PuraTech®Owner’s Manual 12/11/2013 2
Limited Warranty
To Whom Warranty Is Extended
TO PLACE THE EQUIPMENT UNDER WARRANTY, THE
WARRANTY REGISTRATION CARD MUST BE COMPLETED
AND RETURNED BY THE ORIGINAL OWNER TO PuraTech®
WITHIN 30 DAYS OF INSTALLATION.
Coverage
This limited warranty covers the PuraTech®system delivered to
the original owner when the system is purchased for personal,
family, or household use. It is intended to cover defects
occurring in workmanship or materials or both.
Warrantor’s Performance and Length of Limited Warranty
PuraTech®warrants that upon receipt from the original owner of
any mechanical or electronic part which is found to be defective
in materials or workmanship, PuraTech®will repair or replace
the defective item for 3 years from date of original installation.
Media is not warranted.
PuraTech®further warrants that upon receipt from the original
owner of any PuraTech®media tank, main control valve, or
brine tank, found to be defective in material or workmanship,
PuraTech®will repair or replace the defective item for 10 years
from date of original installation.
All defective parts must be returned, along with the equipment
serial number and date of original installation, to PuraTech®
PREPAID, and replacement parts will be returned by
PuraTech®to the original owner FREIGHT COLLECT.
Further Exclusions and Limitations on Warranty
THERE ARE NO WARRANTIES OTHER THAN THOSE
DESCRIBED IN THIS WARRANTY INSTRUMENT.
This warranty does not cover any service call or labor costs
incurred with respect to the removal and replacement of any
defective part or parts. PuraTech®will not be liable for, nor will it
pay service call or labor charges incurred or expended with
respect to this warranty.
If the water supply being processed through this product
contains bacterial iron, algae, sulphur, tannins, organic matter,
or other unusual substances, then, unless the system is
represented as being capable of handling these substances in
the system specifications, other special treatment of the water
supply must be used to remove these substances before they
enter this product. Otherwise, PuraTech®shall have no
obligations under this warranty.
This warranty does not cover damage to a part or parts of the
system from causes such as fire, accidents, freezing, or
unreasonable use, abuse, or neglect by the owner.
This warranty does not cover damage to a part or parts of the
system resulting from improper installation. All plumbing and
electrical connections should be made in accordance with all
local codes and the installation instructions provided with the
system. The warranty does not cover damage resulting from use
with inadequate or defective plumbing; inadequate or defective
water supply or pressure; inadequate or defective house wiring;
improper voltage, electrical service, or electrical connections; or
violation of applicable building, plumbing, or electrical codes
laws, ordinances, or regulations.
THIS WARRANTY DOES NOT COVER INCIDENTAL,
CONSEQUENTIAL, OR SECONDARY DAMAGES.
ANY IMPLIED WARRANTIES ON THE PRODUCT
DESCRIBED IN THIS WARRANTY WILL NOT BE EFFECTIVE
AFTER THE EXPIRATION OF THIS WARRANTY.
No dealer, agent, representative, or other person is authorized
to extend or expand this limited warranty.
Some states do not allow limitations on how long an implied
warranty lasts or the exclusion or limitation of incidental or
consequential damages, so the above limitations and exclusion
may not apply to you. This warranty gives you specific legal
rights and you may also have other rights which vary from state
to state.
Claims Procedures
Any defects covered by this warranty should be promptly
reported to:
PuraTech®
4343 S. Hamilton Rd.
Groveport, OH 43125
When writing about the defects, please provide the original
owner’s name, telephone number, and original address, serial
number and model number of the product, and date of
purchase. (This information should be listed in General
Information on page 4 of this manual.) PuraTech®reserves the
right to replace defective parts with exact duplicates or their
equivalent.

PuraTech®Owner’s Manual 12/11/2013 3
Contents
OWNER INFORMATION......................................................................................................................................4
General Information .......................................................................................................................................4
Getting Maximum Efficiency from the Appliance............................................................................................5
Five-Button Controller ....................................................................................................................................5
Customer Settings..........................................................................................................................................7
INSTALLATION AND MAINTENANCE INFORMATION .....................................................................................8
Checklist Before Installation...........................................................................................................................8
Precautions....................................................................................................................................................9
Installation Steps and Start-Up Procedures .................................................................................................10
Bypass Valve ...............................................................................................................................................14
Setting and Using the Controller ..................................................................................................................15
Service Settings ...........................................................................................................................................16
Optional Plumbing Procedures.....................................................................................................................19
Assembly and Parts .....................................................................................................................................21
Troubleshooting ...........................................................................................................................................29
Water Conditioner Specifications .................................................................................................................31

