Varytec EASY MOVE DUAL WASH User manual

Table of content

2 / 12
1. Safety instructions............................................................................................................................ 3
1.1. FOR SAFE AND EFFICIENT OPERATION............................................................................ 3
2. Introduction....................................................................................................................................... 4
2.1. Packing list............................................................................................................................... 4
2.2. Unpacking instructions ............................................................................................................ 4
2.3. AC Power................................................................................................................................. 4
2.4. Additional safety instructions................................................................................................... 4
3. Features ........................................................................................................................................... 5
4. DMX Channels................................................................................................................................. 6
5. Set up............................................................................................................................................... 6
5.1. Fuse replacement.................................................................................................................... 6
5.2. Fixture linking........................................................................................................................... 6
5.2.1. Data cabling..................................................................................................................... 7
5.3. Conversion chart 3-Pin to 5-Pin............................................................................................... 7
5.4. Setting up a DMX serial data link ............................................................................................ 7
5.4.1. Master/Slave fixture linking.............................................................................................. 7
5.5. Orientation............................................................................................................................... 7
6. Operation.......................................................................................................................................... 8
6.1. Navigating the control panel.................................................................................................... 8
6.2. Menu map................................................................................................................................ 8
6.3. User configurations.................................................................................................................. 8
6.3.1. Setting PAN angles ......................................................................................................... 8
6.3.2. Setting TILT angles ......................................................................................................... 8
6.3.3. 1-in-built program mode .................................................................................................. 8
6.3.4. Setting reversed or normal PAN...................................................................................... 9
6.3.5. Setting reversed or normal TILT...................................................................................... 9
6.3.6. Setting reversed or normal LED Display......................................................................... 9
6.3.7. Auto run mode................................................................................................................. 9
6.3.8. Sound activated mode..................................................................................................... 9
6.3.9. Slave mode.................................................................................................................... 10
6.3.10. Service modes............................................................................................................... 10
6.3.11. DMX modes................................................................................................................... 10
6.3.12. Color options.................................................................................................................. 11

3 / 12
1. Safety instructions
•This device is suitable for indoor use only.
•All modifications to the device will void the warranty.
•Repairs are to carry out by skilled personnel only.
•Use only fuses of the same type and original parts as spare parts.
•Protect the unit from rain and humidity to avoid fire and electric shocks.
•Make sure to unplug the power supply before opening the housing.
1.1.FOR SAFE AND EFFICIENT OPERATION
Be careful with heat and extreme temperature
Avoid exposing it to direct rays of the sun or near a heating appliance.
Not put it in a temperature bellow 41°F /5°C, or ex ceeding 113°F /45°C.
Keep away from humidity, water and dust
Do not place the set in a location with high humidity or lots of dust.
Containers with water should not be placed on the set.
Keep away from sources of hum and noise
Such as transformer motor, tuner, TV set and amplifier.
To avoid placing on un-stable location
Select a level and stable location to avoid vibration.
Do not use chemicals or volatile liquids for cleaning
Use a clean dry cloth to wipe off the dust, or a wet soft cloth for stubborn dirt.
If out of work, contact sales agency immediately
Any troubles arose, remove the power plug soon, and contact with an engineer for repairing,
do not open the cabinet by yourself, it might result a danger of electric shock.
Take care with the power cable
Never pull the power cable to remove the plug from the receptacle, be sure to hold the plug.
When not using the device for an extended period of time, be sure to disconnect the plug
from the receptacle .
Important: Damages caused by the disregard of this user manual are not subject to
warranty. The dealer will not accept liability for any resulting defects or
problems. Make sure the electrical connection is carried out by qualified
personnel. All electrical and mechanical connections have to be carried out
according to the European safety standards.

4 / 12
2. Introduction
2.1.Packing list
Product name
Quantity
Wash light 1 pcs
Power line 1 base
User manual 1 pcs
2.2.Unpacking instructions
After receiving a fixture, carefully unpack the carton, check the contents to ensure that all
parts are present and have been received in a good condition. Notify the shipper immediately
and retain packing material for inspection if any parts appear damaged from shipping or the
carton itself shows signs of mishandling. Save the carton and all packing materials. In the
event that a fixture must be returned to the factory, it is important that the fixture is returned
in the original factory box and packing.
2.3.AC Power
To determine the power requirements for a particular fixture, see the label affixed to the back
plate of the fixture or refer to the fixtures’ specifications chart. A fixture listed current rating is
its average current draw under normal conditions. All fixtures must be directly powered by a
switched circuit and must not be run by a rheostat (variable resistor) or dimmer circuit, even if
the rheostat or dimmer source voltage matches the fixtures requirement. Check the fixture
carefully to make sure that if a voltage selection switch exists, it is set to the correct line
voltage you will use.
WARNING: Verify that the voltage select switch on your unit matches the line voltage applied.
Damage to your fixture may result if the line voltage applied does not match the voltage
indicated on the voltage selector switch. All fixtures must be connected to circuits with a
suitable earth.
2.4.Additional safety instructions
Please read these instructions carefully, they include important information about the
installation, usage and maintenance of this product.
Be sure that the local power outlet matches that of the required voltage of your unit.

