PULSE+ QUADRA MOON User manual

1
Four Way 220 LED DMX Moonflower
Model: QUADRA MOON
www.pulse-light.co.uk

2
Safety Information
The lightning bolt within a
triangle is intended to alert
the user to the presence of
dangerous voltage levels
within the product s
enclosure.
This voltage may be of
sufficient magnitude to
constitute an electric shock
risk.
To reduce the risk of electric
shock, do not remove cover of
this device. There are no user
serviceable parts inside. Refer
servicing only to qualified
service personnel.
The exclamation point within a
triangle is intended to alert the
user to important operating and
maintenance (servicing)
instructions in the literature
accompanying the appliance.
Safety Precautions
•Read and retain these instructions
•Follow all instructions and heed warnings
•Do not use this device near water or in damp environments
•If the surface becomes dirty, clean only with dry cloth, do not use solvents or thinners
•Install in accordance with the manufacturer s instructions
•Do not install near heat sources such as radiators, heat registers, stoves, or other devices that
produce heat
•Only use accessories specified by the manufacturer
•Refer all servicing to qualified personnel
•If mounting on a stand please ensure the stand has a sufficient load capacity to hold the unit. The
stand must be operated in accordance with the stand manufacturer s instructions.
•Rigging of lighting products should only be carried out by a competent person in accordance with
current guidelines. All fixings used should be correctly rated taking care to observe 10:1 safety
factors and utilise “Secondary” fixings as backup to the primary fixing methods.
•This device must not be exposed to water in any way. No object filled with liquids should be placed
on apparatus

3
Pulse QUADRA MOON – Four Way 0 LED DMX Moonflower
The Pulse QUADRA MOON features 220 super bright, 5mm LED s offering rich colours and a host of
operating modes and effects. Shining thru four optic lenses the 220x 5mm LED s produce a dazzling array
of beams filling dancefloors. The rugged housing features corner guards to help fend off scratches and
bumps.
Features
•220x 5mm LEDs (48 red, 48 green, 48 blue, 28 white, 48 amber)
•LED display with four button menu system for ease of setup
•15 degree beam angle (per lens)
•Built-in programs: Auto, Sound Active, Slave Mode, Static Colour
•DMX controllable (2CH / 3CH)
•3-pin XLR DMX connections
•Integral microphone for Sound Active mode
•IEC power input
•Low power consumption: 40W
•Dimensions (WxHxD): 500x140x285mm (not including brackets)
•Universal input voltage: AC120-240V/50-60Hz
•Weight: 5.1kg
Operation:

4
1) Yoke
The QUADRA MOON is fitted with a hanging yoke to allow rigging from trussing or stands. Care
should be taken to ensure all rigging is carried out by a competent person and that all fixings used
are suitably rated.
2) Hand Wheel
The yoke has tilt adjustment built in. Once the desired angle has been set the hand wheels should
both be tightened. Both hand wheels should be inspected on regular occasions to ensure they are
tight.
3) Lens
Clean the lenses on regular occasions with a soft cloth to ensure the QUADRA MOON operates at
the optimum brightness.
4) Chassis
The chassis of the QUADRA MOON features rugged corner guards to help protect from small
scratches and bumps. Transportation in a padded flight case is recommended. The upper panel of
the chassis features ventilation slots, these should be kept clear of dust and blockages.
5) DMX Input
Standard 3-pin XLR male chassis socket for DMX input. Pin configuration for this product is Pin1=
Ground, Pin2= Negative (-ve) and Pin3= Positive (+ve)
6) DMX Output
Standard 3-pin XLR female chassis socket for DMX input. Pin configuration for this product is Pin1=
Ground, Pin2= Negative (-ve) and Pin3= Positive (+ve).
7) Mains Power Input
The QUADRA MOON operates from a standard mains voltage outlet (AC120-240V/50-60Hz). DO
NOT connect this to a dimmer pack as this can damage the unit and/or the dimmer pack. Dimming
or control of this product is done utilising the onboard DMX functions.
8) Mode
Press the “MODE” button to access the internal menu system and select from the different
operating modes.
9) Setup
Press the “SETUP” button to access the sub menu of a selected operating mode (ie speed control
within Auto mode)