PuraTech®Owner’s Manual 12/11/2013 4
General Information
Congratulations on choosing a superior PuraTech®water treatment appliance! Soon you and
your family will be enjoying clean, clear water. Use this guide to attain the maximum benefit from
the appliance. As an owner, you may find the first few pages to be the most helpful. If you have
trouble with the operation of the appliance, see Troubleshooting in the back of this manual or
contact your independent dealer.
Warning: This appliance must be applied to potable water only. It is recommended that an
independent dealer install and maintain this appliance.
Note: The manufacturer reserves the right to make specification and product changes without
prior notice.
This manual is for installation, operation, and maintenance of the following water conditioning
appliance model:
•PuraTech®5100
For Owner’s Reference
Date of Installation:
Model Number:
Serial Number
1
:
Installer’s Signature:
Dealership Name:
Dealership Address:
Dealership Phone Number:
Hardness:
Iron:
pH:
Water Pressure:
Water Temp:
Returned Warranty Card Date
2
:
1The serial number is located on the main control valve in front of the bypass.
2Completely fill out the Warranty Card and return it by mail to ensure that the appliance is registered with the factory and the warranty
becomes validated.
O
WNER
I
NFORMATION

PuraTech®Owner’s Manual 12/11/2013 5
Getting Maximum Efficiency from the Appliance
To achieve the maximum benefit and performance
from this appliance, familiarize yourself with this
manual and the appliance.
1. The salt level should always be at least 1/3 full.
Refill the salt when the level drops below the
water level in the brine tank. A resin cleaner
can be used on a monthly basis. Clean white
pellet salt, cube-style salt, or solar salt is
recommended. Do not use rock salt.
Caution: Do not mix different types of salt.
2. You may use a salt substitute (such as
potassium chloride) in place of water
conditioner salt. An independent dealer should
be contacted before a switch is made to a salt
substitute. If potassium chloride is used in
place of salt, the technician must select the
potassium chloride option during the
programming of the controller. See Service
Settings.
Caution: Do not use potassium chloride if
there is iron and/or manganese in the water.
3. Should the electricity be off for any reason,
check the controller for the correct time and
reset as necessary. See Customer Settings.
4. Program the appliance to regenerate at a time
when the water is not being used. If there is
more than one appliance, allow two hours
between each regeneration.
5. If dirt, sand, or large particles are present in the
water supply, pre-treat with the appropriate
filter.
6. The appliance may be disinfected with 5.25%
sodium hypochlorite, which is the active
ingredient in household chlorine bleach. To
disinfect the appliance, add 4.0 fluid ounces
(120 mL) of chlorine bleach solution to the brine
well of the brine tank. The brine tank should
have water in it. Start a manual regeneration.
7. Protect the appliance, including the drain line,
from freezing.
8. The bypass valve (located on the main control
valve) enables you to bypass the appliance if
any work is being performed on the appliance,
well pump, or plumbing. See Bypass Valve.
Use the Bypass mode for watering plants or
lawns with untreated water.
9. Before putting the appliance back in service
after work has been performed, turn on the
nearest cold water tap until water runs clear.
10. Adhere to all operational, maintenance, and
placement requirements.
11. Inspect and clean the brine tank and
air check/draw tube assembly annually or when
sediment is present in the brine tank.
Five-Button Controller
This appliance features a five-button controller with an
LCD display. The controller can be used to view the
appliance’s status, perform regenerations, and change
settings. An independent dealer should set the Service
Settings during installation of the appliance.
Note: Ensure that the bottom of the controller is
firmly locked onto the four tabs on the top of the
drive end cap assembly. See Cabinet and Cover
Assemblies diagram later in this manual.
Figure 1: Five-Button Controller
LCD Display
Buttons