5 / 12
Do not attempt to operate this unit if the power cord has been frayed or broken. Do not
attempt to remove or break off the ground prong from the electrical cord. This prong is used
to reduce the risk of electrical shock and fire in case of an internal short.
Disconnect from main power before making any type of connection.
Do not remove the cover under any conditions. There are no user serviceable parts inside.
Never operate this unit when its cover is removed.
Never plug this unit in to a dimmer pack.
Always be sure to mount this unit in an area that will allow proper ventilation.
Allow about 6 inch (15cm) between this device and a wall.
Do not attempt to operate this unit, if it becomes damaged.
During long periods of non-use, disconnect the unit's main power.
Always mount this unit in safe and stable matter.
Power-supply cords should be routed so that they are not likely to be walked on or pinched
by items placed upon or against them, paying particular attention to the point they exit from
the unit.
Cleaning -The fixture should be cleaned only as recommended by the manufacturer.
Heat -The appliance should be situated away from heat sources such as radiators, stoves or
other appliances (including amplifiers) that produce heat.
The fixture should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen or liquid has been spilling onto the appliance.
C. The appliance has been exposed to rain or water.
D. The appliance does not appear to operate normally or exhibits a marked change in
performance.
3. Features
•Multi colors
•Color strobe
•Electronic Dimming 0-100%
•Built-in microphone
•DMX-512 Control
•Master/Slave & Auto synchronization
•Multi channel mode

6 / 12
4. DMX Channels
In 16 channel mode:
Channel
Function
1 PAN
2 TILT
3 Pan fine
4 Tilt fine
5 Pan/Tilt Speed
6 Master Dimmer
7 Red side1
8 Green side 1
9 Blue side 1
10 White side 2
11 White side 2
12 Amber side 2
13 Strobe
14 Color changer side 1
15 Color changer side 2
16 Reset
5. Set up
Disconnect the power cord before replacing a fuse and always replace with the same type fuse.
Power Supply: Before plugging your unit in, be sure the source voltage in your area matches the
required voltage. The light is available in a 110V to 250V version. Because line voltage may vary from
venue to venue, you should be sure your unit voltage matches the wall outlet voltage before
attempting to operate you fixture.
5.1.Fuse replacement
With a screwdriver wedge the fuse hold out of its housing. Remove the damaged fuse from its holder
and replace with exact same type fuse. Insert the fuse holder back in its place and reconnect power.
5.2.Fixture linking
You will need a serial data link to run light show of one or more fixtures using a DMX-512 controller or
to run synchronized on two or more fixtures set to a master/slave operating mode. The combined

7 / 12
number of channels required by all the fixtures on a serial data link determines the number of fixtures
the data link can support.
Maximum recommended serial data link distance: 500 meters (1640ft).
Maximum recommended number of fixtures on a serial data link: 32 fixtures.
5.2.1. Data cabling
To link fixtures together you must use data cables. If you choose to create your own cable please use
data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
5.3.Conversion chart 3-Pin to 5-Pin
NOTE: If you use a controller with a 5 pin DMX output connector, you will need to use a 5pin to 3 pin
CHAUVET Model No: DMX 5M or DMX 5F
The chart below details a proper cable conversion:
5.4.Setting up a DMX serial data link
5.4.1. Master/Slave fixture linking
1. Connect the (male) 3 pin connector side of the DMX cable to the output (female) 3pin
connector of the first fixture.
2. Connect the end of the cable coming from the first fixture which will have a (female) 3 pin
connector to the input connector of the next fixture consisting of a (male) 3 pin connector.
Then, proceed to connect from the output as stated above to the input of the following fixture
and so on.
5.5.Orientation
This fixture may be mounted in any position as long as there is adequate room for ventilation.

