Hatco FLAV-R-SAVOR FSD-1 User manual

HOLDING & DISPLAY
CABINETS
®
Fresh merchandising ideas for
daytime, nighttime and all of
the snack times in between.
Heat up your
impulse-buy sales.

221⁄2"(572 mm)
24" (610 mm)
Models -2 & -2X only
251⁄8" (638 mm)
Models FSD
271⁄2"
(699 mm)◆
Models FSDT
321⁄2"
(826 mm)◆
RIGHT VIEW
OPERATOR VIEW
DIMENSIONS
Cabinet Openings: FSD – 19"W x 185⁄8"H (483 x 473 mm).
FSDT – 19"W x 233⁄4"H (483 x 603 mm).
◆
Add 1" (25 mm) to height for display sign.
FLAV-R-SAVOR®HUMIDIFIED DISPLAY CABINETS
Choose display cabinets that will work harder for you around the
clock. Choose Flav-R-Savor from Hatco.
Balancing the right combination of heat and humidity, the rugged
Flav-R-Savor humidified cabinet keeps food fresh and safe for up to
four hours, reducing waste and maintaining the high quality you need
to satisfy your customers.
Plus, with a complete range of sizes, door options and rack types, you
can select the cabinet that will let you sell more whether it’s breakfast,
lunch or dinner.
• Keep food hot and fresh at safe temperatures
• Internal fluorescent lighting helps showcase product
• Full cabinet display with tempered glass doors and side panels
retains maximum heat
• Heat is diffused throughout cabinet providing gentle, even heat
• Continuous humidity keeps food fresher
• Two-door models offer pass-through convenience
FSDT
FSD
Choose a Designer Color to match
any décor.
CUSTOM FOOD DECALS:
Pizza, Chicken, Pretzel, Croissant/Biscuit
Hunter
Green
Printed colors are a representation and may not
exactly match our Designer colors.
Navy
Blue
Antique
Copper
Gray
Granite
Black
Warm
Red
White
Granite
2

DISPLAY RACK SELECTIONS
(Racks shown are for FSDT models only)
DISPLAY RACK SELECTIONS
(Racks shown are for FSD models only)
4-Tier Circle Rack ▲
(Max. 19" Dia.
(483 mm) Pans)
(Rack Opening
4
5⁄8
" (117 mm))
4-Tier Pan Rack
(Max. 18” x 13”
(457 x 330 mm)
Half-Size Sheet Pans)
(Rack Opening
3
1⁄2
" (89 mm))
7-Shelf
Multi-Purpose Rack
(Max. 18” x 13”
(457 x 330 mm)
Half-Size Sheet Pans)
(Rack Opening
2
1⁄2
" (64 mm))
5-Shelf Angle Rack
(Rack Opening
2
1⁄2
" (64 mm))
3-Shelf Angle Rack
(Rack Opening
3
1⁄2
" (89 mm))
3-Tier Pretzel Tree ▲
(Rack Opening
5
7⁄8
" (149 mm))
Model FSDT-1 with
rotating rack motor, 4-tier circle
rack, optional Designer color,
accessory decals, and pans
Model FSD-2X with
3-tier pan rack, accessory
decals, and pans
Model* TypeRack Style†Shipping Weight
FSD-1 1 Door 3-Tier Circle 113 lbs. (51 kg)
Rack w/Motor
FSD-1X 1 Door 3-Tier Pan 111 lbs. (50 kg)
Rack w/o Motor
FSD-2 2 Doors 3-Tier Circle 114 lbs. (52 kg)
Rack w/Motor
FSD-2X 2 Doors 3-Tier Pan 112 lbs. (51 kg)
Rack w/o Motor
SPECIFICATIONS
Standard Models
Model* TypeRack Style†Shipping Weight
FSDT-1 1 Door 4-Tier Circle 120 lbs. (54 kg)
Rack w/Motor
FSDT-1X 1 Door 4-Tier Pan 118 lbs. (54 kg)
Rack w/o Motor
FSDT-2 2 Doors 4-Tier Circle 122 lbs. (55 kg)
Rack w/Motor
FSDT-2X 2 Doors 4-Tier Pan 120 lbs. (54 kg)
Rack w/o Motor
VOLTAGE
120 volts, 60 Hz, 1440 watts, 12 amps (NEMA 5-15P).
Export voltages available, see specification sheet.
CORD LOCATION
Facing controls, right-hand side panel, lower
right corner.
WATER TANK CAPACITY
3⁄4gallon (3 liters).
