Pyle PMX802M User manual

Pyle'PMX'SeriesMultiChannelMixers
 www.PyleAudio.com


Warnings

xPleasebesuretoread,keepandrefertoinstructionslistedinthismanual.
xDonotusethisdevicenearwaterorexposetomoisture.
xCleanonlywithadrycloth.
xDonotblockanyventilationopeningsandallowadequatespaceforairflowduringoperation.
xDonotinstallnearanyheatsourcesorotherdevicesthatproduceheat.
xDonotdefeatthesafetypurposeofthepolarizedorgroundingtypeplug.
xProtectthepowercordfromanykindofdamageorcorrosion.
xUnplugthemixerwhennotinuseorwhenunusedforlongperiodsoftime.
xReferallservicetoqualifiedservicepersonnel.Servicingisrequiredwhenthemixerhasbeendamagedorperformsinanunusually.
xUseonlyspeakercableswhenconnectingspeakerstoamplifieroutputs.Usingothertypesofcablesisafirehazard.
xExposuretoextremelyhighnoiselevelsmaycauseinpermanenthearingloss.Individualsvaryconsiderablytonoiseinducedhearinglossbut
takeprecautionwhenlisteningathighlevels.
xIfthepowercordisdamaged(i.e.,cutorabarewireisexposed),askyourdealerforareplacement.Usingtheunitwithadamagedpowercord
isafireandelectricalshockhazard.
xShouldthisunitbedroppedorthecabinetbedamaged,turnthepowerswitchoff,removethepowerplugfromtheACoutlet,andcontactyour
dealer.Ifyoucontinueusingtheunitwithoutheedingthisinstruction,fireorelectricalshockmayresult.

CAUTION
Iftheunitisdamagedornonoperational,pleasenotifyyourdealerandtheshippingcompanyimmediately.Claimsfor
damageorreplacementmaynotbegrantedifnotreportedproperlyorinatimelymanner.





xConnectthisunit’spowercordonlytoanACoutletofthetypestatedinthisManualorasmarkedontheunit.Failuretodosomayresultin
fireand/orelectricalshock.
xDonotplaceheavyobjectsontopofthepowercord.Adamagedpowercordisalsoafireandelectricalshockhazard.
xUseonlytheincludedpowercordforthisunit,usingothertypesmayagainresultinfireandelectricalshock.
xDonotsetallequalizercontrolsandfaderstomaximumlevels.Doingsomaycauseoscillationdependingontheconditionoftheconnected
unitandspeakers,andmayalsodamagethespeakers.
xTheperformanceofcomponentsonthismixersuchasswitches,rotarycontrols,faders,andconnectors,deterioratesovertime.Therate
dependsontheoperatingenvironmentandissometimesunavoidable.Consultyourdealeraboutreplacingdefectivecomponents.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DONOTATTEMPTTOOPENORACCESSTHEINSIDEOF
THEUNIT.REFERALLSERVICINGTOAQUALIFIEDPYLE
SERVICEPERSONNEL.
This lightning flash symbol is intended to alert the user to the presence of uninsulated and “dangerous
voltage”withinthemixer'senclosurethatmaybeofsufficientpowertoconstituteariskofelectricshock.
Thisexclamationpointsymbolisintendedtoalerttheusertothepresenceofimportantoperating
andmaintaininginstructions,thatoneshouldpayattentiontoandkeepforfuturereference.

Pyle'PMX'SeriesMultiChannelMixers
 www.PyleAudio.com


Installation
Installthemixeronanevensurfacetoallowforsufficientairflowandventilationduringuse.Thedeviceisequippedwith
electronicallycontrolledcoolingfanstoprotectagainstthermaloverloadandinternalcircuitryfromdamagedueto
extremeheat.Pleaseavoidcoveringanysidesoftheunitorplacingobjectsorotheraudiodevicestooclosetoyourmixer.
Priortoconnectingandpoweringontheunit,makesurethatthedevicematchesthevoltageandfrequencyofyour
powersupply.Poweroffthemixerwhennotinuse.

