Pullman Holt Gloss Boss GB-1500F Application guide

Save For Future Reference
Replacement Parts List
“Gloss Boss” Burnisher GB-1500F

10702 N 46th Street • Tampa, FL 33617
[phone] • toll free [phone]
fax [phone] • order entry fax [phone]
www.pullmanholtcorp. com B701292 Rev. 2/00
REPLACEMENT PARTS LIST
Ref. B
No. Part No. Description Qty.
1 B600021 Switch Box 1
2 B932046 Right Handle Grip 1
3 B980547 Circuit Breaker 1
4 B932062 Trigger Sleeve 2
5 B980302 Trigger 1
6 B205079 Switch Box Cover 1
7 B932631 Screw (8-32 x 1/2”)3
8 B930431 Switch Assembly 1
9 B932123 Trigger Spring 1
10 B932721 Nut w/Integral LockWasher 2
11 B524548 Safety Latch Spring 1
12 B524244 Safety Latch 1
13 B524825 Safety Latch Spacer 1
14 B914705 Ring 1
15 B524716 Left Handle Grip 1
16 B930404 Cord Set (14/3x50 ft.) 1
17 B205084 Strain Relief 1
18 B525046 Cordset (14/3x33”)1
19 B525311 Restraint Shroud 1
20 B524399 Handle Plug 1
21 B524393 Bushing 2
22 B525022 Handle Pipe 1
23 B932090 Cord Hook 1
24 B932647 Screw (8-32 x 3/8”)2
25 B522777 Ammeter 1
26 B522795 Ammeter Housing 1
27 B800037 Lead Assembly 2
28 B932668 Screw (10-32 x 1/2”)2
29 B527092 Canopy Bumper 1
30 B205081 Motor Canopy 1
31 B930522 Canopy Spacer 1
32 B932599 Nut (5/16”- 18) 1
33 B932664 Flat Washer 1
34 B932648 Flat Washer 2
35 B524356 Handle Latch Pin 1
36 B524384 Handle Release Spring 1
37 B522102 Bumper Pad 1
38 B524320 Shoulder Bolt (3/8-16x2”)1
39 B980257 Screw (1/2”-20 x 5/16”)1
40 B526149 2”Pedal Disc 1
41 B524856 Pedal Release 1
42 B522799 Knob and STEMAssembly 1
43 B522506 Bushing 1
44 B524344 Chassis 1
45 B932159 4”Wheel 2
47 B524064 Belleville Washer 1
Ref. B
No. Part No. Description Qty.
48 B932683 Nut (1/2-13) 1
49 B522505 Washer 2
50 B980565 6”Wheel 2
51 B522772 Shoulder Bolt (1/2”x 1 3/4”)2
52 B960501 Flat Washer 4
53 B932599 Nut (5/16”-18) 4
54 B931308 Screw (#10 x 1/2”)3
55 B700378 Pad Lock Device 1
56 B932589 Screw (5/16”-18x 1-1/2”)4
57 B932665 Split Lock Washer 4
58 B960501 Flat Washer 4
59 B980559 Pad Driver 1
60 B522774 Drive Belt 1
61 B980550 Tapered Bushing 1
62 B522782 Wheel Adjustment Bracket 1
63 B522768 Motor Pulley 1
64 B521479 Lock Nut (3/8”-16) 2
65 B522771 Washer 2
66 B932599 Lock Nut (5/16”-18) 1
67 B932664 Flat Washer 3
68 B914705 Retaining Ring 2
69 B914679 Setscrew (5/16”-18) 2
70 B980586 Driven Pulley 1
71 B932684 Lock Nut (3/8”-16) 4
72 B960501 Flat Washer 4
73 B521111 Flange Bearing 2
74 B980570 Cam Tensioner 1
75 B932679 Screw (5/15-18 x 1”)1
76 B980554 Shaft Bearing 1
77 B932648 Flat Washer 4
78 B980571 Screw (3/8”-16x2”)4
79 B932969 Motor Gasket 1
80 B980548 1.5 HP Motor 1
81 B932679 Screw (5/16”-18 x 1”)4
82 B932702 Screw (10-24 x 3/4”)6
83 B980564 Handle Cap 1
84 B980562 Handle 1
85 B932716 Screw (8-32) 2
86 B980563 Handle Bracket 1
87 B524866 Shroud Assembly 1
88 B521479 3/8-16 Lock Nut 2
Motor Parts Not Shown
B527371 Capacitor (run)
B527353 Capacitor (start)
B527345 Stationary Switch
B527348 Rotor Switch
