Pure Tesla TeslaCam microSD User manual

TeslaCam microSD Package User Guide
Updated 10/2019
Version 1.02
Prepared by Pure Tesla LLC
Copyright 2019
For distribution to Pure Tesla customers only.

TeslaCam microSD Package
puretesla.com Formatted TeslaCam Drives
2
Table of Contents
Quick Start Guide
3
1.1 Installing your new drive
3
1.2 Safely removing the drive
4
1.3 Quick Term Definitions
4
Using Dashcam
5
2.1 What is being recorded
5
2.2 Dashcam icons explained
6
2.3 Saving Dashcam footage
6
Using Sentry Mode
7
3.1 Enabling Sentry Mode
7
3.2 Sentry Mode Alert States
7
3.3 Location Based Sentry Mode
8
Reviewing the Footage
9
4.1 Removing the USB Drive
9
4.2 Reviewing footage
10
Deleting Footage
11

TeslaCam microSD Package
puretesla.com Formatted TeslaCam Drives
3
Quick Start
1.1 Installing your Pure Tesla TeslaCam Drive
The USB drive you purchased from Pure Tesla comes completely formatted and
ready to use in your Tesla.
1. Open the package
2. Plug the USB drive into one of the front USB ports in your Tesla
Model 3 Model S/X (center console below armrest)
You’ll know your drive is recording properly when you see the camera icon with
the red dot (pictured below):

TeslaCam microSD Package
puretesla.com Formatted TeslaCam Drives
4
1.2 Safely Removing the Drive
When removing your USB drive from your Tesla, treat it like you would a USB
drive attached to your computer. Follow this process each time:
1. Tap and hold the camera icon with the red dot until you see a white pulse
come from that icon.
2. Once the icon dot turns gray, it is no longer recording and is safe to remove the
drive.
Removing it using this method helps ensure that your files do not get corrupted.
Always remember to properly eject the drive from your computer when
connected. Failure to do so may corrupt the drive and render it not usable with
Dashcam until reformatted.
1.3 Quick Term Definitions
TeslaCam –Tesla’s Dashcam and security solution using the built-in cameras on your Tesla.
Dashcam –System that records driving footage from the front, left, right, and rear cameras.
Sentry Mode –Security feature that detects potential threats to your Tesla and will display an alert and
also record footage surrounding the Tesla.
Left Repeater –Camera on the left side of the vehicle pointing backwards (towards the trunk).
Right Repeater –Camera on the right side of the vehicle pointing backwards (towards the trunk).

TeslaCam microSD Package
puretesla.com Formatted TeslaCam Drives
5
Using Dashcam
2.1 What is being recorded by Dashcam?
While the car is on and “active” the following cameras are saving footage to your
USB drive:
Front
Left Repeater
Right Repeater
Rear
The Dashcam system overwrites itself (RecentClips folder) after approximately an
hour of saved footage.

TeslaCam microSD Package
puretesla.com Formatted TeslaCam Drives
6
2.2 Dashcam Icons Explained
There are three different icons that show you the status of the Dashcam system:
RECORDING –The Dashcam temporarily stores
approximately one hour of the most recent video
footage to the USB drive (RecentClips folder)
before overwriting old video.
PAUSED –Press and hold the dashcam icon,
while recording, to pause recording. Be sure to
pause recording prior to removing the USB drive
to avoid file corruption.
SAVED –Tap the dashcam icon while recording to
save the most recent ten minutes of video to the
SavedClips folder. This folder is NOT overwritten.
2.3 Saving Dashcam Footage
As a reminder, Dashcam footage is saved into the RecentClips folder and
overwrites itself after approximately an hour.
If you want to save Dashcam footage until you’re ready to delete it yourself, tap
the camera icon with the red dot (upper right corner of the screen). This saves the
last 10 minutes of recorded footage to the SavedClips folder on your USB drive.
**TIP: Wait approximately one minute after the conclusion of the event you want
to save to tap the camera icon. The current software version is known to clip the
most recent 20-40 seconds of footage when the icon is tapped, which is typically
the footage you want to keep.

