PURSUIT 2870 Walkaround User manual

2870 WALKAROUND
1
2870 WALKAROUND
OWNER’S MANUAL
FISHING BOATS
3901 St. Lucie Blvd.
Ft.Pierce,Florida34946
921197
January 2004

2870 WALKAROUND
2
THIS PAGE WAS LEFT BLANK
INTENTIONALLY

2870 WALKAROUND
3
SAFETY INFORMATION
Your 2870 Walkaround Owner’s Manual
has been written to include a number of safety instructions to
assure thesafeoperationandmaintenanceofyourboat. These
instructions are in the form of DANGER, WARNING,
CAUTION, and NOTICE statements. The following
definitions apply:
IMMEDIATE HAZARDS WHICH WILL RESULT IN
SEVERE PERSONAL INJURY OR DEATH.
HAZARDS OR UNSAFE PRACTICES WHICH COULD
RESULT IN SEVERE PERSONAL INJURY OR DEATH.
HAZARDS OR UNSAFE PRACTICES WHICH COULD
RESULT IN MINOR PERSONAL INJURY OR PRODUCT
AND PROPERTY DAMAGE.
INFORMATION WHICH IS IMPORTANT TO PROPER
OPERATION OR MAINTENANCE, BUT IS NOT HAZARD
RELATED.
All instructions given in this book are as seen from the stern
looking toward the bow, with starboard being to your right,
and port to your left. A glossary of boating terms is included.
IMPORTANT NOTE: Your boat uses internal combustion
engines and flammable fuel. Every precaution has been taken
by Pursuit Fishing Boats to reduce the risks associated with
possible injury and damage from fire or explosion, but your
own precaution and good maintenance procedures are neces-
sary in order to enjoy safe operation of your boat.
NOTICE

2870 WALKAROUND
4
THIS PAGE WAS LEFT BLANK
INTENTIONALLY

2870 WALKAROUND
5
BOAT INFORMATION
MAKE:
SERIAL #:
MODEL:
GVRW:
PHONE:
REPRESENTATIVE:
TRAILER
NAME:
DEALER/PHONE:
ADDRESS:
SERVICE MANAGER:
ADDRESS:
SALESMAN:
DEALER PURSUIT
MODEL:
PURCHASE DATE:
IGNITION KEYS #:
DRAFT:
HULL SERIAL #:
DELIVERY DATE:
REGISTRATION #:
WEIGHT:
TRANSMISSION(S) (Inboard)
OUTDRIVE(S) (Inboard/Outboard)
MAKE:
PORT SERIAL #:
MODEL:
STARBOARD SERIAL #:
PORT SERIAL #:
MAKE: MODEL:
STARBOARD SERIAL #:
PROPELLER(S)
MAKE: MODEL:
STARBOARD SERIAL #:
MAKE:
DIAMETER/PITCH:
PORT SERIAL #:
RATIO:
ENGINE(S)
BLADES:
OTHER:
BOAT
Pursuit Fishing Boats reserves the right to make changes and improvements in equipment, design and vendored
equipment items, at any time without notification.
Please fill out the following information section and leave it in your Pursuit
2870 Walkaround Owner’s Manual. This information will be important for
you and Pursuit service personnel to know, if and when you may need to call
Pursuit for technical assistance or service.

2870 WALKAROUND
6
THIS PAGE WAS LEFT BLANK
INTENTIONALLY

2870 WALKAROUND
7
CERTIFICATIONS & SPECIFICATIONS
(For Export Only)
Manufacturer:
Name _____________________________________________________________
Address _____________________________________________________________
______________________________ZiipCode ___________________
Identification Numbers:
HullIdentificationNumber _______________________________________________
EngineSerialNumber _______________________________________________
TransmissionSerialNumber _______________________________________________
Intended Design Category:
Ocean _______ Inshore_______
Offshore_______ ShelteredWaters______
Weight and Maximum Capacities:
UnladenWeight-Kilograms(Pounds) ________________________________________
MaximumLoad-Weight-Kilograms(Pounds) _________________________________
NumberofPeople ________________________________________
MaximumRatedEngineHorsepower-Kilowatts (Horsepower)______________________
Certifications:
Certifications&ComponentsCovered
_______________________________________________________________________________________________________________
______________________________________________________________________________________
______________________________________________________________________________________
To be in compliance with European directives for recreational boats as published by the
InternationalOrganizationforStandardization(ISO)ineffectatthetimethisboatwasmanufac-
tured,weareproviding the following information.