CablesandConnections













RCA1/4''TRSandMono XLR3Pin
RCA connector jacks have been most
commonly used in home audio systems
and configurations for years. Also known
as RCA 'phono', 'plugs' or 'audio
connectors' , these jacks  are always
unbalanced, and generally carry a line
level signal at –10 dB, nominal signal
levels. The RCA connector jacks are most
likely used when connecting an audio
devicelikeamediaplayerorotherhome
audio type source to your mixer.  These
connector jacks are also used when
connectingtotheoutputofyourdevices.

1/4''monoandstereoconnectorjacksare
labeled for use as unbalanced mono,
unbalanced stereo, balanced mono, or as
an insert patch point. A 1/4'' TRS (Tip,
Ring, Sleeve), 3conductor connection, or
'Stereo' cable allows a single connection
signal to carry 2channels of audio; also
can be used for mono balanced signals.
While,a1/4''TS(Tip,Sleeve),2conductor,
or'Mono'cablearemostpopularlyknown
for their use in guitar or linelevel
instrument connection; they can also be
usedformonounbalancedsignals.

XLRconnectorjacks,almostalwayscarries
a balanced signal. Depending on your
device,theseconnectorjacksmayalsobe
capable of handling unbalanced signals.
Microphones generally have this type of
connector, as well as most other
professionalaudioequipmentanddevices.
Typical3PinXLRsocketsarefixedwiththe
rightmostpinbeingthe'ground',theleft
most pin being 'hot'  and the bottom pin
asthe'neutral'.


  TechnicalSpecifications
MonoInputs
MicrophoneInputs(XENYXMicPreamp) XLR,electronicallybalanced,discreteinputcircuit
MicE.I.N.(20Hz20kHz)
@0OhmSourceResistance
@50OhmSourceResistance
@150OhmSourceResistance
134dB/135.7dBAWeighted
131dB/133.3dBAWeighted
129dB/130.7dBAWeighted
FrequencyResponse <10Hz150kHz(1dB)
<10Hz200kHz(3dB)
GainRange +10dBto+60dB
MaximumInputLevel +12dB@+10dBGain
Impedance Approximately2.6kOhm,Balanced
SignaltoNoise 110dB/112dBAWeighted
Distortion(THD+N) 0.005%/0.004%,AWeighted
LineInput 1/4''TRSConnectors,ElectronicallyBalanced
ChannelEqualization
(FrequencyHz)
ControlRangeHigh:@10k+/15dB
ControlRangeLow:@60k+/15dB
Master5BandGraphicEQ Frequency:Hz(60,250,1K,4K,12K)
ControlRanges:+/12dB

Pyle'PMX'SeriesMultiChannelMixers
 www.PyleAudio.com


 ConnectorSpecifications

EffectsConnectors
EffectsSendEffectsReturn


1/4''TSConnector,Unbalanced
Impedance:Approx.1kOhm
OutputLevel:10dB
ControlRoomOutputs
RCAUnbalanced
Impedance:Approx.1kOhm
OutputLevel:10dB
HeadphoneOutput 1/4''TRSConnector,Stereo
OutputLevel:+19dB/150Ohm(+25dB)

 MixerLayoutandControlsFrontPanel
























1. 3PINLOWIMPEDANCEMICINPUT

Electronically balanced XLR input is designed to accept signals from any
balanced or unbalanced low impedance (Low Z) microphone. (Pin 1 to the
shield,Pin2tothe'hot'(positivepolarity)sideoftheaudiosignal,andPin3
tothe'cold'sideofthesignal.Dynamicorribbontypemicrophonesdonot
require phantom power. Microphone inputs are generally more sensitive
thantheLineinputs.
2. 1/4''LINEINPUT

