D5X-ULEP
Technical Data Sheet
P/N 0495782_B
NSF®Certified
March 2008
We reserve the right to change or revise specifications
and product design in connection with any feature of
our products. Such changes do not entitle the buyer to
corresponding changes, improvements, additions or
replacements for equipment previously sold or shipped.
Item Part # Description Wiring Item #
FAN ASSEMBLIES
4 Ft, 8 Ft & 12 Ft
A. 12W Standard Fan Assembly (1)
0047000 Fan Motor, Evaporator
(MO.4410103)
0461805 Fan Blade (FB.4780446)
12W Energy Efficient Fan Assembly (1)
0477655 Fan Motor, Evaporator
(MO.4410546)
0461805 Fan Blade (FB.4780446)
6 Ft Only
A. 7W Standard Fan Assembly (1)
0058698 Fan Motor, Evaporator
(MO.4410102)
0142780 Fan Blade (FB.0142780)
7W Energy Efficient Fan Assembly (1)
0477654 Fan Motor, Evaporator
(MO.4410545)
0142780 Fan Blade (FB.0142780)
Item Part # Description Wiring Item #
THERMOSTATS
B. Optional Adjustable Refrigeration Thermostat (2)
LAMPS AND BALLASTS
C. Ballast, Electronic (3)
0480130 2 lamps (BA.4481676)
0480131 3 lamps (BA.4481654)
0480132 4 lamps (BA.4481677)
D. Fluorescent Lamp (4)
Replace with like fixtures
E. 0501213 Power Supply (EP.4481861) (5)
F. LED Fixture (6)
Replace with like fixtures
©2008 HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
U.S. & CANADA 1-800-922-1919 • MEXICO 1-800-522-1900 • WWW.HUSSMANN.COM
ONE FLOOR DRAIN IS
REQUIRED FOR EACH CASE.
IMPORTANT
Note: Revision B adds Important Note on Page 1, adds optional LED lighting (Pages 1, 3, 4, 8);
adds capacity and weight (Page 5)

4 ft 6 ft 8 ft 12 ft
General
(A) Case Length (without ends or partitions) 48 3/8(1229) 72 3/8(1838) 96 3/8(2448) 144 1/2(3670)
(Each end and insulated partition adds 1 1/2 in. (38 mm) to case line up.)
Maximum O/S dimension of case back to front
(includes bumper) 42 (1064) 42 (1064) 42 (1064) 42 (1064)
Back of case to front of splashguard 38 3/8 (975) 38 3/8 (975) 38 3/8 (975) 38 3/8 (975)
Back of case to O/S edge of front rails 30 1/4 (767) 30 1/4 (767) 30 1/4 (767) 30 1/4 (767)
Distance between edges of external rails and center rails NA 29 1/2 (750) 41 1/2 (1054) 41 1/2 (1054)
Distance between edges of center rails NA NA NA 43 7/8 (1114)
Distance between front rails and splashguard 8 (203) 8 (203) 8 (203) 8 (203)
Electrical Service (Electrical Field Wiring connection point located on top of case)
(B) RH End of case to center of 4 x 4 x 2 Electrical Box 39 3/8 (1000) 63 3/8 (1610) 87 3/8 (2219) 135 1/2 (3442)
Back of case to center of 4 x 4 x 2 Electrical Box 17 3/4 (451) 17 3/4 (451) 17 3/4 (451) 17 3/4 (451)
Waste Outlets (One each end)
(C) RH End of case to the center of LH waste outlet 36 1/4 (921) 60 1/4 (1530) 84 1/4 (2140) 132 3/8 (3363)
RH End of case to the center of RH waste outlet 12 1/8 (307) 12 1/8 (307) 12 1/8 (307) 12 1/8 (307)
Back O/S of case to center of waste outlets 36 3/4 (933) 36 3/4 (933) 36 3/4 (933) 36 3/4 (933)
Schedule 40 PVC drip pipe 1 1/4 (32) 1 1/4 (32) 1 1/4 (32) 1 1/4 (32)
Refrigeration Outlet
Back of case to center of refrigeration outlet 26 1/4 (665) 26 1/4 (665) 26 1/4 (665) 26 1/4 (665)
RH end of case to center of refrigeration outlet 8 (203) 8 (203) 8 (203) 8 (203)
2 of 8 D5X-ULEP Technical Data Sheet
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
Engineering
Plan Views
Dimensions shown as in. and (mm).
Ultra Low Front
Dairy & Delicatessen
07-2007
4 3/4 (120)
Splashguard
36 3/4
(933)
42
(1064)
A
41 1/2
(1054)
3 In.
(77 mm)
Required
Air Gap
Refrigeration
Outlet
Electrical Box
Waste Outlet
Waste Outlet
FRONT
26 1/4
(665)
C
B
8(203)
4 1/2 (115)
12 1/8 (307)
41 1/2
(1054)
43 7/8
(1114)
4 3/4 (120)
4 1/4 (108)
17 3/4
(451) 38 3/8
(975)
30 1/4
(767)
9
(229)
D5X
Note: ALL FIELD WIRING CONNECTION POINTS ARE ABOVE THE CASE.
Case to case connections are made in the electrical box at the top of
the case.
PHYSICAL DATA
Merchandiser Drip Pipe (in.) 1 1/4
Merchandiser Liquid Line (in.) 3/8
Merchandiser Suction Line (in.) 7/8

