Prolon PL-RS User manual

QUICK START GUIDE
VAV CONTROLLERS & WALL SENSORS
www.proloncontrols.com |[e-mail]
17 510 rue Charles, Suite 100, Mirabel, QC, J7J 1X9
REV 5.0 / PL-QCK-WSENSOR/VC2000-EN

REV 5.0 / PL-QCK-WSENSOR/VC2000-EN 2
Table of Contents
© Copyright 2023 Prolon. All rights reserved.
No part of this document may be photocopied or reproduced by any means, or translated to another language without prior written consent of Prolon. All specications are nominal and may change as
design improvements are introduced. Prolon shall not be liable for damages resulting from misapplication or misuse of its products. All trademarks are the property of their respective owners.
Analog Sensor (PL-RS)................................................................................................................................................................................................................................................................. 3
Dimensions and Wiring ..................................................................................................................................................................................................................................................... 3
Digital Sensor (PL-T200) ............................................................................................................................................................................................................................................................. 4
Dimensions and Wiring ..................................................................................................................................................................................................................................................... 4
Digital Sensor (PL-T500) ............................................................................................................................................................................................................................................................. 5
Dimensions and Wiring ..................................................................................................................................................................................................................................................... 5
Digital Sensor (PL-T1000)........................................................................................................................................................................................................................................................... 6
Installation.............................................................................................................................................................................................................................................................................. 6
Auxiliary Analog Input ....................................................................................................................................................................................................................................................... 7
Operation................................................................................................................................................................................................................................................................................ 8
Changing the Setpoint ...................................................................................................................................................................................................................................................... 8
Schedule Override............................................................................................................................................................................................................................................................... 8
VAV Zone Controller (PL-C1050-VAV).................................................................................................................................................................................................................................... 9
VAV Zone Controller (PL-VC2000).........................................................................................................................................................................................................................................10
Compliance...................................................................................................................................................................................................................................................................................11
Technical Specications...........................................................................................................................................................................................................................................................11

REV 5.0 / PL-QCK-WSENSOR/VC2000-EN 3
Analog Sensor (PL-RS)
COM
THERM
COM
POT
4.96”
(126 mm)
1.30”
(33 mm)
3.23”
(82 mm)
Schedule override
Room temperature
Setpoint (10K)
COM
THERM
COM
POT
4.96”
(126 mm)
1.30”
(33 mm)
3.23”
(82 mm)
Schedule override
Room temperature
Setpoint (10K)
Dimensions and Wiring
Temperature table (thermistor: 10K Type 3)
Fahrenheit 41 50 59 68 77 86 95 104
Celsius 5 10 15 20 25 30 35 40
Ohms 25395 19903 15714 12493 10000 8056 6530 5324

REV 5.0 / PL-QCK-WSENSOR/VC2000-EN 4
Digital Sensor (PL-T200)
Dimensions and Wiring
INT +
INT -
24VAC
COM
4.96”
(126 mm)
1.30”
(33 mm)
3.23”
(82 mm)
Schedule override
(hold for 3 second)
Communication (RS485)
Power (2 VA max)
RJ45 connection
INT +
INT -
24VAC
COM
4.96”
(126 mm)
1.30”
(33 mm)
3.23”
(82 mm)
Schedule override
(hold for 3 second)
Communication (RS485)
Power (2 VA max)
RJ45 connection

REV 5.0 / PL-QCK-WSENSOR/VC2000-EN 5
Digital Sensor (PL-T500)
Dimensions and Wiring
INT +
INT -
24VAC
COM
4.96”
(126 mm)
1.30”
(33 mm)
3.23”
(82 mm)
Communication (RS485)
Power (2 VA max)
RJ45 connection
Schedule override:
Hold 3 seconds
Change unit °F/°C:
Double-click INT +
INT -
24VAC
COM
4.96”
(126 mm)
1.30”
(33 mm)
3.23”
(82 mm)
Communication (RS485)
Power (2 VA max)
RJ45 connection
Schedule override:
Hold 3 seconds
Change unit °F/°C:
Double-click