PuraTech®Owner’s Manual 12/11/2013 6
Five-Button Controller, Cont.
Controller Part
Function
LCD Display
Shows the status of the controller; it is very important to know which mode the controller is in for
proper operations
Normal Operating
Mode
Shows
•The amount of soft water remaining until the next automatic regeneration (Each person in
the household uses about 75 gallons [290 liters] per day)
•The number of days until the next regeneration (Mode 1, Filter = No)
•The flow rate in gallons (or liters) per minute (Filter = No)
•Whether the appliance will regenerate tonight (If the Regenerate button has been pressed
and released)
•If the appliance will regenerate based on usage, the display will show “Regen. Scheduled”
Service Settings
Mode
Includes settings such as the language, mode, water hardness, and time of each regeneration
step. Service Settings must be set before Customer Settings. Otherwise, some values may not be
available. Service Settings Mode is intended for use by qualified service personnel
Customer Setting
Mode
Includes setting the time of day, the regeneration time, and the number of people in the
household; depending on the Service Settings, this option may not be available
Water Flowing
Indicator
Indicates that water is flowing through the appliance; useful for checking for proper plumbing and
leaks
Recharge/
Regeneration Status
Shows regeneration cycle positions during regeneration
Buttons
The Change, Select, Display, and Scroll Back buttons are used when changing Customer
Settings and Service Settings.
Change
The Change button is used with the Select button to set the value of certain parameters.
•When you press the Change button, the value under the cursor changes to the next
available value, typically increasing by one until all values have been displayed and the
process begins again.
Select
The Select button is used to move the cursor when setting parameters.
1. Press and release the Select button to move the cursor one digit to the right of the
parameter to be changed.
2. When the cursor is at the extreme right position, press the Select button again to reset
the cursor to the extreme left position.
Display
The Display button is used to enter programming modes and also to save a value and display the
next value to be changed.
1. To program Service Settings, press and hold both the Display button and the Select
button for about five seconds while “Service Setting” is displayed.
2. To program Customer Settings, press and hold the Display button for about five seconds
while “Customer Setting” is displayed.
Scroll Back
The Scroll Back function is used to step back to a previous parameter setting. It is typically used
to go back to correct a setting without the need to scroll forward through all settings.
Regenerate
The Regenerate button at the bottom of the controller is used when starting the water
conditioning appliance, to start an immediate regeneration, or to restore capacity if you run out of
salt.

PuraTech®Owner’s Manual 12/11/2013 7
Customer Settings
Service Settings must be set before Customer Settings; Service Settings should be set during installation of the
appliance.
To set Customer Settings, press and hold the Display button for about five seconds while “Customer Setting”
displays. Release the button when “Set Time” displays. If the setting displayed is correct, press Display to move
to the next setting. If metric units are selected when the Service Settings are set, the time of day and
regeneration time will be based on a 24-hour clock.
Step 1
Set Time of Day
Display reads “Set Time” followed by the current time that is set; the cursor will be under the
second hours digit.
To Change the Time of Day
A. Press Change repeatedly until the current hour is displayed.
B. Press Select to set the hour and move the cursor to the right.
C. Do the same to set the minutes. Select AM or PM. When the desired time is displayed,
press Display to step to the next parameter.
Note: Whenever you experience an electrical outage, check the controller for the correct time.
Make any necessary corrections.
Step 2
Set Regeneration Time
Display reads “Reg. Time” followed by the current regeneration time that is set; the cursor will be
under the second hours digit. Usually you want to set a regeneration time when water will not be
used.
To Change the Regeneration Time
A. Follow the procedure outlined above for setting the time.
B. When the desired regeneration time is displayed, press Display.
Step 3
Set Number of People
Display reads “# People” followed by the current setting for the number of people in the
household; the cursor will be under the tens digit.
To Change the Number of People
A. Press Change repeatedly until the desired value is displayed; values will cycle from 0 to 9.
B. Press Select and the cursor moves to the right.
C. When the desired number of people is displayed, press Display to exit the Customer Setting
mode.
When you press the Display button at “# People,” the values are saved, and the controller
returns to normal operating mode.

PuraTech®Owner’s Manual 12/11/2013 8
Checklist Before Installation
Refer to this checklist before installation.
Water Quality—If the water supply contains sand, sulfur, bacteria, iron bacteria, tannins, algae, oil, acid, or
other unusual substances, pre-treat the water to remove these contaminants before the water supply enters the
appliance, unless the appliance is represented as being capable of treating these contaminants in its
specifications.
Iron—A common problem found in many water supplies is iron. It is important to know what type of and how
much iron is in the water supply.
Iron Type
Description
Ferrous Iron*
(sometimes called clear
water or dissolved iron)
Only type of iron that can be treated with a water softener
Ferric Iron
Insoluble and the particles can eventually foul a resin bed. It should be filtered out before
the water reaches the softener
Organic Iron or Bacterial
Iron
Attached to other organic compounds in the water. Additional treatment is needed to
remove this type of iron
Colloidal Iron
Not dissolved, yet stays in suspension. A softener cannot remove this type of iron
* If the water supply contains ferrous iron, a commercially available resin bed cleaner should be used every six months. Follow the
instructions on the container. You should also increase the water hardness setting by 5 grains per gallon (86 mg/L) for every
1 ppm (mg/L) of ferrous iron.
Water Characteristics—The 5100 Water Softeners require a pH of 7 or above to function properly. An iron test
to determine iron levels is also necessary.
Water Hardness—Double check the hardness of water to verify that the appliance is right for the job. See
Water Conditioner Specifications.
Water Pressure—Not less than 20 psi (1.4 bar) or greater than 120 psi (8.3 bar) constant. If water pressure
exceeds 70 psi (4.8 bar), a pressure regulator is recommended.
Water Supply Flow Rate—A minimum of 2.4 gallons (9.1 L) per minute is recommended. For the purposes of
plumbing sizing, only the rated service flow rate and corresponding pressure loss may be used. Prolonged
operation of a water conditioner at flow rates exceeding the tested service flow rate may compromise
performance.
Water Temperature—Not less than 40°F (4°C) or greater than 120°F (49°C).
Drain—Drain the appliance to an appropriate drain, such as a floor drain or washer drain that will comply with
all local and state plumbing codes. To prevent back-siphoning, provide an adequate air gap or a siphon break.
See Installation Steps and Start-Up Procedures.
Electricity—The transformer supplied is for a standard 115 volt, 60-cycle AC outlet for locations in North
America or 220 volt, 50-cycle AC outlet for locations outside North America.
I
NSTALLATION AND
M
AINTENANCE
I
NFORMATION

