Pyle PSBT65A User manual

PSBT65A
Compact & Portable Wireless
BT Streaming PA Speaker
Karaoke Sound System with Wireless Microphone,
Built-in Rechargeable Battery, MP3/USB/SD

www.PyleUSA.com www.PyleUSA.com
1 2
IMPORTANT SAFETY INSTRUCTIONS
1. Read and keep these instructions.
2. Heed all warnings.
3. Follow all instructions.
4. Do not use this apparatus near water.
5. Clean only with a dry cloth.
6. Do not block any ventilation openings. Install in accordance with the
manufacturer's instructions.
7. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarised or ground plug:
A polarised plug has two blades with one wider than the other.
The wide blade is provided for your safety. When the provided plug
does not t into your outlet, consult an electrician for replacement of
the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly
at plug, convenience receptacles, and the point where they exit from
the apparatus.
11. Only use attachments/accessories specied by the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table
specied by themanufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for
long periods of time.
14. Refer all servicing to qualied service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power
supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
15. To reduce the risk of re or electric shock, do not expose this
apparatus to rain or moisture.
16. Apparatus should not be exposed to dripping or splashing and no
objects lled with liquids, should be placed on the apparatus.
17. Use only with the battery which specied by manufacturer.
18. The power supply cord set is to be the main disconnected device.
WARNING
This symbol indicates that dangerous voltage constituting a risk of
electric shock is present within this unit.
This symbol indicates that there are important operation and
maintenance instructions in the literature accompanying this unit.
1. FOR OUTDOOR USE:
To reduce the risk of re or electric shock, do not expose this apparatus
to rain or moisture.
2. UNDER WET LOCATION:
Apparatus should not be exposed to dripping or splashing and no
objects lled with liquids, such as vases should be placed on the
apparatus.
3. SERVICE INSTRUCTIONS:
CAUTION - These servicing instructions are for use by qualied service
personnel only. To reduce the risk of electric shock, do not perform any
servicing other than that contained in the operating instructions
unless you are qualied to do so.
TIPS - TO PROLONG THE LIFE OF RECHARGEABLE BATTERIES
1. Store portable system with batteries in a fully charged condition. 8-10
hours to fully charge.
2. The battery prefers a partial rather than a full discharge. A partial
discharge reduces stress and prolongs battery life.
3. Avoid frequent full discharges because this puts additional strain on
the battery.
4. Avoid keeping the battery at full charge and high temperature.
5. Fully charge the system at least once every 3~6 months. Battery may
not charge if not charged for a prolonged periods of time.
6. Do not freeze the battery. Store in a dry, cool place away from heat.
Elevated temperature reduces battery lifespan.
7. Rechargeable batteries have a limited number of charge cycles and
may eventually need to be replaced. Battery life and number of charge
cycles vary by use and settings.

www.PyleUSA.com www.PyleUSA.com
3 4
SIMPLE TROUBLE SHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
No Sound or Faint
Sound From Speaker
Volume turned down
Power switch is turned o
Power Indicator
Not ON
Distorted Sound
From Speaker
Excessive Feedback
Weak, Distorted Sound.
Power Indicator Flickers
Excessive Hum or Noise
Battery CHARGE
Indicator Not Flickering
when plugged into
AC Outlet
Shortened Battery
Life
Power switch is turned o
Rechargeable Battery is
discharged
Rechargeable Battery is
“dead”
Volume set too high
Excessive wind noise
breath “pops”
Input signal too strong
Microphone too close or
directly in front of the
speaker
Volume set too high
Microphone too far from
sound source (requiring
the volume to be turned
up to compensate)
Batteries level is low
Input Cable not shielded
Old or overused battery
Battery is not charged
for over 3~4 months
Rechargeable Battery is
“dead”
Battery is not charged
for over 3~4 months Replace battery
Adjust volume
Turn power switch on
Turn power switch on
Plug into AC outlet
to recharge
Replace battery and plug
into AC outlet to recharge
Reduce volume
Use windscreen on
wireless & wiredmicrophone
Adjust input signals
Move microphone away
from the speaker
Plug into AC outlet to
recharge
Recharge
Speak closer to the
microphone or move
microphone closer to
sound source
Use shielded cable
Recharge or replace
battery
Recharge or replace
battery
Recharge or replace
battery
1 2 3 4 5 6
7
8
9
10
11
12
13
14
15
1. Input Mode switch
2. Record
3. Cycling mode
4. Previous song
5. Pause and play
6. Next song
7. External battery input
8. Power on/o

www.PyleUSA.com www.PyleUSA.com
5 6
PSBT65A
Compact & Portable Wireless BT Streaming PA Speaker
Karaoke Sound System with Wireless Microphone,
Built-in Rechargeable Battery, MP3/USB/SD
Features:
• Compact, Portable & Powerful PA Speaker
• High-Powered Audio Karaoke Sound System
• Built-in Rechargeable Battery
• Bluetooth Wireless Audio Streaming
• Digital Audio Recording Mode
• Sound System: 6.5'' Subwoofer, 3'' Treble Speaker
• Rear Panel Button Control Center
• Includes Wireless Microphone
• 1/4'' Microphone Input
• Aux (3.5mm) Input
• Connect & Stream Audio from External Devices
• USB Flash + Micro SD Memory Card Readers
• MP3 Digital Audio File Playback
• Audio Conguration: Echo, Bass and Treble Controls
• LCD Digital Display Screen
• External 12V Power DC Input Connector
• 35mm Speaker Stand Mount
• Perfect for Karaoke, Public Events, Crowd Control, etc.
Bluetooth Wireless Connectivity:
• Built-in Bluetooth for Wireless Music Streaming
• Works with All of Your Favorite Devices
(iPhone, Android, Smartphone, iPad, Tablet, Computer, etc.)
• Bluetooth Wireless Network Name: ‘PYLE PSBT65A’
• Bluetooth Version: 3.0
• Wireless Range: 33’+ ft.
MP3 Audio Recording Ability:
• It's Easy: Mode Button Record Activation
• Record Audio as Streamed through the Speaker System
• Ability to Record Vocals via Microphone
• Records to USB Flash & SD Memory Card
• Audio File Type Created: .mp3
• Easy Transfer to PC & Mac
What’s in the Box:
• PA Speaker
• Handheld Microphone
• Wall Power Adapter
Technical Specs:
• Power: 600 Watt
• Wireless Frequency Mode: VHF
• Frequency Response: 55Hz-20kHz
• Sensitivity: 95dB (+/-2dB)
• Impedance: 4 Ohm
• S/N Ratio: >50dB
• T.H.D.: <1%
• Rechargeable Battery: 4400mAh, 3.7V Lithium
• Battery Operated Microphone: Requires (2) x ‘AA’ Batteries
• Digital Audio File Compatibility: MP3, WMA, ACC
• Maximum USB/Micro SD Support Size: 32 GB
• Power: 110/220V (9V Power Adapter)
• Speaker Dimensions (L x W x H): 10.6’’ x 9.0’’ x 13.0’’-inches
• Sold as: 1
