PROPOINT 8730574 User manual

V1.0 8730574
Please read and understand all instructions before use. Retain this
manual for future reference.
USER MANUAL
INFRARED
THERMOMETER

8730574 INFRARED THERMOMETER V1.0
2 For technical questions call 1-800-665-8685
SPECIFICATIONS
Laser
Classification
Class IIIA
Max Power Output <5mW
Wavelength
635 to 660 nanometers (nm)
Unit of Measurement Celsius or Fahrenheit
Temperature Range
-83.2 to 932°F
(-64 to 500°C)
Accuracy
To b j & Ta m b
Tobj 15 to 35°C &
Tamb 25°C 1.8°F (±1.0°C)
Tobj 59 to 95°F &
Tamb 77°F
Accuracy
Ta m b 7 3 ±5.4°F
Tamb 23 ±3°C
Tobj -83.2 to 32°F
Tobj -60 to 0°C
3.6 ± 0.09°F per degree
2.0 ± 0.05°C per degree
Tobj 32 to 932°F
Tobj 0 to 500°C
± 2% of reading or 4°F
(2°C), whichever is greater
Resolution Range -83.2 to 999.9
degrees (°F/°C)
0.1°F / 0.1°C, otherwise
1°F / 1°C
Emissivity
0.95 Default, adjustable 0.1
to 1 in 0.1 steps.
Distance to Measurement Spot Ratio 12:1
Response Time
1 second (90%)
Power Battery Type AAA Battery x 2
Battery Life
10 to 14 Hours Continuous
INFRARED
THERMOMETER

V1.0 INFRARED THERMOMETER 8730574
Visit www.princessauto.com for more information 3
THERMOCOUPLE PROBE
Measurement Range
-83.2 to 2,552°F (-64 to 1,400°C)
Accuracy ±1% of reading or 1°C (1.8°F) whichever is
greater (Test under Tamb=23±6°C)
INTRODUCTION
The Infrared Thermometer can measure temperatures from a
distance, making it ideal for hard-to-reach or dangerous places.
A multi-laser system defines the measurement area to improve
the reading accuracy.
The Infrared Thermometer has a port for a K-type Thermocouple
Probe (not included).
SAFETY
WARNING! Read and understand all instructions before using
this tool. The operator must follow basic precautions to reduce
the risk of personal injury and/or damage to the equipment.
Keep this manual for safety warnings, precautions, operating or
inspection and maintenance instructions.
HAZARD DEFINITIONS
Please familiarize yourself with the hazard notices found in this
manual. A notice is an alert that there is a possibility of property
damage, injury or death if certain instructions are not followed.
DANGER! This notice indicates an immediate and specific
hazard that will result in severe personal injury or death if the
proper precautions are not taken.
WARNING! This notice indicates a specific hazard or unsafe
practice that could result in severe personal injury or death if
the proper precautions are not taken.
CAUTION! This notice indicates a potentially hazardous
situation that may result in minor or moderate injury if proper
practices are not taken.

8730574 INFRARED THERMOMETER V1.0
4 For technical questions call 1-800-665-8685
NOTICE! This notice indicates that a specific hazard or unsafe
practice will result in equipment or property damage, but not
personal injury.
WORK AREA
1. Operate in a safe work environment. Keep your work area
clean, well-lit and free of distractions. Place lights so you
are not working in a shadow.
2. Keep anyone not wearing the appropriate safety equipment
away from the work area.
3. Store tools properly in a safe and dry location. Keep tools
out of the reach of children.
PERSONAL SAFETY
WARNING! Wear personal protective equipment approved by
the Canadian Standards Association (CSA) or American
National Standards Institute (ANSI).
PERSONAL PROTECTIVE EQUIPMENT
1. Always wear impact safety goggles that provide front and
side protection for the eyes. Eye protection equipment
should comply with CSA Z94.3-07 or ANSI Z87.1 standards
based on the type of work performed.
2. Wear protective clothing designed for the work
environment and tool.
PERSONAL PRECAUTIONS
Control the tool, personal movement and the work
environment to avoid personal injury or damage to the tool.
1. Do not operate any tool when tired or under the influence
of drugs, alcohol or medications.
2. Do not overreach when operating the tool. Proper footing
and balance enables better control in unexpected situations.

