ProX XW-HDU04J User manual

XW-HDU04J
XW-HDU04JR
XW-HDU04J
XW-HDU04JR

Table of Contents
1.IMPORTANT INFORMATION .............................. 1
2.SAFETY PRECAUTIONS .................................... 1
3.INTRODUCTION ................................................ 2
4.FEATURES......................................................... 2
5.SPECIFICATION ................................................ 5
6.WIRELESS VIDEO TRANSMISSION .................. 7
7.NOTES .............................................................. 8
8.TROUBLE SHOOTING ...................................... 9
9.PACKING CONTENT ......................................... 10

Important Information
Read this user ’s manual carefully before use and retain for future reference.
The XW-HDU04J/04JR warranty may NOT apply to below cases:
■ Repairs or product modification and alterations executed by unauthorized service
personnel.
■ When damages caused by accidents include but not limited to lightning, water or fire.
■ The serial number on the product has been altered, deleted, removed or made illegible.
Safety Precautions
TO AVOID RISK OF ELECTRICAL
SHOCK, DO NOT ATTEMPT TO OPEN
THE UNIT BY YOURSELF. FOR ANY
ASSIST, PLEASE CONTACT YOUR
LOCAL DISTRIBUTOR OR PRO-X.
■ Before using an external power supply, always check that the voltage is within the
specified range and that the polarities of the connector are correct.
■ Do not use the unit in high moisture environment, which may cause electric shock or fire.
■ Avoid overloading electrical outlets or extension cords which otherwise could result in
electric shock or fire.
■ For protection from lightning or when the product is left unused for a long period of time,
disconnect it from the power source. Always disconnect the power cord from the power
outlet when not using. This reduces the risk of electric shock or fire.
■ Do not place the unit on an uneven surface or somewhere with vibration, which may
cause unit failure or damage.
■ After long time of continuous use, the outer case of the unit may be warm to touch.
■ In case of damage, smoke, unusual smell or other unexpected situations, stop using the
unit immediately and consult your local distributor or PRO-X.
■ The HDMI interface does not support hot plug.
■ This product should not be exposed to dripping or splashing. No object filled with liquid
should be placed on the product.
WARNING
RISK OF
ELECTRICAL
SHOCK
DO NOT OPEN
1

Statements
●
instruments, it may cause interference and fault on the operation.
● The unit is approved for technical standard compliance certification as a wireless device
of radio stations with low antenna power specified under international radio wave
regulations. Therefore a license for radio station use is not required to operate this
product.
● Optimal distance of working between XW-HDU04J/04JR TX (transmitter) and
XW-HDU04J/04JR RX (receiver) is between 3 meters and 300 meters LOS (line of
sight).
Introduction
The XW-HDU04J/04JR system is designed for wirelessly transmitting uncompressed
1080P HD SDI/SDI video and audio from camera to field monitors.
XW-HDU04J/04JR TX is the transmitter, and connects to a camera.
XW-HDU04J/04JR RX is the receiver, and connects to a monitor.
Video signals from the camera can be transmitted in a distance of 300m without cables. The
director, producer and even film crew can see exactly what the camera is shooting in real
time.
It works on 5.1GHz ~ 5.9GHz band radio frequencies and there are 0~9, total 10 frequency
points for selection.
With omni-directional and high efficiency antennas, it transmits uncompressed video in 300
meters LOS with less than 1ms latency.
Features
1.Video transmitted in real time with latency less than 1 millisecond.
2.Fully uncompressed 1080P video.
3.High definition video with embedded sound.
4.SDI input /output, automatically detects HD-SDI and SD-SDI video.
5.Transmission distance within 300m LOS.
6.0~9 total 10 frequency point selections on 5.1GHz~5.9GHz.
7.Power can be supplied by V type or 3-Stud mount Lithium ion battery or by AC
adaptor.
8.Back-up power failure function enables immediate and automatic switching to a
connected battery if the external DC connected power is disconnected
Note: The transmission distance may vary depending on surroundings, radio
wave conditions, etc. The transmission distance of approximately 300m is
not guaranteed.
In locations with many other devices operating in 5GHz frequencies,
operation of the set can be affected, and video may be interrupted.
Never use the unit nearby an aircraft, medical devices or other high-accuracy electronic
2

HDMI OUT
SDI OUT
V Type Mount
Power
HDMI OUT
SDI OUT
3-Stud Mount
Power
3
HD
WIRELESS TRANSMISSION
Power Switch
VIDEO LED
Video Signal Intensity
Frequency Points Selector Dial
POWER LED
Antenna Connectors
Screw Hole Ventilation Hole SDI OUT
XW-HDU04JS/04JRS RX
▲
▲
XW-HDU04J/04JR RX
▲
XW-HDU04JA/04JRA RX
▲
XW-HDU04J/04JR RX

Power Switch
NET LED
VIDEO LED
Frequency Points
Selector Dial
V Type Mount
SDI IN
SDI OUT
POWER
Power Switch
3-Stud Mount
SDI IN
SDI OUT
XW-HDU04JS TX
4
XW-HDU04JA TX
Antenna Connectors
NET LED
VIDEO LED
POWER
Screw Hole Ventilation Hole
XW-HDU04J TX
▲
Frequency Points
Selector Dial
POWER LED
POWER LED

XW-HDU04JR TX
5
Antenna Connectors
Power Switch
NET LED
VIDEO LED
Frequency Points
Selector Dial
POWER LED
SDI IN
SDI OUT
POWER
Screw Hole