Line/High impedance input, 1/4” connector jack is designed to accept
balanced or unbalanced linelevel signals such as those from keyboards,
drum machines, or samplers. There is enough gain available on the line
inputtoacceptevenlowerlevelsignals,suchasthosefromanunbalanced
microphoneorguitaroutput.Ifabalancedsignalistobeconnectedtothe
line input, then a 1/4” TRS (stereo) phone plug should be wired for: Tip =
positive(+),Ring=negative(),Sleeve=ground.
*Please note, the diagram above does not reflect allPyle 'PMX' Series models.  Some features listedare model specific, and are just made for descriptive
purposesforamorethoroughunderstandingofthePMXSeriesMixers.Toviewmodelspecificinformation,pleasevisitwww.PyleAudio.comandbrowsefor
thespecificmodelnumber.(PMXMixerSeriesModels:PMX401,PMX402M,PMX602M,PMX630I,PMX640BT,PMX802M,PMX830I,PMX840BT)

Pyle'PMX'SeriesMultiChannelMixers
 www.PyleAudio.com


3. GAINCONTROL
Adjustthevolumefortheselectedchannel'ssignal.It sendthesignaltothe
mastermixbuss,pleaserememberthisfunctionallowstheunittoactasa
preamp (...so if you are using a device that has its own unique volume
control, you will need to perform some volume adjustment and level
matching.Optimalsoundperformanceisachievedwhenaudiodistortionis
ataminimum.

4. EQCONTROLINDEPEDANTCHANNEL
Independent channel selection allows equalization effect controls for the
input signal. This gives you the ability to adjust the overall tone of the
selectedinput. Itacts as acut orboostcontrol, that addsto or diminishes
thesoundquality60Hz10kHz(+/15dB).

5. EFFECTCONTROLINDEPEDANTCHANNEL
Also known as EFFX controls, this is a 'send' control to the reverb buss. It
controls the amount of reverberation added to the selected destination
channelinputsignal.

6. LCDDISPLAYUSB/SDCONTROL
Use the digital LCD control panel and touch button to control your
connected flash memory drive.  Take music from your computer's media
library,transferittoyourremovablememorystoragedeviceandletitplay
throughthemixer.SupportsMP3andWMAmusicformats.

7. EFFECTSCONTROLLERS
TakecontroloftheEffectsVolume,EffectsEchoandEffectsDelay.Control
theoverallsignalleveloftheeffects'mix'thatisreceived.DelayandEcho
controlsallowyoutovariablyadjusttheeffectintervaltime.Setthiscontrol
lower for shorter Echo times to emulate similar 'doubling' effects while
setting a higher level provides longer effect times for 'stadiumlike' delay
sound.
8. USB/SDVOLUMECONTROL AdjustthevolumeforconnectedmediastreamingviaUSBFlashMemoryor
SDMemoryCards
9. MASTERVOLUMECONTROL Adjust the volume for the entire mixer and connected devices playing
throughthemixer.
10. MASTERGRAPHICEQUALIZERCONTROL
(LowLow/MidMidMid/HighHigh),thesemasterEQcontrolsallowyou
to adjust the levels of signal frequencies.  5Band frequency. graphic EQ
faders put you in control and allow you to achieve optimal sound
performance. Adjust the faders accordingly with different acoustic and
environmentalconditions.

11. POWERLED ThisLEDwillilluminatewhentheunitisswitchedon.

12. AUX(3.5mm)INPUT
Auxiliary input connector jack for connecting devices like MP3 Players,
Smartphones,Tablets,etc.

13. CD/TAPE:INPUT
Use the RCA (L/R) input connector jacks to connect a stereo signal output
devicetothemixer.(CD,Tape,Cassette,MP3,Smartphone,Tablet,Mac,PC,
Laptop,etc.)