V1.0 INFRARED THERMOMETER 8730574
Visit www.princessauto.com for more information 5
SPECIFIC SAFETY PRECAUTIONS
WARNING! DO NOT let comfort or familiarity with product
(gained from repeated use) replace strict adherence to the
tool safety rules. If you use this tool unsafely or incorrectly,
you can suffer serious personal injury.
1. Use the correct tool for the job. This tool was designed for
a specific function. Do not modify or alter this tool or use it
for an unintended purpose.
2. Do not use the tool if any parts are damage broken or
misplaced. Repair or replace the parts.
3. Do not carry the tool with fingers near or on the trigger/switch.
4. The lnfrared Thermometer should be protected from
the following:
4.1 EMF (electro-magnetic fields) from arc welders, induction
heaters, etc. The electromagnetic field strength radio
frequency of approx. 3 volts per meter will temporarily
affect the readings. The maximum error is 14.4°F (8°C) if
the 3V/m range is from 350 to 550 MHz.
4.2 Thermal shock caused by large or abrupt ambient
temperature changes. Allow 30 minutes for the unit to
stabilize before using.
4.3 Do not leave the unit on or near objects of high
temperature.
5. Do not expose the tool to rain or wet conditions.
6. Do not measure live circuits with voltages that exceed 24V
DC RMS or 60V DC with the thermocouple probe.
LASER EMITTER
WARNING! Laser light is emitted from this tool. Follow all
instructions and procedures in this manual when using or
adjusting the laser. Failure to follow instructions may result in
exposure to hazardous radiation.

8730574 INFRARED THERMOMETER V1.0
6 For technical questions call 1-800-665-8685
WARNING! Do not stare into the laser light. The laser light
may damage the eye and cause vision injuries including
partial or complete blindness.
1. This tool contains a Class IIIA laser product that emits
laser light.
1.1 A Class IIIA laser product can produce spot blindness
and other injuries to the unaided eye.
2. Never point the laser at yourself, another person or an
animal. Avoid shining the laser light into the eyes as it may
cause an injury.
3. Do not stare into the laser light or aperture, even with
protective eyewear. Eye damage may result from exposure
to the laser light.
4. Be aware of laser light reflected from work surfaces. Cover
or remove objects with a reflective surface when possible.
Also remove any jewelry or watches from the lower arms
and hands to avoid unintended reflections.
4.1 Reflected laser light from a mirror-like surface can
cause the same level of damage as looking into a laser.
4.2 Diffuse reflection is not as powerful, but can cause
cumulative damage with prolonged or multiple
exposures.
5. Do not try to service or disassemble the laser device.
Doing so may expose the user to a radiation hazard. Have
a qualified technician service the device.
6. Use the laser only when performing the intended task. Turn
the laser off once the task is complete.
7. Always wear safety eyewear designed to block the laser
wavelength and reduce the laser light exposure to a safe
level when operating or adjusting the laser.
8. Set the room’s light levels as bright as possible to keep the
eye’s pupil small. The pupil will grow larger in dim light and it is

V1.0 INFRARED THERMOMETER 8730574
Visit www.princessauto.com for more information 7
easier for direct or reflected laser light to damage the retina.
UNPACKING
WARNING! Do not operate the tool if any part is missing.
Replace the missing part before operating. Failure to do so
could result in a malfunction and personal injury.
Remove the parts and accessories from the packaging and inspect
for damage. Make sure that all items in the contents are included.
Contents:
• Infrared Thermometer
IDENTIFICATION KEY
A Liquid Crystal Display (LCD)
B °C/°F Button
C Mode Button
D Lock Button
E Thermocouple Port
F Measurement Trigger
G Battery Cover
H Infrared Lens
I Multi-Beam Laser
J Laser Indicator
K Backlight Indicator
L Scan Indicator
M Hi/Lo Indicator
N Temperature Bar
O Temperature Reading
P Function Mode Indicator
Q Battery Indicator
R Function Mode Reading