PuraTech®Owner’s Manual 12/11/2013 9
Precautions
Do
1. Comply with all state and local building, plumbing, and electrical codes.
2. Install the appliance before the water heater.
3. Install the appliance after the pressure tank on well-water installations.
4. Install a pressure-reducing valve if the inlet pressure exceeds 70 psi (4.8 bar).
5. Examine the inlet line to ensure water will flow through it freely and that the inlet pipe is sized correctly. For
well water with iron, the recommended minimum inlet pipe size is 3/4-inch I.D. and for municipal water the
recommended minimum inlet pipe size is 1/2-inch I.D.
6. Install a gravity drain on the cabinet.
7. Secure the drain line on the appliance and at the drain outlet. See Installation Steps and Start-Up
Procedures.
8. Allow a minimum of 8 to 10 feet (2.4 to 3.0 m) of 3/4-inch pipe from the outlet of the appliance to the inlet of
the water heater.
Do Not
1. Do not install if checklist items are not satisfactory. See Checklist Before Installation.
2. Do not install if the incoming or outlet piping water temperature exceeds 120°F (49°C). See Water
Conditioner Specifications.
3. Do not allow soldering torch heat to be transferred to valve components or plastic parts when using the
optional copper adapters.
4. Do not over tighten the plastic fittings.
5. Do not plumb the appliance against a wall that would prohibit access to plumbing. See Installation Steps
and Start-Up Procedures.
6. Do not install the appliance backward. Follow the arrows on the inlet and outlet.
7. Do not plug the transformer into an outlet that is activated by an On/Off switch.
8. Do not connect the drain line and the gravity overflow drain line together.
9. Do not use to treat water that is microbiologically unsafe or of unknown quality without adequate
disinfection before or after the appliance.
10. Do not allow the appliance or drain line to freeze.
Note: A bacteriostasis claim does not mean that these devices will make microbiologically unsafe water safe to
consume or use.

PuraTech®Owner’s Manual 12/11/2013 10
Installation Steps and Start-Up Procedures
Step 1
Prepare the Placement Area
A. Make sure the placement area is clean.
B. Turn off the electricity and water supply to the water heater. For gas water heaters, turn the
gas cock to “Pilot.”
C. Examine the inlet plumbing to ensure that the pipe is not plugged with lime, iron, or any
other substance. Clean or replace plugged plumbing.
D. Make sure the inlet/outlet and drain connections meet the applicable state and local codes.
E. Check the arrows on the bypass valve to ensure that the water flows in the proper direction.
See Figure 6.
Caution: Do not plumb the appliance in backward.
F. Place the appliance in the desired location using Figure 2 as a guide. The diagram in
Figure 2 applies to basement, slab, crawl space, and outside installations.
G. For most installations, install the appliance after the pressure tank and any water filter
appliance or water meter and before the water heater unless otherwise recommended.
When installing any additional filters, such as a carbon filter for well water, place the filter
after any water conditioning appliance unless otherwise recommended.
Water Heaters: If less than 10 feet (3 m) of pipe connects the water treatment appliance(s)
to the water heater, install a check valve between the water treatment appliance and the
water heater as close to the water heater as possible. Ensure that the water heater has an
adequately rated temperature and pressure safety relief valve.
H. For outside installations, the appliance should be enclosed so it is protected from the
weather.
Figure 2: Appliance Placement

