PuriCle AAC-220 User manual

Product name portable air purifier
Air purification method 3-in-1 Triple filter
Filter life 6 months in normal environments (filter life may vary depending
on contaminated environment)
Power DC 5V/1A
Power consumption 5W or less
Control Capacitive touch
Wind volume 3 Steps
Size 195 Χ 125 Χ 220mm
Product specification
• Product name: PURICLE portable air purifier
• Model name: AAC-220
• Manufacturer: Mugunghwa Electronics
• Country of manufacture: Korea
• Agent: Atech
• Service center: 070-7777-2077
◎ This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
◎ Children should be supervised to ensure that they do not play with the appliance.
◎ Supply the voltage corresponding to the notation of the product.
Description based on the ELECTRICAL APPLIANCES
SAFETY CONTROL ACT
Product warranty period: One year from the date of purchase
Not covered by product warranty if one of the following applies:
A. One year has passed since the date of purchase.
B. Damage caused by arbitrary disassemble.
C. Modified and used for other purposes.
D. Damage caused by drop of product, strong impact, etc.
E. Damage caused by improper use and storage, such as submergence in water.
Product warranty
1) Use of USB adapter or power bank with an output of less than 5V/1A may cause a product's
performance degradation or make product broken.
2) Use the adapter that has been approved for domestic and international standards (KC,CE,ETL,US,
etc), as the uncertified chargers may cause damage to the purifier or cause accidents.
3) Check the rated voltage of this product and use the charger that corresponds to it before you
connect the appliance.
4) Only suitable for use in dry environments. Do not let water or any other liquid enter the
appliance. Do not use this appliance if it has been damaged or submerged in water.
5) Do not use the product near an open flame. Do not use or store combustible or flammable
substances near the product, such as ether, benzene, alcohol, drugs, propane, butane,
combustible sprays, insecticide, air freshener, cosmetics, candles, and lamps.
6) Make sure not to disassemble or repair the appliance arbitrarily. Use this product only for its
intended purpose.
7) Turn off power or disconnect cable before turning off car engine when it is used by car
charger.
8) Do not insert hands or metal objects into inside the body of appliance. This may cause an
electric shock , personal injury, or product malfunction.
INSTRUCTION
PURICLE
Portable Air Purifier

Powerful Triple-Filtration System for pleasant air
3-in-1 compound filters: Free filter, Hepa13 Filter, Colgate Fillter
1. Features of free filter
•Removal of coarse dust such as animal hair, lint, hair, dust etc.
•Protect high performance filters like Hepa filter, colgate filter.
2. Features of Hepa Filter
•H13 hepa filter used, filtering performance of efficiency 99.95%
• Remove pollutants such as house dust mite, viruses, mold etc. as small as 0.3 microns
• The strong electrostatic force of specially designed fibers removes contaminants, resulting in
high performance with low pressure loss.
3. Features of colgate filter
•Remove odor, hazardous gas
• Especially good at removing ammonia, acetaldehyde, acetic acid, formaldehyde, and toluene.
Control with gentle capacitive touch
Turn on and off without switch or button, Control speed level with capacitive touch.
Use everywhere
Puricle A1 is easy to carry: Use at home, in the office, in car.
Low power design enables long-term operation with power bank
Stylish Design
Unique roundish design goes well with all home decor and
makes it a perfect match wherever you put it.
1) Connect the micro 5-pin connector to the back of the
appliance.
2) Connect the USB terminal to the usb charger or power
bank. USB charger or powerbank must support an output
of 5V and a current of 1A or more.
3) After connecting the power, touch the top ‘POWER’ icon
to activate the product.
The LED of ‘POWER’ and ‘SPEED 1’ turn on, It means that
air purifier is working. Speed can be changed in 1-2-3
steps by the number of times it is pressed.
4) Touch the ‘LIGHT’ icon to turn on Mood light at the top.
5) LED light of ‘FILTER’ turns on when you use it for
approximately six months. The filter needs to be replaced
in this case. To replace the filter, press the side PUSH
button to remove the rear cover and replace it with a new
filter.
After replacement, touch the FILTER icon for more than 3
seconds and the LED will turn off. FILTER LED will turn on
again after approximately 6 months for replacement.
PURICLE Portable Air Cleaner Features How to Use Display
Components
Air purifier USB power cable instruction manual filter (inside)
POWER SPEED LIGHT FILTER
POWER SPEED LIGHT FILTER
Press the PUSH button. Close after replacement.Remove the filter.
LED display
leather handle
vent hole
body
slide cover
PURICLE 휴대용 공기청정기
Portable Air Purifier
안전을 위한 주의사항은 사용자의 안전을 지키고, 재산상의 손해 등을 막기 위한 내용입니다. 반드시 읽고 올바르게 사용해 주세요.
※ 본 제품은 대한민국에서만 사용하도록 만들어져 있으며, 해외에서는 품질을 보증하지 않습니다. (FOR KOREA UNIT STANDARD ONLY)