14. REC:OUTPUT
ThissignalRCA(L/R)outputconnectorjacksareforconnectinganexternal
device to record from the mixer. Both channels are conformed into mono
forcompatibility.Thesignalsarethentaken'premaster'meaningthesignal
is without reverb or the master tone section does not include the tape
signal.The connectedsignal becomesthe 'main'bus signalbefore passing
through the mixer's 'master' level controls and graphic equalizer.
(Impedance:1kOhm@10dB)

15. INPUTVOLUMECONTROL
This control adjusts the level of the input signal applied to the CD/TAPE
Input.



Pyle'PMX'SeriesMultiChannelMixers
 www.PyleAudio.com


MixerLayoutandControlsBackPanel
























16. ACPOWER
ThepowersupplycableisthestandardvoltageforUSACwall
outlets.Itisgroundedandshouldneverhavethegroundpin
removedforanyreason.
17. SPEAKEROUTPUTS
1/4''speakeroutputs(A/B).Standard2conductorphonejacks
arewiredinparallel,witheachhavingtheabilitytoconnectto
yourspeakersystem.
18. EFFECTLOOP
Return:
Monounbalanced1/4''connectorjackforincorporatingreturn
effectorotherlinelevelsource.Itbringstheoutputofthe
externaleffectsdevicebackintothemixerforfurtherprocessing.
(Impedance:10KOhms@10dB).
Send:
Monounbalanced1/4''2Conductorlineoutputs.Usedto
connectadditionalrecordingdeviceorexternaleffectsprocessor.
Appliestotheinputofanexternaleffectsunitandallowsyouto
'send'yourdedicatedsignalouttotheconnectedexternal
device.(Impedance:1kOhm@10dB).
19. POWERSWITCH ControlthepoweroftheunitON/OFF.Whentheunitispowered
on,theLEDindicatorlightonthefrontwillshineblue.

Balancedvs.Unbalanced






Balancedlines are made specifically for reducingaudiointerference and noise rejection.  The rule ofthumb says, the longer thecable,the
morenoiseyouraudiosignalislikelytoencounter.Youraudiocableactsasanantennaandhastheabilitytopickupneighboringfrequencies,
andotherenvironmentalfactors,thatmayinterferewiththewayyoursoundperforms.The'noise'thatcanaffectyouraudiosignalsinclude
electromagnetic sound waves that are generated by devices like neighboring sound processors, computers, fans, motors, etc. Therefore,
balancedlinesarethebestoptionforrunninglongcablethroughyouraudioequipment.However,ifyouraudioequipmentisconfinedwithin
a single room or small space, then unbalanced lines will function sufficiently; keep in mind, the less interfering electromagnetic wave
producing devices around your equipment, the better.   Balanced connector lines are also widely used with microphone connection.  The
outputsignalfrommostmicrophonesisrathersmall,soeventhesmallestamountofinterfering'noise'willbeevidenttoyourears.

Pyle'PMX'SeriesMultiChannelMixers
 www.PyleAudio.com


Models:PMX630iandPMX830iwithBuiltin30PiniPodDocks












Models:PMX640BTandPMX840BTwithBuiltinBluetoothWirelessMusicStreaming












All'PMX'Mixerscomewithincludedpowercable:

























AudioConnectionsandAdditionalNotes:

Weshouldliketodrawyourattentiontothefactthatextremevolumesmaydamageyourhearingand/oryour
headphones or loudspeakers. Turn the MAIN MIX control and phones control in the main section fully down
beforeyouswitchontheunit.Alwaysbecarefultosetappropriatevolumelevels.

Please,preferably,usecommercialqualityRCAcablestowiretheinputsandoutputs.Youcan,ofcourse,also
connect unbalanced devices to the balanced input/outputs. Use either mono plugs, or ensure that ring and
sleevearebridgedinsidethestereoplug(orpins1&3inthecaseofXLRconnectors).

You will need a larger number of cables for the various connections to and from the mixer console. Please
operatewithcare,followinstructionsanduseonlyhighgradeconnectioncablesduringanyandalloperation.

Pleaseuseonlythepowersupplyunitprovidedwiththeconsole.

