protech 84-25050-01 User manual

Warranty
Duct Mount
Media Air Cleaner
CAUTION:
READ INSTALLATION, OPERATION, AND MAINTENANCE
INSTRUCTIONS CAREFULLY FOR SAFE OPERATION.
Installation • Operation • Maintenance
10
155595-002 12/03
Limited Warranty
This product comes with a two (2) year limited warranty on parts. The warranty provides that
a replacement will be furnished for any part of the product that fails in normal use and service
during the applicable warranty period specified, in accordance with the warranty’s terms. The
replacement part is warranted for only the unexpired portion of the original warranty.
All parts are warranted for a period of TWO (2) YEARS after the effective date. The effective
date is the date of installation if properly documented. Otherwise, it is the date of
manufacture plus twenty four (24) months.
STANDARD PROVISIONS AND CONDITIONS
The following terms are common to all of PROSTOCK’S individual product warranties.
THIS WARRANTY WILL NOT APPLY: a) to defects or malfunctions resulting from failure to
properly install, operate or maintain the unit in accordance with the manufacturer’s printed
instructions; b) to damage from abuse, accident, fire, flood, and the like; c) to parts used in
connection with normal maintenance, such as cleaning or replacing air filters; d) to units that
are not installed in the United States of America or Canada; e) to units that are not installed
in accordance with applicable local codes, ordinances and good trade practices; or f) to defects
or damage caused by the use of any attachment, accessory or component not authorized by
PROSTOCK.
SHIPPING COSTS: You will be responsible for the cost of shipping warranty replacement parts
from our factory to our PROSTOCK distributor and from the distributor to the location of your
product. You also are responsible for any shipping cost of returning the failed part to the
distributor. (If in Alaska, Hawaii, or Canada, you also must pay the shipping cost of returning
the failed part to the port of entry into the continental U.S.)
SERVICE LABOR RESPONSIBILITY: This Warranty does not cover any labor expenses for service,
nor for removing or reinstalling parts. All such expenses are your responsibility, unless a service
labor agreement exists between you and your contractor.
HOW TO OBTAIN WARRANTY PERFORMANCE: You must promptly report any failure covered
by this warranty to the installing contractor or distributor. Normally, the installing contractor
from whom the unit was purchased will be able to take the necessary corrective action by
obtaining through his PROSTOCK distributor any replacement parts. If the contractor is not
available, simply contact any other local contractor handling PROSTOCK products.
The name and location of a local contractor can usually be found in your telephone directory
or by contacting a PROSTOCK distributor. If necessary, the following PROSTOCK office can
advise you of the nearest PROSTOCK distributor:
P.O. Box 17010 • Fort Smith, Arkansas 72917-7010 • [phone] • (For CA only: [phone])
HOWEVER, ANY REPLACEMENTS ARE MADE SUBJECT TO VALIDATION BY PROSTOCK OF IN-
WARRANTY COVERAGE.
An item to be replaced must be made available in exchange for the replacement.
MISCELLANEOUS: No one is authorized to make any warranties on behalf of PROSTOCK. ANY
IMPLIED WARRANTIES, INCLUDING MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, SHALL NOT EXTEND BEYOND THE APPLICABLE WARRANTY PERIODS SPECIFIED
ABOVE, PROSTOCK SOLE LIABILITY WITH RESPECT TO DEFECTIVE PARTS SHALL BE AS SET
FORTH IN THIS WARRANTY, AND ANY CLAIMS FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES ARE EXPRESSLY EXCLUDED. Some states do not allow limitations on how long an
implied warranty lasts, or for the exclusion of incidental or consequential damages, so the
above limitation or exclusion may not apply to you.
This Warranty gives you specific legal rights, and you may also have other rights that vary from
state to state.
P.O. Box 17010 • 3900 South Zero Street • Fort Smith, Arkansas 72917-7010
Phone: [phone] (For CA only: [phone])
¤
84-25050-01 2000 CFM 20” x 25”
84-25050-05 1400 CFM 20” x 20”
84-25050-06 1400 CFM 16” x 25”

