Purelogic PLD330 User manual

01. General information
02. Delivery set
03. Technical features
04. Driver installation and ventilation
05. Driver functional capabilities
06. Control Signal Connections to the driver
07. Current and power option
08. Stepper motor connection to the driver
09. Protection functions
10. Step division option
11. Terms of Warranty
INSTRUCTION MANUAL
2
2
3
5
6
7
10
10
11
12
12
PLD330
Stepper motor driver

Edition from 23.11.2017 3
PLD330. Stepper motor driver
www.purelogic.ru8 (800) 555 63 74
01
02
General information
Delivery set
Technical features
PLD330 is a modern and available microstep stepper motor driver.
The driver has inbuilt coil short-circuit protection, back EMF effect
protection, exceeding STEP signal frequency, power unit overheating
and inbuilt automatic compensator of normal speed stepper motor
resonance.
The device works with standard control protocol STEP/DIR/ENABLE.
The module has discrete regulation of operating current of stepper
motor phases. All driver’s control inputs are optoisolated and logic
levels 2.5V, 3.3V, 5V compatible.
The driver is AUTO-SLEEP mode supplied which is turned on when
there is no STEP signal.
The device is optimal for control of bipolar and unipolar Purelogic
R&D stepper motors (PL42/PL57 series). Operation with other stepper
motors is also possible.
• New generation stepper motor driver PLD330 — 1 pcs.
• Instruction manual — 1 pcs.
03
01. General information
Stepdivision (microstep)
Max shaft rotation frequency
Module power supply
Operating temperature
STEP Max signal frequency
Operating current of stepper motor driver
Isolation resistance
Unit weight without packaging
100 kHz
0.7А, 1.7А, 2.7А, 3.3А (discrete adjustment)
500 MOhm
0,15 kg
1:1, 1:2, 1:8, 1:16
30 cycles per second
12...32V (bogey value 25V)
0...60 °С
!Check www.purelogic.ru for more information.
Power off device before making any connections.
Do not mount the power switch after the power source (on the driver
power line).
Power switch should be installed before power supply, at ~220V side.
Do not connect the drivers in series, only ‘star’ connection is allowed.
Do not connect power supply’s «-» to ground, mass, housing, etc.
strictly observe the polarity of power supply and control signals
connections.
01 General information 01 General information

Edition from 23.11.2017 5
PLD330. Stepper motor driver
www.purelogic.ru8 (800) 555 63 74
03. Technical features
Fig. 1. PLD330 driver dimensions
grooves
In order to ensure optimal thermal conditions of installation of the
equipment inside the rack CNC control must be carried out, adhering
to the scheme below:
Installing environmental conditions
1) Working environment temperature: 0~45 °C.
2) Work environment humidity: lower than 40~80% (non condensing).
3) Storage environment temperature: -40~55 °C.
4) Storage environment humidity: lower than 80% (non condensing).
5) Vibrate: lower than 0.5G.
6) Avoid direct sunlight.
7) Prevent oil mist, erosion of salt.
8) Prevent corrosive liquid, gas.
Driver installation and ventilation 04

Edition from 23.11.2017 7
PLD330. Stepper motor driver
www.purelogic.ru8 (800) 555 63 74
05. Control Signal Connections to the driver
The driver operates with standard signals STEP/DIR/ENABLE.
The signals’ inputs are optoisolated. Fig. 2 shows control input
device and the method of of controlling system connection with ‘open
collector’ type.
STEP signal characteristics — working voltage 5...12V, current
consumption 10mА...20mА, min signal duration is 2ms. Stepper motor
step is performed on signal’s front edge.
DIR signal’s characteristics — working voltage 5...12V, current
consumption 10mА...20mА, min signal duration is 5ms.
ENABLE signal’s characteristics — working voltage 5...12V, current
consumption 10mА...20mА, min signal duration is 1ms. min signal
duration is 5ms.
Fig. 2. Differential input device
05 Driver functional capabilities
• Optoisolation of module control signals STEP/DIR/ENABLE.
• AUTO-SLEEP mode automatically reduces the current in coil stepper
motor during standstill, for heating reduction.
• Inbuilt automatic midfrequency stepper motor resonance
compensator.
• Coil short-circuit module protection, wrong stepper motor connection
protection.
• Module protection against exceeding supply power, back EMF effect.
• Module protection against power section overheating.
• Module protection against exceeding STEP signal frequency.
• Convenient dismountable clip connectors to step motor, power source
and control signals.
Control Signal Connections to the driver 06

Edition from 23.11.2017 9
PLD330. Stepper motor driver
www.purelogic.ru8 (800) 555 63 74
06. Control Signal Connections to the driver
Fig. 3. General scheme of CNC control
Stepper motor driver