8730574 INFRARED THERMOMETER V1.0
8 For technical questions call 1-800-665-8685
OPERATION
WARNING! The laser is active while the trigger is depressed.
Please consult Laser Emitter precautions under Safety.
Letter references in parenthesis (A) refer to the included
Identification Key.
The infrared thermometer will automatically shut off if left idle
for more than 60 sec.
1. Choose Celsius or Fahrenheit by pushing the °C/°F Button
(B). The temperature reading (O) will show which
temperature scale is in use. This function is only available in
modes E, MAX, MIN, DIF and AVG.
2. The infrared thermometer has a distance to measurement
spot ratio of 12 to 1. The measurement area is 1 inch in
diameter for every 12 inches away. Ensure you are an
adequate distance away to measure the area.
3. Turn the multi-beam laser (I) ON or OFF by depressing the
measurement trigger (F), then pressing the °C/°F button (B).
The laser indicator icon (J) will appear when the laser is ON.
4. Select a function (See Function Mode Selection). The selected
mode will appear in the Function Mode Indicator (Q).
5. Aim the infrared thermometer and press the trigger. The
multi-beam laser will activate and a circular pattern will
appear on the target. This defines the area being measured.
5.1 An area measurement at a distance of less than 36 in.
will be slightly wider than the multi-beam laser
indicates. This is due to the different in aperture size of
the laser and infrared lens (I). The measurement will be
in sync farther than 36 in.
6. Hold the trigger and the current reading (O) will appear in the
display. This reading can change during the measurement.
The scan icon (L) will also appear while the trigger is held.

V1.0 INFRARED THERMOMETER 8730574
Visit www.princessauto.com for more information 9
6.1 Lock the infrared thermometer into ON mode by
pressing the Lock Button (D). This is useful to take a
continuous reading up to 60 minutes. Unlock the
infrared thermometer by pressing the lock button
again. This function is only available in modes E, MAX,
MIN, DIF and AVG.
7. The function mode reading (R) will appear on the LCD next
to the function mode indicator (Q). The data displayed will
vary depending on the mode selected.
8. The temperature bar (N) has three colour sections. Two
colours appear when the trigger is held in either MIN or
MAX mode.
8.1 The yellow section is visible in both MIN and MAX
mode to indicate the temperature is above the MIN
reading or below the MAX reading.
8.2 Select MIN and the blue section appears on the left
when the reading is close to the minimum
measurement.
8.3 Select MAX and the red section appears on the left
when the reading is close to the maximum
measurement.
9. The thermometer automatically shuts off if left idle for
more than 60 seconds. This is extended to 12 minutes when
in PRB mode.
USING THE THERMOCOUPLE PROBE
WARNING! The probe’s tines may be hot and could inflict a
burn injury after a measurement reading. Allow the probe
tines to cool after removal.
The infrared thermometer accepts a K-type thermocouple
probe (not included) for a greater measurement range.
1. Insert the probe terminal end into the infrared thermometer
port (E).
2. Select Function Mode PRB (see Function Mode Selection).

8730574 INFRARED THERMOMETER V1.0
10 For technical questions call 1-800-665-8685
3. Insert the probes tines into the
object. You may lay the probe
tines on the object instead.
4. The temperature readings will
display automatically without
pressing any buttons.
5. Remove the probe from the object when finished with the
measurement.
FUNCTION MODE SELECTION
Several different readings are available before taking a
measurement. Select the function to view the following data.
Displays the emissivity data. The default emissivity
is 0.95.
Press the Mode Button (C), then press the Lock
Button (D) or °C/°F Button (B) to set the
emissivity. Press the Mode Button again to confirm
the setting. The emissivity can be changed from
0.10 (10E) to 1 (100E).
Press the Mode Button (C) repeatedly to select one
of the following modes: Maximum (MAX), Minimum
(MIN), Difference between MAX and MIN (DIF) or
Average (AVG). The measurement reading will
display beside the mode icon during the reading.
Press Lock Button (D) or °C/°F Button (B) to change
the High Alarm (HAL) or Lo Alarm (LAL), then press
Measurement Trigger (F) to confirm it. The High or
Low icon (M) will flash and you will hear a beep
when the reading is outside the High Alarm (HAL) or
Lo Alarm (LAL) limit set.
Connect the thermocouple to the thermocouple port
(E). To see the minimum or maximum data during
the probe measurement, hold down the Lock Button
(D) or °C/°F Button (B).

