Pyle PLRVST300 User manual

RVWallMountWirelessBTAudio/VideoReceiver
A/V Stereo Headunit, Multimedia Disc Player, USB Reader
PLRVST300

www.PyleUSA.com
1
CONTENT
Installation ...................................................................... 3
DIN Front - Mount Rear-Mount .............................. 3
Mounting ........................................................................ 4
Wiring Connection ...................................................... 5
Operation ........................................................................ 6
Location of keys ............................................................ 6
Turn ON/OFF the unit ................................................ 7
Sound adjustment ....................................................... 7
Loudness ......................................................................... 7
EQ function .................................................................... 7
Loc ON/OFF ................................................................... 7
Stereo/mono function ............................................... 7
Liquid crystal display (LCD) ....................................... 7
Alarm ON/OFF .............................................................. 7
Setting alarm time ....................................................... 7
Setting the alarm ......................................................... 7
Stop the Alarm output ............................................... 7
Brightness of the LCD ................................................. 7
Clock display .................................................................. 8
Clock setup ..................................................................... 8
Speaker output ............................................................. 8
Auxiliary input function ............................................. 8
Reset function ............................................................... 8
Radio operation ............................................................ 8
Switching to radio mode ........................................... 8
Selecting the frequency band ................................. 8
Selecting station .......................................................... 8
Automatic memory storing and
program scanning ....................................................... 8
Manually store station & recall
Preset station ................................................................. 9
CD/MP3 operation ....................................................... 9
Switching to CD mode ............................................... 9
Selecting tracks ............................................................ 9
Pause playing ................................................................ 9
Previewing all tracks ................................................... 9
Repeating the same track ......................................... 9
Playing all tracks in random ..................................... 9
Ejecting a disc ............................................................... 9
Selecting directory UP/DOWN ............................... 9
Selecting les by AS/PS button .............................. 9
Searching le number ............................................. 10
Searching le name .................................................. 10
Searching from folder .............................................. 10
WMA operation .......................................................... 10
USB play operation ................................................... 10
Supported MP3/WMA decoding modes ............. 11
Disc notes ..................................................................... 11
DVD Video menu play .............................................. 12
Bluetooth operation ................................................. 15
Remote control .......................................................... 16
Troubleshooting ........................................................ 18
Specication ............................................................... 19

www.PyleUSA.com
2
INSTALLATION
Notes:
• Choose the mounting location where the unit
will not interfere with the normal driving
function of the driver.
• Before nally installing the unit, connect the
wiring temporarily and make sure it is all
connected up properly and the unit and the
system work properly.
• Use only the parts included with the unit to
ensure proper installation. The use of
unauthorized parts can cause malfunctions.
• Consult with your nearest dealer if installation
requires the drilling of holes or other
modications of the vehicle.
• Install the unit where it does not get in the
driver’s way and cannot injure the passenger if
there is an emergency stop.
• If installation angel exceeds 30°from horizontal,
the unit might not give its optimum performance.
• Avoid installing the unit where it would be subject to
high temperature, such as from direct sunlight, or from
hot air, from the heater, or where it would be subject to
dust, dirt or excessive vibration.
DIN FRONT/REARMOUNT
This unit can be properly installed either from“Front”
(conventional DIN Front-mount) or “Rear”(DIN Rear -
mount installation, utilizing threaded screw holes at the
sides of the unit chassis). For details, refer to the
following illustrated installation methods.
INSTALLATION OPENING
This unit can be installed in any dashboard having an
opening as shown:
ATTENTIONS OF INSTALLATION
1. This player should be installed by a professional
technician.
2. Please read the instruction and operation of
equipment carefully before installing.
3. Make sure to connect other wires before power
connection.
4. To avoid short circuit, please make sure all the
exposed wire are insulating.
5. Please x all the wires after installation.
6. Please make connection to the player
accordingly to this instruction manual.
Wrong connection may cause damage.
7. This player only ts for 12V DC device.
Please make sure your car belongs to this kind
of cathode grounding electrical system.
8. Please connect the wires correctly.
Wrong connection will cause malfunction or
damage to the electrical system.
30

www.PyleUSA.com
3
INSTALLATION
MOUNTING
CAUTION: Do not install radio without rear cover installed. No user serviceable parts inside.
Rear cover provides protection against potential re hazard.