Pyle'PMX'SeriesMultiChannelMixers
 www.PyleAudio.com


'PMX'MixerSeriesModels&Specifications:



















































PMX630i
x6-Channel System Power Mixer
x(6) Balanced 3-Pin Microphone Inputs
x(6) 1/4'' High Impedance Inputs
xBuilt-in 30-Pin iPod Dock
xAux (3.5mm) Input Connector Jack
xConnect iPod, MP3 Players, iPhone, Smartphones, Tablets, etc.
xMaster System EFFX, EQ & Volume Controls
x5-Band Graphic Equalizer
xEffects Control & Send
xUSB Flash & SD Memory Card Readers
xFile Compatibility: MP3 & WMA Formats
xLCD Digital Display Screen with Touch Button Controls
xIndependent Channel EQ, Treble, Bass, Reverb Controls
x1/4'' Send/Return Jacks & (2) Conductor } Speaker Outputs
xRCA (L/R) Record Connector Jacks
xConvenient Carry Handle
xBuilt-in Cooling Fan
Technical Specs:
xMaximum Power Output: 600 Watts 4-Ohms
xFrequency Response: <10Hz - 150Hz (-1dB)
xMax. Input Level +12dBu @ +10dB Gain
xS/N Ratio: 110dB / 112dB A-Weighted
xChannel Tone Adjust (+/-15dB)
xGain Range: +10 to +60dB
xMaster EQ Control Ranges: +/- 12dB
xDistortion (THD+ N): 0.005% / 0.004%
xPower: 110/220 Voltage Switchable
xDimension: 17.91'' x 12.79'' x 9.64''
PMX830i
x8-Channel System Power Mixer
x(8) Balanced 3-Pin Microphone Inputs
x(8) 1/4'' High Impedance Inputs
xBuilt-in 30-Pin iPod Dock
xAux (3.5mm) Input Connector Jack
xConnect iPod, MP3 Players, iPhone, Smartphones, Tablets, etc.
xMaster System EFFX, EQ & Volume Controls
x5-Band Graphic Equalizer
xEffects Control & Send
xUSB Flash & SD Memory Card Readers
xFile Compatibility: MP3 & WMA Formats
xLCD Digital Display Screen with Touch Button Controls
xIndependent Channel EQ, Treble, Bass, Reverb Controls
x1/4'' Send/Return Jacks & (2) Conductor } Speaker Outputs
xRCA (L/R) Record Connector Jacks
xConvenient Carry Handle
xBuilt-in Cooling Fan
Technical Specs:
xMaximum Power Output: 600 Watts 4-Ohms
xFrequency Response: <10Hz - 150Hz (-1dB)
xMax. Input Level +12dBu @ +10dB Gain
xS/N Ratio: 110dB / 112dB A-Weighted
xChannel Tone Adjust (+/-15dB)
xGain Range: +10 to +60dB
xMaster EQ Control Ranges: +/- 12dB
xDistortion (THD+ N): 0.005% / 0.004%
xPower: 110/220 Voltage Switchable
xDimension: 20.67'' x 12.80'' x 9.64''
PMX640BT
xBluetooth Wireless Music Streaming
xWorks with Virtually Any Bluetooth Enabled Device
x(iPhone, Android, Smartphone, iPad, Tablet, PC, etc.)
xDigital LCD Display & Front Facing Control Center