E

E
MAX
MIN
DIF
AVG
HAL
LAL
PRB

V1.0 INFRARED THERMOMETER 8730574
Visit www.princessauto.com for more information 11
LCD ERROR MESSAGES
The thermometer incorporates visual diagnostic messages
as follows:
1. ‘Er2’ is displayed when the thermometer is
exposed to rapid changes in the ambient
temperature.
2. ‘Er3’ is displayed when the ambient
temperature is lower than 32°F (0°C) or
exceeds 122°F (50°C). The thermometer
should be allowed plenty of time (minimum
30 minutes) to stabilize to the
working/room temperature.
3. Error 5~9, for all other error messages it is
necessary to reset the thermometer. To reset it,
turn the instrument off, remove the battery and
wait for a minimum of one minute, reinsert the
battery and turn on. If the error message
remains please contact Princess Auto Ltd. for
further assistance.
4. ‘Hi’ or ’Low’ is displayed when the
temperature being measured is outside of the
measurement range.
BATTERY MESSAGES
The thermometer displays a visual low battery indication
as follows:
Battery OK: measurements are possible.
Battery Low: battery needs to be replaced,
measurements are still possible. Replace batteries
immediately.
Battery Exhausted: measurements are not possible.
Replace batteries.
IMPORTANT! Turn the instrument off before replacing the
battery otherwise the thermometer may malfunction. Dispose
of used battery promptly.

8730574 INFRARED THERMOMETER V1.0
12 For technical questions call 1-800-665-8685
CARE & MAINTENANCE
1. Maintain the tool with care. A tool in good condition is
efficient, easier to control and will have fewer problems.
2. Inspect the tool components periodically. Repair or replace
damaged or worn components. Only use identical
replacement parts when servicing.
3. Keep the tool handles clean, dry and free from oil/grease at
all times.
4. Maintain the tool’s labels and name plates. These carry
important information. If unreadable or missing, contact
Princess Auto Ltd. for replacements.
WARNING! Only qualified service personnel should repair the
tool. An improperly repaired tool may present a hazard to the
user and/or others.
CLEANING
The sensor lens is the most delicate part of the thermometer.
The lens should be kept clean at all times. Clean the lens using
only a soft cloth or cotton swab with water or medical alcohol.
Allow the lens to fully dry before using the thermometer. Do
not submerge any part of the thermometer.
STORAGE
Store the thermometer at room temperature between -4 to
149°F (–20 to 65°C).
DISPOSAL
Recycle a tool damaged beyond repair at the appropriate facility.
Contact your local municipality for a list of disposal facilities or
by-laws for electronic devices, batteries, oil or other toxic liquids.

V1.0 INFRARED THERMOMETER 8730574
Visit www.princessauto.com for more information 13
TROUBLESHOOTING
Visit a Princess Auto Ltd. location for a solution if the tool does
not function properly or parts are missing. If unable to do so,
have a qualified technician service the tool.
THERMAL EMISSIVITY
All objects will emit infrared energy (heat) based on its
temperature. This is called Thermal Emissivity. The chart below
shows the approximate temperature for different substances.
The temperature may be higher or lower depending on external
influences such as sunshine, etc.
SUBSTANCE THERMAL
EMISSIVITY
Aluminum 0.3
Asphalt
0.94
Brass 0.5
Brick (red)
0.95
Carbon 0.85
Cement
0.96
Ceramic 0.93
Charcoal (Powder)
0.96
Chromium Oxides 0.81
Concrete
0.94
Copper 0.95
Copper Oxides
0.78
Earth 0.94
Glass
0.93
Human Skin 0.98
Ice
0.97
Iron 0.7
Iron Oxides
0.8
Lacquer 0.88
Lacquer (Matte)
0.97
Lead 0.5
Limestone
0.98
Marble 0.94
Mortar
0.9
Oil 0.94
Paper
0.82
Plaster 0.85
Plastic
0.9
Rubber (Black) 0.94
Sand
0.9
Snow 0.83
Steel
0.8
Tex t i l e s 0.9
Timber
0.9

8730574 INFRARED THERMOMETER V1.0
14 For technical questions call 1-800-665-8685

V 1,0 8730574
Vous devez lire et comprendre toutes les instructions avant d'utiliser
l'appareil. Conservez ce manuel afin de pouvoir le consulter plus tard.
MANUEL D'UTILISATEUR
THERMOMÈTRE
INFRAROUGE