2870 WALKAROUND
8
THIS PAGE WAS LEFT BLANK
INTENTIONALLY

2870 WALKAROUND
9
Warranty and Warranty Registration Cards
ThePursuitLimitedWarrantyStatementisincludedwithyourboat. Ithasbeenwrittentobeclearly
statedandeasilyunderstood. Ifyouhaveanyquestionsafterreadingthewarranty,pleasecontact
thePursuitCustomerRelationsDepartment.
Pursuit, engine manufacturers, and the suppliers of major components maintain their own
manufacturer's warranty and service facilities. It is important that you properly complete the
warranty registration cards included with your boat and engine(s) and mail them back to the
manufacturers to register your ownership. This should be done within 15 days of the date of
purchaseandbeforetheboatisputintoservice. Aformforrecordingthisinformationisprovided
atthebeginningofthismanual. Thisinformationwillbeimportantforyouandservicepersonnel
to know, if and when you may need service or technical information.
Theboat warrantyregistrationrequirestheHullIdentificationNumber“HIN” whichislocated
on the starboard side of the transom, just below the rubrail. The engine warranty registration
requirestheengineserialnumber(s). Pleaserefertotheengineowner'smanualforthelocationof
theserialnumber(s).
IMPORTANT:
All boat manufacturers are required by the Federal Boat Safety Act of 1971 to notify first time
ownersintheeventanydefectisdiscovered“whichcreatesasubstantialriskofpersonalinjuryto
thepublic.” Itisessentialthatwehaveyourwarrantyregistrationcardcompletewithyour
nameandmailingaddressinourfilessothatwecancomplywiththelawifitshouldbecome
necessary.
Product Changes
Pursuit is committed to the continuous improvement of our boats. As a result, some of the
equipmentdescribedinthismanualorpicturedinthecatalogmaychangeornolongerbeavailable.
Pursuit reserves the right to change standard equipment, optional equipment and specifi-
cationswithoutnoticeorobligation. IfyouhavequestionsabouttheequipmentonyourPursuit,
pleasecontactthePursuitCustomerRelationsDepartment.
Transferring The Warranty
For a Transfer fee, S2 Yachts will extend warranty coverage to subsequent owners of Pursuit
modelsforthedurationoftheoriginalwarrantyperiod. PleaserefertothePursuitLimitedWarranty
Statementfortheprocedureto transfer the warranty.
To take advantage of this program, notification of the change of ownership, including the new
owner's name, address and telephone number together with the appropriate fee, must be sent to
Pursuit Fishing Boats, Customer Relations Department, 3901 St. Lucie Boulevard, Ft. Pierce,
Florida 34946, within 30 days of the date of resale.
IMPORTANT INFORMATION

2870 WALKAROUND
10
S2Yachtswillconfirm,inwriting,thatthetransferofthewarrantyhastakenplace. Afterwhich,
thetransfereewillbetreatedastheoriginalpurchaserasoutlinedinthePursuitLimitedWarranty
Statement.
Service
AllwarrantyrepairsmustbeperformedbyanauthorizedPursuitDealer. Shouldaproblemdevelop
that is related to faulty workmanship or materials, as stated in the Limited Warranty, you should
contact your Pursuit dealer to arrange for the necessary repair. If you are not near your dealer or
anotherauthorizedPursuitdealerorthedealerfailstoremedythecauseoftheproblem,thencontact
thePursuitCustomerRelationsDepartmentwithin15days. Itistheboatowner'sresponsibility
to deliver the boat to the dealer for warranty service.

