Pullman Holt Gloss Boss GB-1500X Application guide

Save For Future Reference
Replacement Parts List
“Gloss Boss” Burnisher GB-1500X

10702 N 46th Street • Tampa, FL 33617
[phone] • toll free [phone]
fax [phone] • order entry fax [phone]
www.pullmanholtcorp. com B703453 1/99
REPLACEMENT PARTS LIST: CHASSIS & HANDLE ASSEMBLY
Ref. B
No. Part No. Description Qty.
1 B527633 Switch Box w/Safety Latch 1
2 B932046 Right Handle Grip 1
3 B980547 Circuit Breaker 1
4 B932062 Trigger Sleeve 2
5 B980302 Trigger 1
6 B205079 Switch Box Cover 1
7 B932631 Screw (8-32x1/2”)3
8 B930431 Switch Assembly 1
9 B932123 Trigger Spring 1
11 B524548 Safety Latch Spring 1
12 B524244 Safety Latch 1
13 B524825 Safety Latch Spacer 1
14 B914705 Ring 1
15 B524716 Left Handle Grip 1
16 B930404 Cord Set (14/3x50ft) 1
17 B205084 Strain Relief 1
18 B525046 Cordset (14/3x33”)1
19 B525311 Restraint Shroud 1
20 B524399 Handle Plug 1
21 B524393 Bushing 2
22 B525022 Handle Pipe 1
23 B932090 Cord Hook 1
24 B932647 Screw (8-32x3/8”)2
27 B800037 Lead Assembly 2
28 B932668 Screw (10-32x1/2”)2
29 B527092 Canopy Bumper 1
30 B205081 Motor Canopy 1
31 B930522 Canopy Spacer 1
32 B932599 Nut (5/16”- 18) 1
33 B932664 Flat Washer 1
34 B932648 Flat Washer 2
35 B524356 Handle Latch Pin 1
36 B524384 Handle Release Spring 1
37 B522102 Bumper Pad 1
38 B524320 Shoulder Bolt (3/8-16x2”)1
39 B980257 Screw (1/2”-20x5/16”)1
40 B526149 2”Pedal Disc 1
41 B524856 Pedal Release 1
44 B200519 Chassis 1
45 B932159 4”Wheel 2
46 B932661 Acorn Nut (3/8”-16) 2
Ref. B
No. Part No. Description Qty.
50 B980565 6”Wheel 2
52 B960501 Flat Washer 4
53 B932599 Nut (5/16”-18) 4
54 B931308 Screw (#10x1/2”)3
55 B700378 Pad Lock Device 1
56 B932589 Screw (5/16”-18x1 1/4”)4
57 B932665 Split Lock Washer 4
58 B960501 Flat Washer 4
59 B980559 Pad Driver 1
60 B522774 Drive Belt 1
61 B980550 Tapered Bushing 1
63 B522768 Motor Pulley 1
66 B932599 Lock Nut (5/16”-18) 1
67 B932664 Flat Washer 3
68 B914705 Retaining Ring 2
69 B914679 Setscrew (5/16”-18) 2
70 B980586 Driven Pulley 1
71 B932684 Lock Nut (3/8”- 16) 4
72 B960501 Flat Washer 4
73 B521111 Flange Bearing 2
74 B980570 Cam Tensioner 1
75 B932679 Screw (5/16-18x1”)1
76 B980554 Shaft Bearing 1
77 B932648 Flat Washer 4
78 B980571 Screw (3/8”-16x2”)4
79 B932969 Motor Gasket 1
80 B980548 1.5 HP Motor 1
81 B932679 Screw (5/16”-18x1”)4
82 B932702 Screw (10-24x3/4”)6
83 B980564 Handle Cap 1
84 B980562 Handle 1
85 B980563 Handle Bracket 1
86 B932716 Screw (8-32) 2
87 B524866 Shroud Assembly 1
Motor Parts Not Shown
B527360 Capacitor (run)
B527353 Capacitor (start)
B527345 Stationary Switch
B527348 Rotor Switch
WARNING : Always disconnect power cable from electrical outlet when working on this machine.
Trouble Shooting Guide
Symptom Possible Cause(s) Corrective Action
Motor Won’t Run 1) Circuit breaker open on handle 1) Reset circuit breaker
2) Blown fuse or tripped circuit 2) Replace fuse or reset circuit breaker
3) Defective switch 3) Replace switch
4) Defective power cord 4) Replace power cord
5) Low in voltage 5) If voltage under recommended minimum,check size of wiring
from main switch. If okay, contact power company.
6) Defective motor capacitor 6) Refer to service center
7) Pad loaded,heavily soiled 7) Clean or replace pad
8) Loose or broken belt 8) Tighten or replace belt
Machine Noisy 1) Defective motor 1) Return to service center
2) Dry bearings 2) Replace the bearing or return to service center.
Machine Vibrates 1) Pad 1) Check pad for unevenness. Change if necessary
2) Drive block 2) Check wooden drive block for cracks,chips or wax and dirt
build-up. Replace or clean block.
