PROLED L6OP Series User manual

Montageanleitung / Installation manual
MBN GmbH, Balthasar-Schaller-Str. 3, 86316 Friedberg - Germany
www.proled.com
PROLED FLEX STRIP OPAL
BERLIN / HAMBURG / LONDON /LIVERPOOL / MILAN / SIDE VIEW
L6OPxxx
Characteristics:
•SMD CHIP MONO (white, neutral white, warm white, super warm white, ultra warm white) as well as
RGB.
•Power supply 24 VDC.
•Homogenous light. No single points visible.
•Safety class IP54. Suitable for wet room.
•Operating temperature range -10° C till +45° C.
•CE compliant with applicable European directives.
Warning:
1. For indoor use only.
2. Please ensure that the packaging is disposed of in a safe environment.
3. We do recommend that a qualified electrician should be used to install the products.
4. Do not look at the lighted lamp directly.
Safety indices:
Be sure to have a qualified electrician complete installation. The customer is not entitled to claim for any
lights installed without observing European safety directives. The manufacturer is then discharged from
liability when damage is caused by improper use or installation. For indoor use only. Protection class IP40.
Preinstallation:
Please follow the sequence of installation step by step. Non-observance can lead to damage of the flex strip.
1. Switch off the electricity at the mains before commencing installation or lamp change and (if a fuse box is
installed) remove the appropriate circuit fuse to avoid accidental switching on of the mains supply.
2. Connect the flex strip to the power supply 24 VDC output (secondary side).
3. Connect connector (primary side) of power supply to mains (220-240VAC).
4. If a dimmer is used, than it must be placed between power supply and the flex strip.
Installation possibilites:
1. Please keep in mind, that following strain is not allowed:
DO NOT PRESS DO NOT TWIST DO NOT STRETCH
2. Minimum bending diameter at FLEX STRIP OPAL LONDON, LIVERPOOL & MILAN
Light output <8mm Light output >8mm
NOT ALLOWED
3. Minimum bending diameter at FLEX STRIP OPAL BERLIN, HAMBURG & SIDE VIEW
NOT ALLOWED

Montageanleitung / Installation manual
MBN GmbH, Balthasar-Schaller-Str. 3, 86316 Friedberg - Germany
www.proled.com
Installation:
1. Installation with short profiles
Short fixing profiles must be in level. It is recommended to use at least two short fixing profiles each meter.
2. Procedure during mounting and demounting
Simultaneously install from Installation from one side Min. 2 Persons needed at
both ends is not allowed a length of more than 2m.
Please use tools when removing Pulling on strip is not Min. 2 Persons needed at
strip out of profile. Do not bend allowed and results a length of more than 2m.
more than 15° in strip damages.
3. Preparing of strip
Cut straight, along the cutting marks.
Shorten the strip Expose the soldering pads with a knife Solder power cable to PCB
Put the cable through end cap. Put the end cap on the strip. Put glue on the strip.
Fill in 1/3 –1/2 end cap with glue Laid flat for 2 hours. Place end cap on the strip
Laid flat for 2 hours.
The glue is dry after 24
hours

Montageanleitung / Installation manual
MBN GmbH, Balthasar-Schaller-Str. 3, 86316 Friedberg - Germany
www.proled.com
Energy efficiency class of the light source:
Products listed in this manual contain a light source of following efficiency class, listed according to the item
codes:
Item code Efficiency class of light source
L6OP0xx G
L6OP0xx2G F
L6OP1xx G
L6OP1xx2G F
L6OP2xx G
L6OP2xx2G F
L6OP30x F
L6OP326 G
L6OP336 G
L6OP3xx2G F
L6OP4xx G
L6OP4xxDx G
L6OP4xx2G F
L6OP5xx G
ATTENTION:
Installation and commissioning may only be performed by qualified persons.
National installation regulations must be observed.
Luminaires must be disconnected from mains before any work.
The product is a “containing product”according to directive (EU) 2019/2020 and (EU) 2019/2015.
The light source is an integral part of the containing product. Separating of light source and containing
product results in irreversible damage. Exchange of the light source with commonly available tools is not
useful for this product.
The installed light source can be removed for testing purpose.
The replacement of light source is not intended, as the containing product will be destroyed.
03.22 Technical amendments reserved
