Pyle Pcm60a User manual

WARNING!

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE

THE COVER OF THIS UNIT. THERE ARE NO USERSERVICEABLE PARTS

INSIDE. REFER ALL SERVICING TO A QUALIFIED TECHNICIAN.

1. Read these instructions thoroughly before using this item.

2. Keep these instructions for future reference.

3. Heed all warnings.

4. Follow all instructions.

5. WARNING: To prevent re or electric shock, do not expose this equipment to rain

or moisture. Do not store or operate this product near any liquids.

6. Clean only with a dry cloth.

7. Do not store or operate this product near any heat sources such as radiators, heat

registers, stoves, or other apparatuses (including ampliers) that produce heat.

8. Do not defeat the safety purpose of the polarized or grounding-type plug.

A polarized plug has two blades with one wider than the other. A grounding plug

has two blades and a round grounding prong. The wide blade or third prong is

provided for your safety. If the provided plug does not t your outlet, consult an

electrician for the replacement of the obsolete outlet.

9. Protect the all wires connected to this unit from being walked on or pinched,

particularly plugs and the point where they exit from the unit. When removing the

cord from the power outlet, remove it by holding the plug not by pulling the cord.

10. Unplug the unit during lighting storms or when unused for long periods of time.

11. When wiring this unit and all other equipment used in connection to this unit

make sure that all of your equipment is turned OFF.

The lighting ash with arrow head symbol within an equilateral triangle is intended

to alert the user to the presence of “DANGEROUS”voltage within the product’s

enclosure that may be of sucient magnitude to constitute a risk of electric shock

to humans. Users should exhibit extra safety when this symbol appears in this

instruction manual and follow all precautions as they are stated.

The exclamation point within an equilateral triangle is intended to alert the user to

the presence of important operating and maintenance (servicing) instructions in

this manual.

www.PyleUSA.com

12. Once installation and wiring is complete power on all your equipment with the

volume and level controls turned DOWN. Once all the equipment is ON slowly

raise the volume or level controls to their proper positions.

13. When grounding this unit, be sure to do so correctly, so as not to defeat the

built-in grounding in this unit.

14. Before placing, installing, rigging, or suspending any product, inspect all

hardware, suspension, cabinets, transducers, brackets and associated equipment

for damage. Any missing, corroded, deformed, or non-load rated component

could signicantly reduce the strength of the installation, placement or array.

Any such condition severely reduces the safety of the installation and should be

immediately corrected. Use only hardware which is rated for the loading

conditions of the installation and any possible short-term, unexpected

overloading. Never exceed the rating of the hardware or equipment.

15. Consult a licensed, professional engineer regarding physical equipment

installation. Ensure that all local, state and national Regulations regarding the

safety and operation of equipment are understood and adhered to.

16. Refer all servicing to qualied service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power supply cord or plug is

damaged, liquid has been spilled or objects have fallen into the apparatus, the

apparatus has been exposed to rain or moisture, does not operate normally, or

has been dropped.

FM RADIO CONTROL INSTRUCTIONS

A. Connect the FM antenna before using the FM radio.

B. Press MODE button on the front panel or remote control to select FM mode.

C. Press PLAY/PAUSE button on the front panel or remote control, and will auto scan

and sore FM Radio station from 87.5Mhz to 108Mhz.

D. Press NEXT/PREV button to select the FM station.

REMOTE CONTROL

Remote control gives you commanding access only to USB/SD, Wireless BT and FM

functions and not the Master volume, microphone, bass, treble and other functions.

A. Please take out the battery sheet before using the remote control, otherwise the

remote control will not work.

B. Press these two buttons to select the previous or next track in USB/SD or

Wireless BT mode, there is no response in the FM mode.

C. Press this two buttons to select previous or next channel in FM mode,

there is no response in the USB/SD and BT mode.

D. Press these two buttons to increase or decrease Wireless BT volume, USB/SD

and FM. This buttons doesn’t control the master volume.

E. Press this button to auto scan all frequencies from 87.5MHz to 108MHz, the

unit will auto store the channels in FM mode. Please see 4, C for other details.

F. Press this button to select one from play mode (USB/SD mode, FM mode and

Wireless BT mode). Turning ON the unit will set the USB/SD mode automatically.

MP3 les will be played automatically after inserting USB ash drive or SD card.

You cannot select the AUX, CD and DVD input with this button.

G. Press and hold this button for 5 seconds to turn ON or OFF the USB/SD,

Wireless BT and FM mode but not to power ON/OFF the unit. The unit will output

the signal in CD, DVD, AUX input mode if you turn OFF the USB/SD, Wireless BT

and FM.

H. Aim the remote controller at the receiver of the main unit.

1. Press this button to chose the ID3 display model, will show TITLE/ARTIST/ALBUM/OFF.

Hold this button for 5 second to turn ON or OFF the MP3.

2. When in the FM mode, press this two buttons to tune FM Frequency.

3. Press these two buttons to select the previous or next track in USB or SD or

Bluetooth mode, to select previous or next channel in FM mode.

4. Volume up or down

5. Press the numbers to select the tracks directly.

The unit takes 1-2 seconds to response in USB or SD mode.

6. Press this button to repeat mode.