8730574 THERMOMÈTRE INFRAROUGE V 1,0
2 En cas de questions techniques, appelez le 1-800-665-8685
SPÉCIFICATIONS
Laser Classification Catégorie IIIA
Puissance de
sortie max.
< 5 mW
Longueur d’onde 635 à 660 nanometers (nm)
Unité de mesure
Celsius ou Fahrenheit
Plage de température -64 à 500 °C
(-83,2 à 932 °F)
Précision
To b j e t Ta m b
Tobj 1 5 à 35 °C et
Tamb 25 °C 1,8 °F (±1,0 °C)
Tobj 5 9 à 95 °F et
Tamb 77 °F
Précision
Tamb 73 ±5,4 °F
Tam b 23 ±3 °C
Tobj -83,2 à 32 °F
Tobj -64 à 0 °C
2.0 ± 0.05°C per degree
3.6 ± 0.09°F per degree
Tobj 32 à 932 °F
Tobj 0 à 500 °C
± 2 % de lecture ou 4 °F
(2 °C), selon le plus élevé
des deux
Résolution
Plage de -83,2 à 999,9
degrés (°F/°C)
0,1 °F / 0,1 °C, otherwise
1 °F / 1 °C
Émissivité 0,95 par défaut – réglable
de 0,1 à 1 en 0,1 étape
Ratio de la distance de mesure au point
12 : 1
Temps de réponse 1 seconde (90 %)
Pile
Type de pile
Piles AAA x 2
Durée de vie de la pile 10 à 14 heures continues
THERMOMÈTRE
INFRAROUGE

V 1,0 THERMOMÈTRE INFRAROUGE 8730574
Visitez www.princessauto.com pour plus d'informations 3
SONDE THERMOCOUPLE
Plage de lectures
-64 à 1 400 °C (-83,2 à 2 552 °F)
Exactitude ± 1 % de lecture ou 1 °C (1,8 °F), selon le plus
élevé des deux (essai sous temp. amb. =
23±6 °C)
INTRODUCTION
Le thermomètre infrarouge permet de mesurer la température
à distance, ce qui le rend idéal pour les endroits dangereux ou
difficiles d’accès. Un système à lasers multiples définit la zone
de mesure afin d’améliorer la précision de lecture.
Le thermomètre infrarouge comporte un port de connexion
pour sonde thermocouple de type K (non comprise).
SÉCURITÉ
AVERTISSEMENT ! Veuillez lire et comprendre toutes les
instructions avant d'utiliser cet outil. L'utilisateur doit respecter
les précautions de base lorsqu'il utilise cet outil afin de réduire
le risque de blessure ou de dommage à l'équipement.
Conservez ce manuel qui contient les avertissements de
sécurité, les précautions, les instructions de fonctionnement ou
d'inspection et d'entretien.
DÉFINITIONS DE DANGER
Veuillez-vous familiariser avec les avis de danger qui sont
présentés dans ce manuel. Un avis est une alerte indiquant qu'il
existe un risque de dommage à la propriété, de blessure ou de
décès si on ne respecte pas certaines instructions.
DANGER ! Cet avis indique un risque immédiat et particulier
qui entraînera des blessures corporelles graves ou même la
mort si on omet de prendre les précautions nécessaires.
AVERTISSEMENT ! Cet avis indique un risque particulier ou
une pratique non sécuritaire qui pourrait entraîner des
blessures corporelles graves ou même la mort si on omet de
prendre les précautions nécessaires.

8730574 THERMOMÈTRE INFRAROUGE V 1,0
4 En cas de questions techniques, appelez le 1-800-665-8685
ATTENTION ! Cet avis indique une situation possiblement
dangereuse qui peut entraîner des blessures mineures ou
modérées si on ne procède pas de la façon recommandée.
AVIS ! Cet avis indique un risque particulier ou une pratique
non sécuritaire qui entraînera des dommages au niveau de
l'équipement ou des biens, mais non des blessures corporelles.
AIRE DE TRAVAIL
1. Travaillez dans un environnement de travail sécuritaire.
Gardez votre aire de travail propre, bien éclairée et
exempte de toute distraction. Placez les lampes de façon à
ne pas travailler dans l’ombre.
2. Assurez-vous que les personnes qui ne portent pas
l'équipement de sécurité approprié ne se trouvent pas à
proximité de l'aire de travail.
3. Rangez les outils correctement dans un lieu sécurisé et sec.
Gardez les outils hors de la portée des enfants.
SÉCURITÉ PERSONNELLE
AVERTISSEMENT ! Portez de l'équipement de protection
personnelle homologué par l'Association canadienne de
normalisation (CSA) ou l'American National Standards
Institute (ANSI).
ÉQUIPEMENT DE PROTECTION PERSONNELLE
1. Portez toujours des lunettes antiprojections qui offrent une
protection frontale et latérale pour les yeux. L'équipement de
protection des yeux devrait être conforme à la norme CSA
Z94.3-07 ou ANSI Z87.1 fonction du type de travail effectué.
2. Portez des vêtements de protection conçus pour
l'environnement de travail et pour l'outil.
PRÉCAUTIONS PERSONNELLES
Gardez le contrôle de l'outil, de vos mouvements et de
l'environnement de travail pour éviter les blessures ou le bris
de l'outil.