www.PyleUSA.com
4
WIRING CONNECTION
The receiver features independent channel volume control. To adjust the volume for each audio zone,
you must press the desired lettered zone button on the front panel zone -- to adjust the designated
channel volume (Front panel zone/ speaker buttons: A / B / C).
PIN NO WIRE COLOR DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
ORANGE
ORANGE / BLACK
PINK
BLUE
GRAY / BLACK
GRAY
PURPLE / BLACK
PURPLE
BROWN
BROWN / WHITE
RED
YELLOW
BLACK
WHITE / BLACK
WHITE
GREEN / BLACK
GREEN
C RIGHT SPEAKER (+)
C RIGHT SPEAKER (-)
ILLUMINATION CONTROL
POWER ANTENNA
A RIGHT SPEAKER (-)
A RIGHT SPEAKER (+)
B RIGHT SPEAKER (-)
B RIGHT SPEAKER (+)
C LEFT SPEAKER (+)
C LEFT SPEAKER (-)
ACC
B+
GROUND
A LEFT SPEAKER (-)
A LEFT SPEAKER (+)
B LEFT SPEAKER (-)
B LEFT SPEAKER (+)
WIRE INSERTION VIEW

www.PyleUSA.com
5
OPERATION
LOCATION OF KEYS
The unit has independent volume control
1. When you press button (7) speaker A, LCD (2) will display A, then you can rotate Round knob (1) to
increase or decrease speaker A volume output.
2. When you press button (7) speaker B, LCD (2) will display B, then you can rotate Round knob (1) to
increase or decrease speaker B volume output.
3. When you press button (7) speaker C, LCD (2) will display C, then you can rotate Round knob (1) to
increase or decrease speaker C volume output.
1. VOL/PWR/SEL
2. LCD
3. DISC SLOT
4. ALARM SET
5. ALARM ON/OFF
6. DIM (Dimmer)
7. SPEAKER A/B/C
8. 1 PAU (Pause/Play)
9. 2 INT
10. 3 PRT
21. EARPHONE OUTPUT
22. AUX IN Jack
23. USB INTERFACE
24. RESET button
11. 4 RDM
12. 5 DIR-
13. 6 DIR+
14. WEATHER BAND/BAND
15. MODE
16. AS/PS
17. DISP
18.
19.
20. (Eject)

www.PyleUSA.com
6
OPERATION
TRUN ON/OFF THE UNIT
Press PWR button (1) to turn on the unit. When the
unit is ON, press and hold PWR button (1) for 2
seconds to turn the unit o.
SOUND ADJUSTMENT
Press SEL button (1) shortly to select the desired
adjustment mode. The adjustment mode will
change in the following order:
BAS TRE BAL LOUD EQ LOC ST
VOL N1
6 0606
BAS: Bass
TRE: Treble
BAL: Balance
FAD: Fader
EQ: Equalization
LOUD: Loudness
LOC: Local
STEREO: Stereo
VOL: Volume
N16 0606: MCU version
In each item, by rotating the audio knob (1) it is
possible to adjust the desired sound quality.
LOUDNESS
In LOUD item you can turn it ON/OFF by rotating
the audio knob (1).
EQ FUNCTION
In EQ item you can select the preset EQ mode by
rotating the audio knob (1) as below.
CLASS - ROCK - POP - FLAT - EQ OFF
LOC ON/OFF
In LOC item rotating the audio knob (1) to turn
ON/OFF local function. In LOC ON mode the unit
will reduce the receiving sensitivity when you
search station. That means you can receive the
station that sound is good. It will ignores the
station that sound is not good. In LOC OFF mode it
will increase the receiving sensitivity when you
search the station. That means you can receive
more stations.
STEREO/MONO Function
In STEREO item rotating the audio knob (1) to
choose STEREO or MONO mode. In STEREO mode
you can receive FM stereo signal. In MONO mode
the stereo station will be switched to monochrome.
Sometimes when the signal is not good. Changing
it to MONO mode will reduce the noise.
LIQUID CRYSTAL DISPLAY (LCD)
The liquid crystal display (LCD) displays the
frequency, time and activated functions.
ALARM ON/OFF
Press ALARM ON/OFF button (5) to turn ON/OFF
alarm function.
SEEING ALARM TIME
Short press ALARM SET button (4) to see the
alarm time.
SETTING THE ALARM
To set the alarm, press and hold the ALARM SET
button (4) for 2 seconds. The number representing
the hours will ash. Rotating the VOL control (1) to
adjust the hour. Press ALARM SET again briey
and the number representing the minutes will
ash. Rotating the VOL control (1) to adjust the
minutes. Press the ALARM SET button (4) again to
store the alarm time.
Once a time is set, press ALARM ON/OFF (5) to
turn the alarm function on or o.
STOP THE ALARM OUTPUT
When time ran to the alarm time. The head unit
will output the alarm sound. Pressing ALARM
ON/OFF button (5) to stop the alarm output.