xUSB Flash Drive & SD Memory Card Readers
x3-Pin Low Impedance Balanced Microphone Inputs
x1/4'' Line/ High Impedance Balanced Inputs
xIndependent Channel Volume, EQ & EFFX Controls
xMaster 5 Band Graphic Equalizer
xEQ & Master EFFX Control of Level, Echo & Reverb Controls
xAux (3.5mm) Input Jack for Connecting External Devices
xHeadphone Output: 1/4'' TRS Stereo Connector
xRCA & 1/4'' Effects Loop Connectors
xAdditional RCA Inputs: Tape Play (L/R), Tape Record (L/R)
Technical Specs:
x600 Watt Output Power
x8 Ohm Impedance Each Channel
xLine Level Impedance 10K Ohms @ -10dBv
xMono Microphone Inputs (XENYX Mic Pre-Amp)
xXLR: Electronically Balanced Discrete Input Circuit
xFrequency Response: <10Hz150kHz (-1dB), <10Hz200kHz (-
3dB)
xGain Range: +10 - +60dB
xMax. Input Level: +12dBu @ +10dB Gain
xImpedance: Approx. 2.6k Balanced
xSignal-to-Noise Ratio: 110dB / 112dBA Weighted
xDistortion: (THD+N): 0.005% / 0.004% A- Weighted
xChannel Equalization: Control Range
xHigh @ 10K +/-15dB, Low @ 60K +/-15dB
xMaster EQ Frequency Hz: 60, 250, 1K, 4K, 12K
xBoost/Cut Control: +
/
-12dB
PMX840BT
xBluetooth Wireless Music Streaming
xWorks with Virtually Any Bluetooth Enabled Device
x(iPhone, Android, Smartphone, iPad, Tablet, PC, etc.)
xDigital LCD Display & Front Facing Control Center
xUSB Flash Drive & SD Memory Card Readers
x3-Pin Low Impedance Balanced Microphone Inputs
x1/4'' Line/ High Impedance Balanced Inputs
xIndependent Channel Volume, EQ & EFFX Controls
xMaster 5 Band Graphic Equalizer
xEQ & Master EFFX Control of Level, Echo & Reverb Controls
xAux (3.5mm) Input Jack for Connecting External Devices
xHeadphone Output: 1/4'' TRS Stereo Connector
xRCA & 1/4'' Effects Loop Connectors
xAdditional RCA Inputs: Tape Play (L/R), Tape Record (L/R)
Technical Specs:
x800 Watt Output Power
x8 Ohm Impedance Each Channel
xLine Level Impedance 10K Ohms @ -10dBv
xMono Microphone Inputs (XENYX Mic Pre-Amp)
xXLR: Electronically Balanced Discrete Input Circuit
xFrequency Response: <10Hz150kHz (-1dB), <10Hz200kHz (-
3dB)
xGain Range: +10 - +60dB
xMax. Input Level: +12dBu @ +10dB Gain
xImpedance: Approx. 2.6k Balanced
xSignal-to-Noise Ratio: 110dB / 112dBA Weighted
xDistortion: (THD+N): 0.005% / 0.004% A- Weighted
xChannel Equalization: Control Range
xHigh @ 10K +/-15dB, Low @ 60K +/-15dB
xMaster EQ Frequency Hz: 60, 250, 1K, 4K, 12K
xBoost/Cut Control: +
/
-12dB