V 1,0 THERMOMÈTRE INFRAROUGE 8730574
Visitez www.princessauto.com pour plus d'informations 5
1. N'utilisez pas l'outil si vous êtes fatigué ou sous l'effet de
drogues, d'alcool ou de médicaments.
2. N'utilisez pas l'outil si vous devez étirer les bras pour vous
en servir. Une stabilité et un équilibre appropriés sont
nécessaires afin d'avoir un meilleur contrôle en cas de
situations inattendues.
CONSIGNES DE SÉCURITÉ SPÉCIFIQUES
AVERTISSEMENT ! Ne permettez PAS au confort ou à votre
familiarisation avec l'outil (obtenus après un emploi répété) de
se substituer à une adhésion stricte aux règles de sécurité de
l'outil. Si vous utilisez cet outil de façon dangereuse ou
incorrecte, vous pouvez subir des blessures corporelles graves.
1. Utilisez le bon outil pour la tâche à effectuer. Cet outil a été
conçu pour une utilisation spécifique. Évitez de modifier ou
d'altérer cet outil ou de l'utiliser à une fin autre que celle
pour laquelle il a été conçu.
2. N’utilisez pas l’outil si des pièces présentent des dommages
ou sont déplacées. Réparez ou remplacez les pièces.
3. Ne transportez pas l'outil avec les doigts sur la gachette ou
à proximite de celle-ci.
4. Le thermometre infrarouge doit etre protege de ce qui suit :
4.1 Champs electromagnetiques causes par des soudeuses
à l'arc, rechauffeurs à induction, etc. Un champ
electromagnetique presentant une frequence radio de
pres de 3 V par metre influencera temporairement les
lectures. L'erreur maximale atteint 8 °C (14,4 °F) si la pi
age de 3 V /m varie de 350 à 550 MHz.
4.2 Choe thermique cause par des changements majeurs
ou brusques de la temperature ambiante. Attendez 30
minutes pour stabiliser l'appareil avant de l'utiliser.
4.3 Ne laissez pas l'appareil sur ou à proximite des objets à
temperature elevee.

8730574 THERMOMÈTRE INFRAROUGE V 1,0
6 En cas de questions techniques, appelez le 1-800-665-8685
5. Les outils ne doivent jamais etre exposes à la pluie ou à une
forte humidite.
6. Do not measure live circuits with voltages that exceed 24V
DC RMS or 60V DC with the thermocouple probe.
ÈMETTEUR LASER
AVERTISSEMENT ! Un rayon laser est émis par cet outil.
Observez toutes les instructions et les procédures qu'on
retrouve dans ce manuel avant d'utiliser ou d'ajuster le laser.
Le non-respect des instructions pourrait entraîner une
exposition aux radiations dangereuses.
AVERTISEMENT ! Ne regardez pas le rayon laser. Le rayon laser
peut endommager les yeux et nuire à la vision, sans compter
qu'il peut provoquer une cécité partielle ou complexe.
1. Cet outil renferme un laser de catégorie IIIA qui émet un
rayonnement laser.
1.1 Un produit avec laser de catégorie IIIA peut provoquer
la cécité et d'autres blessures aux yeux non protégés.
2. Ne dirigez jamais le laser vers vous-même, vers une autre
personne ou vers un animal. Évitez de pointer le rayon laser
dans les yeux, puisqu'il peut provoquer des blessures.
3. Ne regardez pas le rayon laser ou l'ouverture, même si vos
yeux sont protégés. L'exposition au rayon laser peut
endommager les yeux.
4. Faites attention à la lumière laser que reflètent les surfaces
de travail. Recouvrez ou enlevez les objets présentant une
surface réfléchissante si possible. Enlevez toujours les
bijoux et les montres des bras inférieurs et des mains afin
d'éviter toute réflexion involontaire.
4.1 Le rayon laser réfléchi sur une surface ressemblant à
un miroir peut provoquer autant de dommage que si
on le regarde.