www.PyleUSA.com
7
OPERATION
BRIGHTNESS OF THE LCD
Press the DIM button (6) to adjust the LCD bright-
ness from “DIMMER 1” (brightest) to “DIMMER 2”
(less bright)
CLOCK DISPLAY
Press DISP button (17) to display the time. Each
displaying time is several seconds, and come back
to current position after several seconds.
CLOCK SETUP
Press and hold the DISP button (16) for 2 seconds
to access Clock Setup mode.
The number representing the hours will ash.
Rotating the VOL control (1) to adjust the hour.
Press DISP again briey and the number
representing the minutes will ash. Rotating the
VOL control (1) to adjust the minutes. Press the
DISP button again to exit clock setup mode.
SPEAKER OUTPUT
The three speaker output buttons (7) (SPEAKER A,
SPEAKER B and SPEAKER C) control speaker
output. Press any of the three buttons to turn up or
down the corresponding speaker output.
AUXILIARY INPUT FUNCTION
Press the MODE button (15) to access auxiliary
input mode (AUX). The unit can be connected to a
portable audio player through the AUX IN jack (22)
or the Audio/Video Inputs on the back of the unit.
RESET FUNCTION
RESET button (24) must be activated with either a
ballpoint pen or thin metal object. The RESET
button is to be activated for the following reasons:
• Initial installation of the unit when all wiring is
completed.
• All the function buttons do not operate.
• Error symbol on the display.
RADIO OPERATION
• SWITCHING TO RADIO MODE
Press MODE button (15) to select radio mode,
the radio mode appears in the display together
with the memory band and frequency.
• SELECTING THE FREQUENCY BAND
At radio mode, press BAND button (14) shortly
to select the desired band. The reception band
will change in the following order:
FM1 FM2 FM3 WB AM1 AM2
Note:
Press and hold BAND button for 2 seconds will
directly skip to the WB.
• SELECTING STATION
Press (19) button or (18) button shortly to
activate automatic seek function. It will search
up/down a station automatically. Press for 2
seconds until “MANUAL” appears on the display,
the manual tuning mode is selected. In this mode
you can turn UP/DOWN a step frequency one by
one till searched a station. If both buttons have not
been pressed for 5 seconds, it will return to seek
tuning mode and “AUTO” appears on the display.
• AUTOMATIC MEMORY STORING & PROGRAM
SCANNING
Automatic Memory Storing
Press AS/PS button (16) for 2 seconds, the radio
searches from the 87.5 MHz frequency and
checks the signal strength until one cycle search
is nished. And then some strong stations are
stored into the corresponding preset number
button. In the rst cycle it will in LOCAL mode to
receive the stronger station. If it is less than 18
pcs. station it will searching stations in 2nd cycle
in LOCAL OFF mode.