5
10) Up
Press the “UP” button to increase the value of the selected parameter.
11) Down
Press the “DOWN” button to decrease the value of the selected parameter.
12) LED Display
The QUADRA MOON features a four digit LED display allowing the user to setup and program the
unit.
After power on, Press “MENU” button to activate the main menu: Built-in programs mode, Auto
running mode, DMX mode, Slave mode, sound-activated mode.
“SETUP” is to set the relative specification for current mode.
“UP” is to add the value of current specification.
“DOWN” is to decrease the value of current specification.
Built-in Programs: 23 built-in programs allow the user to generate a light show without the need for
a controller. Each program can be adjusted for speed or fade time.
Auto Run: This adds variety to the light show by running the built-in programs one after another in
continuous loop.
DMX mode: Controlled by DMX controller
Slave Mode: Used in conjunction with the Program, Auto, Sound Active or Static Colour modes
Sound Active Mode: In Sound Active mode the fixture will react to the mid/low tones, with each
beat the fixture will move the program forward one step.
Static Colour mode: Static Colours can be preset from 12 selectable colours.
1. Built-in Programs Mode
1. Press MODE, enter the program mode " "
2. Press UP or DOWN button select the program from Pr.01~Pr.23.
FLASH RATE: All built-in programs feature an adjustable flash/strobe mode. Press the SETUP button
while in a selected mode and the display will show " ", using the UP or DOWN button the
flash speed can be adjusted from FS00 thru FS99.
SPEED RATE: Built-in programs Pr.02 thru Pr.10 feature an adjustable fade speed. While the display
shows Pr.02- Pr.10 press the SETUP button, the display will then show " ", the UP or DOWN
buttons will then adjust the programs speed SP01~SP100(FL), a second press of the SETUP button
will then access the flash rate as above.
. Auto run mode
1. Press MODE button, enter the auto program mode “ ”
2. Press SETUP button, the display will show n.001
3. Press UP or DOWN button, setup the number of loops n.001~n.100
4. Press SETUP button, enter setup auto running speed “ ”
5. Press UP or DOWN button, setup the value of speed SP01~SP100 FL
6. Press SETUP button, enter setup auto running program of flash mode“ ”
7. Press UP or DOWN button, setup the value of flash FS00~99
8. Press SETUP button, enter setup auto running program value fade mode “Fd××”
9. Press UP or DOWN button, setup the value fade mode Fd00~99
3. DMX mode
1. Press MODE button, enter DMX mode “ ”
2. Press UP or DOWN button, setup DMX address value d.001—d.512.
3. Press SETUP button, enter setup DMX mode d-P1 (3 channel) or d-P2 (2 channel)
4. Press UP or DOWN button, setup DMX mode : 2-ch or 3-ch

6
DMX mode 1 (d-P1) = 3-CH
CH1
CH1CH1
CH1 CH2
CH2CH2
CH2 CH3
CH3CH3
CH3
NO.
NO.NO.
NO. DMX value
DMX valueDMX value
DMX value FUNCTION
FUNCTIONFUNCTION
FUNCTION SPEED
SPEEDSPEED
SPEED FLASH
FLASHFLASH
FLASH
1 0 OFF NO USE NO USE
2 1--10 PROGRAM01
SPEED
0—255
SPEED
0—255
FLASH
0—255
FLASH
0—255
3 11--21 PROGRAM02
4 22--32 PROGRAM03
5 33--43 PROGRAM04
6 44--54 PROGRAM05
7 55--65 PROGRAM06
8 66--76 PROGRAM07
9 77--87 PROGRAM08
10 88--98 PROGRAM09
11 99--109 PROGRAM10
12 110--120 PROGRAM11
13 121--131 PROGRAM12
14 132--142 PROGRAM13
15 143—153 PROGRAM14
16 154--164 PROGRAM15
17 165--175 PROGRAM16
18 176--186 PROGRAM17
19 187--197 PROGRAM18
20 198--208 PROGRAM19
21 209--219 PROGRAM20
22 220--230 PROGRAM21
23 231--241 PROGRAM22
24 242--252 PROGRAM23
25 253--255 Sound Mod S nsitivity 0—255