WATER QUALITY REQUIREMENTS
Water supply in excess of 3.0 grains of hardness per
gallon (GPG) (.75 grains of hardness per liter) must be
treated and softened before being used. Water
containing over 3.0 GPG (.75 GPL) will decrease the
efficiency and reduce the operating life of the unit.
Note: Product failure caused by liming or sediment
buildup is not covered under warranty.
* Models FSD-1, FSD-2, FSDT-1, and FSDT-2 include display motor.
Models with “X” designator do not have revolving display and are
NOT available for retrofit.
† Rack listed is included with unit. Optional racks available, see
Display Rack Selection.
Tall Models
3-Tier Circle Rack
▲
(Max. 19" Dia.
(483 mm) Pans)
(Rack Opening
4
5⁄8
" (117 mm))
3-Tier Pan Rack
(Max. 18” x 13”
(457 x 330 mm)
Half-Size Sheet Pans)
(Rack Opening
3
1⁄2
" (89 mm))
5-Shelf
Multi-Purpose Rack
(Max. 18” x 13”
(457 x 330 mm)
Half-Size Sheet Pans)
(Rack Opening
2
1⁄2
" (64 mm))
CONTROLLED MOISTURIZED HEAT KEEPS HOT FOODS FRESH, LONGER
The Hatco “operator friendly” control panel makes it easy to set the correct heat and
humidity levels. Convenient dials regulate temperature and moisture, while a green
light indicates the humidity-cycle. A red light signals low-water in the reservoir. The
cabinet heat is monitored by a temperature indicator, and a front-fill reservoir cup
makes it easy to add water.
COUNTERTOP
HUMIDIFIED
HOLDING & DISPLAY
CABINETS
▲Requires motorless rack
coupling on -X Models
3
Humidity Selector
Reservoir Fill Cup Temperature
Indicator
Temperature
Selector
Humidity-Cycle Light
Low-Water Light

Model FDWD-2X with
accessory 4-shelf angle rack
207⁄8" (530 mm)
Models FDWD-2 & -2X only
22" (559 mm)
SIDE VIEW
285⁄8"
(727 mm)
FRONT VIEW
193⁄8" (492 mm)
* Models FDWD-1 and FDWD-2 include rack motor. Models with “X”
designator do not have revolving display and are NOT available
for retrofit.
† Pretzel Rack available as substitute for Circle Rack.
•Accommodates half-size sheet pans.
DIMENSIONS
Cabinet Opening: 153⁄4"W x 193⁄4"H (400 x 502 mm).
VOLTAGE
120 volts, 60 Hz, 1420 watts, 11.8 amps
(NEMA 5-15P).
Export voltages available, see specification sheet.
CORD LOCATION
Facing controls, right-hand side panel, lower right
corner.
WATER TANK CAPACITY
1⁄2gallon (2 liters).
WATER QUALITY REQUIREMENTS
Water supply in excess of 3.0 grains of hardness
per gallon (GPG) (.75 grains of hardness per liter)
must be treated and softened before being used.
Water containing over 3.0 GPG (.75 GPL) will
decrease the efficiency and reduce the
operating life of the unit.
Note: Product failure caused by liming or
sediment buildup is not covered
under warranty.
Model* TypeRack Style Shipping Weight
FDWD-1 1 Door Circle Rack† 80 lbs. (36 kg)
with Rack Motor
FDWD-1X 1 Door Multi-Purpose Rack 82 lbs. (37 kg)
without Rack Motor
FDWD-2 2 Doors Circle Rack† 86 lbs. (39 kg)
with Rack Motor
FDWD-2X•2 Doors Multi-Purpose Rack 88 lbs. (40 kg)
without Rack Motor
SPECIFICATIONS
FLAV-R-FRESH®
HUMIDIFIED DISPLAY CABINETS
It’s time to make a maximum impact on your bottom line using
a minimum of counterspace. The compact Flav-R-Fresh line gives
you a profitable way to increase your impulse-buy sales.
• Separate humidity and heat controls keep crisp foods crisp
and moist foods moist for hours
• Large single door models provide fast access to food racks
• Reversible two door models offer pass-through convenience
• A variety of racks add flexibility and merchandising appeal
• Ideal for restaurants, pizzarias, convenience stores,
concession stands, snack bars, and kiosks
FDWD
4-Tier Circle Rack ▲
(Max. 15" Dia.