REFRIGERATION DATA
Note: This data is based on store temperature and
humidity that does not exceed 75°F and 55% R.H.
D5X-ULEP* UNLIT LIT
Discharge Air °F 32 30
Evaporator °F 28 26
Unit Sizing °F 26 24
Btu/hr/ft
D5X-ULEP* Parallel Conventional
UNLIT‡‡ 1510 1590
*Hussmann Peg Shelves are no longer
recommended.
‡‡ Add 10 Btu/hr/ft per shelf row for LED fixtures.
Add 20 Btu/hr/ft per shelf row for fluorescent lamps.
DEFROST DATA
Frequency Hrs 6
Defrost Water (lb/ft/day) 10.5
(± 15% based on case configuration and
product loading).
OFFTIME D5X-ULEP
Time (minutes) 20
ELECTRIC OR GAS Not
Recommended
CONVENTIONAL CONTROLS
Low Pressure Backup Control
CI/CO** D5X-ULEP
19°F/9°F
Indoor Unit Only, Pressure Defrost
Termination** 48°F
**Use a Temperature Pressure Chart to
determine PSIG conversions.
PHYSICAL DATA
Estimated Charge (lb)*** D5X-ULEP
4 ft 1.9
6 ft 2.8
8 ft 3.7
12 ft 5.1
***This is an average for all refrigerant
types. Actual refrigerant charge may vary by
approximately half a pound.
3 of 8
P/N 0495782_B HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM
Impact Excel D5X-ULEP
Dairy & Delicatessen
Dimensions shown as in. and (mm).
Multi-deck, 6 Display Levels, Ultra Low Front
36 3/4 (934)
4 3/4 (120)
30 1/4 (767)
42 (1064)
42
(1064)
38 3/8 (975)
81 3/4
(2077)
D5X-ULEP
30
(762)
64 5/8
(1641)
FAN
C
O
I
L
10 1/4
(260)
3 In. (77 mm)
Required
Air Gap
7 1/4 (183)
12 3/4
(324)
26 1/4 (667)
Refrigeration
Outlet
1 1/4
(32)
20 1/4
(514)
4 x 4 x 2
Electrical
Case to Case
Connections
61 3/4
(1568)
17 3/4 (451)
4 3/4
(121)
83 1/4
(2115)
ALL FIELD WIRING CONNECTION POINTS ARE ABOVE THE CASE.
NSF Certification
This merchandiser model is manufactured to meet ANSI/NSF
(National Sanitation Foundation) Standard #7 requirements for
construction, materials & cleanability.