NotesTable of Contents
Table of Contents Page
Introduction ......................................................1
Unit Diagram .................................................. 2
Capacity Selection Guide ..................................2
Unit Dimensions ................................................3
Installation ........................................................4
Maintenance ....................................................8
Warranty ..........................................................10
9

Maintenance
8
Introduction
Your media air cleaner is a high efficiency air filtration device designed
to remove dirt, dust, pollen and other microscopic particles from the air
passing through it. Considering the messy dirt collecting job it
performs, you will be pleased with the simplicity of its operation and
care.
How the Air Cleaner Works
Dirty air enters the air cleaner by way of the return air duct system in
your home. Particles are collected by the special pleated filter media.
The pleats provide an exceptionally large filtering face area in a very
compact space which allows maximum dirt holding capacities with
minimum air flow resistance.
POLLEN & SPORES
DIRT & DUST
GREASE & SOOT
CLEAN
AIR
Introduction
1
How to Maintain Your Air Cleaner
The media filter cartridge in your air cleaner must be replaced
periodically. The frequency of filter replacement is best
determined by visual examination. On average, filter cartridges
should be replaced every 9-12 months with normal usage.
STEPS FOR REPLACING FILTER CARTRIDGE
1. Open access door by pulling the handle. Remove door
completely.
2. Pull used filter straight out of cabinet and place to side.
3. Remove new filter cartridge from plastic bag and save the
bag.
4. Slide new filter cartridge into cabinet with “AIR-FLOW”
arrow pointing in the direction of airflow.
5. Replace door and place used filter in plastic bag for easy
disposal.
Replacement Filter Cartridges For Your Media Air Cleaner
Remember, periodic inspection and replacement of your filter
will ensure high efficiency air cleaning. Contact your HVAC
dealer for replacement filter cartridges.
Air Cleaner
Part No.
84-25050-05
84-25050-06
84-25050-01
Model
(CFM)
1400
1400
2000
Filter Cartridge
Size
5 x 19 3/4” x 20 3/4”
5 x 15 3/4” x 24 1/4”
5 x 19 3/4” x 24 1/4”
Replacement
Filter Cartridge
Part Number
54-25051-03
54-25051-04
54-25051-01
Number
Per
Carton
4
3
3
Vendor
Number
252990-103
252990-105
252990-102

Installation
7
2000 CFM (20” x 25” x 5”) 84-25050-01
1400 CFM (16” x 25” x 5”) 84-25050-06
1400 CFM (20” x 20” x 5”) 84-25050-05
1. Cabinet
2. Filter Cartridge
3. Access Door
1
2
3
Part Number
Model
Air flow (CFM)
600
800
1000
1200
1400
1600
1800
2000
84-25050-05
1400 CFM (20”x20”)
.04
.08
.12
.18
.24
.
.
.
84-25050-06
1400 CFM (16”x25”)
.04
.08
.12
.18
.24
.
.
.
84-25050-01
2000 CFM (20”x25”)
.03
.05
.07
.10
.14
.18
.22
.27
Resistance (Inches W.G.)
Unit Diagram
Capacity Selection Guide
2
Physical Installation
The air cleaner can be installed in any position, except with the access door
facing down. The section entitled Typical Mounting Positions shows
examples of proper air cleaner mounting with a variety of furnace
installations.
Prior to installing this product . . .
1. Read rules and instructions carefully for safe operation. Failure to follow
them could damage the product or cause a hazardous condition.
2. Check the ratings given on the product to make sure it is suitable for
your application.
3. Remove the old furnace filter and discard.
4. The air cleaner cannot remove existing dirt from the blower and ducts.
Clean the area thoroughly before beginning installation.
NOTE:
The following is a typical installation of the air cleaner on a highboy furnace.
You may have to alter the installation to fit your specific application.
5. Locate the cabinet in the cold air return duct such that all of the return
air flows through the unit. If the furnace and air cleaner openings are
different, use a transition.
6. Mounting holes are provided in the air cleaner cabinet for ductwork
attachment. The .140” diameter holes are sized for #8 sheet metal
screws, or 1/8” rivets. If the adjoining ductwork is flanged, install the
screws with the screw heads inside the cabinet, to prevent damage to
the filter cartridge during removal and installation.
7. Remove the plastic bag from the filter cartridge and replace filter
cartridge in cabinet.
8. After the unit has been secured, seal seams air tight with duct tape or
caulking. Reinstall access door to ensure a tight seal.