2870 WALKAROUND
11
Registration and Numbering
Federal law requires that all undocumented vessels equipped with propulsion machinery be
registeredinthestateofprincipaluse. Acertificateofnumberwillbeissueduponregisteringthe
boat. These numbers must be displayed on your boat. The owner/operator of a boat must carry
avalidcertificateofnumberwhenevertheboatisinuse. Whenmovedtoanewstateofprincipal
use, the certificate is valid for 60 days.
Inorder to be valid,the numbers must beinstalled to the properspecifications. Check with your
dealer or State Boating Authority for numbering requirements. The Coast Guard issues the
certificate of number in Alaska; all others are issued by the state.
Insurance
In most states, the boat owner is legally responsible for damages or injuries he or someone else
operating the boat causes. Responsible boaters carry adequate liability and property damage
insurancefortheirboat. Youshouldalsoprotecttheboatagainstphysicaldamageandtheft. Some
states have laws requiring minimum insurance coverage. Contact your dealer or State Boating
Authorityforinformationontheinsurancerequirementsinyourboatingarea.
Reporting Boating Accidents
All boating accidents must be reported by the operator or owner of the boat to the proper marine
lawenforcementauthorityforthestateinwhichtheaccidentoccurred. Immediatenotificationis
required if a person dies or disappears as a result of a recreational boating accident.
Ifapersondiesorthereareinjuriesrequiringmorethanfirstaid,aformalreportmustbefiledwithin
48 hours.
Aformalreportmustbemadewithin10daysforaccidentsinvolvingmorethan$500.00damage
or the complete loss of a boat.
A"BoatingAccidentReport"formislocatednearthebackofthismanualtoassistyouinreporting
an accident. If you need additional information regarding accident reporting, please call the
BoatingSafety Hotline, 800-368-5647.
Education
Ifyou are not anexperiencedboater, werecommend that the boat operatorandotherpeople that
normally accompanies the operator, enroll in a boating safety course. Organizations such as the
U.S. Power Squadrons, United States Coast Guard Auxiliary, State Boating Authorities and the
AmericanRedCrossofferexcellentboatingeducationalprograms. Thesecoursesareworthwhile
even for experienced boaters to sharpen your skills or bring you up to date on current rules and
OWNER'S/OPERATOR'S
RESPONSIBILITIES

2870 WALKAROUND
12
regulations. Theycanalsohelpinprovidinglocalnavigationalinformationwhenmovingtoanew
boating area. Contact your dealer, State Boating Authority or the Boating Safety Hotline, 800-
368-5647for further information on boating safety courses.
Required Equipment
U.S.CoastGuardregulationsrequirecertainequipmentoneachboat. TheCoastGuardalsosets
minimumsafetystandardsforvesselsandassociatedequipment. Tomeetthesestandardssomeof
the equipment must be Coast Guard approved. “Coast Guard Approved Equipment” has been
determinedtobeincompliancewithUSCGspecificationsandregulationsrelatingtoperformance,
construction,ormaterials. Theequipmentrequirementsvaryaccordingtothelength,typeofboat,
and the propulsion system. Some of the Coast Guard equipment is described in the Safety
Equipmentchapterofthismanual. Foramoredetaileddescription,obtain“FederalRequirements
AndSafetyTipsForRecreationalBoats” bycontactingtheBoatingSafetyHotline800-368-5647
or your local marine dealer or retailer and read the book “Sportfish, Cruisers, Yachts - Owner's
Manual,”included with thismanual.
Some state and local agencies impose similar equipment requirements on waters that do not fall
underCoastGuardjurisdiction. Theseagenciesmayalsorequireadditionalequipmentthatisnot
requiredbytheCoastGuard. Yourdealerorlocalboatingauthoritycanprovideyouwithadditional
informationforthe equipmentrequirements foryourboatingarea.

2870 WALKAROUND
13
TABLE OF CONTENTS
Chapter 1::
::
:Propulsion System
1.1 General....................................................................................19
1.2 Corrosion ................................................................................20
1.3 EngineLubrication..................................................................20
1.4 Engine Cooling System...........................................................21
1.5 Propellers ................................................................................21
1.6 EngineInstrumentation ...........................................................22
Chapter 2: Helm Control Systems
2.1 General ................................................................................... 25
2.2 Engine Throttle and Shift Controls ......................................... 25
2.3 Neutral Safety Switch............................................................. 26
2.4 Engine Power Tilt and Trim ................................................... 26
2.5 Engine Stop Switch ................................................................ 27
2.6 SteeringSystem ...................................................................... 28
2.7 Trim Tabs ............................................................................... 28
2.8 ControlSystems Maintenance ................................................ 29
Chapter 3: Fuel System
3.1 General ................................................................................... 31
3.2 Outboard Fuel System ............................................................ 32
3.3 FuelingInstructions ................................................................ 34
3.4 Oil Tanks................................................................................ 25
3.5 FuelSystem Maintenance....................................................... 36
Chapter 4: Electrical System
4.1 General .................................................................................. 37
4.2 Batteries ................................................................................. 37

