OWNER’SMANUAL
INSTALLATIONANDOPERATION
INSTRUCTIONSFOR:
SUBMERSIBLEUTILITYPUMPS
Models:
PF91025,PF91250,PF91251
PF91255,PF91257,PF91330
PF91335,PF91331,PF91501
PROFLO
UtilityManual
Revised 12
-
06

Carefullyreadand understand all oftheWarningsandinstallationinstructionsinthismanual.
Failuretofollowthese instructionscouldleadtoseriousbodilyinjuryand/orpropertydamage.
Retainthese instructionsforfuturereference.
Thispumphasbeenmanufactured withyourneedsinmind.Properlyinstalled intheright application,
yournewPROFLOPumpwill giveyouyearsofcarefree performance.
DANGER Waterand electricitycanbe dangerousifcertainprecautionsarenotadheredto.This
pumpisdesigned tooperateperfectlysafeinawaterenvironment; however,improperuseand
installationcanresultinpersonalharm fromelectricalshock.Pleasepayattention tothefollowing
warnings.
WARNING
Nevertouchanyelectricaldevice,including thispump,when itistouching water,inwater, oreven ina
moistenvironment. Always unplug(disconnectthe electricity)when working on orinstallingthe unit.
WARNING
RISKOFELECTRICALSHOCK.Thispumpissupplied withagroundingconductorand grounding-
type attachmentplug.Toreducethe risk ofelectricalshock,be certainthatitisconnected onlytoa
properlygrounded, grounding-type receptacle.
WARNING Donotusethepowercordordischarge hosetocarryorhandlethepump. Doingso
maycausedamage tothe powercordordischargehose.Usethecarrying handlesupplied withthe
pump.
WARNING Always useagrounded outlettoattachthe plug.Athree-prong mating type
receptacleisneeded forsafeuse.Thisshouldbe inaccordancewiththe NationalElectricCode and
anyadditionalcodesorlawsrequired byyourlocalgovernment.
NOTICE Itisstronglyrecommended touseaground faultinterruptdeviceon anyelectrical
appliance,including thispump,when usedinawetormoistenvironment.ThisGFCI(groundfault
circuitinterrupter)shouldbe listed byUnderwritersLaboratories(UL).Thisisrequired bymanylocal
codesand enforcementagencies.
LIMITEDWARRANTYANDLIMITATIONOFLIABILITY
Thispumpiswarranted freefrommaterialand/ormanufacturing defectsforoneyearfromdateof
purchase(three yearson selectcastironpumps).Asthesoleand exclusiveremedyforabreachof
thislimited warranty,ifthe productisfound tobe defective,itwill be replacedwithanequivalent
productif itisreturned totheplaceofpurchasewithproofofpurchase.Anydisassembly,modification,
orabuseofthisproductvoidsthislimited warranty.Thisproductisnotdesigned forpumping
flammableorcorrosivefluids,and useofthisproducttopumpsuchmaterialsalsovoidsthislimited
warranty
ALL OTHEREXPRESS ORIMPLIEDWARRANTIES,
INCLUDINGWARRANTIES OFMERCHANTABILITYORFITNESS
FORAPARTICULARPURPOSEAREDISCLAIMED
IMPORTANTNOTICE:Somecommercialandresidentialinsurancepoliciesextendcoverage for
damagesincurredbyproduct failure.Inmostcases,you willneedtohavepossession ofthe product
tosupportyourclaim.Inthecasewhereyou needtoretainpossession ofthe producttosupporta
damage claimyou submittoyourinsurancecompany, the pumpwillbe exchangedwithand equivalent
ortheoriginalpricewillbe refunded oncetheclaimissettled withtheinsurer.
2
7

REPLACEMENTPARTS
DANGER Donotusethisunittopumpchemicals,flammableliquids,sewage orcorrosive
liquids.You couldinjureyourselfand thepumpwillfail.Pumpingthesetypesofliquidsvoidsthe
warranty. Thispumpwillhandlefluidswiththesamecharacteristics aswater
WARNING
Yourpumphasthermalover-loadprotection builtin.Itisnotrecommended forpumpingliquidsover
120°F. The thermaloverload protectorwillautomaticallyshutdownthe pumpinanoverheatsituation.
It willthen resetitselfoncethe pumpcoolsdown.Thepumpwillthen workagain.Thisoverloadis
designedasasafetydeviceand itwillfail afterrepeated use.Normaloperationisforfluidsbetween
32°F&120°F.
DONOTRUN THEPUMPDRY.The pumpdependson waterforcoolingand lubrication.Operating
the pumpwithoutwatermaycausethemotortooverheatorcausedamage topartsofthepump.It
mayalsoshorten the lifeof yourpump.
NOTICE
EXTENSIONCORDS
Forbestperformance,itisrecommended toconnectthe powercorddirectlytothegrounded GFCI
outlet.If the useofanextension cordisnecessary,always useagroundedwaterprooftypecord.
Neveruselongerthana25-ft.cordthatislighterthan 14/3gauge.
DANGER Keepallelectricalconnectionsawayfromwetand moistenvironments.Wet
connectionscan causeelectricalshock resulting inpersonalinjury.
USES
YourPROFLOPumpisdesignedtogiveyoureliableperformanceand longlife.Itisdesignedtomove
waterfromoneplacetoanother.It isgreat forwetbasements,roofs,pondsorwaterfalls.
Part#forModels:
Ref.# Description
PF91025
PF91250 PF91255
PF91257
PF91251 PF91330 PF91335 PF91331 PF91501
1 PowerCord PF99008 PF99009 PF99008 PF99009
2 Handle PF99050 PF99050 PF99050 PF99050 PF99050 PF99050 PF99050
3 GardenHoseAdapter PF99006 PF99006 PF99006 PF99006 PF99006 PF99006
4 OilFillPlug withO-ring PF99055 PF99055 PF99056 PF99055 PF99055 PF99056 PF99056
5 Shaft Seal PF99057 PF99057 PF99057 PF99057 PF99057 PF99057 PF99057
6 Impeller PF99060 PF99060 PF99060 PF99065 PF99065 PF99065 PF99070
7 Gasket PF99062 PF99062 PF99062 PF99062 PF99062 PF99062 PF99064
8 Base PF99067 PF99067 PF99078 PF99069 PF99069 PF99070 PF99071
9 IntakeScreen PF99073 PF99073 PF99076 PF99073 PF99073 PF99076 PF99074
*Replacement powercordsnot availableforcast ironpumps
**If motorfails,replaceentirepump
1
4
2
3
5
6
7
8
9
1
2
4
5
6
7
8
3
6

