LEF-5 & LEF-10 Intercom Connections

The following are instructions for connecting PTI Remote Keypad with Intercom, CodeXpress with Intercom and APEX Access

Devices with intercom to the Aiphone LEF-5 or LEF-10 Open Voice Selective Call Intercom Base Station. There are two

options for this connection (Single LEF Intercom Base Station and LEF Dual Intercom Base Station). Planning and installing the

wiring of a site is a process that requires a high degree of technical knowledge, PTI recommends that this be done by a

knowledgeable, trained professional. Please read this entire document before proceeding. Follow these steps in order. If you

have questions about installing or troubleshooting the LEF, contact Aiphone technical support by telephone at (800) 692-0200,

by email at Tech-Serv@aiphone.com or on the web at www.aiphone.com. If you have questions about PTI access devices,

please contact our Technical Support Department by telephone at (480) 941-1513 or by email at [email protected]om.

Warning – Incorrect installation of electrical components can result in damage to electronics as well as personal injury.

Warning – Failure to follow prudent installation guidelines and concepts can result in long-term problems.

Warning – Crosswiring DC+ to DC– or to common (E) will damage the electronics.

Warning – Crosswiring Intercom + to Intercom – or to common (E) will damage the electronics.

Warning – Introducing AC power into the LEF Intercom Base Station will damage the electronics.

Warning – Running Intercom wires in the same conduit as high voltage will generate noise on the intercom.

Option I – Single LEF Intercom Base Station

This is the most common LEF Installation with 1 – 10 remote intercoms and one LEF 5 or 10 Base Station Unit in the office.

Please note, the LEF-5 and LEF-10 look very similar, differing only in the number of screw terminals on the terminal block.

1. Run a separate 18awg, 2 conductor, shielded cable from the LEF Intercom Base Station to each remote intercom

location. Strip back the outside insulation and inner foil layer of the cable approximately 2” from each end, being

careful not to damage the bare shield wire or the insulation around either conductor. 2 spade connectors and 2 wire

nuts/crimp connectors are required for each remote. Spade connectors, wire nuts, and/or 3M crimp connectors must be

provided by the installer. The maximum distance per Aiphone is 1600’ with 18 awg wire.

2. At each Keypad with Intercom or CodeXpress with LEF Intercom, connect the Intercom + (generally the Red wire) to

the Red + wire coming from the intercom button in the Keypad or CodeXpress. Connect the Common (E) wire to the

Black/Green wires coming from the speaker and intercom button in the Keypad or CodeXpress. Use a wire nut or 3M

UY2 connector for to make these splices. Wrap the splice connection with electrical tape to seal it. See Correct

Splicing Techniques document.

3. At each APEX Series Access Device with LEF Intercom, connect Intercom + and Intercom – wires to the tan intercom

terminal block. This terminal block is located in the Upper left hand corner of the circuit board, next to the speaker,

directly below the black terminal block containing all of the speaker and intercom button wire connections. Strip the

Intercom + and Common (E) wires back ¼”. Insert the Intercom + wire in the top (1) position on the tan terminal block

and tighten down the screw connection. Insert the Common (E) in the center (E) position on the tan terminal block and

tighten down the screw connection. On the APEX circuit board, slightly above the tan terminal block and to the right of

the black terminal block is a jumper. Verify that the jumper is set to “LEF Single Station”.

4. At each Remote (APEX, Keypad with Intercom, CodeXpress with Intercom), fold back the bare shield wire even with

the insulation on the cable and wrap electrical tape around the end of the insulation to make sure that the bare shield

wire and foil insulation cannot touch the components inside the remote. If the intercom is receiving interference or has

noise on it, one or both ends of this bare shield wire can be tied to the Common (E) to help reduce interference.

Z:\Quick Documentation\Intercoms\Aiphone\LEF\LEF 5 & 10 Intercom Connections.doc – last updated 02/26/03 rsl

2 of 9

PTI Integrated Systems

LEF-5 & Lef-10 Intercom Connections

Technical Support Form

8271 East Gelding Drive Scottsdale, AZ

85260

Phone: 480-941-1513 Fax: 480-346-

3817

LEF-5 & LEF-10 Intercom Connections (Page 2)

5. At the LEF Intercom Base Station, connect the Common (E) from all of the remotes to the (E) terminal on the terminal

strip using spade connectors. Connect the Intercom + wire from the first remote to the (1) terminal on the terminal strip

using a spade connector. Connect the Intercom + wire from the second remote to the (2) terminal on the terminal strip

using a spade connector. Connect the Intercom + wire from the third remote to the (3) terminal on the terminal strip

using a spade connector. Continue connecting the Intercom + wires from each remote to the next numbered terminal in

line until all remotes are connected. Fold back the bare shield wire even with the insulation on the cable and wrap

electrical tape around the end of the insulation to make sure that the bare shield wire and foil insulation cannot touch the

components inside the remote. If the intercom is receiving interference or has noise on it, one or both ends of this bare

shield wire can be tied to the Common (E) to help reduce interference. Do not wrap wires around the terminal screws.

Warning – There is a jumper between Intercom – and common (E) that must remain in place. Do not remove this.

6. Verify that there aren’t any stray wires touching the terminal strip connections and verify that all of the connections are

made correctly. If any connections are miswired or crosswired, the electronics will be damaged when power is

connected. This is NOT a warranty issue.

7. Do NOT plug the transformer into 120V power until all connections are made. At the LEF Intercom Base Station,

connect the DC– wire from the transformer power plug cord to the (–) terminal on the terminal strip using a spade

connector. Then, connect the DC+ wire from the transformer power plug cord to the (+) terminal on the terminal strip

using a spade connector. Do not wrap wires around the terminal screws.

8. Close the LEF case and test the intercoms. Refer to the LEF Instruction Manual that accompanies the LEF 5 or LEF 10

for instructions on mounting, troubleshooting, and operating the LEF Intercom Base Station.

LEF Intercoms are manufactured by Aiphone and are not warrantied by PTI Integrated Systems. All potential warranty issues must be referred to Aiphone.

These guidelines are subject to change without notice. With any setup or configuration, some troubleshooting and adjustment of the configuration may be

required. This will differ with every installation depending on many outside and site-specific variables. This troubleshooting and configuration may include

purchasing additional equipment. In no circumstances will PTI Integrated Systems be responsible for any damages either incidental or consequential based on
