Qtx U-MIC User manual

U-MIC
Item ref: 171.812UK
USB Dual Neckband UHF Wireless System
User Manual
Version 1.0
Caution: Please read this manual carefully before operating
Damage caused by misuse is not covered by the warranty

171.812UK User Manual
Introduction
Thank you for choosing the U-MIC for your wireless microphone requirements.
This system is designed to provide a reliable, cable-free solution with minimal
setup and ease of use. Please read and keep this user manual to get the best
results from your product and avoid damage through misuse.
Layout
Setting up
The U-MIC is supplied as 2 individual beltpack microphone transmitters and a USB
receiver with a 3.5mm to 6.3mm jack lead.
The USB type A plug (6) on the receiver should be connected to a USB port for
power (5V, 1000mA). This can be from a USB power adaptor or power bank for
portable use if required. The connection can also be made to the receiver using
an optional USB extension lead if preferred.
Note: the audio is not transmitted to the USB port. The USB is for power only.
If the USB port is a U-Disk player or computer port, the digital media (USB stick)
or other peripheral device can still be connected through the receiver by
connecting to the USB type A socket (8) on the rear of the receiver.
1.
Volume control
2.
3.5mm mic input
3.
LED power indicator
4.
Power switch
5.
Battery compartment
6.
USB type A plug
7.
3.5mm audio output
8.
USB type A socket

171.812UK User Manual
Operation
The U-MIC receiver is designed to connect to a microphone input jack on a mixer
or amplifier. Turn down the volume level on the microphone input of the mixer or
amplifier before connecting to avoid loud noises when connecting.
Connect the 3.5mm plug of the supplied lead into the USB receiver (7) and
connect the 6.3mm plug to the appropriate microphone input jack on the mixer
or amplifier.
Note: The output of both of the beltpack transmitters is mixed to the same single
3.5mm output.
Each beltpack transmitter has an on/off switch (4), which should be in the up
position (off). The top volume control (1) should be turned fully down. Connect
the neckband microphone to the 3.5mm microphone input (2).
Slide open the cover of the battery compartment (5) and insert 2 x AA alkaline
batteries per transmitter, ensuring that the polarity is the correct way around.
Move the switch down to the “on” position and the power indicator (3) should
light. Note that the switch has a centre position which is also “on”.
Gradually turn up the volume control on top of each beltpack transmitter and the
level on the mixer or amplifier and speak into the neckband microphones in turn
until the sound can be heard through the connected speakers or recording
equipment. Increase the volume to the required level.
If the microphones are not being used, turn down the volume level on the top of
each beltpack transmitter and the mixer/amplifier and switch the power off.
For long term storage, unplug the jack and USB receiver and remove the
batteries from both beltpack transmitters.

171.812UK User Manual
Specifications
Carrier frequency
863.2MHz + 864.8MHz
RF power
10mW
Power supply: transmitter
2 x AA batteries (each)
Power supply: receiver
5Vdc 1000mA (USB)
Frequency response
50Hz - 15kHz
Capsule
Back electret condenser
Output connection
3.5mm mono jack
Wireless range
Up to 50m
Dimensions: transmitter
105 x 65 x 30mm each
Weight: transmitter
67g (no battery) each
Dimensions: receiver
80 x 34 x 15mm
Weight: receiver
17g
Disposal: The “Crossed Wheelie Bin” symbol on the product means that the product is classed as
Electrical or Electronic equipment and should not be disposed with other household or commercial waste
at the end of its useful life. The goods must be disposed of according to your local council guidelines.
Hereby, AVSL Group Ltd. declares that the radio equipment type 171.812UK is in compliance
with Directive 2014/53/EU
The full text of the EU declaration of conformity is available at the following internet address:
http://www.avsl.com/assets/doc/1/7/171812UK.pdf
Errors and omissions excepted. Copyright© 2020. AVSL Group Ltd.
Unit 2-4 Bridgewater Park, Taylor Rd. Manchester M41 7JQ
