERVICE PARTNER.
WARNING
FAILURE TO CLEAN YOUR CONDENSER COULD
CAUSE COMPONENT FAILURE AND WILL
INVALIDATE YOUR WARRANTY.
XDMANUAL.indd 9 16/07/2021 11:19:52

PART V
8
MODEL XD1NW XD2NW XD260C XD701 XD701S XD1201 XD1201S
CABINET
TEMPERATURE -18°C to -22°c -18°C to -22°c 2°c to 10°c 2°c to 10°c 2°c to 10°c 2°c to 10°c 2°c to 10°c
CLIMATE CLASS 4 4 4 4 4 4 4
GROSS
CAPACITY 350 Litres 730 Litres 252 Litres 750 Litres 750 Litres 1200 Litres 1200 Litres
NET
CAPACITY 283 Litres 565 Litres 232 Litres 670 Litres 670 Litres 1000 Litres 1000 Litres
INTERNAL
ILLUMINATION
2 X 10 WATT LED
VERTICAL
2 X 12 WATT LED
VERTICAL
6 WATT LED
VERTICAL
2 X 12 WATT LED
VERTICAL
2 X 12 WATT LED
VERTICAL
2 X 12 WATT LED
VERTICAL
2 X 12 WATT LED
VERTICAL
CANOPY
ILLUMINATION 7 WATT LED 14 WATT LED 4 WATT LED 14 WATT LED 14 WATT LED 14 WATT LED 14 WATT LED
FEET / CASTORS CASTORS
(4 - 2 LOCKABLE)
CASTORS
(4 - 2 LOCKABLE)
CASTORS
(4 - 2 LOCKABLE)
CASTORS
(4 - 2 LOCKABLE)
CASTORS
(4 - 2 LOCKABLE)
CASTORS
(4 - 2 LOCKABLE)
CASTORS
(4 - 2 LOCKABLE)
LOCK & KEY YES YES YES YES YES YES YES
DOORS
1 TRIPLE GLAZED
WITH LOW E
GLASS AND
HEATER
2 TRIPLE GLAZED
WITH LOW E
GLASS AND
HEATER
1 DOUBLE
GLAZED
2 HINGED
DOUBLE
GLAZED
2 SLIDING
DOUBLE
GLAZED
2 HINGED
DOUBLE
GLAZED
2 SLIDING
DOUBLE
GLAZED
SHELVES 5 10 4 8 8 8 8
DEFROST
SYSTEM
AUTOMATIC
HEATED
AUTOMATIC
HEATED OFF CYCLE OFF CYCLE OFF CYCLE OFF CYCLE OFF CYCLE
CONTROLLER SF-820T SF-820T MANUAL/DIAL
THERMOSTAT SF-101 SF-101 SF-101 SF-101
PACKAGED
DIMENSIONS
670 x 730
x 2120
(WxDxH mm)
1270 x 730
x 2120
(WxDxH mm)
555 x 610
x 1794
(WxDxH mm)
1150 x 655
x 1995
(WxDxH mm)
1150 x 655
x 1995
(WxDxH mm)
1360 x 740
x 2110
(WxDxH mm)
1360 x 740
x 2110
(WxDxH mm)
GROSS WEIGHT 134 kg 228 kg 62 kg 121 kg 121 kg 148 kg 148 kg
NET WEIGHT 119 kg 208 kg 58 kg 113 kg 113 kg 132 kg 132 kg
OPERATING
TEMPERATURE
UP TO 30°c
55% RH
UP TO 30°c
55% RH
UP TO 30°c
55% RH
UP TO 30°c
55% RH
UP TO 30°c
55% RH
UP TO 30°c
55% RH
UP TO 30°c
55% RH
REFRIGERANT R290 R290 R290 R290 R290 R290 R290
REFRIGERANT
CHARGE 70g 150g 40g 85g 85g 110g 110g
PRODUCT
DIMENSIONS
670 x 700
x 1980
(WxDxH mm)
1220 x 700
x 1980
(WxDxH mm)
525 x 561
x 1752
(WxDxH mm)
1120 x 610
x 1973
(WxDxH mm)
1120 x 610
x 1973
(WxDxH mm)
1330 x 690
x 2079
(WxDxH mm)
1330 x 690
x 2079
(WxDxH mm)
POWER 610 WATTS 1150 WATTS 235 WATTS 450 WATTS 450 WATTS 480 WATTS 480 WATTS
VOLTAGE 230V/50Hz 230V/50Hz 230V/50Hz 230V/50Hz 230V/50Hz 230V/50Hz 230V/50Hz
CURRENT* 3.6 AMPS 5.1 AMPS 1.8 AMPS 1.95 AMPS 1.95 AMPS 2.08 AMPS 2.08 AMPS
SPECIFICATION
XD080818UM Rev 1.4
* ELECTRICAL CONNECTION MUST ALWAYS BE MADE TO A DEDICATED 13 AMP SOCKET
POWER LOAD WILL INCREASE ABOVE THE SPECIFIED RANGE AT COMPRESSOR START
XDMANUAL.indd 10 16/07/2021 11:19:52