(381 mm) Pans)
(Rack Opening
3
1⁄4
" (83 mm))
4-Shelf
Multi-Purpose Rack
(Max. 18” x 13”
(457 x 330 mm)
Half-Size Sheet Pans)
(Rack Opening
3
1⁄2
" (89 mm))
3-Tier Pretzel Tree ▲
(Rack Opening
5
7⁄8
" (149 mm))
4-Shelf Angle Rack
(Rack Opening
3
3⁄4
" (95 mm))
DISPLAY RACK SELECTIONSCUSTOM FOOD DECALS:
Pizza, Hot Pizza, Hot Pretzels
▲Requires motorless rack coupling on -X Models
Model FDWD-1 with rotating
rack motor, 4-tier circle rack,
optional three sided sign
holder (signs not included),
and accessory pans
COUNTERTOP
HUMIDIFIED
HOLDING & DISPLAY
CABINETS
Navy
Blue
Printed colors are a
representation and may
not exactly match our
Designer colors.
White
Granite
Hunter
Green
Gray
Granite
Black
Warm
Red
Choose a Designer Color to match any décor.
Antique
Copper
4

VOLTAGE
120 volts, 470 watts, 3.9 amps (NEMA 5-15P).
CORD LOCATION
Facing controls, lower right corner.
DIMENSIONS
Cabinet Opening: 121⁄2"W x 16"H (318 x 406 mm).
Trapezoid Shape Sign Holder: 81⁄2"W at top x 4"H x
115⁄8"W at bottom (216 x 102 x 295 mm).
161⁄2" (419 mm)
171⁄4" (438 mm)
RIGHT VIEW
16"
(406 mm)
4"*
(102 mm)
*Sign cutout
dimensions
251⁄8"
(638 mm)
OPERATOR VIEW
153⁄4" (400 mm)
115⁄8"*
(295 mm)
81⁄2"*
(216 mm)
Model TypeRack Style Shipping Weight
MDW-1X 1 Doors 3-Shelf Adjustable 46 lbs. (21 kg)
MDW-2X 2 Doors 3-Shelf Adjustable 48 lbs. (22 kg)
SPECIFICATIONS
Model MDW-1X
In Designer black with
optional hood with backlit
sign cutout on one side
(graphic included)
MINI DISPLAY WARMER
NON-HUMIDIFIED DISPLAY CABINETS
Warm cookies. Hot sandwiches. Soft pretzels. Make anytime
the right time for these types of items. This non-humidified,
compact model keeps them hot and ready for your
customers to grab-and-go.
• Merchandising flexibility thanks to magnetically
adjustable slant or horizontal shelves for maximum
visibility
• Single-door or pass-through models available for server
and self-serve operations
• Perfect for locations with limited counterspace
MDW
5
COUNTERTOP
NON-HUMIDIFIED
HOLDING & DISPLAY
CABINETS
Choose a Designer Color to match any décor.
Antique
Copper
Hunter
Green
Gray
Granite
Black
Warm
Red
White
Granite
Navy
Blue
Printed colors are a representation
and may not exactly match our
Designer colors.

Model WFST-2X with
4-shelf multi-purpose
rack, optional Designer
color and sliding doors,
and accessory pans
Model WFST-1X with
4-shelf multi-purpose rack
and accessory decals and pans
Model WFST-1X operator side
VOLTAGE
120 volts, 60 Hz, 1790 watts, 14.9 amps (NEMA 5-15P,
NEMA 5-20P – Canada).
Export voltages available, see specification sheet.
CORD LOCATION
Facing controls, left-hand side panel, lower
right corner.
WATER TANK CAPACITY
3⁄4gallon (3 liters).
WATER QUALITY REQUIREMENTS
Water supply in excess of 3.0 grains of hardness per
gallon (GPG) (.75 grains of hardness per liter) must be
treated and softened before being used. Water
containing over 3.0 GPG (.75 GPL) will decrease the
efficiency and reduce the operating life of the unit.
Note: Product failure caused by liming or sediment
buildup is not covered under warranty.
DIMENSIONS
Cabinet Opening: 28"W x 217⁄8"H (711 x 556 mm).
321⁄8" (816 mm)
OPERATOR VIEW RIGHT VIEW
27
5
⁄ 8 " (702 mm)
25
1
⁄ 4 " (641 mm)
32
3
⁄ 4 "
(832 mm)
Model WFST-2X only
Model TypeRack Style Shipping Weight
WFST-1X 2 Doors 4-Shelf Stationary 163 lbs. (74 kg)
WFST-2X 4 Doors 4-Shelf Stationary 188 lbs. (85 kg)
SPECIFICATIONS
FLAV-R-SAVOR®
HUMIDIFIED LARGE CAPACITY
DISPLAY CABINETS
Expecting peak crowds at meal time? Turn to the larger capacity
Flav-R-Savor Wide Display Cabinet. Place hot product straight
from the oven directly into the full-view cabinets and increase
your impulse sales.
