PULSEEIGHT HDBaseT Lite User manual

HDBaseT™Lite
HDMI Extender Kit
Quick Setup Guide
P8-HDBT-L-NP-EXSET

SAFETY PRECAUTIONS
Please read all instructions before attempting to install or
operate this equipment.
Please keep the following in mind as you unpack and install
this equipment:
• Always follow basic safety precautions to reduce the risk
of re, electrical shock and injury.
• To prevent re or shock hazard, do not expose the unit
to rain, moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product
through any openings or empty slots in the unit, as you
may damage parts inside the unit.
• Use only the supplied power supply unit (PSU). Do not
use the PSU if it is damaged.
• Do not allow anything to rest on the power cabling or
allow any weight to be placed upon it.
• To protect the unit from overheating, do not block
any vents or openings in the unit housing that provide
ventilation and allow for sucient space for air to
circulate around the unit.

This HDBaseT™ Lite HDMI Extender Kit allows un-compressed HDMI and 2-way
IR signals to be transmitted via a Single CAT5e/6/7 cable; over distances of up
to 70 metres.
PACKAGE CONTENTS
• 1× Transmitter - HDMI to HDBaseT with IR
• 1× Receiver - HDBaseT to HDMI with IR
• 2× IR Emitter
• 2× IR Receiver
• 2× 5V/1.2A DC Power Adaptor
FEATURES
• HDMI 1.4 with 3D, 4K×2K (Ultra HD) support, HDCP and DVI compliant
• Full HDMI 1.4 (including HDCP) via a single CAT5e/6/7 cable up to 70m
• Complies with HDBaseT Class B specications
• Full HD resolution support (1080p@60Hz/36-bit), 3D over 70m, 4Kx2K
(UltraHD) over 40m and PC resolution support (VGA to WUXGA)
• HDMI input up to 15m with 8-bit deep colour or 10m with 12-bit deep colour
• Supports HDMI output up to 15m with 8/12-bit deep colour
• Supports 2-way IR
• Supports High Denition LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and
DTS-HD Master Audio transmission

HDBaseT
Connect with a single CAT5e/6/7 cable for data transmissions.
The Green LED will illuminate when the device is connected to the power supply.
The
Yellow LED will illuminate when both devices are connected and powered.
5V
Connect only to the power supplies provided.
RX (IR Receiver)
Receives signals via the supplied IR receiver cable from your remote
HDMI
Connect to your HDMI equipment.
TX (IR Emitter)
Transmits signals via the supplied IR transmitter cable from your remote
RECEIVER AND TRANSMITTER PORTS
9
9
1
2
3
4
5
1 2 3 4 5

TECHNICAL SPECIFICATIONS
Transmitter
Input 1× HDMI, 1× IR Receiver
Output 1× RJ45, 1× IR Emitter
Receiver
Input 1× RJ45, 1× IR Receiver
Output 1× HDMI, 1× IR Emitter
Max Video Bandwidth 300MHz/10.2Gbps
Power Consumption 3W (TX), 5.5W (RX)
Power Supply 2×5V/1.2A DC
(US/EU standards, CE/FCC/UL certied)
Dimensions 55mm(W) ×82mm (D)×22.5mm (H)/each
Weight 245g (TX), 255g (RX)
Chassis Material Folded Steel
Colour Black
Operating Temperature 0˚C~40˚C/ 32˚F~104˚F
Storage Temperature −20˚C~60˚C/−4˚F~140˚F
Relative Humidity 20~90% RH (non-condensing)
IR PIN ASSIGNMENT
IR EMITTER
Ground
IR Signal
5V
IR RECEIVER
5V
IR Signal
Ground
1
1
2
2
3
3
1
1
2
2
3
3

Should you encounter installation diculties or issues with device communication, the
following checklist of common issues and causes should help resolve your issues.
If you still continue to experience issues, please email [e-mail] for
further assistance
No or poor picture quality:
• Connected and powered? Double check all HDMI, Ethernet and power cables are rmly
connected into the correct ports an all devices are correctly powered
• Cable length? Are you approaching the maximum distance of the cable (70m) if so,
adjust the picture quality or try using an additional extender kit to go further distance.
Cables bundled together may cause cross talk and further degrade signal quality.
• Signal strength? The use of cable joins, stranded patch panels, wall outlands and
stranded patch leads as interconnects between them, can signicantly reduce signal
strength. Use solid core straight through connections wherever possible
• If you reduce the resolution of the source do you get a picture? If so, this suggests a
conicting resolution between source and display or a bandwidth capacity issue with
your cable. Check all inputs and outputs share the same resolution capabilities.
• Picture ‘snow’ / HD ‘hoise’ signies a failure to fully establish a signal and can often be
caused by poorly terminated RJ45 connectors or excess cable lengths. Ensure your
cable is correctly wired to 568B standards.
• Cable quality and condition - HDMI cable/connectors can easily be damaged and the
quality of material can vary, Always use good quality leads and cables and try swapping
cables that are known to be working into the solution to see if this improves your image.
IR control:
• Are the IR emitters and receivers correctly positioned to allow infrared signals to be
transmitted and received through the extender kit? Emitters should be xed rmly over
infrared sensors of sources. Receivers should be attached to displays ensuring a clear
line of sight to the remote control used to operate.
• Is your remote control powered and sending a signal? As IR is invisible to the naked
eye, check your remote is transmitting a signal by viewing the remote handset sensor
thought a digital camera/camera phone. The sensor should ash when a button on the
handset is held down.
• IR signal dropout can be experienced due to exterior emissions of infrared radiation.
Ensure emitters and receivers are away from direct sunlight. Halogen lighting and
plasma screens may also interfere with IR signals
TROUBLESHOOTING

REFERENCE CABLE DISTANCES
Cable Type Range Pixel Clock
Rate
Video Data
Rate
Supported
Video
CAT5e/6/7 70 metres <=225 MHz <=5.3 Gbps
(HD Video)
Up to 1080p,
60Hz, 36-bit, 3D
(data rates lower
than 5.3 Gbps or
below 225 MHz
TMDS clock).
40 metres >225 MHz >5.3 Gbps
(Ultra HD Video)
4K@60 4:2:0,
30Hz video
formats
DISCLAIMERS
The information in this manual has been carefully checked and is believed to be accurate, however,
Pulse-Eight Limited assumes no responsibility for any inaccuracies that may be contained in
this document. Pulse-Eight Limited also makes no commitment to update or to keep current the
information contained in this document.
Pulse-Eight Limited reserves the right to make improvements to this document and/or product at
any time and without notice.
Pulse-Eight Limited assumes no responsibility for any infringements of patents or other rights of
third parties which may result from its use.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system,
or any of its part translated into any language or computer le, in any form or by any means
(electronic, mechanical, magnetic, optical, chemical, manual, or otherwise) without express written
permission and consent from Pulse-Eight Limited.
© Copyright 2013 Pulse-Eight Limited
All Rights Reserved.
Version 1.2 - November 2015