2870 WALKAROUND
14
TABLEOFCONTENTS
Chapter 4: Electrical System (Continued)
4.3 DC Distribution System ......................................................... 38
4.4 Switch Panels......................................................................... 38
4.5 AC System............................................................................. 42
4.6 ElectricalSystemMaintenance .............................................. 46
Chapter 5: Fresh Water System
5.1 General ................................................................................. 49
5.2 FreshWater SystemOperation ............................................. 49
5.3 WaterHeater ......................................................................... 50
5.4 ShoreWater Connection ....................................................... 50
5.5 Shower Operation ................................................................. 51
5.6 FreshWaterSystemMaintenance ......................................... 51
Chapter 6: Raw Water System
6.1 General................................................................................... 53
6.2 High Pressure Washdown ...................................................... 53
6.3 Livewell ................................................................................. 55
6.4 Raw Water System Maintenance ........................................... 55
Chapter 7: Drainage Systems
7.1 General...................................................................................57
7.2 Cockpit Drains .......................................................................57
7.3 Hard-Top and Radar Arch Drains..........................................57
7.4 Bilge Drainage .......................................................................57
7.5 Cooler and Fishbox Drains ....................................................58
7.6 Water System Drains..............................................................59
7.7 Shower and Cabin Sink Drains ..............................................59
7.8 Rope Locker Drains...............................................................59
7.9 DrainageSystem Maintenance ...............................................59

2870 WALKAROUND
15
TABLEOFCONTENTS
Chapter 8: Ventilation System
8.1 CabinVentilation .................................................................... 61
8.2 WindshieldVentilation ........................................................... 61
8.3 Carbon Monoxide and Ventilation.......................................... 61
8.4 Maintenance............................................................................ 63
Chapter 9: Exterior Equipment
9.1 Deck........................................................................................ 65
9.2 Hull ......................................................................................... 69
9.3 Cockpit.................................................................................... 70
Chapter 10: Interior Equipment
10.1 Marine Head System ............................................................... 73
10.2 Galley...................................................................................... 74
10.3 Carbon Monoxide Detector..................................................... 75
10.4 Convertible V-Berth and Table ............................................... 76
Chapter 11: Safety Equipment
11.1 General.................................................................................... 77
11.2 EngineAlarms ........................................................................ 77
11.3 NeutralSafety Switch ............................................................. 78
11.4 Engine Stop Switch ................................................................ 78
11.5 RequiredSafetyEquipment .................................................... 78
11.6 Carbon Monoxide Detector .................................................... 81
11.7 FirstAid.................................................................................. 83
11.8 AdditionalSafetyEquipment.................................................. 84

2870 WALKAROUND
16
TABLEOFCONTENTS
Chapter 12: Operation
12.1 General ................................................................................... 85
12.2 Rules of the Road ................................................................... 86
12.3 Pre-CruiseCheck .................................................................... 87
12.4 Operating Your Boat .............................................................. 89
12.5 Fishing .................................................................................... 92
12.6 Tower Operation..................................................................... 92
12.7 Docking, Anchoring and Mooring.......................................... 94
12.8 Controls,Steeringor PropulsionSystem Failure..................... 96
12.9 Collision.................................................................................. 96
12.10 Grounding, Towing and Rendering Assistance ...................... 96
12.11 Floodingor Capsizing............................................................. 97
12.12 Transporting Your Boat .......................................................... 98
12.13 TraileringYour Boat............................................................... 98
12.14 Man Overboard....................................................................... 100
12.15 WaterSkiing ........................................................................... 101
12.16 TrashDisposal ........................................................................ 102
Chapter 13: Routine Maintenance
13.1 Exterior Hull and Deck............................................................ 103
13.2 Upholstery, Canvas and Enclosures ........................................ 106
13.3 CabinInterior........................................................................... 108
13.4 Bilge ........................................................................................ 108
13.5 DrainageSystem...................................................................... 109
Chapter 14: Seasonal Maintenance
14.1 Storage and Lay-up ................................................................. 111
14.2 Winterizing .............................................................................. 114
14.3 Recommissioning .................................................................... 117