• Holds standard 18" x 26" (457 x 660 mm) sheet pans for
efficient kitchen operation
• Multipurpose display rack included
• Optional self-closing sliding doors for self-serve applications
• Stacking kit available to maximize floor space and double
display capacity
WFST
CUSTOM FOOD DECALS:
Chicken, Ribs, Today’s Hot Specials
SPECIALTY COUNTERTOP
HUMIDIFIED
Holding & Display
Cabinets
6
WFST 4-Shelf Multi-
Purpose Rack with
removable shelves
offering up to 9°
angle of flexibility
(3" (76 mm) difference
from front to back)
Choose a Designer Color to match
any décor.
Hunter
Green
Printed colors are a representation and may not
exactly match our Designer colors.
Navy
Blue
Antique
Copper
Gray
Granite
Black
Warm
Red
White
Granite

Model LFST-48 with 3-shelf
multi-purpose rack, sign
holders (graphic not included),
and optional Designer color
VOLTAGE
120/208-240 volts, 2150 watts, 14.6 amps
(NEMA L14-20P).
Export voltages available, see specification sheet.
CORD LOCATION
Facing controls, left-hand side panel, lower
right corner.
DIMENSIONS
Cabinet Opening: 427⁄8"W x 217⁄8"H (1089 x 556 mm).
OPERATOR VIEW RIGHT VIEW
271⁄8" (689 mm)487⁄8" (1241 mm)
30"
(762 mm)
Model TypeRack Style Shipping Weight
LFST-48 4 Doors 3-Shelf Stationary 190 lbs. (86 kg)
SPECIFICATIONS LFST
FLAV-R-SAVOR®
NON-HUMIDIFIED LARGE CAPACITY
DISPLAY CABINETS
When capacity is an issue and humidified heat is not needed,
choose the Hatco Large Capacity Display Cabinet. Items such
as wraps and sandwiches can be prepared in advance and still
stay hot, safe and tasty with this large model. And you will
always be ready for your daily rush – whatever time it occurs.
• Perfect for large quantities of wrapped or boxed food
• Sign holders on all four sides for easy personalization
(signs not included)
• Holds two standard sheet pans side-by-side on
three shelves for increased product visibility and
easy accessibility
SPECIALTY COUNTERTOP
NON-HUMIDIFIED
Holding & Display
Cabinets
7
LFST 3-Shelf Multi-Purpose Rack
with Non-Adjustable Shelves
Choose a Designer Color to match
any décor.
Hunter
Green
Printed colors are a representation and may not
exactly match our Designer colors.
Navy
Blue
Antique
Copper
Gray
Granite
Black
Warm
Red
White
Granite

MACHO NACHO®
CHIP WARMERS
When it’s time for a snack, Macho Nacho is always ready. Keep
your chips hot, crisp and tasty with this specialty warmer and
display unit. The unique two-door design allows for first-in, first-
out chip delivery. And since Macho Nacho circulates air to prevent
the loss of natural oils, you will not need to replace stale chips.
• Hold 25 or 40 pounds (11 or 18 kg) of chips in a very small
footprint, reducing refill time
• Two-door access permits easy loading and serving
• Special ductwork forces heat through chips from the
bottom up, providing efficient heating
MN
SPECIALTY COUNTERTOP
NON-HUMIDIFIED
Holding & Display
Cabinets
Model FDW-1-MN
8
Model FST-1-MN
SPECIFICATIONS
VOLTAGE
FDW-1-MN: 120 volts, 1128 watts, 9.4 amps
(NEMA 5-15P).
FST-1-MN: 120 volts, 1245 watts, 10.4 amps
(NEMA 5-15P).
Export voltages available, see specification sheet.
CORD LOCATION
FDW-1-MN: Facing controls, bottom left corner.
FST-1-MN: Facing controls, left-hand side panel,
lower right corner.
PRODUCT CAPACITY
FDW-1-MN: 25 lbs. (11 kg).
FST-1-MN: 40 lbs. (18 kg).
DIMENSIONS
FDW-1-MN:
Cabinet Openings: Upper Door 151⁄4"W x 91⁄4"H
(387 x 235 mm).
Lower Door 151⁄4"W x 91⁄4"H
(387 x 235 mm).