REV 5.0 / PL-QCK-WSENSOR/VC2000-EN 6
Digital Sensor (PL-T1000)
Installation
1. Open casing to remove back cover by pushing on the tab located
underneath the thermostat. (See Figure 1)
2. Pull wire(s) throught central hole of back cover.
3. Screw in the back cover to the wall.
4. Connect wires:
• If using twisted pair wires:
- Pull out screw terminal block.
- Remove 1 cm insulation from each wire.
- Connect the wires to the terminal blocks and reconnect the
terminal blocks. (See Figure 2)
• If using CAT5 cable:
- Plug the cable into the RJ45 jack of the T1000 (if CAT5 cable is
opened at the controller, refer to Figure 3 for pinout of the
T1000’s RJ45 jack).
5. Reconnect top cover.
IMPORTANT! Do not install the thermostat under the following
conditions:
• Any location exposed to direct sunlight.
• On an outside wall.
• Near an air dischatge grill.
• In a location where vertical sir circulation is retricted.
• Near a dimmer switch.
Figure 1
Figure 2
Figure 3
INT +
INT -
24 VAC
COM
24V
RJ45 (Female)

REV 5.0 / PL-QCK-WSENSOR/VC2000-EN 7
Digital Sensor (PL-T1000)
Auxiliary Analog Input
The T1000 has auxiliary analog input which can be used to connect
another thermistor. The T1000 can be congured to use this alternate
temperature reading for a variety of functions, including temperature
averaging or radiant oor slab temperature. The alternate thermistor
(10KΩ type 3) can be connected to the auxiliary input using the “AUX
IN“ and “COM“ pins.
Case #1 Remote sensor only
•Physical connection: connect remote sensor (10KΩ type 3) into ter-
minals 9 and 10 (see gure A)
• T1000 conguration: set T1000 analog input to “Aux Only”
Case #2 Averaging 2 sensors (1x remote, 1x internal)
•Physical connection: connect remote sensor (10KΩ type 3) into ter-
minals 9 and 10 (see gure A)
• T1000 conguration: set T1000 analog input to “Average”
Case #3 Averaging 4 sensors (4x remote)
•Physical connection: connect 4 sensors (10KΩ type 3) in Series-
Parallel conguration (see gure B) or in Parallel-Series congura-
tion (see gure C) to terminals 9 and 10
• T1000 conguration: set T1000 analog input to “Aux Only”
(B) Averaging multiple remote sensors
(Series-Parallel)
(A) Remote Temp Sensor
(C) Averaging multiple remote sensors
(Parallel-Series)

REV 5.0 / PL-QCK-WSENSOR/VC2000-EN 8
Digital Sensor (PL-T1000)
Changing the Setpoint
Schedule Override
The First, go to the Setpoint screen.
Scroll or tap
(any direction)
Heat SP
Cool SP
Adjust your setpoint
by scrolling clockwise
or counterckwise
View current zone
temperature
Home Screen Setpoint Screen
Tap anywhere
(or simply wait)
return to
Home Screen
The sun icon is
displayed when
overridden
OVERRIDE ACTIVE
(Occupied mode)
The moon icon
indicates
unoccupied mode
Scroll clockwise
to override
67.5
79.5
67.5
79.5
Operation
The T1000 is controlled using the circular touch pad on the bottom
half of the thermostat. The touch pad uses capacitive sensing technology
to detect nger proximity. There are no moving parts to push or rotate.
The T1000 is controlled using simple scrolling, tapping or holding
motions, performed around the circle of the touch pad. The center of
the circle is unused.
Scroll clockwise or
counterclockwise
to adjust or navigate
Tap here to
ENTER
Tap here to
go BACK

