Pulsar go Series User manual

Thank you for purchasing the Pulsar®Go
Series Wax/Smoker! In order to ensure
safe use, please read all instructions
and safety warnings before operating.
Failure to follow instructions may result in
injury and may void your warranty.
HELPFUL TIPS:
• Before using you Go Series Wax/
Smoker, first, fully charge the unit, and
then heat the atomizers several times
empty. This will burn off any impurities
collected during manufacturing.
• To load the herb atomizer, place
ground herb directly onto the
Ceramic Power Pad, prior to
heating. Fill about halfway up. Once
loaded, begin heating, and observe
the amount of smoke inside the glass
chamber to gauge the size cloud you
would like to inhale.
• To load the wax atomizer, you can
place your concentrate directly on
the cool quartz coils, prior to heating;
or, you can prime your coils by gently
pre-heating them, and placing your
concentrate on the slightly warmed
coils. Once loaded, begin heating,
and observe the amount of vapor
inside the glass chamber to gauge
TECH SPECS:
• Input: 5V/1A
• Battery Capacity: 1100mAh
• Battery Output: 30W
• Wax Atomizer Resistance: 0.7Ω(Pure
Quartz Chamber - Triple Quartz Coil)
• Herb Atomizer Resistance: 0.5Ω(Pure
Quartz Chamber - Ceramic Power Pad)
• Heating time: 5 seconds
• Temperature Range: 932°F-1112°F
• Temperature Indicator
Red Light: Heating up
Green Light: Device ready
• Micro USB Charging Port
• 5-Minute Safety Auto Shut Off
• Battery Recharge Cycle count: 300+
• Battery Charge Indicator
CHARGING INSTRUCTIONS:
• Battery Power & Charging Indicator
- Green Light: 100%
- Yellow Light: 70%
- Red Light: 30%
- Light glows Red while charging,
turning to Green when fully charged.
the size cloud you would like to inhale.
• For both herb and wax atomizers,
after pressing, and holding the
button for the initial heating time of
5 seconds, release the button,
and then instantly, press again, for
3 seconds and repeat. This
technique of pulsing the atomizers,
simulates “stoking” the material,
like a traditional pipe. Always allow
atomizer to reheat for 5 seconds
after having completely cooled.
• Be sure to turn off the unit when you
are done by pressing the on/off
button 5 times.
KIT CONTENTS:
• Wax/Smoker Unit
• Glass Mouthpiece
• 1x Herb Replaceable Atomizer
• 1x Wax Replaceable Atomizer
• Micro USB Charging Cable
• Cleaning Brush
• Wax Tool
• USB Cable
• Silicone Container

IMPORTANT: You will need to fully
charge your Pulsar®Go Series Wax/
Smoker before using it. Insert charging
cable into unit & the other end into a
dedicated USB port or wall socket if
using AC wall adapter (Not Included).
Set Pulsar®Go Series Wax/Smoker on
its side – do not let unit dangle from
charge cord. This puts pressure on the
charger plug that can result in the unit
not charging fully.
• Battery Charge Time: Allow
approximately 1.5 hours for the first
full charge. Do not charge for more
than 24 hours.
• Battery Charging: Battery indication
light will show charging connection
is made by glowing Red. When fully
charged, light turns to Green.
The Pulsar®Go Series Wax/Smoker
battery will deliver approximately
1.5 hours of continuous power,
depending on use. Both the battery
and chargers are designed to prevent
overcharging. ONLY USE APPROVED
PULSAR® CHARGERS! Failure to do so
can damage the battery, which can
result in property damage or personal
injury and may void the warranty.
Using the Pulsar®Go Series
Wax/Smoker
1. Load the chamber.
2. Turn the unit on by pressing the
button rapidly 5 times. Light will flash
Green 3 times to confirm it is
powering on.
3. The unit will begin heating
immediately after the button is
pressed and held. The LED light
will turn from Red to Green as the unit
reaches the desired temperature
(5 seconds).
- After the initial heating, you can
press, or pulse the button, and
the atomizers will heat almost
instantaneously.
4. Release the button to halt the
heating process as the smoke builds
inside the glass mouthpiece.
5. Inhale.
6. Turn the unit off by pressing the
button rapidly 5 times.
Important Safety Warnings:
Do not expose to extreme
temperature or direct sunlight.
Do not drop the Pulsar®Go Series
Wax/Smoker or accessories.
Do not drop or submerge in any liquid.
Do not modify the electronics in any way.
Only charge using Pulsar®brand
chargers and Pulsar®brand accessories.
Pulsar®Go Series Wax/Smoker is
intended for adults only.
Do not sell or provide to minors.
Keep all parts, herbs, and liquids
away from children and pets.
Pulsar®Go Series Wax/Smoker is not a
medical device and is not intended
to diagnose, treat, mitigate, cure, or
prevent any ailment, disease, or other
conditions. Consult a physician before
use, especially if you suffer from
heart disease or any other medical
condition, or if you are pregnant or
breastfeeding. Failure to follow any
of these instructions could result in
product damage, property damage,
or personal injury.
Limited Warranty:
Pulsar®Go Series Wax/Smoker is guaranteed from
manufacturer defects or malfunction from the
original date of purchase for a period of 1 year.
This limited warranty protects against manufacturer
defects under normal use and does not apply
to normal wear and tear, improper use, and
accidental damage from dropping or submerging
in liquid, improper cleaning, neglect, or any other
damage that is not a result of defective materials or
workmanship. If your Pulsar®Go Series Wax/Smoker
qualifies for servicing, we will repair or replace, at
our discretion and expense, any defective parts
or materials. Purchaser must provide a copy of the
original dated sales receipt and may be required
to provide shipping to return defective parts or
materials. We intend to complete all repairs/
replacements within 7 business days, although
this timeframe may vary depending on shipping,
replacement part availability, or other related
factors. The lawful and proper use of this device is a
condition of sale. Any improper use of the Pulsar®Go
Series Wax/Smoker will void the warranty. Warranty is
nontransferable. This warranty gives you specific legal
rights, and you may also have other rights, which
vary from state to state.
For warranty servicing, contact us at:
www.PulsarVaporizers.com
