ProVista Technology TSW600 Basic User manual

Operating Manual TSW600 Basic

Index
Introduction ..........................…………………………………………………....... 1
Description of symbols .........…………………………………………………....... 2
1 About this manual .........………………………………………………………...... 2
1.1 Applicability .............………………………………………………………....... 2
1.2 Users .....................………………………………………………………........ 2
2 Safety .........................…………………………………………………………..... 3
2.1 Proper usage ...........……………………………………………………….…..3
2.2 Improper usage .......……………………………………………………….….. 3
2.3 Other risks ............…………………………………………………………….. 3
2.4 Fault behaviour ..............………………………………………………….…...3
3 Description ................……………………………………………………………... 4
3.1 Construction ..........…………………………………………………………..... 4
4 Installation ............…………………………………………………………….… 4-6
4.1 Mounting .............…………………………………………………………….... 4
4.1.1 Mounting location………………………………………………………….....
4.1.2 Mounting the inverter……………………………………………………......
4.2 Connection .............………………………………………………………....... 5
5
5
5
6
4.2.1 AC output of the inverter…………………………………………………....
4.2.2 Connecting the battery to the inverter………………………………..........
5 Operation ...................………………………………………………………...... 6-7
5.1 Switching the power supply on/off ..……………………………………….... 6
5.2 Switching off the power supply …………………………………………….... 6
5.3 Protection function ...........………………………………………………........ 7
6 Care, maintenance and service ……………………………………………….... 7
7 Technical data …………………………………………………………………...... 8
7.1 Device data …………………………………………………………………..... 8
8 Fault and troubleshooting ......………………………………………………….... 9
9 Part list ………………………………………………………………………….....
10 Exclusion of liability …………………………………………………………......10
10
11 Contact …………………………………………………………………………...11

Introduction
The TSW600 Basic is stand-alone inverter for PV battery systems. They convert the battery’s
DC voltage into pure sine wave AC voltage, this can provide nice power to any normal AC
appliances such as consumer electronics, tools, household appliances, lamps, etc.
TSW600 Basic can provide power of 230V AC /50Hz.
1

Description of symbols
1. The structure of the warning notices
SIGNAL WORD
2. Danger levels in warning notices
Danger level Probability of occurrence Consequences resulting
from non-compliance
DANGER Imminent threat of danger Death, serious bodily injury
WARNING Possible threat of danger Death, serious bodily injury
CAUTION Possible threat of danger Minor bodily injury
CAUTION Possible threat of danger Property damage
3. Notes
NOTE
Note on easier and safer working habits.
zMeasures for easier and safer working habits.
1 About this manual
These instruction manual are part of the product.
zRead these operating instructions carefully before use,
zKeep them over the entire lifetime of the product,
zPass them on to any future owner or user of this product.
1.1Applicability
This manual describes the function, operation ，installation, and maintenance of the
stand-alone inverters.
1.2Users
Installation, commissioning, operation, maintenance and take-down of the inverter may only
be done by professional worker in accordance with the applicable on-site installation
regulations. The professional worker must be familiar with this operating manual and follow
the instructions contained herein.
The end user may only perform operating functions.
2

2 Safety
2.1 Proper usage
The inverters are exclusively intended for use in off-grid power supplies in accordance with
these operating instructions. Any other use is regarded as improper use of the device.
2.2 Improper usage
zThe inverter must never be connected to the utility grid or a generator.
zThe casing must not be opened and should not show any damage.
zThe pre-fitted battery cables must not be extended.
zThe inverter can not be connected in parallel way.
2.3 Other risks
WARNING
Danger of fire and explosion
zA stand-alone power supply system (including inverter) must not be installed, operated or
maintained in locations where inflammable gases and vapors can occur, in dusty
environments, or in the vicinity of solvents.
zNo open fires, flames or sparks in the vicinity of the batteries.
zEnsure that the room is ventilated.
Battery acid
zAcid splashes on skin or clothing should be immediately treated with soap suds and rinsed
with plenty of water.
zIf acid splashes enter the eyes, immediately rinse with plenty of water and seek medical
advice.
2.4 Fault behaviour
DANGER
Operating the system is dangerous in the following situations:
zThe inverter does not appear to work at all.
zThe inverter, mains cable or battery cables are visibly damaged.
zEmission of smoke or fluid penetration.
zWhen parts are loose.
¾In these cases immediately turn off inverter and remove the inverter from the battery
and consumer devices.
3