Tur ning Vanes
If the air cleaner is installed adjacent to a 90° duct elbow,
add turning vanes inside the duct to improve the air
distribution across the face of the air cleaner.
Direction of Air Flow Through the Air Cleaner
The air cleaner is set up for left to right air flow, when
facing the access door. For right to left air flow remove filter
cartridge, turn it around and replace in cabinet. The
directional arrows on the filter cartridge must point in the
direction of air flow.
Humidifiers
Location of the system humidifier is important to the
operation of the air cleaner. When an evaporative type
humidifier is used, it may be installed between the furnace
warm air duct and the return air duct without effecting the
air cleaner. Atomizing and spray type humidifiers should be
installed downstream of the air cleaner. If the humidifier
must be installed upstream of the furnace, allow at least 6’
between the air cleaner and humidifier.
Installation
6
Part Number
Model
Filter Cartridge
Air Flow (CFM)
Dimensions
A
B
C
Duct Opening
D
E
Filter Cartridge
Replacement
84-25050-05
1400 CFM
20” x 20” x 5”
600-1400
7 1/8” (181mm)
21 3/8” (543mm)
20 1/4” (514mm)
19” (483mm)
17 7/8” (454mm)
84-25050-06
1400 CFM
16”x25”x5”
600-1400
7 1/8” (181mm)
24 7/8” (632mm)
16 1/4” (413mm)
22 1/2” (572mm)
13 7/8” (352mm)
84-25050-01
2000 CFM
20”x25”x5”
600-2000
7 1/8” (181mm)
24 7/8” (632mm)
20 1/4” (514mm)
22 1/2” (572mm)
17 7/8” (454mm)
9-12 months between changes
UL class 2
Dimensions
3

Application
This air cleaner is used in forced air heating, cooling, and ventilating
systems. The air cleaner should be installed in the system such that all the
system air is circulated through the air cleaner. The air cleaner will only
remove the airborne contaminants delivered to it; therefore maximum
performance is obtained with the system blower set for continuous
operation.
Installation Requirements
The best location for the air cleaner is in the return air duct next to the
blower compartment. In this location, the blower motor and cooling coils
will be kept clean. Do not install the air cleaner in the discharge air duct.
Before installing the air cleaner, consider the application. If a transition
between the ductwork and air cleaner is required, refer to section entitled
Transitions. The unit must be readily accessible for periodic inspection and
replacement of the filter cartridge to maintain maximum efficiency and
trouble-free operation. Allow a minimum of 26” clearance in front of the
access panel for filter cartridge replacement.
Air Conditioning
The air cleaner should be installed upstream of the cooling coil to keep the
coil clean and reduce air conditioning coil maintenance. A clean coil will
reduce utility costs by maintaining the coil’s efficiency. Failure to replace
filter cartridge can cause damage to the cooling system.
Transitions
If the air duct does not fit the air cleaner cabinet opening, gradual
transitions are recommended to reduce air turbulence through the air
cleaner and maximize efficiency. Not more than 20° (about 4” per running
foot) of expansion should be used on each side of the transition fitting.
Air Flow
Air Flow
Furnace
Transition section
Air Cleaner
Air Cleaner
opening
Furnace
opening
Maximum 4" drop
per linear foot
Installation
5
TYPICAL MOUNTING POSITIONS
(Shaded illustrations are for positioning use only.)
Space Saver (Highboy)- Installation
beneath furnace. Cleaner mounts
horizontally, where return air enters
from below. Raise furnace by installing a
suitable wood structure and install air
cleaner.
Horizontal Furnace– Mounted vertically in
return duct as close to the furnace as
possible.
Offset Installation– If there is less than 7-in. for
mounting the air cleaner between the duct
and the furnace, move the return air drop.
Space Saver Furnace
(Highboy)- Side installation.
Mounted vertically, where
return air enters side inlet of
furnace.
Counterflow Furnace–
Mounted horizontally in
return duct– just above
the furnace.
Basement Furnace (Lowboy) -
Mounted horizontally in
return plenum– just above
the furnace.
Installation
4
