Pulsar Flow Monitor User manual

Flow Monitor
INSTRUCTION MANUAL

FLOW MONITOR (SECOND EDITION REV 4)
February 2020
Part Number M-560-A-002-4P
COPYRIGHT
© Pulsar Process Measurement Limited, 2003-20. All rights reserved. No part of this publication may
be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in
any form without the written permission of Pulsar Process Measurement Limited.
WARRANTY AND LIABILITY
Pulsar Process Measurement Limited guarantee for a period of 2 years from the date of delivery that it
will either exchange or repair any part of this product returned to Pulsar Process Measurement
Limited if it is found to be defective in material or workmanship, subject to the defect not being due to
unfair wear and tear, misuse, modification or alteration, accident, misapplication or negligence.
DISCLAIMER
Pulsar Process Measurement Limited neither gives nor implies any process guarantee for this product
and shall have no liability in respect of any loss, injury or damage whatsoever arising out of the
application or use of any product or circuit described herein. Every effort has been made to ensure
accuracy of this documentation, but Pulsar Process Measurement Limited cannot be held liable for
any errors.
Pulsar Process Measurement Limited operates a policy of constant development and improvement and
reserves the right to amend technical details as necessary. The Flow Monitor shown on the cover of
this manual is used for illustrative purposes only and may not be representative of the actual Flow
Monitor supplied.
COMMENTS,SUGGESTIONS AND TECHNICAL ENQUIRIES
Please contact Pulsar Measurement if you have any comments, suggestions or if you require technical
support using the information below:
UK Office
Canada Office
USA Office
Pulsar Process Measurement Ltd.
Cardinal Building
Enigma Business Centre
Sandy’s Road
Malvern
Worcestershire
WR14 1JJ
United Kingdom
Greyline Instruments Inc.
16456 Sixsmith Drive
Long Sault
ON
K0C 1P0
Canada
Greyline Instruments Inc.
11451 Belcher Road South
Largo
FL 33773
USA
Tel: [phone]
Fax: [phone]
Tel:
Toll Free:
Fax:
613-938-8956
855-300-9151
613-938-4857
Tel:
Tax Free:
Fax:
315-788-9500
888-473-9546
315-764-0419
Website:
www.pulsar-pm.com
General Information email:
[email protected]
Technical Support email:
[e-mail]
Website:
www.greyline.com
General Information email:
[e-mail]
Technical Support email:
[e-mail]
Website:
www.greyline.com
General Information email:
[e-mail]
Technical Support email:
[e-mail]

...................................................................................................................1
About this Manual........................................................................................................................................... 1
About the Flow Monitor.................................................................................................................................2
Product Specification.......................................................................................................................................3
EU Declaration of Conformity .......................................................................................................................4
.....................................................................................................................5
Unpacking........................................................................................................................................................ 5
Power Supply Requirements...........................................................................................................................5
Location...........................................................................................................................................................5
Dimensions......................................................................................................................................................6
Cable Entry..............................................................................................................................................7
Terminal Connection Detail....................................................................................................................8
Terminal Connections.....................................................................................................................................9
AC and Fuse Location...................................................................................................................................10
Preparation for Operation..............................................................................................................................10
Maintenance...................................................................................................................................................10
........................................................11
Operating the Controls..................................................................................................................................12
Display...................................................................................................................................................12
Keypad...........................................................................................................................................................13
Run Mode......................................................................................................................................................15
LED’s.....................................................................................................................................................15
Program Mode...............................................................................................................................................16
How to Access Program Mode.............................................................................................................16
Test Mode......................................................................................................................................................18
Using the RS232 Serial Interface..................................................................................................................19
Parameter Defaults........................................................................................................................................19
Factory Defaults.....................................................................................................................................19
................................................................................................21
Menu System Diagrams................................................................................................................................21
Top Level Menu....................................................................................................................................21
Application Menu..................................................................................................................................22
RelaysMenu..........................................................................................................................................23
Display Menu ........................................................................................................................................24
mA Output Menu ..................................................................................................................................25
Totaliser Menu.......................................................................................................................................25
System Menu.........................................................................................................................................26
Test Menu ..............................................................................................................................................27
Application Parameters.................................................................................................................................28
Operation................................................................................................................................................28
Device Comms......................................................................................................................................31
Relay Parameters...........................................................................................................................................33
Relay Type.............................................................................................................................................33
Alarms....................................................................................................................................................34
Control....................................................................................................................................................37
Totaliser..................................................................................................................................................38
Common Parameters.............................................................................................................................38
Display Parameters........................................................................................................................................39
Options...................................................................................................................................................39
Failsafe...................................................................................................................................................40
Auxiliary................................................................................................................................................41
mA Output Parameters..................................................................................................................................41
Range.....................................................................................................................................................41
Operation................................................................................................................................................42