WARNING ALWAYS DISCONNECTTHEPOWERSOURCEBEFOREATTEMPTINGTOINSTALL,SERVICEOR
PERFORMMAINTENANCEONTHEPUMP.FAILURE TODOSOMAY RESULT INFATALELECTRICALSHOCK.
INSTALLATION/OPERATION
1. Placethe pumponahardsurfaceinthewater.Donotset the pumpdirectlyinmud orsand.This
maycausethe intakescreentoclog ordamagetoyourpump.
2. The waterlevelmustbeat least1”deepforthe pumptooperate.
3. Plug the powercordintoagrounded120-volt ACoutlet. Thepumpwillstart tooperateassoon
asthe cordispluggedin.
4. The pumpshouldbe turnedoffoncethewaterreachestheselevels.
5. Donotletthepumprun dry.Thepumpdependsonwaterforcooling and lubrication. Operating
the pumpwithout watermaycausethemotortooverheatorcausedamagetopartsof the pump.
Itmayalsoshortenthelifeofyourpump.
Anything that willpass throughthe intakescreen holeswillpass through the pumpwithoutcausing
damage.Theintakescreenon thepumpremoveseasilyforcleaning.Theunitscan alsobeback-
flushed using the garden hoseadapter(select modelsonly).
NOTE:Thispumphasabuiltinanti-airlock device.Leakageisnormalfromthisdevice.
TROUBLESHOOTING
WARNING ALWAYS DISCONNECTTHEPOWERSOURCEBEFOREATTEMPTINGTOINSTALL,SERVICEOR
PERFORMMAINTENANCEONTHEPUMP.FAILURE TODOSOMAY RESULT INFATALELECTRICALSHOCK.
Ifthepumpdoes notstartorrun.
1. Makesurepumpispluggedin.
2. Check forblownfusesortripped circuitbreakersortrippedGFCI outlets.
Ifthepumprunsandmoves littleornowater.
1. Check toinsuredischargepipeisnot plugged.
2. Unit maybe airlocked.Thispumphasananti-airlock devicebuilt in.Cleanout airlock.
3. Check intakescreen forobstructions,cleanif necessary.
NOTICE Heightand/orpiping restriction willreducethepumpoutputperformance.See the
performancechart belowtoinsureyouhavethe properpumpforyourapplication. Wheneverpossible
usethe sameorlargersizepipe thanthepumpdischargeforoptimumperformance.Reducing the
pipe sizewillnotharmyourpump; it will justreducetheoutput.
PERFORMANCE CHART
DischargeHeightAbovePumping Level
Model 0’ 5’ 10’ 15’ 20’ 25’
Gallons perMinute
PF91025 26 21 14 10 7 1
PF91250, PF91251,PF91255, PF91257 30 22 20 16 9 2
PF91330,PF91331,PF91335 40 34 28 22 12 2
PF91501 70 66 58 48 25 10
SPECIFICATIONS
Powersupplyrequirements120V,60Hz
MotorContinuousDuty***,CapacitorStart,
ThermallyProtected
LiquidTemperatureRange32°F-120°F(0°C-49°C)
CircuitRequirements15amp
***Forcontinuousduty,thepumpmust be submerged toprevent overheating
Model PF91025 PF91250
PF91255
PF91251
PF91257
PF91330
PF91335 PF92331 PF91501
HP 1/4 1/4 1/4 1/3 1/3 1/2
Amps 3.61 3.82 3.82 4.1 4.1 7.6
Solids
Handling 1/8” 1/8” 1/8” 1/8” 1/8” 1/2”
Warranty
(Years) 1 1 3 1 3 3
Discharge
Size 1¼” 1¼” 1¼” 1¼” 1¼” 1½”
PumpDown
Level 1/8” 1/8” 1/8” 1/2” 1/2” 1”
