Proton ArtNet-DMX 8Port Node User manual

ArtNet-DMX 8Port Node
User Manual
Version: 2.1

The ARTNET-DMX 8Port Node is a reliable and versatile ArtNet-to-DMX
adapter designed to expand DMX networks. It allows conversion of Ethernet
data into 8 universes of DMX signal. Additionally, it can be used as a DMX
Splitter with 2 inputs to 8 DMX signal outputs. It is intended for control of all
kinds of lighting products such as conventionals, moving lights, LEDs, video
and media via DMX signal. To optimize the performance of this product,
please read the user manual carefully before use.
INTRODUCTION
Safety Instruction
WARNING!!! To reduce the risk of fire, electric shock, or injury to
persons, follow these important safety instructions:
1
▪This product is intended for indoor use only!
▪Always turn off, unplug power and allow fixture to cool before servicing.
▪Ensure that fixture is properly grounded.
▪Please keep this User Guide for future consultation.
▪To prevent risk of fire or shock, do not expose fixture to rain or moisture.
▪The unit must be installed in a location with adequate ventilation. Be sure no
ventilation slots are blocked.
▪Make sure power cord is never crimped or damaged.
▪Do not remove the top cover under any conditions. There are no user
serviceable parts inside.
• Disconnect the unit’s main power when left unused for long periods of time.
• Never connect this unit to a dimmer pack.
• Never operate this unit when it’s cover is removed.
• Any damage caused by manual modifications are not subjuect to warranty.
What Is Included
Carefully unpack the carton, check the contents to ensure that all parts are
present, and have been received in good condition. Contact your supplier
immediately and retain packing material for inspection if any part is missing or
damaged.
The following items are included in the box:
▪1pc ArtNet-DMX 8Port Node
▪1pc Power cable
▪1pc User Manual

The unit fits nicely in a standard 19” rack or sits on a flat surface.
SETUP
Installation
Features
Product Overview
2
The unit has an internal auto-ranging power supply that works with an input
voltage range of 100–240 VAC, 50/60 Hz. Before applying power to a unit,
make sure that the unit’s input voltage matches the power source voltage.
▪Supports ArtNet (V4) and DMX
▪8 Universal DMX ports
▪1 x RJ45 TCP/IP 10/100M Ethernet connector
▪Artnet to DMX signal conversion
▪2 inputs to 8 outputs DMX Splitter function
▪LED indicator for each output
▪16 x 2 digits LCD menu/fuction display
▪USB port for fireware updating
AC Power
160
418,2
482
44
Power In
Fuse
LCD Menu Menu ButtonsUSB Port Signal Out Indicators
Ethernet
In DMX In
1 - 2 DMX Out 1 - 8
WARNING: All units must be connected to circuits with a suitable Earth Ground.

3
The unit receives signal though 2 DMX In ports and one of 2 Neutrik®
etherCON® ports. It sends signal out through 8 DMX Out ports and the other
Neutrik® etherCON® port.
The unit can be used as ArtNet to DMX, DMX splitter function, and both
ArtNet-DMX and DMX splitter simultaneously. Once it is properly configured it
operates without user intervention.
Signal Connection
Connection Diagram
ArtNet to DMX Conversion
Both ArtNet to DMX and DMX Splitter Function
Router
Lan cable
Lan cable
elbacXMDelbacXMD
DMX cable
DMX Splitter Function
elbacXMDelbacXMD
DMX cable
DMX cable DMX cable
Router
Lan cable
DMX cable
Lan cable
Please see connection diagram as below.

OPERATING INSTRUCTIONS
4
The setup of menu is operated by 5 buttons as described belows.
Menu Buttons
Menu Button
When navigating the menu:
Use to scroll 1st level menu or
back to higher level.
Use to increase value.
Use to decrease value.
Use to move right.
Use to move left.
Menu Map
Menu
Menu
System Setup
[ IP address ] 002.168.001.200
Password:0000
[00] - 09 - F6
D7 - FF - 31
Pass word: 1234
System Setup
[ Net Mask ] 255.255.000.000
subnet Mask:[2]
System Setup
[ OEM code ] [ 0x0000]
OEM code
System Setup
[ Port Address ] [000]
Net
000
sub-Net-Uni
System Setup
[ DMX Hold ] [01]
Port
No/Yes
DMX_Hold
Password:0000
Pass word: 1234
System Setup
[ New Firmware ] Please wait ....
Password:0000
Pass word: 1234
System Setup
[ Factory Reset ] Boot system...
System Setup
[ Output Set ] [01]
Port
ArtNet-U1
Output
01
Port
[ArtNet-U1]
Output
01
Port
[ArtNet-U2]
Output
01
Port
[ArtNet-U3]
Output
01
Port
[ArtNet-U7]
Output
01
Port
[ArtNet-U8]
Output
System Setup
[ Device MAC ]

5
When the unit is used as an ArtNet to DMX converter, Art-Net universes must
be assigned to DMX output ports, and the Net, Subnet, IP address settings must
be configured.
ArtNet to DMX
When the unit is used as a DMX splitter only, DMX output ports must be
assigned to either DMX IN-1 or DMX IN-2, no need to configurate Net,
Subnet, IP address, etc.
DMX Splitter function
Note: DMX output ports can be assigned to only ArtNet or DMX -1 /2 , not
both.
System Setup
[ Output Set]
System Setup
[ Output Set]
Port Output
[01] ArtNet-U1
Port Output
[01] DMX -IN1
Port Output
[01] DMX -IN2
To configure Net and Subnet setting, do the followings:
1) Use button to select
2) Press button to access
3) When there are more than 8 universes, setup for port address is required
for different nodes.
For example, 1st Node is set as then it outputs universe 1 to 8.
,use and to select Port
number and then press assign output universe or DMX In.
1) Press button and select
3) Press button and use to select or
System Setup
[ Port Address ] [000]
Net
000
sub-Net-Uni
[000]
Net
000
sub-Net-Uni
2nd Node is set as then it outputs universe 9 to 16.
[000]
Net
009
sub-Net-Uni

6
USB port for software updating via USB-stick only. Do not connect
any peripheral device (mouse, keyboard or similar).
IMPORTANT INFORMATION!
In order to optimize the recovery and recycling of the materials
that old appliances contain and reduce the impact on human
health and the environment, ensure that this product is recycled
at the end of its life.
SPECIFICATIONS
Power Input: AC 100-240V 50-60Hz
Power consumption: 6W
Data inputs: EtherCon and 3pin XLR In(or 5pin)
Data outputs: 8 x 3pin XLR Out (or 5pin)
Dimension: 482 x 168 x 44 (1U rack mount)
Weight: 2.2 kg
On the front panel there are indicators described as below.
Indicators
1) Copy the new software to the root directory of your USB stick.
2) Insert USB stick in the USB port.
3) Press Menu button and select [New Firmware], input password and press
Software updating
LINK Solid
Blinks
Ethernet IN is connected to ArtNet source
Solid DMX IN-1 is connected to DMX source
Solid DMX IN-2 is connected to DMX source
DMX OUT ports output DMX signal
Unit receives ArtNet signalDATA
DMX 1
DMX 2
Signal Out Solid
Indicator Behavior Meaning
Password:0000
Pass word: 1234
System Setup
[ New Firmware ] Please wait ....
button.