www.PyleUSA.com
8
OPERATION
PROGRAM SCANNING
Press AS/PS button (16) shortly to scan preset
station. The radio is holding at that preset number
for several seconds with release mute,
then searches again.
• MANUALLY STORE STATION & RECALL PRESET
STATION
To received a station, Press one of the preset
button (1~6) for 2 seconds. The current station is
stored into the number button. Shortly press the
preset button (1~6) to directly listen the station
that saved in the corresponding preset button.
In WEATHER BAND
1. Button (20): 162.550MHz
2. Button (21): 162.400MHz
3. button (22): 162.475MHz
4. button (23): 162.425MHz
5. button (24): 162.450MHz
6. button (25): 162.500MHz
The next station is 162.525 MHz. Press /
button to change these stations.
CD/MP3 OPERATION
• SWITCHING TO CD MODE
If there is no DISC inserted in the driver:
Gently insert the DISC with the printed side
uppermost into the DISC compartment until you
feel some resistance. The DISC is drawn into the
driver automatically. DISC playback begins.
If a DISC is already inserted in the driver:
Keep pressing MODE button (15) shortly until
the DISC mode display appears.
• SELECTING TRACKS
Press button (18) or button (19) to move to
the previous track/le or the following track/le.
Track/le number shows on display.
Hold button (18) or button (19) to fast
reverse or fast forward. DISC play starts from when
you release the button.
• PAUSING PLAYING
Press PAU button (8) to pause playing.
Press it again to resume play.
• PREVIEWING ALL TRACKS
Press INT button (9) to play rst several seconds
of each track/le on the current disc. Press again
to stop intro and listen to track/le.
• REPEATING THE SAME TRACK
Press RPT button (10) to continuously repeat the
same track/le. Press it again to repeat all the
tracks/les.
• PLAYING ALL TRACKS IN RANDOM
Press RDM button (11) to play all tracks/les in
random order. Press again to cancel the random
function.
• EJECTING A DISC
Press button (20) to stop disc playing and
eject the disc from the disc slot (3).
• SELECTING DIRECTORY UP/DOWN
Press DIR - button (12) or DIR + button (13) to
select previous directory or next directory. If the
MP3/WMA disc does not contain any directory,
there is no function of pressing DIR- button (12)
or DIR + button (13).
• SELECTING FILES BY AS/PS BUTTON
AS/PS button (16) is assigned as selection
button in MP3/WMA operation.

www.PyleUSA.com
9
OPERATION
Press to activate the selected mode as below:
Search le number => Search File Name =>Search
from folder.
• Searching File Number
Press AS/PS button one time to enter into
“Searching le number” mode.
Rotating audio knob (1) to select the le number
then press the audio knob (1) to conrm. The
unit searches the selected le to play.
If the le number was selected. The unit waits for
audio knob (1) for seconds. The unit searches the
le after few seconds, even if the audio knob (1)
button is not pressed.
You also can select the le by using the numeric
buttons. The unit searches the le selected by
following direct numeric buttons:
M1-M6: 1~6
MODE: 7
: 8
: 9
DISP: 0
• Searching File Name
Press AS/PS button for two times. It enters into
“Search File Name” mode. The unit searches les
that have the same character which is inputted
by the user pressing the corresponding buttons
listed on the Table 1 below.
KEY Assigned IN Searching mode (Table 1)
Explain as follows:
• Use the corresponding buttons to select the
characters A to Z, blank, 0 to 9, _, -, +. (of course
you can use knob (3) to select the characters A to
Z, blank, 0 to 9, _, -, +.)
• Press knob (3) to start the le search.
SEARCH FROM FOLDER
Press AS/PS button for three times. It enters into
“Searching from folder”mode. Rotating the audio
knob (1) to select desired folder. After that press
audio knob (1) to enter the folder. Rotating audio
knob (1) to select desired le. And then press
audio knob (1) again to play.
WMA OPERATION
The unit that can play the WMA disc and the
operation is the same with MP3 operation
described above.
USB PLAY OPERATION
In the front panel of the unit, there is an USB
interface (23). You can connect an USB driver
through this interface (23).
When you connect an USB driver through the
interface, the unit will search the MP3/ WMA les
in the USB driver and start to play. If in other mode,
you can also press MODE button (15) to select USB
mode. The USB operation is the same with the
CD/MP3/WMA operation described above.
MODE S, T, U, 7
TUNE/SEEK/TRACK
DOWN
V, W, X, 8
TUNE/SEEK/TRACK
UP
Y, Z, SPACE, 9
DISP _,-,+,0
AUDIO KNOB
CHARACTER SELECT
All the CHARACTER
above
AMS
Mode Select
SEL ENTER
M1
A, B, C, 1
D, E, F, 2
G, H, I, 3
J, K, L, 4
M, N, O, 5/Directory
DOWN
P, Q, R, 6/Directory UP
M2
M3
M4
M5
M6