FST-1-MN:
Cabinet Openings: Upper Door 181⁄4"W x 111⁄4"H
(464 x 286 mm).
Lower Door 181⁄4"W x 91⁄4"H
(464 x 235 mm).
Model TypeShipping Weight
FDW-1-MN 2 Doors 80 lbs. (36 kg)
FST-1-MN 2 Doors 132 lbs. (60 kg)
Model FDW-1-MN
Model FST-1-MN
18" (457 mm)
225⁄8"(575 mm)
18" (457 mm)
271⁄2"
(699 mm)
OPERATOR VIEW RIGHT VIEW
27" (686 mm)
227⁄8" (581 mm)227⁄8" (581 mm)
325⁄8"
(829 mm)
OPERATOR VIEW RIGHT VIEW

Model FSHACH-3
Model FSHACH-2
with accessory pans
Model FSHACH-2PT
Pass-through with
accessory pans
SPECIFICATIONS
91⁄8"
(232 mm)
41⁄2"
(114 mm)
41⁄2"
(114 mm)
181⁄8"
(460 mm)
201⁄8"
(511 mm)
FSHACH-2 only
207⁄8"
(530 mm)
181⁄4"
(464 mm)
187⁄8"
(479 mm)
FSHACH-2 only
243⁄8"
(619 mm)
227⁄8"
(581 mm)
121⁄2"
(318 mm)
OPERATOR VIEW
RIGHT VIEW
171⁄4"
(438 mm)
181⁄8"
(460 mm) 6"
(152 mm)
6"
(152 mm)
261⁄2"
(673 mm)
4" (102 mm)
201⁄8"
(511 mm)
181⁄4"
(464 mm)
175⁄8"
(448 mm) 187⁄8"
(479 mm)
227⁄8"
(581 mm)
207⁄8"
(530 mm)
OPERATOR VIEW
RIGHT VIEW
FSHACH-3 only
207⁄8"
(530 mm)
FSHACH-3 only
243⁄8"
(619 mm)
Model TypeShipping Weight
FSHAC-2 2-Tier 100 lbs. (45 kg)
FSHACH-2 2-Tier Humidified 100 lbs. (45 kg)
FSHAC-3 3-Tier 115 lbs. (52 kg)
FSHACH-3 3-Tier Humidified 115 lbs. (52 kg)
FSHAC-2PT 2-Tier Pass-Through 150 lbs. (68 kg)
FSHACH-2PT 2-Tier Humidified 150 lbs. (68 kg)
Pass-Through
VOLTAGE
FSHAC-2: 120 volts, 60 Hz, 1850 watts, 15.4 amps
(NEMA 5-20P).
FSHAC-2, -3: 120/208 volts, 60 Hz, 1877 watts, 9.0 amps
(NEMA L14-20P).
FSHAC-2PT: 120/208 volts, 60 Hz, 3152 watts, 15.2 amps
(NEMA L14-20P).
FSHAC-2PT: 208 volts, 60 Hz, 3152 watts, 15.2 amps
(NEMA L6-20P).
FSHAC-2PT: 240 volts, 60 Hz, 3200 watts, 13.3 amps
(NEMA L6-20P).
FSHACH-2, -3: 120/208 volts, 60 Hz, 2950 watts,
14.2 amps (NEMA L14-20P).
FSHACH-2PT: 120/208 volts, 60 Hz, 4952 watts,
23.8 amps (NEMA L14-30P).
FSHACH-2PT: 208 volts, 60 Hz, 4952 watts, 23.8 amps
(NEMA L6-30P).
CORD LOCATION
FSHAC-2, -3, FSHACH-2, -3: Top of unit towards the
back, middle.
FSHAC-2PT, FSHACH-2PT: Top of unit towards the
back, left side.
WATER TANK CAPACITY (Humidified Models)
FSHACH-2, -3: 21⁄4gallons (9 liters).
FSHACH-2PT: 3 gallons (11 liters).
WATER QUALITY REQUIREMENTS
Water supply in excess of 3.0 grains of hardness per
gallon (GPG) (.75 grains of hardness per liter) must be
treated and softened before being used. Water
containing over 3.0 GPG (.75 GPL) will decrease the
efficiency and reduce the operating life of the unit.
Note: Product failure caused by liming or sediment
buildup is not covered under warranty.
DIMENSIONS
Cabinet Opening
FSHAC-2, FSHACH-2: 181⁄4"W x 91⁄8"H (464 x 232 mm).
FSHAC-3, FSHACH-3: 181⁄4"W x 181⁄8"H (464 x 460 mm).
