Pullman Holt UV5 User manual

Ref Part No.
1 B160558
2 B230366
3 B160559
4 B230368
5 B230369
6 B230370
7 B230371
8 B230372
9 B230373
10 B230374
11 B230375
12 B230376
13 B160560
14 B160561
15 B230379
16 B230382
17 B230383
18 n/a
19 n/a
20 B230384
21 B230385
22 B230386
23 B230387
24 B230388
25 B160562
26 B230389
27 B230390
28 B230391
29 B230392
30 B230393
31 B230394
32 B230395
33 B230396
34 B230397
35 B230398
36 B230399
37 B160563
38 B160564
39 B160565
40 B230400
41 B230401
42 B230403
43 n/a
44 B230398
45 n/a
B200672
A B230377
B B230378
C B230380
D B230381
EB230402
F B230404
UV5 Motor Housing
and Power Nozzle

Description Qty
Wheel, Rear 2
Air Duct Assembly 1
Motor Assembly Kit (includes C,D) 1
Bearing, Pivot 2
Foam, Sound, Motor Housing Front Panel 1
Motor Housing 1
Foam, Sound Motor L Panel 1
Foam, Sound, Motor Housing R Panel 1
Bulkhead, Black 1
Seal, Lower Air Duct, 1
Upper Motor Mount 1
Lower Motor Mount 1
HEPA Exhaust Filter 1
Exhaust Filter Cov er 1
Upper Air Duct 1
Screws, Phillips, 4.2mm x 12mm 2
Screws, Phillips, 4.2mm x 19mm 2
Motor Housing Sound Filter Kit (# 5,7,8) 1
Lower Air Duct Kit (# 2,10,17) 1
Power Nozzle Cover w/Detent Springs, decal 1
1
Switch, Safety, Power Nozzle Lockout 1
Circuit Breaker 1
Screws, Phillips, 2.9mmx13mm, F/br retainer 4
Retainer, Brush Roll 2
Brush Roll, Power Nozzle 14" 1
Bumper, Power Nozzle, Vinyl 1
Seal, Base Cover, Air Duct, Left, 7.5" long 1
Seal, Base Cover, Air Duct, Right, 5.5" long 1
Brace, Formed Wire, F/Power Nozzzle Base 2
Baseplate, Power Nozzle 1
Screw, Phillips, 4.2mm x 32mm F/Base Cover 8
Roller, Front 2
Shaft, Front Roller Axle 2
Clamp, Rear Wheel 1
Screw, Phillips, 4.2mmx19mm F/Powerhead 5
Sleeve, Hose, Air Duct 1
Hose, Power Nozzle to Air Duct, Lower 1
Belt, Drive, F/Brush Roll 1
Brush Motor 1
Grommet, Vibration, Power Nozzle Motor 2
Cover, Air Duct, Power Nozzle 1
Board, Vacuum, Operation Indicator 1
Spring, Detent, Upright Lock 2
Screw, Phillips, 4.2mmx19mm, F/Power Nozzle Motor 1
Carbon Brushes/Motor 2
Wire Harness Kit Includes( A,B,C,D,E,F) 1/st
Sensor, bag full indiator
Harness, Wire, main power supply
Harness, Jumper, white
Harness, Jumper, red
Harness, Wire, Power Nozzle
Harnerr, Power Nozzle Switch