PuraTech®Owner’s Manual 12/11/2013 11
Installation Steps and Start-Up Procedures, Cont.
Step 2
Turn Off Water Supply
A. Turn off the water supply.
B. Open the hot and cold water taps to depressurize the lines.
Step 3
Connect Water Lines
Note: See Optional Plumbing Procedures for information on
copper fittings and joining plastic pipe.
A. Lift and remove the cabinet cover.
B. Install Qest fittings. Qest connection fittings are provided
with your appliance. Qest fittings provide a convenient,
easy-to-use three-piece assembly for 3/4-inch copper
plumbing or 3/4-inch CTS CPVC plastic tubing (copper is
shown in Figure 3). Ensure that the three components
(1: collar, 2: metal retaining ring, and 3: nylon sleeve) are
correctly installed in sequence on the pipe.
(See Figure 3.)
Note: Teflon tape or plumber’s putty is NOT necessary
and should NOT be used with Qest fittings.
C. Attach the water lines to the appliance in compliance
with all applicable building, plumbing, and electrical
codes. (See Figure 4). Do NOT overtighten the
connections on the plastic threads.
Figure 3: Qest Fittings
Figure 4: Connect Water Lines
D. Check the arrows on the valve to ensure that the water flows in the proper direction.
Caution: Do NOT plumb your appliance in backward.

PuraTech®Owner’s Manual 12/11/2013 12
Installation Steps and Start-Up Procedures, Cont.
Step 4
Connect Gravity Overflow Connection and Secure Brine Well
Into Proper Position
The gravity overflow line drains away excess water should
the tank fill with too much water or the appliance
malfunction.
A. Attach the overflow elbow to the cabinet by removing
the safety shutoff from the brine well. (See Figure 5.)
1. Place the elbow through the hole in the cabinet wall
and the hole in the brine well.
2. Screw the overflow nut onto the overflow elbow
and tighten. This will also hold the brine well in the
proper position.
3. Reassemble the safety shutoff into the brine well.
Note: Ensure that the elbow is in the down position.
B. Connect 1/2-inch I.D. tubing (size cannot be reduced)
between the overflow elbow and a floor drain, laundry
tub, or other suitable waste receptor. This tubing is not
supplied with the appliance. Ensure that the overflow
line ends at a drain that is at least 3 inches (8 cm) lower
than the bottom of the overflow elbow. Maintain a
minimum of 2-inch (5 cm) air gap between the overflow
line and the flood level rim of the waste receptor to
prevent back-siphoning. The gravity line cannot be run
overhead.
Figure 5: Gravity Overflow
Elbow
Step 5
Connect Drain Line
The drain line carries away the backwash water as part of the regeneration cycle.
A. Connect the drain line to the drain end cap with a 5/8-inch I.D. tubing (supplied). The size
cannot be reduced.
Note: If the drain line is 25 feet (7.6 meters) or longer, increase the drain line to 3/4-inch I.D
tubing using the appropriate fittings. The end of the drain line must be equal to or lower in
height than the control valve.
Caution: The drain line must not be kinked, crimped, or restricted in any way.
B. Route the drain line to a floor drain, laundry tub, or other suitable waste receptor. Maintain a
minimum 2-inch (5 cm) air gap as with the overflow line. This drain line should make the
shortest run to the suitable drain.
C. The drain line may be elevated up to 8 feet (2.4 m) from the discharge on the appliance as
long as the water pressure in the system is 40 psi (2.8 bar) or more.
Step 6
Flush Lines
A. Place the bypass valve in the Bypass position.
B. Turn on the main water supply.
C. Open the nearest cold water faucet to flush the plumbing of any excess soldering flux, air, or
any other foreign material until the water runs clear.
Gravity
Overflow
Elbow

PuraTech®Owner’s Manual 12/11/2013 13
Installation Steps and Start-Up Procedures, Cont.
Step 7
Check for Leaks
A. Close all faucets.
B. Check all lines and connections for leaks. If leaks are found:
1. Turn off the main water supply.
2. Open a cold water faucet to depressurize the lines.
3. Close the faucet to eliminate any siphoning action.
4. Repair all leaks.
5. Turn on the main water supply.
6. Place the bypass valve in the Service position to slowly fill the media tank.
7. Open a cold water faucet to purge air out of the media tank.
8. Close the faucet and recheck for leaks.
Step 8
Plug in the Transformer
A. Connect the transformer power cord to the back of the controller.
B. Plug the transformer into an outlet that is not operated by an On/Off switch.
Step 9
Set Up the Controller
A. Program the appliance controller. See Setting and Using the Controller.
Step 10
Add Water to the Brine Cabinet
A. Add 2 gallons (8 L) of water to the brine cabinet. After the first regeneration, the appliance
will automatically refill the correct amount of water into the brine cabinet.
Note: This initial startup is the only time you will add water to the brine cabinet. Do not add
water at any other time.
B. Ensure the appliance is in Service position and your water supply is turned on.
C. Initiate a manual regeneration (see Five-Button Controller) and inspect for proper operation.
Allow the appliance to draw all the water out of the brine tank until the air check/draw tube
sets (8–10 minutes).
D. Press the Regenerate button to advance to the Brine Refill position. Let the tank fill with the
proper amount of water. The controller will then step the main control valve to the Home
position.
Step 11
Fill the Brine Cabinet With Salt
A. Fill the brine cabinet with salt. Use clean, white pellet salt, cube-style salt, or solar salt.
Caution: Do not mix different types of salt.
Note: Always keep the salt level above the water level. For convenience, completely fill the
tank when refilling with salt.
B. After you add salt, including adding it after the tank has run out of salt, wait two hours for
saturated brine before starting any regeneration.
Caution: Use of potassium chloride when iron and/or manganese are present in the
raw water supply is not recommended.