FSHAC-2PT, FSHACH-2PT: 181⁄4"W x 91⁄4"H (464 x 235 mm).
Models:
FSHAC-2
FSHACH-2
241⁄8" (613 mm)
181⁄4"
(464 mm)
91⁄4"
(235 mm)
18"
(457 mm) 117⁄8"
(302 mm)
41⁄2"
(114 mm)
41⁄2"
(114 mm)
29" (737 mm)
341⁄8" (867 mm)
FSHACH-2PT only
355⁄8" (905 mm)
OPERATOR VIEW RIGHT VIEW
4" (102 mm)
Models:
FSHAC-2PT
FSHACH-2PT
(with accessory
4" (102 mm) legs)
FSHAC
FSHACH
SPECIALTY COUNTERTOP
HEATED AIR CURTAIN
Cabinets
FLAV-R-SAVOR®
HUMIDIFIED & NON-HUMIDIFIED
HEATED AIR CURTAIN CABINETS
Deliver exactly what your clientele hungers for anytime of
the day. The patented Flav-R-Savor Heated Air Curtain
Cabinets give you immediate access to food with no doors to
slow you down during your daily rush. Peak rush times can
challenge your operation – Hatco helps you meet this demand
with ease.
• A “curtain” of heated air is created by warm air being
forced downward through ducts above the opening and
then drawn towards the back of the unit
• Perfect for wrapped product and product on sheet pans
• Available in sizes to accommodate half-size or full-size
sheet pans
• Available in both humidified and non-humidified to
match your product offering
Models:
FSHAC-3
FSHACH-3
9
Removable
Slant Rack
Removable
Rib Rack

SPECIFICATIONS
223⁄4"
(578 mm)
Model FSHC-7-1
291⁄2" (749 mm)
351⁄8" (892 mm)
with Standard
Casters
323⁄4" (832 mm)
with Optional
Low Profile
Casters
Model FSHC-7-2
32" (813 mm)
OPERATOR VIEW RIGHT VIEW
253⁄8" (645 mm)
OPERATOR VIEW RIGHT VIEW
Model FSHC-6W1
291⁄2" (749 mm)
Model FSHC-6W2
32" (813 mm)
321⁄8" (816 mm)
with Standard
Casters
293⁄4" (756 mm)
with Optional
Low Profile
Casters
Model TypeRack Style Shipping Weight
FSHC-7-1 1 Door Adjustable 168 lbs. (76 kg)
Angle Slides✖
FSHC-7-2▲2 Doors Adjustable 172 lbs. (78 kg)
Angle Slides✖
FSHC-6W1 1 Door Adjustable 175 lbs. (79 kg)
Angle Slides•
FSHC-6W2▲2 Doors Adjustable 179 lbs. (81 kg)
Angle Slides•
✖7 slides on each side standard. Additional slides available.
Sheet Pans not included.
▲FSHC-7-2 and FSHC-6W2 are each a two-door pass-through
single cabinet, not two units stacked.
•6 slides on each side standard. Additional slides available.
Sheet Pans not included.
VOLTAGE
FSHC-6W1, -6W2: 120 volts, 60 Hz, 1697 watts,
14.1 amps (NEMA 5-15P, NEMA 5-20P – Canada).
FSHC-7-1, -7-2: 120 volts, 60 Hz, 1697 watts, 14.1 amps
(NEMA 5-15P, NEMA 5-20P – Canada).
Export voltages available, see specification sheet.
CORD LOCATION
Back of unit, upper right side.
WATER TANK CAPACITY
FSHC-6W1, -6W2: 11⁄4gallons (5 liters).
FSHC-7-1, -7-2: 3⁄4gallon (3 liters).
DIMENSIONS
Cabinet Opening: FSHC-7-1, -7-2 – 181⁄2"W x 22"H
(470 x 559 mm).
FSHC-6W1, -6W2 – 211⁄2"W x 19"H
(546 x 483 mm).
Top Surface: FSHC-7-1, -7-2 – 225⁄8"W x 257⁄8"D
(575 x 657 mm).
FSHC-6W1, -6W2 – 253⁄8"W x 257⁄8"D
(645 x 657 mm).
Models FSHC-7-1, -7-2
Models FSHC-6W1, -6W2
FLAV-R-SAVOR®
LOW PROFILE & PORTABLE
HUMIDIFIED HOLDING CABINETS
When it’s time for flexibility, turn to Hatco portable cabinets.
