Prooff Johannes Verhuls Ninebyfour User manual

PROOFF.COM
INSTALLATION MANUAL
NINEBYFOUR

Thanks for choosing Ninebyfour.
Since we’ve pre-assembled the lamps,
installing them is done in a few simple steps.
Please have an electrician
do the electrical installation part.
Design by HeijltjesAkkaya
NINEBYFOUR
32
PROOFF.COM

Notice: If you encounter anything unusual during the installation,
or if the item differs from the description in this manual, we
recommend to stop the installation process and contact us directly.
2014/35/EU - Low voltage directive
2014/30/EU - Electromagnetic compatibility
2011/65/EU - RoHS
Product: LED Tubelight luminary
Model / Type: Ninebyfour / Johannes Verhulst st
Power: 220 V
Production year: 2017
Object and Momentum B.V.
Keerpunt 10, 1013 DK
Amsterdam, the Netherlands
[phone]
[email protected]om
www.prooff.com
tel
email
web
A++
A+
A
B
C
D
E
kWh/1000h
Y IJA
IE IA
A++
waarmakers T8-900-12W
12
OAM
L N
THIS SIDE
TO POWER
DO NOT
CONNECT
A.
A.
B.
B.
SAFETY INSTRUCTIONS
As you unpack and prepare for assembly,
place the contents on a carpeted or
padded area to protect them from
damage.
Note: 2 people are required to safely
install this product.
IMPORTANT:
Installation of this wall mounted lamp
should be performed by a licensed
electrician. Plugs and screws for
mounting the lamp are not included.
CAUTION! Always connect the side with
printed info to power. Look for the sticker
with L + N sign.
DO NOT insert the other end of the LED
tube in the fitting connected to power.
IP20 [this lamp is not moisture or water
resistant].
Clean using a dry or damp cloth. Do not
soak or immerse in water.
To maintain the wood in best condition,
oil once every 5 years, or whenever the
wood looks particularly dry
WARNING: TO AVOID THE RISK OF
SUFFOCATION, KEEP THE CORK OUT
OF REACH OF SMALL CHILDREN AND
ANIMALS.
NINEBYFOUR
54
PROOFF.COM

overall dimensions
950x90x40mm
black cloth wire 2m
cord length 4m
Dimensions
Items included
Eye-bolts 2x (screw in hooks) M4
Lamp stopper 1x conical cork
32.5x28.5x27mm
Cable + plug 1x cloth wire + 1x plug
Stopper Cork
Light source T8 LED tube
29
6
3 3
8 8
4737
43
47,5
95
950
650
29
6
3 3
8 8
4737
43
47,5
95
950
650
95
65
230
4 9
Height adjusting system Wooden Spindle
82x10x12mm
Cord 2mm waxed cotton
Pendant cord kit
NINEBYFOUR
76
PROOFF.COM

30
6
3 3
8 8
4737
43
45
90
950
650
650
1. 2.
C.
B.
A.
D. 3.
1. Screw in both eye-bolts in the
ceiling. Use appropriate mounting
method for your ceiling.
(plugs not included)
2. Guide the cotton cord through
the hooks.
3. Guide the cotton cord through
the holes in the wooden fixture.
4. Tie a knot to secure. Pull to
check if the knot stops the cord for
sliding though the hole.
BEFORE STARTING,
TURN OFF MAIN POWER.
Drill two holes 650 mm apart.
[make sure to use the appropriate
plugs - not included]
Installation
650 MM
Mounting on ceiling
NINEBYFOUR
98
PROOFF.COM

1. 2. 3.
PLEASE NOTE! Always check if the cord is securely clamped
inside bottom and top slit in the wooden pen (figure 3).
650
A.
C.
B.
D.
E.
WARNING: TO AVOID THE
RISK OF SUFFOCATION,
KEEP CORK (B) OUT OF
REACH OF SMALL CHILDREN
AND ANIMALS.
1. Drill holes at a distance of 650mm
and insert plugs into holes in wall
(not included).
2. Remove cork-stop from lamp, then
carefully remove the led tube.
3. Place the bolts through the wooden
light-fixture and optional place the
spacers (not included) over the ends
of the bolts.
4. CAUTION! Install led-tube with
printed information and L + N signs
to powered fitting and close with
cork-stop.
Adjusting the height
1. Clamp the wooden pen at the
bottom end on the cotton cord.
2. Wrap the cord around the pen
until reaching the desired height.
3. Fix the cord by clamping
the cord in the top end op the
wooden pen.
5. Levelling:
This is, and obviously so, a
natural material. It might occur
that the lamp is not perfectly
horizontal the first try. To adjust,
turn the knot in step 3. (bottom
right of this page) a half or a
quarter turn. This might take a
little tinkering.
Mounting on wall
NINEBYFOUR
1110
PROOFF.COM

B.
B.
b1.
b2.
b2.
C.
L N
C.
c1.
click!
Replacing the LED tube
1. Shut off the electrical power.
2. Pull out cork b1. from the fixture end B.
3. Take out the LED tube by carefully pulling at
powered end while stopping the fitting from coming
out of the hole (side C).
4. Pull the fitting (b2) off the LED tube and reattach
the fitting to the new to be installed LED Tube.
5. CAUTION! LOOK FOR L+N STICKER. CONNECT
ONLY THIS SIDE TO POWER (FIGURE C)
6. Re-insert the LED Tube through hole (side B) and
fix it in the fixture untill it clicks into the powered
fitting c1.
7. Re-insert cork b1 untill its fixed.
NINEBYFOUR
1312
PROOFF.COM
