Pyle Pro Vamp PVAMP120 User manual

USER MANUAL
TITLE GUITAR AMPLIFIER
MODEL PVAMP120
：
：
www.pyleaudio.com

1. HIGH INPUT Plug in high-level instruments here.
2. LOW INPUT Plug in low-level instruments here.
4.
5.
6
7
9
13. POWER This on/off switch provides power the unit
SELECT This switch is select the drive channel or normal
channel.
GAIN This is the distortion intensity control
for the overdrive channel.
. DRIVE VOLUME This is the overall level control for the
overdrive channel.
. TREBLE This equalization control adjusts the amount of
boost in the high frequency range
8. MIDDLE This equalization control adjusts the amount of
boost in the middle frequency range.
. BASS This equalization control adjusts the amount of
boost in the low frequency range
10. EFFECT OUT It is for transferring signals to the input port of the
other amp
11. EFFECT IN It is for receiving signals disposed by the other amp
12.PHONE This is a 1/4"3-conductor stereo headphone jack
for plugging in headphones
Function Explain
TECHNICAL SPECIFICATIONS
Power ~ 110 AC, 60 Hz
Rated Power 120 Watts MAX
Load Impedance 8 Ohms
Speaker 12
Signal/Noise Ratio 70dB
Frequency Response 20HZ to 15KHZ
Dimension 19.5” x 8.86” x 16.33”
Weight 27.6 lbs.
CAUTION:
WARNING:
AVIS:
ATTENTION:
CHASSIS SURFACE HOT.
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK,DO NOT EXPOSE
THIS EQUIPMENT TO RAIN OR MOISTURE.
RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR.
SUPERFICIE DE CHASSIS CHAUDE.
3. NORMAL VOLUME This is the overall level control for the
normal channel.
INPUTS
110
2
3
9
8
4567
110
2
3
9
8
4567
110
2
3
9
8
4567
110
2
3
9
8
4567
110
2
3
9
8
4567
NORMAL
VOLUME
DRIVE
SELECT
DRIVE
VOLUME TREBLE MIDDLE BASS PHONE
EFFECT
POWER
1235678910 11
HIGH LOW
PVAMP120
GUITAR AMPLIFIER
110
2
3
9
8
4567
GAIN
412
OUT IN
13 PVAMP120