PART VI
9
SYMPTOM POSSIBLE CAUSE SUGGESTED SOLUTION
UNIT WILL NOT SWITCH ON
UNIT IS NOT CONNECTED
TO MAINS ELECTRICITY
CORRECTLY
• CHECK POWER IS ON AT THE SOCKET
• CHECK CABLE IS CORRECTLY PLUGGED IN
MACHINE IS SWITCHED OFF • PRESS POWER ON/OFF BUTTON
FUSE BLOWN OR CIRCUIT
BREAKER TRIPPED
• CHECK FUSE IN MAIN 13 AMP PLUG
• CHECK FUSE OR CIRCUIT BREAKER AT MAIN DISTRIBUTION BOARD
POWER CABLE IS DAMAGED • CHECK FOR DAMAGE ON POWER CABLE, USE A QUALIFIED ENGINEER TO
REPLACE IF NECESSARY
LOOSE CONNECTION OR
FAULTY CONTROLLER • CHECK FOR LOOSE CONNECTION, REPLACE IF NECESSARY
COMPRESSOR IS RUNNING BUT
REFRIGERATOR IS NOT COOLING
REFRIGERANT LEAK • CHECK FOR REFRIGERANT LEAK AND REPAIR, RECHARGE SYSTEM AS PER
THE DATA PLATE
SET POINT TOO HIGH • CHECK SET POINT OF THE CABINET, CHANGE IF NECESSARY
BLOCKAGE IN SYSTEM • CLEAR BLOCKAGE, REPLACE FILTER DRIER AND RECHARGE SYSTEM AS PER
THE DATA PLATE
COMPRESSOR WIRING LOOSE
OR DEFECTIVE • CHECK FOR LOOSE CONNECTION, REPLACE IF NECESSARY
LOOSE CONNECTION OR
FAULTY CONTROLLER • CHECK FOR LOOSE CONNECTION, REPLACE IF NECESSARY
REFRIGERATOR IS NOISY
UNIT IS NOT PROPERLY LEVEL • ENSURE UNIT IS INSTALLED ON A LEVEL AND SUITABLE FLOOR
CABINET IS TOUCHING
ANOTHER CABINET OR A WALL
• CHECK CORRECT VENTILATION GAP HAS BEEN ADHERED TO - 100 MM
AROUND ALL SIDES
OBJECT IS FOULING
EVAPORATOR FAN
• CHECK FOR CORRECT LOADING OF PRODUCT AND ENSURE NOTHING IS
IN CONTACT WITH THE EVAPORATOR FAN OR FAN GUARD
REFRIGERATOR IS NOT GETTING COLD
ENOUGH
CONDENSER DIRTY • CLEAN CONDENSER AS NECESSARY
INADEQUATE AIR FLOW
AROUND REFRIGERATOR
• CHECK CORRECT VENTILATION GAP HAS BEEN ADHERED TO - 100 MM
AROUND ALL SIDES
CONDENSER FAN NOT
WORKING • CHECK FOR LOOSE CONNECTION, REPLACE IF NECESSARY
EVAPORATOR FAN NOT
WORKING • CHECK FOR LOOSE CONNECTION, REPLACE IF NECESSARY
HIGH AMBIENT TEMPERATURE • WAIT UNTIL AMBIENT TEMPERATURE DROPS BELOW 32°C
FROST IS FORMING INSIDE THE UNIT
HUMIDITY ABOVE 55% • LOWER HUMIDITY OF THE ENVIRONMENT
DOOR OPENED TOO OFTEN • KEEP DOOR OPENINGS TO A MINIMUM
DOOR HAS BEEN LEFT OPEN • INITIATE MANUAL DEFROST AS LAID OUT IN THIS MANUAL
DOOR GASKET NOT SEALING
CORRECTLY • CHECK FOR DAMAGE/CRACKS, REPLACE IF NECESSARY
DEFROST NOT COMPLETING
CORRECTLY • CHECK CONTROLLER PARAMETERS FOR DEFROST, ADJUST IF NECESSARY
TROUBLESHOOTING
WARNING
ALL MAINTENANCE AND SERVICE WORK
MUST BE UNDERTAKEN BY A QUALIFIED
REFRIGERATION ENGINEER OR AN
AUTHORISED SERVICE PARTNER.
XD080818UM Rev 1.4
XDMANUAL.indd 11 16/07/2021 11:19:52

PROJECT DISTRIBUTION LTD
UNIT 1 SUN STREET
STOKE-ON-TRENT
UNITED KINGDOM
ST1 4JW
TEL: [phone]
[e-mail]
WWW.PRODIS.CO.UK
XD080818UM Rev 1.4
XD1NW - XD2NW - XD260C - XD701 - XD701S - XD1201 - XD1201S
HYDROCARBON
REFRIGERANT
COLDER BY NATURE
R290
XDMANUAL.indd 12 16/07/2021 11:19:53