3 Descriptions
3.1 Construction
TSW600 Basic include following components:
1. LED indication for operating modes
2. ON/OFF switch
3. Aviation plug with 1 m cable (230V AC & 50Hz Output)
4. Fuse box (35A X 2pcs)
5. Battery connector(Black): Negative polarity (Connect to Black cable with Ring connector,
Approx. 1.5m long)
6. Battery connector(Red): Positive polarity (Connect to Red cable with Ring connector,
Approx. 1.5m long)
4. Installation
4.1 Mounting
4.1.1 Mounting location
4

Ensure that the mounting location complied with below requirements:
zMount in a dry, dust-free, ventilated indoor place
zMount on flat surface.
zMount upright on the wall, on concrete
or on any other non-flammable
surface.
zThe mounting location must be
protected from unauthorized access,
especially by small children.
zDistance between inverter and battery:
please note that the pre-fitted cables
must not be extended.
zMinimum clearance of approx. 25 cm
above and below to allow free air
circulation.
4.1.2 Mounting the inverter
zMark and drill the upper holes
(Ø 5 mm).
zInsert the dowels and screw in the
screws. Do not screw tight at this
moment.
zHang the inverter on the two screws
and mark the lower holes.
zRemove the inverter and drill the two
lower holes.
zInsert the dowels.
zHang the inverter on the two upper
screws and screw in the lower screws.
zScrew all screws tight.
4.2 Connection
WARNING
Danger of explosion from sparking! Danger of electric shock!
zThe inverter may only be connected to the local consumer devices and the battery by
trained personnel and in accordance with the applicable regulations.
zConnections must always be made in the sequence described below
zThe cables pre-fitted to the inverter must not be damaged
4.2.1 AC output of the inverter
zConnect suitable AC socket with pre-fitted AC Output cable, Brown cable connect to L,
Blue cable connect to N, Yellow & Green cable connect to GND
zConnect Male aviation plug to AC Output of inverter
5

4.2.2 Connecting the battery to the inverter
WARNING
Danger of explosion from sparking! Danger of electric shock!
zBefore connecting the battery, ensure that no consumer devices are switched on and the
ON/OFF switch is in the "OFF" setting
zEnsure that the polarity of the battery connection is correct
zThe cables pre-fitted to the inverter must not be extended
zFollow the instructions of the battery manufacturer
¾Turn the ON/OFF switch to the "OFF" setting
¾Ensure that the connection to the mains grid has been carried out correctly
¾An easily accessible disconnection device should be connected to the battery cables
immediately next to the battery. The disconnection device should consist of a DC circuit
breaker or a DC fuse.
¾Connect the red battery cable to the positive terminal + of the battery
¾Connect the black battery cable to the negative terminal – of the battery
¾Ensure that the connections are tight
CAUTION
Inverter can only be connected to 12V battery. (10.5-14.5V)
5 Operation
The inverters are equipped with a standby system. To avoid unnecessarily discharging the
battery, in this operating mode switches off the inverter manually when no consumer device is
connected and switches on manually when a consumer device is switched on.
5.1 Switching the power supply on/off
5.1.1 Switching on the power of inverter
5.1.2 Red LED turns on at the first 3 seconds and then Green LED permanent illuminated
5.1.3 Connect consumer device to the inverter
5.1.4 Turn on consumer device
5.2 Switching off the power supply
If power is not required for a longer period of time, e.g. when
you are absent, it’s recommended to switch off the inverter.
5.2.1 Switch off the power of inverter
5.2.2 Turn off the power of consumer device
Notes
The LED of Power permanently illuminated green when switch is on.
The LED of Fault illuminated red when problem happened.
5.3 Protection function
zNoise emission
¾The inverter has a fan that automatically switches on when the device heats up, e.g. in
high ambient temperatures or long-term heavy loads. The fan switches off again as soon
as the device has stopped generating excessive heat.
6