You’ll find the fit that’s right for you with the Flav-R-Savor Low
Profile or standard Portable Holding Cabinets. The low profile
model is perfect for under work counters, and they are all easy
to move and maneuver when necessary.
• Accommodates full sheet pans or Gastronorm pans
• Insulated side walls, field reversible glass doors, large
swivel casters with wheel locks, and 6' (1829 mm)
cord and plug are standard
• Perfect for serving counters, buffet lines, drive-up
windows, point-of-service or preparation areas
FSHC-7
FSHC-6
Model FSHC-7-1 with
standard 4" (102 mm)
casters, tray slides, and
accessory food pans
Models
FSHC-7-1/FSHC-7-1
with accessory
stacking hardware
and pans
10
PORTABLE
HUMIDIFIED
HOLDING & DISPLAY
CABINETS
Model FSHC-6W1
with accessory pans
Model FSHC-6W1
with accessory pans
Navy
Blue
Printed colors are a
representation and may
not exactly match our
Designer colors.
White
Granite
Hunter
Green
Gray
Granite
Black
Warm
Red
Choose a Designer Color to match any décor.
Antique
Copper

SPECIFICATIONS
Single Door
RIGHT VIEW
57"
(1448 mm)
includes
5" (127 mm)
diameter
casters
325⁄8" (829 mm)
FSHC-12W1 only
35" (889 mm)
361⁄2" (927 mm)
Unique notched cord inlet
allows wall hugging
Pass-Through
RIGHT VIEW
307⁄8" (784 mm)
FSHC-12W2 only
353⁄8" (899 mm)
361⁄2" (927 mm)
383⁄4"
(984 mm)
10"
(254 mm)
253⁄8" (645 mm)
311⁄2" (800 mm)
OPERATOR VIEW
Optional transport
package features
include push-pull
standoff handles
and full perimeter
bumper
253⁄8" (645 mm)
Single Opening w/ 2 Dutch Doors
OPERATOR VIEW
Single Door
RIGHT VIEW
733⁄8"
(1864 mm)
includes
5" (127 mm)
diameter
casters
383⁄4"
(984 mm)
10"
(254 mm)
383⁄4"
(984 mm)
10"
(254 mm)
325⁄8" (829 mm)
FSHC-17W1 Series only
35" (889 mm)
253⁄8" (645 mm)
311⁄2" (800 mm) 311⁄2" (800 mm) 361⁄2" (927 mm)
Single Door
OPERATOR VIEW
Optional transport
package features
include push-pull
standoff handles
and full perimeter
bumper
Unique notched cord inlet
allows wall hugging
Pass-Through
RIGHT VIEW
307⁄8" (784 mm)
FSHC-17W2 Series only
353⁄8" (899 mm)
361⁄2" (927 mm)
Model Type* Rack Style Shipping Weight
FSHC-12W1 1 Door Adjustable 265 lbs. (120 kg)
Angle Slides
▲
FSHC-12W2 2 Doors Adjustable 295 lbs. (134 kg)
Pass-Through Angle Slides
▲
FSHC-17W1 1 Door Adjustable 295 lbs. (134 kg)
Angle Slides
•
FSHC-17W1D 1 Opening Adjustable 305 lbs. (138 kg)
2 Dutch Doors Angle Slides
•
FSHC-17W2 2 Doors Adjustable 325 lbs. (147 kg)
Pass-Through Angle Slides
•
FSHC-17W2D 4 Dutch Doors Adjustable 340 lbs. (154 kg)
Pass-Through Angle Slides
•
* Full view Lexan® doors with full perimeter gaskets.
▲12 slides on each side standard. Additional slides available.
Sheet Pans not included.
•17 slides on each side standard. Additional slides available.
Sheet Pans not included.
VOLTAGE
120 volts, 60 Hz, 1750 watts, 14.6 amps
(NEMA 5-15P, NEMA 5-20P – Canada).
Export voltages available, see specification sheet.
CORD LOCATION
Facing controls, right-hand side panel, lower
right corner.
WATER TANK CAPACITY
2 gallons (8 liters).
WATER QUALITY REQUIREMENTS
Water supply in excess of 3.0 grains of hardness per
gallon (GPG) (.75 grains of hardness per liter) must be
treated and softened before being used. Water
containing over 3.0 GPG (.75 GPL) will decrease the
efficiency and reduce the operating life of the unit.
Note: Product failure caused by liming or sediment
buildup is not covered under warranty.
DIMENSIONS
Cabinet Opening: FSHC-12W – 22"W x 41"H (559 x 1041 mm).
FSHC-17W – 22"W x 59"H (559 x 1499 mm).