4 of 8 D5X-ULEP Technical Data Sheet
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
Impact Excel D5X-ULEP
Dairy & Delicatessen
Electrical Data
4 ft 6 ft 8 ft 12 ft
Number of Fans—12W 2 — 4 6
Number of Fans—7W — 4 — —
Amperes Watts
4 ft 6 ft 8 ft 12 ft 4 ft 6 ft 8 ft 12 ft
Evaporator Fan
120V 60Hz Standard 1.30 2.00 2.60 3.90 100 156 200 300
120V 50Hz Standard 1.50 2.20 3.00 4.50 114 168 228 342
230V 60Hz Export 0.66 1.00 1.32 1.98 100 156 200 300
230V 50Hz Export 0.76 1.12 1.52 2.28 114 168 228 342
120V 60Hz Energy Efficient 0.60 0.76 1.20 1.80 36 56 72 108
230V 60Hz Energy Efficient 0.30 0.40 0.60 0.90 36 56 72 108
Minimum Circuit Ampacity
120V 60Hz Standard 1.50 2.20 2.80 4.10
120V 50Hz Standard 1.70 2.40 3.20 4.70
230V 60Hz Export 0.86 1.20 1.52 2.18
230V 50Hz Export 0.96 1.32 1.72 2.48
120V 60Hz Energy Efficient 0.80 0.96 1.40 2.00
230V 60Hz Energy Efficient 0.50 0.60 0.80 1.10
Maximum Over Current Protection 120V 20 20 20 20
Maximum Over Current Protection 230V 15 15 15 15
Standard Lighting
1 Row Canopy 0.26 0.51 0.51 0.77 30 59 59 85
Optional Lighting
Additional 1 Row Canopy 0.26 0.51 0.51 0.77 30 59 59 85
Additional 2 Row Canopy 0.51 1.02 1.02 1.54 59 118 118 170
Additional 3 Row Canopy 0.77 1.53 1.53 2.31 89 177 177 255
1 Row Rail Light 0.26 0.51 0.51 0.77 30 59 59 85
Optional Shelf Lighting
5 Rows of Shelves 1.28 2.55 2.55 3.85 148 295 295 425
6 Rows of Shelves 1.53 3.06 3.06 4.62 177 354 354 510
Optional Always*Bright LED Lighting
5 Rows of Shelves 0.57 0.83 1.13 1.69 68 99 136 203
6 Rows of Shelves 0.67 0.96 1.33 2.00 80 115 160 240
120V Lighting Circuit Total = Standard Lighting + Total Optional Lighting + Optional Shelf Lighting
230V Lighting Circuit Total = Multiply 120V Lighting Circuit Total by 0.52

5 of 8
P/N 0495782_B HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM
ESTIMATED SHIPPING WEIGHT 5
Case Solid End
4 ft 6 ft 8 ft 12 ft (each)
lb (kg) 800 (363) 1000 (454) 1200 (544) 1600 (726) 100 (45)
5Actual weights will vary according to optional kits included.
Impact Excel D5X-ULEP
Dairy & Delicatessen
Product Data
ARI Refrigerated Volume 1 (Cu Ft/Ft) 11.74 ft3/ft (1.09 m3/m)
Recommended Usable Cube 2 (Cu Ft/Ft) 9.97 ft3 /ft (0.93 m3 /m)
ARI Total Display Area 3 (Sq Ft/Ft) 5.19 ft2/ft (1.58 m2 /m)
Shelf Area 4(Sq Ft/Ft) 9.87 ft2/ft (3.01 m2 /m)
1Computed using ARI 1200 standard methodology: Refrigerated Volume, ft3[m3]/Unit of Length, ft [m]
2ARI Refrigerated Volume less shelving and other unusable space: Refrigerated Volume/Unit of Length, ft3/ft [m3/m]
3Computed using ARI 1200 standard methodology: Total Display Area, ft2[m2]/Unit of Length, ft [m]
4Shelf surface area is composed of bottom deck plus standard shelf complement, as shown in the Hussmann Product
Reference Guide. The standard shelf complement for this model is (5) rows of 22-inch shelves.eparately from fans.

Refrigeration
Thermostat
2
To
Condensing
Unit
}
Li
g
ht Blue
2, 4 & 6 Fans
120V NEUTRAL
BROWN BAND
120V POWER
Fans 1
BROWN BAND
4 ft
6 ft
8 ft
12 ft
R = Red Y = Yellow G = Green BL = Blue B = Black W = White
= 120V POWER = 120V NEUTRAL = FIELD GROUND
WARNING
All components must have mechanical ground, and the merchandiser must be grounded.
CIRCLED NUMBERS = PARTS LIST ITEM NUMBERS
= CASE GROUND
4
4
3
3
3
4
4
4
4
4
4
Optional
Two Row
Canopy
Optional
Three Row
Canopy
Connector
4
BL
W
BL
W
G
R
BL
W
B
R
RR
BL BL
R
BL
R
RR
BL
BL
R
BL
R
RR
B
B
Orange or Tan Band
3 Row Canopy
4
344
Connector
W
B
BL
BL
R
BL
R
RR
B
D5X-ULEP Technical Data Sheet