2870 WALKAROUND
17
TABLEOFCONTENTS
Schematics
................................................................................................ 119
Appendix A: Glossary of Terms ......................................................... 131
Appendix B: MaintenanceLog ............................................................ 139
Appendix C: BoatingAccident Report ................................................. 145
Appendix D: Float Plan ....................................................................... 147
AppendixE: TroubleshootingGuide .................................................... 149

2870 WALKAROUND
18
THIS PAGE WAS LEFT BLANK
INTENTIONALLY

2870 WALKAROUND
19
Chapter 1:
PROPULSION SYSTEM
1.1 General
The Pursuit 2870 Walkaround is designed to be powered with twin 2-cycle or 4-cycle outboard
motors.
Eachmanufacturerofthevariousoutboardmotorsprovidesanowner’sinformationmanualwith
itsproduct. Itisimportantthatyoureadthemanual(s)verycarefullyandbecomefamiliarwiththe
proper care and operation of the engine and drive system. A warranty registration card has been
furnishedwitheachnewengineandcanbelocatedintheengineowner’smanual. Allinformation
requestedonthiscardshouldbefilledoutcompletelybythedealerandpurchaserandthenreturned
to the respective engine manufacturer as soon as possible.
DO NOT ATTEMPT TO SERVICE ANY ENGINE OR DRIVE COMPONENT
WITHOUT BEING TOTALLY FAMILIAR WITH THE SAFE AND PROPER
SERVICE PROCEDURES. CERTAIN MOVING PARTS ARE EXPOSED AND
CAN BE DANGEROUS TO SOMEONE UNFAMILIAR WITH THE OPERATION
AND FUNCTION OF THE EQUIPMENT.
2870 Walkaround

2870 WALKAROUND
20
DO NOT INHALE EXHAUST FUMES! EXHAUST CONTAINS CARBON MON-
OXIDE THAT IS COLORLESS AND ODORLESS. CARBON MONOXIDE IS A
DANGEROUS GAS THAT IS POTENTIALLY LETHAL.
1.2 Corrosion
Each outboard motor is a complete drive system with the gear case being just forward of the
propeller and connected to the power head with a vertical drive shaft. Other than the routine
maintenanceoutlinedintheengineowner’smanual,thereislittletobeconcernedwithunlessthe
boat is to be kept in saltwater for extended periods of time. Then, the main concerns are marine
growthand galvanic corrosion.
Marinegrowth occurs when componentsareleftin the water forextendedperiodsand can cause
poorperformanceorpermanentdamagetotheexposedcomponents. Thetypeofgrowthandhow
quickly it occurs is relative to the water conditions in your boating area. Water temperature,
pollution, current, etc. can have an effect on marine growth.
Galvaniccorrosionisthecorrosionprocessoccurringwhendifferentmetalsaresubmergedinan
electrolyte. Sea water is an electrolyte and submerged engine components must be properly
protected. Outboard motors are equipped with sacrificial anodes to prevent galvanic corrosion
problems. The anodes must be monitored and replaced as necessary. For locations and
maintenance, please refer to the engine owner's manual.
Whenleavingtheboatinthewater,tiltthemotorashighaspossible. Thiswill decreasetherisk
ofmarinegrowtharoundthecoolinginlets,propellerandexhaustportsanddamagefromgalvanic
corrosion.
DO NOT PAINT THE OUTBOARD MOTORS WITH ANTIFOULING PAINTS
DESIGNED FOR BOAT HULLS. MANY OF THESE PAINTS CAN CAUSE SE-
VERE DAMAGE TO THE ENGINES. CONTACT YOUR PURSUIT DEALER
OR ENGINE MANUFACTURER FOR INFORMATION ON THE PROPER
PAINTING PROCEDURES.
1.3 Engine Lubrication
2-cycle outboard motors are lubricated by a variable ratio oil injection system. The oil tanks are
mounted below the stern bait station near the transom. Always monitor the oil level before each
cruisebycheckingthegaugeinthehelmorvisuallycheckingtheoillevelusingthereferencemarks
on the tanks. When additional oil is needed, use only the type of oil specified by the engine
manufacturer. Refertotheengineowner’smanualforoilspecificationsandadditionalinformation
onthe oilinjectionsystem.
