Pvelectronics GPS5 Quick start guide

GPS5 Time Receiver
Issue 1 (01 February 2018)
www.pvelectronics.co.uk
-
1
-
Assembly Notes
A d User Guide
GPS5 Time Receiver For
Nixie Clock

GPS5 Time Receiver
Issue 1 (01 February 201
8
www.pvelectronics.co.uk
Issue
Number
Date
1 01 February
201
1.
PACK CONTENTS
Number
Compo e t
1 3.
0 metre (10 ft) cable
2 Adapter PCB
3 SMD Jac s
oc et
4 GPS Module
with
5
M3 X 6mm screw
6 M3 nut
7 S
elf adhesive foam pad
8 Heat shrin
8
)
REVISION HISTORY
Date
Reaso for Issue
201
8 New Document
PACK CONTENTS
Qty
0 metre (10 ft) cable
oc et
with
antenna
M3 X 6mm screw
elf adhesive foam pad
-
2
-
Reaso for Issue
Qty
1
1
1
1
2
2
1
1

GPS5 Time Receiver
Issue 1 (01 February 2018)
www.pvelectronics.co.uk
-
3
-
2. ASSEMBLY
2.1 Prepare the GPS Module
First, apply the self adhesive foam pad to the bac of the antenna,
then stic onto the plain PCB side of the GPS, oriented so that the
antenna cable can pass through the hole intended for it.
Now clip the antenna connector into the small matching connector
on the component side of the GPS module. It helps to press with a
hard surface, such as a small bloc of metal.
2.2 Jack Socket
Solder the jac soc et to the adapter PCB.

GPS5 Time Receiver
Issue 1 (01 February 2018)
www.pvelectronics.co.uk
-
4
-
2.3 Joi the PCBs
Screw the two PCBs together exactly as shown, with the adapter
PCB below the GPS PCB. Then fill the four holes with solder.
2.4 Apply the Heat Shri k
Slide over the heat shrin tubing and shrin over the assembly
with a hot air gun.

GPS5 Time Receiver
Issue 1 (01 February 2018)
www.pvelectronics.co.uk
-
5
-
3. CONFIGURING AND USING THE GPS5 TIME RECEIVER
3.1 Refer to the manual for your cloc to find the appropriate
configuration settings to enable GPS reception, and set baud rate
to 9,600 bps
3.2 Place the module as close to a window as possible, for the best
view of the s y. The closer to the window, the faster the module
will find satellites and synchronise your cloc .
Please allow at least 24 hours before contacting us, if the cloc
does not synchronise.