Setpoint..................................................................................................................................................42
Limits..................................................................................................................................................... 42
Trim.......................................................................................................................................................43
Failsafe...................................................................................................................................................43
Totaliser Parameters......................................................................................................................................44
Setup.......................................................................................................................................................44
Totalisers................................................................................................................................................45
Tot. Audit...............................................................................................................................................45
System Parameters........................................................................................................................................46
Passcode.................................................................................................................................................46
System Information............................................................................................................................... 46
Date & Time.......................................................................................................................................... 47
Daylight Saving Time........................................................................................................................... 47
Test Parameters.............................................................................................................................................51
Simulation..............................................................................................................................................51
Hardware................................................................................................................................................ 52
...................................................................................................53
.........................................................................................................................54
............................................................................................................................................................ 55

Page 1
Congratulations on your purchase of a Pulsar Flow Monitor System. This
quality system has been developed over many years and represents the latest
in high technology ultrasonic flow and velocity measurement and control.
It has been designed to give you years of trouble free performance, and a
few minutes spent reading this operating manual will ensure that your
installation is as simple as possible.
About this Manual
It is important that this manual is referred to for correct installation and
operation.
There are various parts of the manual that offer additional help or
information as shown.
Tips Tip
At various parts of
this manual you will
find tips to help you.
Additional Information
Additional Information
At various parts of the manual, you will find sections
like this that explain specific things in more detail.
References
See Also
References to other parts of the manual

Page 2
About the Flow Monitor
The Pulsar Flow Monitor has been designed to provide a simple interface to
the Pulsar Flow Pulse Sensor.
Housed in an IP67 enclosure the product is ideally suited to applications
where velocity monitoring, reporting or control is required.
The controller is very easy to use and may be quickly and simply setup via
the on-board keypad and display.
The Flow Monitor is designed to provide you with highly reliable
measurement in a robust and functional package that is easy to use and low
in cost.

Page 3
Product Specification
Wall Mount
Outside dimensions 130 x 150 x 63.5 mm
Weight Nominal 0.65 kg
Enclosure material/description ABS base with Polycarbonate lid,
flammability rating UL94HB
Cable entry detail underside fitted with 3 x M20, nylon cable
glands suitable for 6 –12mm cable
Sensor cable extensions 5-core screened
Maximum separation 500 m
IP Rating IP66/67
Max. & min. temperature (electronics) -20 ºC to +50 ºC
CE approval See EU Declaration of Conformity
Max. range 6 m/s
Min. range 0.3 m/s
Analogue output Isolated active output (passive output
optional) of 4-20 mA or 0-20 mA into 1K

(user programmable and adjustable) 0.1%
resolution
Display 2 x 12 alpha numeric
Serial Port RS232 for programming and data extraction
Volt free contacts, number and rating 2 form "C" (SPDT) rated at 2A at 240V AC
On-board programming (standard) By integral keypad
Programming security Via passcode (user selectable and
adjustable)
Programmed data integrity Via non-volatile RAM
Power supply 85 –264V ac 50/60 Hz,
DC 22 - 28V
10W maximum power (typically 8W)
Mains Fuse 2A ‘T’ 20mm
DC Fuse Self Resetting Type
Pulsar Process Measurement Limited operates a policy of constant development and
improvement and reserve the right to amend technical details as necessary.

Page 4
EU Declaration of Conformity

Page 5
Unpacking
Power Supply Requirements
The Flow Monitor can operate from AC supply or from a DC battery. The
AC is 85 –264V, 50/60Hz. The DC is 22 - 28V. In all cases the Flow
Monitor will typically consume 8W of power, with a maximum of 10W.
Location
All electronic products are susceptible to electrostatic
shock, so follow proper grounding procedures during
installation.
The Flow Monitor must be mounted in a non-hazardous (safe) Area.
When choosing a location to mount the enclosure, bear in mind the
following:
•Easy access to the enclosure is maintained.
•The mounting surface is vibration-free.
•The ambient temperature is between -20ºC and 50ºC.
•There should be no high voltage cables or inverters close by.
Important Information
All shipping cartons should be opened carefully. When using a box cutter,
do not plunge the blade deeply into the box, as it could potentially cut or
scratch equipment components. Carefully remove equipment from each
carton, checking it against the packing list before discarding any packing
material. If there is any shortage or obvious shipping damage to the
equipment, report it immediately to Pulsar Process Measurement Limited.

Page 6
Dimensions
The dimensions of the mounting holes are as shown below.
The Flow Monitor should be mounted by drilling four holes suitable for size
8 screws (length and type to suit your application) And fix all four screws by
removing the top cover to access the pre-moulded mounting holes which are
located in the base of the enclosure under the lid retaining screws.

Page 7
The full dimensions of the enclosure are as shown below.
Cable Entry
There are 3 x M20 cable glands, suitable for 6 –12mm cables, fitted to the
base of the Flow Monitor enclosure.
Important Information
All cable glands should be tightened to the manufacturer’s specifications.
The terminal compartment cover screws should be tightened to 0.5Nm
Care should be taken not to over tighten the screws.
Care should be taken not to over tighten the screws.