Notes
Inside Temp is more than 50℃or load power is higher than 500Watt, the fan switch on
automatically,
Temp is lower than 40℃, the fan switch off automatically
zDeep discharge protection
¾The inverter protects the battery from deep discharge. With low battery voltage around
10.5 V, inverter alarm and Red LED turn on, pls switch off inverter till battery is charged.
¾If the voltage of battery is lower than 10V, inverter will switch off automatically to protect
battery is deep discharged.
Notes
Before restart inverter, wait till battery is charged and voltage is higher than 12.5V.
Restart inverter.
zOver voltage protection
¾The inverter protects itself from over voltage. With high input voltage around 15 V from
battery, inverter will turn off automatically
Notes
Before restart inverter, check the output voltage from battery is lower than 14.5V
Restart inverter
zOver load protection
¾The inverter switch off automatically when output power is higher than 650Watt.
¾Inverter will automatically restart after 5 seconds, if the output power still higher than
650Watt, it will keep off. Inverter will detect 3 times automatically, if the output power still
higher than 650Watt, inverter will turn off until it’s restarted manually.
zOver temperature protection
¾The inverter will turn off automatically when the inside temperature is higher than 65℃
Notes
After inverter get cool, restart it manually
6 Care, maintenance and service
The inverter is maintenance-free. If functional faults occur, please consult your dealer and
present the payment receipt / invoice.
zBefore cleaning the inverter, switch off all consumer devices and switch off the inverter via
the ON/OFF switch.
zRegularly clean the outside of the case with a damp duster cloth. Do not use solvents and
wet rag.
zEnsure that the ventilation slots on the side and lower sides of the device are not
obstructed and that the air can freely circulate. If necessary, remove dust by vacuuming.
7

7 Technical data
7.1 Device data
Basic information
1 System voltage 12V
2 Continuous power 600VA
3 Peak surge output power 1200VA
4 Max efficiency 92%
5 Average efficiency >89%
6 Own consumption standby 9Watt
DC input side
1 Battery voltage 10.5-14.9V
2 Reconnection Voltage 12.5V
3 Max. Input current 56Amp @ 600W
AC output side
1 Output voltage 230V AC ±10%
2 Output Frequency 50 ±1 Hz
3 Output current 2.6Amp
4 Total Harmonic Distortion(THD) <4%
Safety
1 Electrical protection Over voltage protection of input,
over current protection of output,
over temperature protection
Operation conditions
1 Ambient temperature -20℃~+45℃
2 Cable length battery/AC 1.5m/1m
3 Degree of protection IP31
4 Dimensions(LxWxH) 336x203x80mm
5 Weight 2.4Kg
8

8 Fault and troubleshooting
Fault Reason Remedy
Red LED illuminate at
the beginning of start System is warming up Wait for 3-5 seconds, it will be ok
Low voltage of battery
protection(Voltage of battery
is lower 10.5V)
Switch off consumer device, charge
battery
Fault battery Change battery
Alarm
Battery isn’t connect tightly Cleaning and reconnect
Over load protection Restart inverter, if the problem can’t
be solved after restart, reduce the
load or change a powerful inverter
Deep discharge
protection(Voltage of battery
lower than 10V)
Charge the battery
Red LED permanent
illuminate
Over temperature protection Cleaning the housing of inverter,
cool it
Noise Fan switched on zWait until the temperature
conditions have normalized
zReduce the load of consumer
devices
9

9. Part list
TSW600 Basic 1pce
Aviationplug 1pce
Cable with eyelet (Red) 1pce
Cable with eyelet (Black) 1pce
Screwsets 4sets
Instruction manual 1pce
Exclusion of liability
The manufacturer can neither monitor compliance with this manual nor the conditions and
methods during the installation, operation, usage and maintenance of the inverter. Improper
installation of the system may result in damage to property and, as a result, to bodily injury.
Therefore, we assume no responsibility and liability for loss, damage or costs which result or
are in any way related to incorrect installation, improper operation and incorrect use and
maintenance.
Similarly, we assume no responsibility for patent right or other right infringements of third
parties caused by usage of this inverter.
The manufacturer reserves the right to make changes to the product, technical data or
assembly and operating instructions without prior notice.
10

10. Contact
In the case of complaints or faults, we request that you contact the local supplier from whom
you purchased the product. They will help you with any issues you may have.
ProVista Technology Limited
Unit 2504, 25/F., Nanyang Plaza,
57 Hung To Road, Kwun Tong,
Kowloon, Hong Kong
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
SerialNumberofproduct:
Comments:
waste electrical products should not be disposed of with household waste
please recycle where facilities exist
check with your local authority or retailer for recycling advice
Specifications are subject to change without prior notice
Copyright reserved by ProVista Technology Limited
Version of Instruction manual 1.1
The Leading Edge of Solar Technology
11