8 / 12
6. Operation
6.1.Navigating the control panel
Access control panel functions by using the four panel buttons located directly under the display.
6.2.Menu map
There are six operating modes, many with sub-modes. Use the “MODE/ESC” button to enter the
menu. Use the “UP” and “DOWN” buttons to choose from values available, with the “ENTER” button
confirm any selection. After a few seconds, the LED Display will black out during operation until
another button is pressed.
6.3.User configurations
6.3.1. Setting PAN angles
To select use the “MODE/ESC” button and choose “PA 18”, “PA 36” or “PA 54”. Cycle with the “UP”
and “DOWN” buttons between all available PAN angles. Press the “ENTER” button to confirm your
selection.
LED Display
Maximum PAN
PA 18 180°
PA 36 360°
PA 54 540°
6.3.2. Setting TILT angles
To select use the “MODE/ESC” button and choose “t.9” or “t.18”. Cycle with the “UP” and “DOWN”
buttons between all available TILT angles. Press the “ENTER” button to confirm your selection.
LED Display
Maximum TILT
t.9 90°
t.18 180°
6.3.3. 1-in-built program mode
As the unit can be mounted hung under earth trussing, or can sit equally well on a flat surface PAN,
TILT and LED display settings can be reserved to provide correct coverage and ease of use.

9 / 12
6.3.4. Setting reversed or normal PAN
To select use the “MODE/ESC” button and choose “Pan” (normal) or “r Pan” (reversed). Use the“UP”
and “DOWN” buttons to cycle between the two settings. Press the “ENTER” button to confirm your
selection.
6.3.5. Setting reversed or normal TILT
To select, use the “MODE/ESC” button and choose “t.L” (normal) or “r tilt” (reversed). Use the“UP” and
“DOWN” buttons to cycle between the two settings. Press the “ENTER” button to confirm your
selection.
6.3.6. Setting reversed or normal LED Display
To select, use the “MODE/ESC” button and choose “d.s” (normal) or “rd.s”(reversed). Use the “UP”
and “DOWN” buttons to cycle between the two settings. Press the “ENTER” button to confirm the
chosen selection.
6.3.7. Auto run mode
One of two Auto run sub-modes can be selected with a choice of preset speeds .This mode enables
the unit to act as a Master to other Slave units.
Choosing Auto run sub-modes
To select use the “MODE/ESC” button to show “NAFA” or “NASL”. Use the “UP” and “DOWN” buttons
to change between the two initial options. With the appropriated option selected, use “ENTER” to
confirm and the LED Display will change to: “Fast” (fast) or “SloU” (slow). The unit will then run at the
chosen speed.
Initial LED Display
Second LED Display
Sub mode
NAFA Fast Fast Auto Run
NAFL SloU Slow Auto Run
6.3.8. Sound activated mode
The unit responds to sounds picked up by the unit built-in microphone to create a light show. Each
sound picked up makes changes to color shown and position of the effects. This mode enables the
unit to act a Master to other Slave units.

10 / 12
Choosing Sound activated mode:
To select, use the “MODE/ESC” button and choose “NStS”. When the “ENTER” button is pressed the
LED Display changes to “SrUn” and the unit enters Sound activated mode.
Initial LED Display
Second LED
Display
Sub mode
NStS SrUn Sound activated
6.3.9. Slave mode
Up to 32 units can be daisy chained together with one single unit acting as Master and all other linked
units as Slaves. Slave units will all run in synch with the master unit without the need for an additional
controller. Connections can be made using standard DMX control cables with Master unit running in
Auto Run or Sound Activated Modes placed at the start of the chain.
Choosing Slave Mode
To select use the “MODE/ESC” button and choose “AUDI”. When the “ENTER” button is pressed the
LED display changes to “Son” and the unit will be slaved to control signals coming from a Master unit
6.3.10. Service modes
After major configuration changes it may be necessary to reboot or reset the unit.
Resetting the Unit
To select, use the “MODE/ESC” button and choose “rEST” (restore). Press “ENTER” to confirm. The
unit powers itself down and then on again for a few seconds. During this time the LED display will
scroll “rEST” from left to right, after which normal operation recommences.
Restoring factory defaults.
To select, use the “MODE/ESC” button and choose “LoAD” (load). Press “ENTER” to confirm. The
LED display will change to “d001” to confirm a factory reset has been completed
Powering the unit initially
During the warm up the unit will auto test itself for a few seconds. During this time the led display will
scroll “rEST” from left to right .The unit then commences operation normally
6.3.11. DMX modes
The unit supports 16 channel DMX. When a suitable DMX connection is made, the “decimal point” in
“d.001” will flash.
Setting DMX addresses
Use the “MODE/ESC” button to display “d001”, “UP” and “DOWN” buttons allows individual DMX
addresses to be set from “d.001” to “d.512”
