Profile MCU/2 User manual

Suppliers to the Education Sector
Philips Screwdriver
Allen Key (supplied)
Familiarise yourself
with the contents
Check there is nothing
missing
Check you have all the
tools required
Make room to assemble
the product
Check List
Tools
Before starting to assemble this unit please
read the step by step assembly instructions
carefully
Modular Cube Unit
Code: MCU/2
Assembly Instructions

Suppliers to the Education Sector
Panels Quantity Size(mm)
2 785x295mm
1785x385mm
2 415x295mm
1 385x279mm
Panels lettered for identication if spare
part is required. Please also state colour.
Components Quantity
Conformat screw 16
Connecting bolt 2
1 x 6 Screw 4
Foot 4
BACK B
ENDS A
SHELF E
TOP/BOTTOM C/D

Suppliers to the Education Sector
Step 1
Step 2
N.B. Panel edges to be face down
D
Secure (4) feet to bottom D using (4) 1x6 screw into ‘pop’
marks.
secure Top C, Bottom D and Shelf E to
End A using (6) conformat screws
N.B. Pop marks to be underside
D
E
C
A

Suppliers to the Education Sector
Step 3
Step 4
Position Back B between Top C and Bottom D
and secure to End A with (2) conformat screws.
Position End A between Top C Bottom D and
secure to Top C, Bottom D, Shelf E and back
B with (8) conformat screws.
B
B
A
C
E
D
C
E
A
D