PuraTech®Owner’s Manual 12/11/2013 14
Installation Steps and Start-Up Procedures, Cont.
Step 12
Complete the Installation
A. Ensure that the appliance is in the Service position. See Bypass Valve.
B. Ensure that the water supply is on.
C. Turn on the electricity and water supply to the water heater. For gas water heaters, return
the gas cock to “On.”
D. Open a cold water tap and allow the appliance to flush for 20 minutes or until approximately
72 gallons (270 L) have passed through the appliance. This procedure is required to meet
NSF requirements. Verify the flow rate on the controller, which indicates water flow.
(See Figure 1.)
E. Replace the cabinet cover.
Bypass Valve
The bypass valve can isolate the appliance should the appliance malfunction or leak. It can also permit the use
of untreated water for watering plants, shrubs, or lawns.
The bypass valve is attached to the main control valve. See Figure 6. To engage the bypass valve, turn the
knob to the Bypass position. The appliance will be bypassed and all water to the home is raw, untreated water.
To prevent untreated water from entering the home, water should not be used inside the home when the
appliance is in Bypass mode. Ensure that the appliance is returned to Service mode when the appliance is
repaired or the use of untreated water is complete by turning the knob to the Service position.
To blend hardness back into the water using the bypass, turn the knob slightly from the Service position toward
the Bypass position.
Figure 6: Bypass Valve

PuraTech®Owner’s Manual 12/11/2013 15
Setting and Using the Controller
The controller must be set up correctly for the appliance to perform properly.
Note: Ensure that the bottom of the controller is firmly locked onto the four tabs on the top of the drive end cap
assembly. See Figure 9.
Regenerate Button
The Regenerate button is used when starting the water filtration appliance and to start an immediate
regeneration. The Regenerate button can be used in three ways:
1. The Regenerate button can be used to put the appliance into an immediate regeneration.
A. Press and hold the Regenerate button for about five seconds until the display changes from
“Regenerate” to “Going to.”
B. The appliance is in regeneration mode and will display the status of each cycle. After all regeneration
cycles are complete, the display will return to Normal operating mode.
2. The Regenerate button can be used to quickly advance through all of the regeneration cycles to speed up
the cycles, which is used when starting up or diagnosing the appliance
only.
A. To advance through the regeneration cycles, press and hold the
Regenerate button for about five seconds until the display
changes to “Going to.”
B. The cycle position will display (for example, Backwash 1).
C. Each cycle can be advanced by pressing the Regenerate button.
Always wait until the cycle position displays before advancing to
the next cycle position.
3. Press and release the Regenerate button in Normal operating mode to
schedule a regeneration tonight or toggle it off.
Figure 7: Regenerate Button