Edition from 23.11.2017 11
PLD330. Stepper motor driver
www.purelogic.ru8 (800) 555 63 74
07. Current and power option
Fig. 4. Purelogic R&D stepper motor connection to the driver
The length of wires leading to the stepper motor from the driver must
not exceed 10 meters. Longer wires can lead to driver’s work failures.
It is strongly recommended to interlace the stepper motor wires per
phase, then put this braid to the screened metal sheath. Sheathes and
stepper motor frame must be grounded.
POWER OFF DEVICE BEFORE MAKING ANY CONNECTIONS.
Coil short-circuit protection – against wrong stepper motor coil
connection and coils linked together / ‘+’ power supply. In some cases
by interturn short-circuit of stepper motor coil, short-circuit protection
may not work because there is no exceeding of permissible alarm
current. This happens because under such coil short circuit resistance
does not equal 0 and the driver maintains the specified current.
Power surges protection is turned on if power supply is more than 35V,
for back EMF driver protection.
Protection against power section overheating – the protection turns on
when it is 170°С.
Protection against exceeding STEP signal frequency – the protection
turns on when STEP signal is given with the frequency which exceeds
the permissible for the step division range given.
PH1.1 [+А] Red (RED)
PH1.2 [-А] Orange (ORG)
PH2.1 [+B] Blue (BLU)
PH2.2 [-B] Green (GRN)
Max supply voltage driver option depends on the applied stepper motor
and desired max rotation speed. Optimal supply voltage calculation
for the stepper driver is carried out according to the formula U=32*v
(stepper motor phase inductance mH), but not more than 32V.
Supply current must be chosen 50...70% from the claimed stepper
motor coil current.
Working current setting must be performed with help of dip-switches
SW3, SW4.
When there is no STEP signal more than 1 sec, the driver goes to
AUTO-SLEEP mode and reduces the coil current to the value identified
by dip-switches SW5, SW6 (the current in hold mode must be less or
equal the working current). It allows to reduce stepper motor heating
when in standstill and reduce current consumption.
Always perform all switch-overs when the driver is powered off.
For back EMF compensation we recommend to use protecting device –
dumper (module PLZ005).
PLD330 driver is optimal for bipolar and unipolar stepper motors
Purelogic R&D series PL42/PL57. Stepper motor connection to the
driver is performed as it is shown in fig. 5 (clips PH1.1[+A], PH1.2[-A]
and PH2.1[+B], PH2.2[-B]).
The driver has protection against wrong stepper motor coil connection
and coils linked together / ‘+’ power supply.
Purelogic R&D stepper motor connection to the driver is performed
according fig. 4.
Please note in case of changing phases PH1.x<>PH2.x, the motor
will start rotating in the opposite direction (inversion analogue of DIR
signal).
07
08
Current and power option
Stepper motor connection to the driver
Protection functions 09

Edition from 23.11.2017 13
PLD330. Stepper motor driver
www.purelogic.ru8 (800) 555 63 74
09. Protection functions
If you have questions please consult our technical support team.
1.2. Seller does not guarantee compatibility of the purchased product
with the one that Buyer already has or bought from third parties.
1.3. Product’s component parts and configuration can be changed by
manufacturer without notice due to the product consistent technical
improvement.
2. Conditions for warranty acceptance
2.1. The product is accepted only in the same completeness of set as it
was purchased.
3. Warranty service procedure
3.1. Warranty service is performed by testing the claimed product
defect.
3.2. If the defect is proved, warranty repair is carried out.
4. We do not assume any responsibility for glass, electric lamps,
starters and expendable materials as well as:
4.1. Damaged product caused by inappropriate transport and store
conditions, wrong connection, operation in abnormal (off-design)
mode, or in conditions which are not manufacturer-supplied (including
temperature and humidity out of limits of recommended range), having
damages due to third-party circumstances (voltage jumps, natural
disasters, etc.), also having mechanical or thermal damages.
4.2. The product with traces of foreign objects or substances impact,
including dust, liquids, insects, also objects having extraneous
inscription.
4.3. The product with traces of unauthorized tampering and (or) repair
process (traces of opening, home-made soldering, elements changing
etc).
4.4. The product with self-diagnostic function that shows improper
exploitation.
4.5. Technically complex product in respect of which assembly
and integration and start-up works were not performed by Seller
specialists or by recommended organizations, except in cases directly
regulated under goods documentation.
Max shaft rotation frequency is 30 cycles per second (under greater
rotation frequency, the torque on the step motor shaft becomes
minimal, you can reach such speed only by rotating stepper motor with
unloaded shaft under laboratory conditions, produced EMF under such
high turnover can result in failure of driver power part so for safety
reasons the driver turns off). For step division 1:1 max frequency STEP
is 6 kHz, 1:2 — 12 kHz, 1:8 — 50 kHz, 1:16 — 100 kHz. When protection
operates the driver turns off stepper motor coil, green LED goes out.
The driver restarts after OFF/ON supply voltage and error-cause
removal.
The driver allows to divide electronically physical stepper motor step -
1, 2, 8 and 16.
Thus positioning accuracy is higher. Step division mode is called
microstep division . This mode allows to reduce stepper motor
resonances at low revs but when using microstep the stated time
on stepper motor shaft is reduced. Switching of step division mode
is performed by dip-switch SW1, SW2. Step division choice must be
performed only when driver supply is OFF.
The warranty period is 12 months after purchasing and is valid only
if all operational conditions and scheduled maintenance are strictly
followed.
1. General terms
1.1. In case of product acquisition as separate components, Seller
guarantees working ability of every component, but does not
assume responsibility for the quality of their joint work (mismatch of
components).
10
11
Step division option
Terms of Warranty

Edition from 23.11.2017 15
PLD330. Stepper motor driver
www.purelogic.ru8 (800) 555 63 74
11. Terms of Warranty
Produced and accepted in accordance with obligatory requirements of
valid technical documentation and is qualified for exploitation.
Lot number:
Technical
Control
Department
4.6. In cases when the product exploitation was performed in
conditions when power supply did not correspond with manufacturer’s
requirements, also when there is no electrical protection device.
4.7. The product which was resold by the initial buyer to the third party.
4.8. The product with defects which were caused by low-quality spare
parts or fulfilled their service life spare parts,consumable materials,
also using spare parts, consumable materials not corresponding with
manufacturer’s requirements.

We draw your attention to the fact that there can be
some changes in this instruction due to the product
consistent technical improvement. You can always
download our latest versions at www.purelogic.ru
www.purelogic.ru
Contacts
Moscow [phone]
Voronezh [phone]
149 Office
160, Leninsky avenue, Voronezh,
Russia, 394033
Monday - Thursday: 8.00–17:00
Friday: 8.00–16.00
Break: 12.30–13.30
[e-mail]
