PREPARATIONS
1-6
WiringDiagram
Amplifier
GroundLead
White/
Black
Stripe
WhiteGray/
Black
Stripe
Green/
Black
Stripe
GrayGreenPurple/
Black
Stripe
Purple
Black
Blue Motor/ElectricAntennarelaycontrolLead
AmplifierrelaycontrolLead
ISOConnector
Connector
Originalwiring
Modifiedwiring
Red
Yellow Yellow
Red
Red
YellowYellow
Red
R(Red)
L(White)
Line-out(Gray)
ForsomeVW/AudiorOpel(Vauxhall)
carmodels,youmayneedtomodify
wiringofthesuppliedpowercordas
illustrated,orelsethememoryofthe
unitmaybelostafteryoupoweroff.
Contactyourauthorizedcardealer
beforeinstallingthisunit.
Ignitionkey
+12VDCWhenON/ACC
Tocarbattery(+)Continuous+12VDC
Yellow
Red
Antenna Fuse15A
1.IfyourcarisequippedwiththeISOconnector,thenconnecttheISOconnectorsasillustrated.
UsingtheISOConnector
2.ForconnectionswithouttheISOconnectors,checkthewiringinthevehiclecarefully
Cuttheconnector,connectthecoloredleadsofthepowercordtothecarbattery,
beforeconnecting,
incorrectconnectionmaycauseseriousdamagetothisunit.
asshowninthecolour
codetablebelowforspeakerandpowercableconnections
ConnectorConnector
Battery12V(+)/yellow
AutoAntenna/blue
ACC+/red
Ground/black
RearRight(+)---Purple
RearRight(-)---Purple/BlackStripe
FrontRight(+)---Gray
FrontRight(-)---Gray/BlackStripe
FrontLeft(+)---White
FrontLeft((-)---White/BlackStripe
RearLeft(+)---Green
RearLeft(-)---Green/BlackStripe