PuraTech®Owner’s Manual 12/11/2013 16
Service Settings
To program Service Settings on the controller, press and hold the Select and Display buttons while “Service
Settings” is displayed until “Set Language Eng” is displayed. Programming Service Settings is similar to
programming Customer Settings (see Customer Settings for programming details). The values that can be set
are listed below.
Note: The Service Settings must be set before the Customer Settings.
Display
Meaning
Possible Values
Comments
Set Language Eng
Set the language of the
display
Set Language Eng
Entrer Langue Fra
Entre La Leng. Esp
Units ENG
Units of measure
ENG or MET
Soft. v. # 1.22B
Displays the current
software version
Cannot be set
Mode
2
Operating Mode:
Timer (Mode 1)
Demand Delayed (Mode 2)
1 or 2
See Operating Modes
Regen Freq.
01
How often regeneration
occurs
1–12 days
Only displays when in Mode 1
Hard. Gr.
040
Hardness of the water that
was tested
003 to 999 Grains
(00000 to 99999 mg/L)
This is the actual hardness reading
and is not compensated for iron
and/or manganese
Iron ppm
00
Amount of iron in parts per
million of the water that
was tested
00 to 99 ppm (mg/L)
This value is used to calculate
compensated hardness automatically
Mang. ppm
00
Amount of manganese in
parts per million of
incoming water
00 to 99 ppm (mg/L)
This value is used to calculate
compensated hardness automatically
Salt =
Sodium
Regenerant filling the brine
tank
Sodium or Potassium
See Warning
Comp. Hard.
00040
Compensated hardness
using the hardness, iron,
and manganese settings
Cannot be set
ppm or mg/L
The formula used is:
Hardness + (4 x each ppm iron) +
(4 x each ppm manganese) =
compensated hardness
Capac. Gr.
24480
The desired softening
capacity number
00000 to 99999 Grains
(0000 to 9999 gm)
See Water Conditioner Specifications
or Modes 1 and 2 Setting Chart for
capacities based on salt usage
72–96 hr Regen
No
A way to force
regeneration at regularly
scheduled intervals
No (or Yes, for iron)
See 72–96 Hour Regeneration
Backwash 1
03.0
Number of minutes the first
backwash cycle lasts
00.0 to 99.9
Set to the nearest tenth of a minute
Warning: When iron and/or manganese is present in the water supply, do not use potassium chloride as a
regenerant. Iron and/or manganese bacteria may develop and foul the conditioning media and may
void the warranty.
This table continues on the next page.

PuraTech®Owner’s Manual 12/11/2013 17
Service Settings, Cont.
Display
Meaning
Possible Values
Comments
Brine/Rinse
30.0
Number of minutes the
brine and slow rinse cycle
lasts
00.0 to 99.9
Set to the nearest tenth of a minute
Backwash 2
02.0
Number of minutes the
second backwash cycle
lasts
00.0 to 99.9
Set to the nearest tenth of a minute
Salt lbs.
06.0
Amount of salt set to be
used in each regeneration
to achieve the capacity
setting
00.0 to 99.9 lb (kg)
Set to the nearest tenth
Turbine Test
No
Used by qualified
personnel for diagnostic
purposes
No or Yes
Do not engage this feature
Reg. Tonight
No
Sets the appliance to
regenerate tonight
No or Yes
If set to Yes, it will force a
regeneration at the next set
regeneration time (such as 02:00
AM). After the regeneration, the value
will be set to No
Filter?
No
Used by qualified service
personnel to set the model
number
No or Yes
Has no effect on the function of the
appliance
When you press the Display button at “Filter?”, the values are saved, and the controller returns to Normal
operating mode.
Operating Modes
The appliance has two operating modes: Timer mode and Demand Delayed mode. Both modes are equipped
with Capacity Guard®, which ensures that a supply of conditioned water will be available even with excessive
water usage.
Mode 1—Timer Mode
When the appliance is in Timer mode, it will regenerate based on the frequency that is set, for example every
day or up to every 12 days. The time of regeneration can be set.
Mode 2—Demand Delayed Mode
When the appliance is in Demand Delayed mode, it will regenerate based on the actual water usage and the
total capacity of the appliance. The time that the regeneration takes place can be set, for example 2:00 AM.
Should the total capacity be depleted before the set regeneration time, a forced regeneration will occur.
72–96 Hour Regeneration
If this value is set to Yes, the appliance will be forced to regenerate every 72–96 hours unless a regeneration
based on water usage occurs within the time interval. The value should always be set to Yes if iron is present in
the water.

PuraTech®Owner’s Manual 12/11/2013 18
Service Settings, Cont.
Mode 1 (Timer Mode) and Mode 2 (Demand Delayed Mode) Setting Chart
This section provides guidance for using different Service Settings to achieve the desired capacity.
PuraTech
Model 5100
Mode 1 and Mode 2
Yes
Regeneration Frequency
Mode 1 only
96 hour regeneration (if iron present—yes)
1
Yes or No
#1 Salt Setting
Backwash 1 (minutes)
01.0
Brine/Rinse (minutes)
19.5
Backwash 2 (minutes)
03.0
Capacity–grains @ salt–lb (grams @ salt–kg)
5,500 @ 1 lb (356 @ 0.5 kg)
#2 Salt Setting
Backwash 1 (minutes)
01.0
Brine/Rinse (minutes)
22.0
Backwash 2 (minutes)
03.0
Capacity–grains @ salt–lb (grams @ salt–kg)
13,700 @ 3 lb (887 @ 1.4 kg)
#3 Salt Setting2
Backwash 1 (minutes)
01.0
Brine/Rinse (minutes)
26.0
Backwash 2 (minutes)
03.0
Capacity–grains @ salt–lb (grams @ salt–kg)
23,700 @ 6 lb (1535 @ 2.7 kg)
#4 Salt Setting
2,3
Backwash 1 (minutes)
01.0
Brine/Rinse (minutes)
30.0
Backwash 2 (minutes)
03.0
Capacity–grains @ salt–lb (grams @ salt–kg)
30,800 @ 9 lb (1995 @ 4.1 kg)
1If iron is present in water supply, use salt setting #3 or #4.
2If iron is present in the water supply, set Backwash 1 to 7 minutes.
3Do not use this salt setting in California.