Specifications
SDI Input
SDI Output
HDMI Output
Power Switch
LED
TX
Model
Video Resolution
Audio Format
Time Code
Transmission Distance
Latency
Frequency
Interfaces
XW-HDU04J/04JR
1080P, 1080i, 720P, 576i, 480i
Digital Audio
LTC; VITC
300m LOS (line of sight)
Less than 1 millisecond
5.1GHz~5.9GHz
Up to 3.072Mbps AC-3 and DTS
Audio/Video
Video
Net
Signal Intensity
Power
Frequency Points Selector Dial
Dimension W× L× H
Wireless Transmission Power
Antenna
Power Supply Input
Approved Standards
Working Temperature
18 dBm
Omni-directional and High Efficiency
Antenna System
DC 6V 4.0A~17V 2.0A
CE, NCC
0-40℃ /32-104 ℉
6
92×69×175 mm
3.62×2.72×6.89 inches
168×34×117mm
6.61×1.34×4.61 inches
XW-HDU04J XW-HDU04JR
RX
XW-HDU04J XW-HDU04JR
1
1
NO
1
1
1
NO
1
1
NO
2
1
1
1
NO
5
1
1

Wireless Video Transmission
1.Install Antennas
TX: Screw three antennas (rubber duck antennas) to
antenna connectors.
RX: Screw six antennas (blade style rubber duck antenna)
to antenna connectors.
2.Cable Connect
Connect camera’s SDI output connector to the SDI input of
TX with SDI cable.
Connect RX HDMI/SDI output connector to the monitor ’s
HDMI/SDI input with HDMI/SDI cable. A second SDI output
connector on RX is available for other equipment.
3.Select Frequency Point
Use frequency points selector dial to select the frequency
point. There are 0-9, total 10 frequency points on both
the TX and RX. To enable the transmission, the frequency
selector dials on TX and RX have to be at the same
position prior to operating wireless transmission.
In case of changing to another frequency, power cycle the set after selecting the
frequency.
* For different sets of XW-HDU04J/04JR, frequency
selector dials have to be at different positions.
4.Power the Set
For XW-HDU04J,both TX and RX can be powered by using V Type or 3-Stud mount
battery.
For XW-HDU04JR, TX can be powered by DC6-17V via DC IN cable. RX can be
powered by using V Type or 3-Stud mount battery.
Turn on power switches of TX and RX, the power LEDs light in green.
5.Link and Transmit
After the input signal identified, VIDEO LED and NET LED light up.
When signal link between TX and RX is established, NET LED on TX flashes, and
VEDIO LED on RX lights up.
Video signal intensity has five LEDs to indicate the intensity of RX received signal
from MIN to MAX.
0
5
9
4
8
3
7
2
6
1
7
HDMI Cable
SDI Cable

Notes:
◆ Signal transmission may be affected by the position, height and angle of
placement. If the signal is weak, look for the best condition by adjusting the
location, height of the unit.
◆ When TX and RX are used very closely to each other (less than 3m as an
example), the received signal becomes too strong and may make the video
unavailable.
◆ Transmission may be interfered if there are other 5GHz wireless devices in
operation nearby.
◆ For XW-HDU04J,when an external power supply is used, power failure can be
avoided by mounting a PRO-X V Type or 3-Stud mount lithium ion battery to the
set at the same time. If the external power supply fails, operation continues via
battery power.
◆ If the video works improperly, restart the set (TX and RX) and try again.
◆ When wireless transmission begins, the set takes about 15-20 seconds to start
its system. During this period of time, do not operate RX.
◆ Do use TX and RX of the same serial number in pairs.
8

Troubleshooting
9
Fault
Power LED doesn’t light up
No video is displayed on
the monitor
Poor picture quality or
intermittent video play
No audio
Solutions
● Check the battery mounted is available.
● Check the power plugs of TX and RX are
properly connected to a functioning power
outlet.
● Verify that the proper cable has been
selected and installed between the TX input
and your SDI output.
● Make sure your camera connected with TX
has been powered.
● Select the right SDI or HDMI video source
on the monitor when connect to RX.
● Check your video resolution with SDI input
from your device is 1080P, 1080i, 720P, 576i
or 480i.
● Check VIDEO LED and NET LED on your TX;
if VIDEO LED doesn’t light up, check the
input signal; if VIDEO LED lights up, but NET
LED doesn’t light up, check TX/RX antennas
installation and their directions.
● Ensure transmission distance is not over
300m (LOS).
● Check your video resolution with SDI input
from your device is 1080P, 1080i, 720P, 576i
or 480i.
● Check TX/RX antennas installation and their
directions.
● Ensure transmission distance is not over
300m (LOS) and there’s no interference
between TX and RX.
● Shutdown and restart the set.
volume is properly set and not in “MUTE”
mode.
●
●
Shutdown and restart the set.
Check your monitor or other equipment’s

Quantity
1
1
1
2
5 (2 spares)
6
2
2
1
1
NO.
1
2
3
4
5
6
7
8
9
10
Standard Packing of XW-HDU04J/04JR
Please check whether the following items are present in the package.
If not, please contact your dealer.
XW-HDU04J RXXW-HDU04J TX
SDI Cable DC IN Cable SP-1BP
PT-2BP
10
Description
XW-HDU04J/04JR TX
XW-HDU04J/04JR RX
SP-1BP Adaptor
DC IN Cable
Rubber Duck Antenna
Blade Style Rubber Duck Antenna
SDI Cable
Magic Arm (7 Inch)
Crab Clamp
User’s Manual
Crab Clamp
Magic Arm
RP-SMA (Short) RP-SMA (Blade Style)
XW-HDU04JR TX
