Pyle PPHP122SM User manual

Questions? Issues?
We are here to help!
Phone: [phone]
Email: suppor[email protected]
Wireless BTStreaming PASpeaker
and Microphone System
PPHP122SM - PPHP152SM
Portable Karaoke Speaker with Wired Mic,
Built-in LED Party Lights, FM Radio,
MP3/USB/Micro SD Readers, Speaker Stand
12’’ Subwoofer, 800 Watt MAX 15’’ Subwoofer, 1200 Watt MAX

www.PyleUSA.com2 3www.PyleUSA.com
WARNING
Illegal operation may cause personal injury, which could be fatal and may cause
damage to property.
1. DO NOT place objects on top of the device, as objects may
scratch the device.
2. DO NOT expose the device to dirty or dusty environments.
3. DO NOT insert any foreign objects into the device.
4. DO NOT expose the device to strong magnetic or electrical field.
5. DO NOT use the device in the rain
6. Please check with your Local Authority or retailer for proper
disposaI of electronic products.
7. DO NOT disassemble the device. Only a certified service
technician should perform repair.
8. The device has apertures to disperse heat. DO NOT block the
device ventilation, the device may become hot and malfunction
as a result.
CONTROL BOARD FUNCTIONS
1. USB Control board
2. USB and MICRO SD Memory Card input jack
3. Master volume control knob
4. 3.5MM AUX input jack
5. Power switch for LED light
6. Power ON/OFF switch
7. Echo volume control knob
8. Microphone volume control knob
9. Charge LED indicator, red color for charging mode and blue color for fully charged.
10. DC 9V input jack
11. 6.5MM microphone input jack
LED POWER
DC 9V
ON ONOFF OFF
REC MODE
REP

www.PyleUSA.com4 5www.PyleUSA.com
REMOTE CONTROL FUNCTIONS
1. Standby button
2. Choose input AUX/FM/BT/USB signal
3. Mute button
4. Play/Stop button on MP3 mode,
scan function on FM mode.
5. Next song on USB/Micro SD card,
next channel on FM mode.
6. Previous song on USB/Micro SD card,
last channel on FM mode
7. EQ effect on MP3 mode
8. Increase speaker volume
9. Choose song number directly
on MP3 mode
10. Stop button
11. Decrease music volume
12. Repeat song on USB/Micro SD memory card
TROUBLESHOOTING
PPHP122SM - PPHP152SM
Wireless BT Streaming PA Speaker and Microphone System
Portable Karaoke Speaker with Wired Mic, Built-in LED Party Lights,
FM Radio, MP3/USB/Micro SD Readers, Speaker Stand
Features:
• Portable PA Speaker System
• High-Powered Loudspeaker Design
• Wired Microphone for Home Karaoke Style Fun
• Wireless BT Music Streaming Ability
• Multi-Color Flashing LED Party Lights
• FM Radio with Digital LCD Display
• Built-in Rechargeable Battery
• Ported Enclosure for Extended Bass
• Full Range Stereo Sound Reproduction
• Sleek & Stylish Speaker Cabinet Housing
• Connect & Stream Audio from External Devices
• MP3 Audio File Playback
• USB Flash Memory Reader
• Micro SD Memory Card Reader
MODEL PPHP122SM PPHP152SM
Power Output 800 Watt MAX 1200 Watt MAX
Sound System 12’’ Subwoofer,
1’’Tweeter
15’’ Subwoofer,
1’’Tweeter
Total Speaker Size
(L x W x H)
13.5’’ x 11.6’’ x 21.3’’
-inches
16.9’’ x 14.2’’ x 26.3’’
-inches
Speaker Stand Height 3.2’ ft. 3.7’ ft.
10
1
1
4
7
9
6
11
2
3
5
8
12
1. The audio format in the U disc is
incorrect.
2. Improper operation has caused
a process disorder.
3. USB disc is disconnected.
1. Convert audio format into Mp3
format.
2. Reboot the machine.
3. Insert USB disc properly.
MP3
does not
play
Fault Possible Cause Solution
No sound
Distortion
of sound
Karaoke
does not
work
1. No input sound source.
2. Volume is too low.
1. Volume too high.
2. Speaker may be damaged
1. Microphone plug is not fully
inserted.
2. Microphone switch is not on.
3. Microphone volume knob is at
the lowest position.
1. Use a better music signal.
2. Adjust volume.
1. Turn down the volume.
2. If speaker is damaged, repair
or replace it.
1. Plug microphone properly into
the socket.
2. Turn on microphone switch.
3. Adjust microphone volume
properly.

www.PyleUSA.com6 7www.PyleUSA.com
• Aux (3.5mm) Input Jack
• 1/4’’ (6.5mm) Microphone Input
• Low Battery Level LED Indicator Light
• Rugged & Durable Molded Cabinet Design
• Convenient Rolling Wheels & Extending Carry Handle
• Used for Public Gatherings, Crowd Control, Karaoke Vocals, Stage Performances
• For Indoor/Outdoor Use
Wireless BT Streaming:
• Built-in BT for Wireless Music Streaming
• Simple & Hassle-Free Pairing
• Works with All of Today’s Latest Devices
• Smartphones, Tablets, Laptops, Computers, etc.
• Wireless BT Version: 5.0
• Wireless BT Network Name: ‘PYLEUSA’
• Wireless Range: Up to 32’ ft.
What's in the Box:
• PA Speaker System
• Speaker Stand
• Wired Microphone
• Remote Control
• Power Adapter
Technical Specs:
• Wired Mic Cable Length: 9.8’ ft.
• Speaker Stand Height: 3.2’ ft.
• Impedance: 4 Ohm
• Frequency Response: 55-20kHz
• S/N Ratio: 60dB +/-3dB
• SPL: 94dB (1W/M)
• T.H.D.: <1%
• USB Interface Type: 2.0
• Digital Audio File Support: MP3
• Maximum USB Flash Support: 32GB
• Mic Nominal Current Drain: < 100mAh
• Construction Material: Polypropylene (PP)
• Battery Life: Up to 2+ Hours
• Battery Operated Remote: (1) x CR-2025 Button Cell, Included
• PA Speaker Battery Type: 7.4V Li-ion - 1800mAh
• Speaker Power Supply: 120/240V, Adapter (9V)