Page 8
Terminal Connection Detail
*On older versions of Flow Monitor the RS485 Screen is connected to terminal
21 (not shown on the above diagram).
Terminal Name
Flow Monitor
Terminal
FlowPulse
Terminal
0V (GND)
22
1
24V DC
23
2
*RS485 SCR
26
8
RS485 +
24
9
RS485 -
25
10
Cable Screen
3 or 6
Not connected
SCREEN NOT
CONNECTED
THIS END.
SCREEN
0V
GND
24V
PWR

Page 9
Terminal Connections
Power
The Flow Monitor can be powered from mains AC or from a DC
source/battery and where a backup DC power source is connected it will
automatically take over in the event of AC power failure; DC will
automatically power the unit. When AC returns it will switch back.
FlowPulse Sensor
The FlowPulse sensor should be installed and connected, in accordance with
the FlowPulse manual.
Wire the FlowPulse sensor to the Flow Monitor sensor terminals, as on the
previous page.
Relay Outputs
The two relays can be programmed to a variety of alarm & control
functions. The relay contacts are all rated at 2A at 240V AC. All
connections should be such that the short circuit capacity of the circuit to
which they are connected, is limited by fuses rated so that they do not
exceed the relay rating.
Current Output
This is an isolated active mA output of 4 - 20mA or 0 - 20mA, with an
option of a passive mA output. The load should not exceed 1K

.
RS485 termination switch
By default, this is switched off, to enable RS485 termination both switches
need to be switched to the ON position.
Important Information
If the equipment is installed or used in a manner not specified in this manual,
then the protection provided by the equipment may be impaired.

Page 10
AC and Fuse Location
AC mains power fuse is located, on bottom board to the left and above of the
power input terminals, as previously illustrated in the Terminal Connections Detail
drawing.
Important Information
Never operate the Flow Monitor with the cover open.
An external switch or circuit breaker should be installed near to the Flow
Monitor to allow the supply to be removed during installation and
maintenance. In addition, the relay contacts should also have a means of
isolating them from the Flow Monitor.
Interconnecting cables must be adequately insulated in accordance with local
regulations. Strip back 30 mm of the outer insulation of the cable. Strip 5 mm
of insulation from the end of each conductor. Twist all exposed strands of the
conductor together. Insert the stripped conductor into the terminal block as far
as it will go and tighten the terminal block screw. Ensure that all strands are
firmly clamped in the terminal block and that there is no excess bare
conductor showing, and no stray strands.
Preparation for Operation
Before switching on, check the following:
✓The Flow Monitor is mounted correctly and is in a ‘safe’ area.
✓The power supply is correctly installed.
✓The relays are connected correctly.
Maintenance
There are no user serviceable parts inside your Flow Monitor, except the
mains power fuse. If you experience any problems with the unit, then please
contact your local Pulsar Process Measurement distributor for advice.
To clean the equipment, wipe with a damp cloth. Do not use any solvents on
the enclosure.

Page 11
Your Flow Monitor can be programmed directly via the integral keypad.

Page 12
Operating the Controls
Display
Whilst in the Run Mode it will display the current flow or velocity reading
and its units of measurement, along with the mA output and status messages
with regards to the communication status and Fail Safe Mode.
When in Program mode, the display is used to read information on the menu
system, the parameter number and parameter details and values, which can
be entered.
During Test Mode the display is used to monitor the simulated flow or
velocity and mA output.
1) Main Display, 12-digit alpha numeric display:
Run Mode:current measurement displayed, dependent on measurement
unit's chosen, and value of Hot Key function selected.
Program Mode: displays parameter number and values entered for
parameters.
Test Mode: displays simulated flow or velocity.
2) Auxiliary Display, scrolling 12-digit alpha numeric display
Run Mode: displays units, totaliser or status messages on
communications, detail of Hot Key function selected.
Program Mode: displays Menu and Sub Menu headings, parameter
details and options.
0.53
Litres/sec
1
2

Page 13
Keypad
Hot Keys
There are five hot keys on the keypad, which can be used to quickly access
common parameters for viewing only, while in Run Mode. Pressing the hot
key once will display the first parameter, then repeated pressing will display
the others, then the Flow Monitor reverts to Run Mode. In program mode,
they have different functions, the functions are shown below.
Hot
Key
Run Mode
Program Mode
System totaliser and resettable
totaliser
Not used with Flow Monitor.
Confidence level and signal
strength.
Not used with Flow Monitor.
Not used with Flow Monitor.
Reset parameter to default
setting.
Instantaneous mA output.
Not used with Flow Monitor.
Flow and velocity readings
Not used with Flow Monitor.
Not used with Flow Monitor.
Takes you to the last
parameter edited, when you
first enter program mode.
Gives details of unit type,
serial number and software
revision
Enter Decimal Point

Page 14
Menu Keys
The menu keys are used to navigate around the built in menu system and
have the following functions:
Menu Key
Function
1) Arrow keys for moving left and right around the menu
system.
2) Used in test mode to simulate the flow or velocity
moving up and down.
1) Used to confirm each action (for example select a
menu option) or when entering a parameter number or
value.
2) Used to confirm questions asked by your Flow
Monitor such as before restoring factory defaults.
Used to navigate up a level in the menu system, and back
to run mode.
Used to cancel a value entered in error.
Numeric Keys
These keys are used for entering all numerical information when in
programming mode.