Model FSHC-12W Series
Model FSHC-17W Series
Model FSHC-17W1
with accessory food pans
Model FSHC-17W1
with accessory food pans
Model FSHC-12W1
with accessory food pans
FSHC-12
FSHC-17
FLAV-R-SAVOR®
TALL HUMIDIFIED
HOLDING CABINETS
People want lots of menu choices – yet often don’t have time to
wait for food to be prepared from start to finish at the time of
order. Give your customers more menu choices and hold larger
quantities of proven favorites ahead of peak serving periods with
these Flav-R-Savor Tall Humidified Holding Cabinets.
• Hold full sheet, Gastronorm, or steam table pans
• Two sizes to fit your kitchen’s needs
• Models are available with pass-through design
• Dutch doors available on FSHC-17W models
• Temperatures from 90° – 200°F (32° – 82°C) will
accommodate proofing
PORTABLE
HUMIDIFIED
HOLDING & DISPLAY
CABINETS
11

P.O. Box 340500
Milwaukee, WI 53234-0500 USA
[phone] [phone]
www.hatcocorp.com
E-mail: [email protected]
Printed in U.S.A. Form No. HDCB-0407-1 HC-CG
Revised July 2008
ANSI/NSF 4
FLAV-R-SAVOR®
TALL NON-HUMIDIFIED HOLDING CABINETS
It’s a great time to build your sales volume with the Flav-R-Savor
Non-Humidified Tall Holding Cabinet. With capacity for up to 16
boxed or 8 bagged pizzas, you’ll have the tools in place to give
your customers hot and fresh carryout and delivery pizza.
• Excellent visibility to assure proper delivery rotation
• Illuminated cabinet interior for easy viewing
• Returns to temperature quickly after opening doors to
keep pizza hot
PORTABLE
NON-HUMIDIFIED
HOLDING & DISPLAY
CABINETS
PFST
Model PFST-2X
with 8-shelf rack
VOLTAGE
120 volts, 1740 watts, 14.5 amps
(NEMA 5-15P, NEMA 5-20P – Canada).
Export voltages available, see specification sheet.
CORD LOCATION
Facing controls, left-hand side panel, lower
right corner.
DIMENSIONS
Cabinet Opening: 183⁄4"W x 401⁄2"H (476 x 1029 mm).
Available Shelf Space: 177⁄8"W x 177⁄8"D (454 x 454 mm).
227⁄8"
(581 mm)
513⁄4"
(1314 mm)
OPERATOR VIEW RIGHT VIEW
563⁄4"
(1441 mm)
includes
4" (102 mm)
diameter
casters
247⁄8"
(632 mm)
271⁄8"
(689 mm)
Model PFST-2X only
SPECIFICATIONS
Model TypeShipping Weight
PFST-1X 1 Door 178 lbs. (81 kg)
PFST-2X 2 Doors 178 lbs. (81 kg)
PLUG CONFIGURATIONS
Colored areas indicate models for export use only.
Model 120 Volt 60 Hz 120/208 Volt 60 Hz 208 Volt 60 Hz 240 Volt 60 Hz 220Volt 50/60 Hz 240 Volt 50/60 Hz
FSD/FSDT NEMA 5-15P – – – CEE 7/7 Schuko BS-1363
FDW NEMA 5-15P – – – CEE 7/7 Schuko BS-1363
MDW NEMA 5-15P – – – – –
WFST NEMA 5-15P* – – – CEE 7/7 Schuko BS-1363
LFST – NEMA L14-20P – – – –
MN NEMA 5-15P – – – CEE 7/7 Schuko BS-1363
FSHAC/FSHACH – NEMA L14-20P – – – –
FSHAC-2PT – NEMA L14-20P NEMA L6-20P NEMA L6-20P – –
FSHACH-2PT – NEMA L14-30P NEMA L6-30P – – –
FSHC NEMA 5-15P* – – – CEE 7/7 Schuko BS-1363
PFST NEMA 5-15P* – – – CEE 7/7 Schuko BS-1363
* NEMA 5-20P for Canada
NEMA 5-15P NEMA 5-20P
NEMA L14-20P NEMA L14-30P
NEMA L6-20P NEMA L6-30P
BS-1363CEE 7/7 Schuko
Unique Needs, Exact Solutions.
At Hatco we look, listen, and bring our full experience to your
operation. “Customerization” is our brand promise…providing you
with foodservice innovations that build your profits. That‘s Hatco,
and that‘s always good for business.
Contact us today for all of your foodservice equipment needs.