REV 5.0 / PL-QCK-WSENSOR/VC2000-EN 9
VAV Zone Controller (PL-C1050-VAV)
cULus Listed; UL 916 Energy Management Equipment, File E364757, Vol.1-4 to 122 °F (-20 to 50 °C) Non-condensing
DO1
DO2
DO3
DO4
AO
DO124V DO2 DO3 DO4 AO HBEAT STAT
NETREC NETSND INTREC INTSND
UI1
UI2
COM
UI3
DI
-
24VAC
COM
INT
+
B
NET
A
RS485
NET
RS485
INT
INT Port: Incoming Modbus RS485 communication from digital
sensor -OR- Remote computer with Prolon Focus software
Power supply to digital sensor (24 VAC)
Digital Input for night setback / Standby mode
Multi-function analog input
Common for all the inputs
Temperature setpoint (0-10K potentiometer)
Room temperature sensor (10K thermistor)
Output 5 (analog 0-10VDC) (Max Current: 40 mA)
Output 4 - Isolated or source, TRIAC 24 VAC
(max current: 300 mA)
Output 3 - Isolated or source, TRIAC 24 VAC
(max current: 300 mA)
Output 2 - Isolated or source, TRIAC 24 VAC
(max current: 300 mA)
Output 1 - Isolated or source, TRIAC 24 VAC
(max current: 300 mA)
Power source of the controller (24 VAC - Class 2)
NET Port: Incoming Modbus RS485 communication
- OR - BACnet MS/TP

REV 5.0 / PL-QCK-WSENSOR/VC2000-EN 10
VAV Zone Controller (PL-VC2000)
32-122 °F (0-50 °C) Non-condensing cULus Listed; UL 916 Energy Management Equipment, File E364757, Vol.1
RS485
NET
RS485
INT
General purpose analog input
(0-5 VDC, 4-20mA, 10K thermistor)
Supply / Radiant / Zone / Occupancy / Discharge
Power source of the controller
(24 VAC - Class 2)
Service pin
Airflow Sensor (PL-VC2000-PI)
Airflow sensors are only included in the PL-VC2000-PI
models only. Adding an airflow sensor to the Prolon VC2000
lets it regulate the airflow as well as temperature in a zone,
independently of the static pressure variations of the system.
The default flow sensor has a range of 0 to 2 in H20
(0 to 500 Pa). Depending on the flow cross used, this
translates to roughly 0-3500 ft/min.
Digital Sensor (T1000, T500 or T200) /
Remote computer with Focus
Analog Output: Demand, Duct Heater, Fan Powered Box
Series or Parallel, Radiant Floor, Slave Damper, Occupancy,
Baseboard, Zone Valve
Network communication
Digital Output: Demand, Duct Heater, Fan Powered Box
Series or Parallel, Radiant Floor, Occupancy, Baseboard,
Zone Valve

REV 5.0 / PL-QCK-WSENSOR/VC2000-EN 11
Compliance Technical Specications
Digital Sensor (PL-T1000)
• FCC Compliant to CFR47, Part 15, Subpart B, Class B
• Industry Canada (IC) Compliant to ICES-003, Issue 5: CAN ICES-3 (B) /
NMB-3(B)
• RoHS Directive (2002/95/EC)
VAV Zone Controller (PL-C1050-VAV / PL-VC2000)
• cULus Listed; UL 916 Energy Management Equipment, File E364757,
Vol.1
• CAN/CSA-C22.2 No. 2015-12, Signal Equipment
• FCC Compliant to CFR47, Part 15, Subpart B, Class B
• Industry Canada (IC) Compliant to ICES-003, Issue 5: CAN ICES-3 (B) /
NMB-3(B)
• RoHS Directive (2002/95/EC)
FCC User Information
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Industry Canada
This Class (B) digital apparatus meets all the requirements of the Cana-
dian Interference-Causing Equipment regulations.
Cet appareil numérique de la Classe (B) respecte toutes les exigences
du Réglement sur le matériel brouilleur du Canada.
PL-RS / PL-T200
Supply: 24 VAC ±10%, 50/60 Hz
Consumption: 2 VA max
PL-T500 / PL-T1000
Supply: 24 VAC ±10%, 50/60 Hz
Consumption: 5 VA max
PL-C1050-VAV
Supply: 24 VAC ±10%, 50/60 Hz
Consumption: 2 VA (Typ), 32 VA (Input)
PL-VC2000
Supply: 24 VAC ±10%, 50/60 Hz, Class 2
Consumption: 3 VA (Typ), 5 VA (Max), 24 VA (Input)