TeslaCam microSD Package
puretesla.com Formatted TeslaCam Drives
7
Using Sentry Mode
3.1 Enabling Sentry Mode
To enable Sentry Mode do one of the following:
•Touch Controls -> Safety & Security -> Sentry Mode
•Use a voice command to enable or disable Sentry Mode (Sentry On, Sentry
Off, Keep Tesla Safe)
•Use the Tesla mobile app to enable or disable Sentry Mode
•Use the Sentry Mode icon in the top right of the Tesla screen
3.2 Sentry Mode Alert States
There are three states in which Sentry Mode operates:
Standby
When Sentry Mode is turned on, the cameras are always
monitoring the Tesla’s surroundings for potential threats.
Alert
The touchscreen displays a message that the cameras are
recording. The last ten minutes of footage are saved to the USB
drive leading up to the event.
Alarm
For major threats (broken window, etc), Sentry Mode triggers
Alarm state. The audio system generates a loud sound, lights and
horn also activate.

TeslaCam microSD Package
puretesla.com Formatted TeslaCam Drives
8
3.3 Location Based Sentry Mode Activation
You can configure Sentry Mode to automatically activate or deactivate based on
your location. Here are your options:
Exclude Home
Sentry Mode will not activate when parked and locked
within 32 feet of the location tagged as “home” in
your Tesla.
Exclude Work
Sentry Mode will not activate when parked and locked
within 32 feet of the location tagged as “work” in your
Tesla.
Exclude Favorites
Locations tagged as a “Favorite” will not trigger
activate Sentry Mode when this option is checked.

TeslaCam microSD Package
puretesla.com Formatted TeslaCam Drives
9
Reviewing Footage
4.1 Removing the USB Drive
When removing your USB drive from your Tesla, treat it like you would a USB
drive attached to your computer. Follow this process each time:
3. Tap and hold the camera icon with the red dot until you see a white pulse
come from that icon.
4. Once the icon dot turns gray, it is no longer recording and is safe to remove the
drive.
Removing it using this method helps ensure that your files do not get corrupted.

TeslaCam microSD Package
puretesla.com Formatted TeslaCam Drives
10
4.2 Viewing Footage
Connect the USB drive to a computer or compatible device. View the footage
using the built-in media player on your computer. If you’re having trouble
opening the files, consider using VLC Player as it opens just about any media files.
Your footage will be separated into one of three folders:
RecentClips
The last hour of Dashcam footage. This
folder automatically overwrites older
video files.
SavedClips
Dashcam footage saved after tapping
the camera icon. Does not overwrite
(remains until user deletes footage).
SentryClips
Footage from SentryMode alerts. This
folder overwrites oldest footage
automatically when space is needed.
Recommended Viewers:
VLC Player
Mac, PC
QuickTime
Mac
Windows Media Player
PC
SentryCam
All (browser based)

TeslaCam microSD Package
puretesla.com Formatted TeslaCam Drives
11
Deleting Footage
5.1 Individual Files
You can delete individual video files by dragging them to the trash.
If you delete footage from the drive while reviewing, make sure you empty the trash on
your computer with the drive connected.
5.2 Entire Folders
You can delete an entire event of files by deleting the whole time-stamped folder (drag to trash, right
click delete, etc).
If you delete footage from the drive while reviewing, make sure you empty the trash on
your computer with the drive connected.
5.3 Delete Major Folders
You can also delete the RecentClips, SavedClips, and/or SentryClips folders to quickly delete footage that
isn’t needed. The car will automatically recreate these folders as needed. Do not delete the TeslaCam
folder as this is not recreated by the car.
If you delete footage from the drive while reviewing, make sure you empty the trash on
your computer with the drive connected.