PuraTech®Owner’s Manual 12/11/2013 19
Optional Plumbing Procedures
This section provides information on plumbing with copper fittings and with plastic pipe.
Hard Plumbing the Bypass With Copper Fittings
Do not use Qest fittings for hard plumbing with copper fittings. When preparing the male threaded fittings of the
I/O adapter, use the following guidelines to avoid damage to the plastic pipe threads.
A. Wrap the threads three times with 1/2-inch wide Teflon tape. Place each consecutive wrap on top of
the previous wrap.
B. To prevent tearing of the tape, use Teflon paste on the first two male threads only. The paste lubricates
the tape and fills the small void areas that might exist between the threads. When the joint is complete,
there will be a small bead of sealant at the fitting interface, which indicates a properly joined
connection.
C. Use a union with a threaded connection to facilitate repair of potential leaks in soldered joints.
D. Prepare the copper tail assemblies in advance to enable them to cool prior to final assembly. Advance
preparation and cooling will prevent heat damage to the plastic pipe threads of the adapter.
E. Ensure that the copper tube is at least 4 inch (10 cm) long.
F. Turn the fitting counterclockwise until you feel the threads engage and then tighten to prevent cross
threading. Do NOT over tighten the fittings.
Caution: Do NOT allow heat from the torch to transfer to the plastic valve component, which
could be damaged.

PuraTech®Owner’s Manual 12/11/2013 20
Optional Plumbing Procedures, Cont.
Plastic (PVC/CPVC) Pipe Joining Procedure
To ensure reliable joint integrity when using solvent cement for PVC/CPVC plumbing, follow these
recommendations:
A. Cutting—The pipe must be cut square to allow for the proper interfacing of the pipe end and the fitting
socket bottom. Use a wheel cutter, miter saw, or a ratchet shear for best results.
B. Deburring and Beveling—Use a knife, plastic pipe deburring tool, or a file to remove burrs from the
end of the pipe. Be sure to remove all burrs from the inside as well as the outside of the pipe. Remove
all loose plastic debris since it could clog the injector. All pipe ends should be beveled to permit easier
insertion of the pipe into the fitting. Failure to bevel the pipe end may cause a “wiping” effect in the
fitting where the cement is forced to the end of the fitting socket. This creates a weak joint.
C. Test Dry Fit of the Joint—Tapered fitting sockets are designed so that an interference fit should occur
when the pipe is inserted about one-third to two-thirds of the way into the socket. Occasionally, when
pipe and fitting dimensions are at the tolerance extremes, it will be possible to fully insert dry pipe to the
bottom of the fitting socket. When this happens, a sufficient quantity of cement must be applied to the
joint to fill the gap between the pipe and fitting.
D. Inspection, Cleaning, and Priming—Inspect the inside of the pipe and fitting sockets and remove dirt,
grease, or moisture with a clean dry cloth. If wiping fails to clean the surfaces, use a chemical cleaner.
Check for possible damage such as splits or cracks and replace if necessary. Use purple primer to
penetrate and soften the bonding surfaces of the PVC or CPVC pipe and fittings. Proceed without
hesitation to the cementing procedure while the primed surfaces are still wet.
E. Application of Solvent Cement—Apply the solvent cement evenly and quickly around the outside of
the pipe while the primer is still wet. Apply a light coat of cement evenly around the inside of the fitting
socket. Do not allow excess cement to “puddle” in the fitting. Apply a second coat of cement to the pipe
end.
F. Joint Assembly—Working quickly, insert the pipe into the fitting socket and give a 1/4-turn of the pipe
or fitting while pushing toward the fitting stop. This action will evenly distribute the cement. Do NOT
continue to rotate the pipe or fitting after the stop has been reached. Hold the joint tightly together for
about 15 seconds to prevent the pipe from “creeping” out of the fitting. A good joint will have sufficient
cement to make a small bead all the way around the outside of the fitting hub. The joint should not be
disturbed immediately after the cementing procedure. Allow adequate time for the joint to cure properly.
Exact drying time is hard to predict because of environmental variables. Follow the recommended joint
curing times on the primer and cement container labels.