7
DMX mode (d-P ) = -CH
CH1
CH1CH1
CH1 CH2
CH2CH2
CH2
NO.
NO.NO.
NO. DMX
DMXDMX
DMX Value
ValueValue
Value FUNCTION
FUNCTIONFUNCTION
FUNCTION FLASH
FLASHFLASH
FLASH
1 0 OFF NO USE
2 1—20 R
FLASH
0—255
3 21—41 G
4 42—62 B
5 63—83 Y
6 84—104 W
7 105—125 RG
8 126—146 GB
9 147—167 BY
10 168—188 YW
11 189—209 RGB
12 210—230 RGBW
13 231—251 RGBYW
14 252--255 Sound activ Mod S nsitivity 0—255
6. Slave Mode
Press the MODE button until the display shows “ ”. The slave fixtures will then mirror the effect
generated by the master (Auto, Master/Slave, Sound Active and Static Colour)
For Master/Slave mode to operate the fixtures must be connected in a chain using the DMX in/out sockets.
The master must be the first fixture in the chain.
6. Sound-active
1. Press the MODE button, until the sound active mode “ ” is displayed on the menu.
2. Press the UP or DOWN button to setup the sensitivity of the sound active menu SU.00~SU.31.
Notice: After 20 seconds inactive, the LED display will switch off. If any button is pressed, the LED display
will be resume to the original state. All buttons will then work as normal.
6. Static Colour Select
Press the “MODE” button to select , there are 12 built-in static color effects. You can select
different effect by pressing “UP” and “DOWN” buttons.

8
Connection:
Pulse DMX fixtures should be connected using high quality, digital signal specific cables to help prevent
connection issues or data errors. It is also best practice to terminate all DMX lines using a DMX Terminator
are available from Pulse retailers & distributors (Code: DMXTERM-3P or DMXTERM-5P). The terminator
should be inserted into the last fixture in each DMX chain.
DMX Pin Configuration
Pin1= Ground
Pin2= Negative (-ve)
Pin3= Positive (+ve).
Care should be taken when manufacturing DMX cables to ensure above pinout is observed. Do not connect
the cable s shield conductor to the ground lug or allow the shield/ground conductor to come in contact
with the XLR s outer casing. Grounding the shield could cause a short circuit and erratic behaviour.
Trouble Shooting:
Unit does not power up: Check mains supply. If mains supply is correct check the fuses in all power
cords and on the fixture. Disconnect all cabling and fixtures from the mains supply before changing mains
fuses.
Unit does not respond to DMX: Check DMX cabling to ensure reliable data connection including DMX
polarity (see diagram above). Check DMX address settings in line with the DMX controller or console.
Unit does not respond to SOUND: The internal microphone features a filter to cancel out high pitched
tones including treble. The fixture will respond to the lower mid and bass tones. The microphone requires
a reasonable sound level before it will activate and trigger the next step.
Compliance
When this product reaches the end of its life, do not dispose with household or general waste. See
www.recycle-more.co.uk for details of how to dispose of PULSE products in an environmentally sound
fashion, or contact PULSE directly via www.pulse-audio.co.uk
Warranty
Pulse products are warranted, by Pulse, against manufacturer defects for a period of one year from the original date
of purchase. This warranty is limited to manufacturer defects, in either materials or workmanship. PULSE, or any
other worldwide divisions of Premier Farnell PLC, is not responsible for any consequential or inconsequential damage
to any other component, structure or the cost of installation or removal of said items. Defective items should be
returned to the retailer/distributor from whom they were originally purchased. Batteries are classed as a consumable
item, as a result any battery will only carry a 90 day warranty from date of purchase.
This warranty will not cover damage due to improper use such as (and not limited to) damaged cones, mounting
frames, voice coils or items damaged by weather including exposure to moisture.
For questions or specific information regarding warranty replacement or repair, contact:
