Pyle PPHD210 User manual

PPHD210
10''PortableWirelessBTPASpeakerSystem
Karaoke Speaker with LED Lights, USB/Micro SD/
FM/BT/Aux/Remote Control/Mic & Guitar Inputs,
Built-in Rechargeable Battery, w/ Wheels
and Handle Bar (1200 Watt)
Questions? Issues?
We are here to help!
Phone: [phone]
Email: [email protected]

www.PyleUSA.com
2
www.PyleUSA.com
3
PLEASE READ THE INSTRUCTION MANUAL CAREFULLY
AND KEEP IT FOR FUTURE REFERENCE
WARNING
Illegal operation may cause personal injury, which could be fatal and may
cause damage to property.
REMOTE CONTROL Functions
1. POWER OFF ONLY
2. CHOOSE SIGNAL INPUT
3. INCREASE MUSIC VOLUME
4. MENU
5. PREVIOUS LED MODE
6. DECREASE MUSIC VOLUME
7. NEXT LED MODE
8. MUTE
9. REPEAT
10. PLAY/PAUSE KEY
11. PREVIOUS SONG/CHANNEL
12. NEXT SONG/CHANNEL
For MENU:
TWS-TRUE WIRELESS STEREO SETUP
1. Turn on two same PA speaker that you’re attempting to pair together and
switch both units to Wireless BT mode.
2. Choose one of units to begin to pairing process.
3. Press down on the NEXT button for 3 seconds until you hear a chiming
sound; This means the unit is ready to pair with another unit.
4. Move onto the second unit and repeat step 3.
5. Now begin playing your music through Wireless BT enabled mobile device.
The speakers will begin to play your music simultaneously.
Control Board Functions
1. DO NOT place objects
on top of the device, as
objects may scratch
the device.
2. DO NOT expose the
device to dirty or
dusty environments.
3. DO NOT insert any
foreign objects into
the device.
4. DO NOT expose the
device to strong
magnetic or electrical
eld.
5. DO NOT use the device in the
rain
6. Please check with your Local
Authority or retailer for proper
disposaI of electronic products.
7. DO NOT disassemble the
device. Only a certied service
technician should perform
repair.
8. The device has apertures to
disperse heat. DO NOT block
the device ventilation, the device
may become hot and malfunction
as a result.
N(0--30) Microphone volume adjustment
E(0--30) Microphone echo volume adjustment
d(0--12) Microphone delay volume adjustment
9(0--30) Guitar volume adjustment
(LED(0--1) LED OFF/ON

www.PyleUSA.com
4
www.PyleUSA.com
5
Troubleshooting and Warning
PPHD210
10'' Portable Wireless BT PA Speaker System
Karaoke Speaker with LED Lights, USB/Micro SD/FM/BT/Aux/Remote Control/
Mic & Guitar Inputs, Built-in Rechargeable Battery, w/ Wheels & Handle Bar
(1200 Watt)
Features:
• True Wireless Stereo Function
• Simple DJ Sound Eect and EQ Adjustable
• USB Charging Power Function
• Portable PA Speaker System
• High-Powered Loudspeaker Design
• Master Volume, Mic Volume, and Mic Echo Adjustable
• (2) 1/4'' -inch (6.5mm) Microphone/Guitar Instrument Inputs
• ON/OFF Switch to Control LED Lights
• Wireless BT Music Streaming Ability
• Multi-Color Flashing LED Party Lights
This products can expose you to a chemical or group of checmicals, which
may include ”Lead and lead compounds” which is known in the state of
California to cause cancer, birth defects, or other reproductive harm. For
more info, go to https://www.p65warnings.ca.gov/.
Fault Possible Cause Solution
No sound
Distortion
of sound
Karaoke
does not
work
MP3
does not
play
1. No input sound source
2. Volume is too low
1. Volume too high
2. Speaker may be damaged
1. Microphone plug is not fully
inserted.
2. Microphone switch is not on
3. Microphone volume knob is
at the lowest position
1. The song format in the U disc
is incorrect
2. Improper operation has caused
a process disorder
3. USB disc is disconnected
1. Use a better music signal
2. Adjust volume
1. Turn down the volume
2. If speaker is damaged,
Repair or replace it
1. Plug microphone properly into
the socket
2. Turn on microphone switch
3. Adjust microphone volume
properly
1. Transform song format into
Mp3 format
2. Reboot the machine
3. Insert USB disc properly
1. Microphone volume knob
2. Guitar volume knob
3. 6.5 MM microphone input jack
4. 6.5MM guitar input jack
5. 3.5MM audio input jack
6. USB jack for DC 5V/1A output
7. Reset button
8. Micro SD jack
9. USB jack for Mp3 play
10. Echo volume knob for microphone
11. Delay volume knob for microphone
12. Input signal choosing
13. 3 kinds of EQ function
14. Record function on USB/Micro SD
mode
15. Repeat song function
16. Last song on USB/Wireless BT
mode, last channel for FM mode
17. Short press for next song on USB/
Wireless BT mode, next channel for
FM mode, press and hold for TWS
-connection
18. LED light swift
19. Dierent DJ eect choose
20. Master volume control for music
21. Stop/Play song on USB/Wireless BT
mode, automatically scan channel
for FM mode
22. Power ON/OFF button
23. 15V/2A DC charge and LED
indicator phone volume knob
