Profile FCMAP3 User manual

Before starting to assemble this unit please read
the step by step assembly instructions carefully
3 SHELF UNIT FOOLSCAP LIBRARY BOXES
Code: FCMAP3
Suppliers to the Education Sector
Philips Screwdriver
Allen Key (supplied)
Familiarise yourself
with the contents
Check there is nothing
missing
Check you have all the
tools required
Make room to assemble
the product
Check List
Tools
Assembly Instructions

Panels Quantity Size(mm)
2 1124x440
2 980x430
1 1024X460
2 980X365
1 980X358mm
Panels lettered for identication if spare
part is required. Please also state colour.
ENDS A
Components Quantity
Conformat screws 25
Feet 4
4 x 25 screws 16
SHELVES B
BACK E
Suppliers to the Education Sector
BOTTOM C
BACKS D

Step 1
C
Secure (4) Feet to Bottom C using 16 4x25 screws. Use pop marks provided.
Suppliers to the Education Sector

Step 2
Secure (1) Back D to (1) End A using (2) Conformat Screws
Secure (1) Back B to (1) End A using (2) Conformat Screws
Secure (1) Back D to (1) End A using (2) Conformat Screws
Secure (1) Back B to (1) End A using (2) Conformat Screws
Secure (1) Back E to (1) End A using (2) Conformat Screws
Secure (1) End A to Backs D Shelves B and Back E using (10) Conformat Screws
Suppliers to the Education Sector
E
B
B
D
D
A A

Step 3
Secure (1) Bottom C to Ends A using (5) Conformat Screws
Suppliers to the Education Sector
YOUR UNIT IS NOW COMPLETE
