CONTENTS
1: Safety Precautions 3
2: Package Contents 3
3: Description of Parts 4
4: Loading Slides 4
5: Loading Negatives 6
6: Loading Photo 7
7: General Operations 8
8: Trouble Shooting 20
9: Technical Specications 20
*Illustrations are for instructional purposes only and may be dierent from the actual product.

www.PyleUSA.com
3
1: SAFETY PRECAUTIONS
Important: Do not expose this product to rain or moisture to preserve the life of
your product.
Caution: Do not disassemble this unit. To prevent the risk of electric shock, do not
remove cover.
Ventilation: The device should be situated so that its location or position does not
interfere with its proper ventilation. For example, the unit should not be situated
on a bed, sofa, rug or similar surface that may block the ventilation openings.
Heat: The device should be situated away from sources of high heat such as
radiators or stoves.
Cleaning: We strongly suggest using a clean, dry, non-alcohol cotton swab to
clean the glass surface periodically to produce a clear image.
Non Use Period: The USB cord for the device should be unplugged from the
computer when the unit is left unused for a long period of time.
USB Overloading: Do not overload the USB connections on your computer. If
you have too many devices connected to your computer such as a wireless mouse,
media player, mobile phone or other USB powered devices. There may not be
enough power for the lm & photo scanner to operate properly.
Servicing: The user should not attempt to service the device beyond those
means described in the operating instructions. All other servicing should be
referred to qualied person.
Film Holder: The design of the lm holder follows ISO standard. In some cases the
holes on the lm will not match exactly to the alignment of the holder. This is
caused by a non-standard camera. In this case there will be a small black line on
the edge of the frame that can easily be cropped out using photo editing
software.
ISO: International Organization for Standardization
For environmental protection and energy conservation, besides in PLAYBACK and
USB mode, the device will be powered o automatically without any operation in
30 minutes of inactivity.
2: PACKAGE CONTENTS
• Film & Photo Scanner
• USB Cable
• Negative Film Holder
• Positive Slide Holder
• 4 in 1 Photo Tray
• OCR CD
• AC/DC adapter
• User’s Manual
Please remove the adaptor from the mains when not in use.

www.PyleUSA.com
4
3: DESCRIPTION OF PARTS
4: LOADING SLIDES
Hold up the slide toward the light. Face the trademark side of the slide away
from you. Look through the slide and it should appear normally (not a mirror
image). Now turn the slide so the image is upside down while looking at the
same side.
Film and Photo Scanner Positive Slide Holder
Photo/Name Card Holder USB cable
Negative Film Holder

www.PyleUSA.com
5
Open the slide holder at the marked spot on the top.
With the slide holder laid open place the slide into
recessed area in the holder- the slide should t
perfectly.
Note: Handle slides with care. Any dust scratches or
ngerprints will show up on your saved images.
You’d better to cotton gloves when handling slides.
It is recommended to use compressed air to remove
any dust on the slides. You can purchase it from an
oce supply or electronics retailer.
Close the slide holder and press the edges so that it locks in place.
Hold it in the position as shown in the lm & photo scanner. Insert the Slide Holder
into the slot on the right side of the lm & photo scanner as shown.

www.PyleUSA.com
6
5: LOADING NEGATIVES
Hold up the negative toward the light. As you look through
the negative you should be able to read the small negative
numbers normally (not a mirror image). Now turn the
negative so the image is upside down while looking at the
same side.
Open the negative holder at the marked spot on the top. With the negative
holder laid open place the negative into holder so the notches line up with the
notches on the holder.
Note: Handle negatives with care. Any dust, scratches or
ngerprints will show up on your saved images. If possible
use cotton gloves when handling negatives.
It is recommended to use compressed air to remove any
dust on the negatives. This is not included with the lm & photo scanner but
can be purchased from an oce supply or electronics retailer.
Close the negative holder and press the edges so that it locks in place
Hold it in the position as shown in the lm & photo scanner.
Insert the negative holder into the slot on the right side of
the lm & photo scanner as shown.
Film Holder:
The design of the lm holder follows ISO standard. In some cases the holes on
the lm will not match exactly to the alignment of the holder. This is caused by
a non-standard camera. In this case there will be a small black line on the edge
of the frame that can easily be cropped out using photo editing software.

www.PyleUSA.com
7
ISO: International Organization for Standardization
6: LOADING PHOTO
Position the brackets according to the marked dimensions on the photo tray. Note
that for 5x7”photographs, the brackets do not need to be tted into the photo tray.
Place the brackets into the slots and slide the brackets downwards to secure.
Check that they are securely fastened by turning the photo tray upside down. The
brackets should not fall o.
Insert the photo into appropriately sized photo tray (5”x7” (5R), 4”x6” (4R), 3 ½”x5”
(3R), name card)
Left Bracket Right Bracket
Photo Tray
1. Place brackets in photo tray 2. Slide brackets downwards
to secure

www.PyleUSA.com
8
Insert the photo tray into the photo tray slot from the top of the lm & photo
scanner as shown.
Note:
• Please use the provided OCR CD to organize the name cards.
• Handle photo with care. Any dust scratches or ngerprints will show up on
your saved images.
• Scanned name cards will capture a standard dimension of 91x55mm. The
scanned image will have a slight border around the name card.
7: GENERAL OPERATIONS
Note: Maybe there is some dierence between the preview image and saved
image, please subject to the image that you saved in SD card.
Quick Start
1. If you want to scan the lms, please switch two switches on the top of the
device to the left side. Otherwise if you want to scan the photos, please
switch to the right side.
2. Put Slide/Negative onto the Slide/Negative Holder or insert photo into
appropriately sized photo tray (5”x7”(5R), 4”x6” (4R), 3 ½”x5” (3R), name card)

www.PyleUSA.com
9
3. Insert the Slide/Negative Holder into the slot on the right of the device or insert
photo tray into photo tray slot from the top of the device.
4. Apply the power to the lm & photo scanner by two ways:
1. USB: Connect the lm & photo scanner to PC with USB cable
2. 5V Adapter: Connect the adapter to the device with USB cable
5. Press POWER button to turn on the lm & photo scanner.
Note:
1. When the Film scanner mode is selected, the Film scan indication LED is on.
2. When the Photo scanner mode is selected, the Photo scan indication LED is on.
6. Follow the menu on screen for scanning.
7. After the scanning is done, take out the memory card.
Note: The lm & photo scanner has a built-in memory for recording, if there
is a memory card inserted, it will be the top priority for saving data
8. View pictures from PC by USB mode
9. When capturing in either photo or lm modes, please remember to push both
slide switches to the correct placement. A notication will appear on-screen as a
reminder to carry out the following:
1. Photo: Push both sliders to the right
2. Film: Push both sliders to the left.
Operation Guide
Home/MODE: Main menu
When the Film scanner mode is selected, the following main menu will appear:
1. Push the slider above to the right ( photo scanning)
2. Please remove lm tray for photo scanning
Push the slider above to the left (lm scanning)
1. Language Mode
2. USB Mode
3. Capture Mode
4. Playback Mode
5. Film Type
6. Resolution

www.PyleUSA.com
10
When the Photo scanner mode is selected, the following main menu will appear:
1. Language mode
2. USB mode
3. Capture mode
4. Playback mode
5. Eect: Multicolor, B&W
6. Crop Proportion: (5”x7” (5R), 4”x6” (4R), 3 ½”x5” (3R), name card)
7. Resolution
Home/MODE: No Memory Card
If there is no memory card inserted into the device, a warning icon will be
shown on screen when entering the main menu
No memory card indicator