Pyle'PMX'SeriesMultiChannelMixers
 www.PyleAudio.com


'PMX'MixerSeriesModels&Specifications:

PMX401
x4-Channel System Power Mixer
x(4) Balanced Microphone Inputs
x(4) 1/4" Line/High Impedance Inputs
xRCA Audio Input & RCA Audio Output
xAux (3.5mm) Input Connector Jack
xAudio Line-In: Connect Devices like Smartphones & MP3 Players
x1/4” Send/Return Jacks & (2) Conductor 1/4” Speaker Outputs
xBuilt-In Reverb with Individual Channel Controls
xMaster Effects Controls with Echo, Delay & Effects Volume
xEqualizer Control For Each Input
xConvenient Carry Handle
xBuilt-in Cooling Fan
Technical Specs:
xMaximum Power Output: 150 Watt / 4 Ohm
xFrequency Response: 20Hz - 20kHz +1dB
x(Lo-Z) Mic Impedance: 1K Ohm
x(Hi-Z) Mic/Line Impedance: 33K Ohm
xImpedance Gain
xGain Range: +10 to +60dB
xMaster EQ Control Ranges: +/- 12dB
xChannel Tone Adjustment: +/-15dB
xS/N Ratio: 110dB / 112dB A-Weighted
xMax. Input Level +12dBu @ +10dB Gain
xDistortion (THD+ N): 0.005% / 0.004%
xPower: 110/220 Voltage Switchable
xDimensions: 12.9''W x 8.3''H x 10.5''D
PMX402M
x4-Channel System Power Mixer
x(4) Balanced 3-Pin Microphone Inputs
x(4) 1/4'' High Impedance Inputs
xAux (3.5mm) Input Connector Jack
xConnect iPod, MP3 Players, iPhone, Smartphones, Tablets, etc.
xMaster System EFFX, EQ & Volume Controls
x5-Band Graphic Equalizer
xUSB Flash & SD Memory Card Readers
xLCD Digital Display Screen with Touch Button Controls
xIndependent Channel EQ, Treble, Bass, Reverb Controls
x1/4'' Send/Return Jacks & (2) Conductor ¼” Speaker Outputs
xRCA (L/R) Record Connector Jacks
x1/4'' Headphone Output
xConvenient Carry Handle
xBuilt-in Cooling Fan
Technical Specs:
xMaximum Power Output: 400 Watts 4-Ohms
xFrequency Response: <10Hz - 150Hz (-1dB)
xMax. Input Level +12dBu @ +10dB Gain
xS/N Ratio: 110dB / 112dB A-Weighted
xChannel Tone Adjust (+/-15dB)
xGain Range: +10 to +60dB
xMaster EQ Control Ranges: +/- 12dB
xDistortion (THD+ N): 0.005% / 0.004%
xPower: 110/220 Voltage Switchable
xDimension: 15.75'' x 12.01'' x 7.87''
PMX602M
x6-Channel System Power Mixer
x(6) Balanced Microphone Inputs
x(6) 1/4" Line/High Impedance Inputs
xAux (3.5mm) Input Connector Jack
xConnect iPod, MP3 Players, iPhone, Smartphones, Tablets, etc.
xMaster System EFFX, EQ & Volume Controls
x5-Band Graphic Equalizer
xUSB Flash & SD Memory Card Readers
xLCD Digital Display Screen with Touch Button Controls
xIndependent Channel EQ, Treble, Bass, Reverb Controls
x1/4'' Send/Return Jacks & (2) Conductor ¼” Speaker Outputs
xRCA (L/R) Record Connector Jacks
x1/4'' Headphone Output
xBuilt-in Cooling Fan
Technical Specs:
xMaximum Power: 600 Watt / 4 Ohms
xFrequency Response: <10Hz - 150Hz (-1dB)
xMax. Input Level +12dBu @ +10dB Gain
xS/N Ratio: 110dB / 112dB A-Weighted
xChannel Tone Adjust (+/-15dB)
xGain Range: +10 to +60dB
xMaster EQ Control Ranges: +/- 12dB
xDistortion (THD+ N): 0.005% / 0.004%
xPower: 110/220 Voltage Switchable
xDimensions (L x W x H): 15.9" x 10.6" x 8.3"
PMX802M
x8-Channel System Power Mixer
x(8) Balanced Microphone Inputs
x(8) 1/4" Line/High Impedance Inputs
xAux (3.5mm) Input Connector Jack
xConnect iPod, MP3 Players, iPhone, Smartphones, Tablets, etc.
xMaster System EFFX, EQ & Volume Controls
x5-Band Graphic Equalizer
xUSB Flash & SD Memory Card Readers
xLCD Digital Display Screen with Touch Button Controls
xIndependent Channel EQ, Treble, Bass, Reverb Controls
x1/4'' Send/Return Jacks & (2) Conductor ¼” Speaker Outputs
xRCA (L/R) Record Connector Jacks
x1/4'' Headphone Output
xBuilt-in Cooling Fan
Technical Specs:
xMaximum Power: 800 Watt / 4 Ohms
x125 Watt RMS x2 @8 Ohms
xFrequency Response: <10Hz - 150Hz (-1dB)
xMax. Input Level +12dBu @ +10dB Gain
xS/N Ratio: 110dB / 112dB A-Weighted
xChannel Tone Adjust (+/-15dB)
xGain Range: +10 to +60dB
xMaster EQ Control Ranges: +/- 12dB
xDistortion (THD+ N): 0.005% / 0.004%
xPower: 110/220 Voltage Switchable
xDimensions: 20.28'' x 12.01'' x 7.87''
