Pyle PPHP1049KT User manual

Active+PassivePASpeakerSystemKit
Dual Loudspeaker Sound Package, 10'' Subwoofers,
Bluetooth Wireless Streaming, Includes (2) Speaker Stands,
Wired Microphone, Remote Control, 1000 Watt
PPHP1049KT

www.PyleUSA.com
2
PPHP1049KT
1. LCD screen
2. Mp3 control
MODE: USB/SD/BT/FM convertor
: Play / Pause
SCAN: Press and hold to auto
search under FM radio
FOL: Press and hold for 5 seconds
to enter the folder option function
mode (press the previous/next songs
button to choose the folder)
: Repeat one / Repeat all / Random
: PRE/NEXT under FM mode
Press and hold to search lower/
higher station manually
: Short press to tune to saved station
: Previous Song
Press and hold for fast rewind
: Next Song
Press and hold for fast forward
3. USB input
4. SD card input
5. Remote control
6. MIC level control
7. MP3 level control
8. Basscontrol
9. Treble control
10. XLR microphone line input
11. Line input
12. AUX input
13. Master volume
14. Speaker out 8Ohm
15. Main power switch
16. Fused IEC mains inlet
IR
MP3 CONTROL DIGITAL DISPLAY
USB
SD card
MIC LINE IN
POWER SWITCH
AC:120-240V 50/60Hz
8Ω
SPEAKER OUT
MIC VOL MP3 VOL TREBLE
AUX MASTER VOL
BASS
-12 +12 -12 +12
3
41
2
9
13
14
6
10
16 15
11 12
8
7
5
MIN MAX MIN MAX
MIN MAX

www.PyleUSA.com
3
REMOTE CONTROL
1. MODE : USB/SD/BT/FM CONVERTER
2. : In USB/SD : Previous Song,
Press and hold for fast rewind
In FM : swich to backward
3. VOL + : Increase volume
4. VOL - : Decresse volume
5. : In USB/SD : next Song,
Press and hold for fast forward
In FM : swich to next channel
6. : Stop Switch the MP3 player o.
7. /SCAN : Play / Pause
In FM : Auto search
8. EQ : NORMAL, ROCK, POP, CLASS, JAZZ.
9. REP : Shot press : Random/Single/Order
10. 0-9 : choosing music by numbers
11. MUTE : Mute the sound of the MP3 player
1
11
3
2
7
4
8
10
6
5
9

www.PyleUSA.com
4
PPHP1049KT
Active + Passive PA Speaker System Kit
Dual Loudspeaker Sound Package, 10'' Subwoofers, Bluetooth Wireless
Streaming, Includes (2) Speaker Stands, Wired Microphone,
Remote Control, 1000 Watt
System Features:
• Dual 10-inch High-Powered Loudspeaker PA Systems
• Includes (1) Active Speaker, (1) Passive Speaker + (2) Stands
• Rugged, Durable & Reliable Sound
• Bluetooth Wireless Music Streaming Ability
• High-Frequency 1.0'' Tweeters
• Compression Driver with Titanium Diaphragm
• 2-Way Full Range Audio Projection
• Built-in Digital Audio Amplier
• XLR Microphone Input
• 1/4’’SpeakOn (8 Ohm) Input
• 1/4’’SpeakOn (8 Ohm) Speaker Output
• Aux (3.5mm) Input Jack
• Connect & Stream Audio from External Devices
• USB Flash Drive & SD Memory Card Readers
• Digital LCD Display
• Rear Panel Rotary Dial & Button Control Center
• Master Volume, Mic Volume, Treble, Bass Adjustable
• Integrated Carry Handles
• 35mm Speaker Stand Mount Compatible
• Heavy Duty Engineered ABS Housing
What's in the Box:
• (1) 10'' Active PA Speaker
• (1) 10'' Passive PA Speaker
• (2) Speaker Stands
• Wired Microphone
• Remote Control
• Power Cable

www.PyleUSA.com
5
Bluetooth Wireless Streaming:
• Instantly Stream Music from Your Bluetooth Devices
• Works with All Your Favorite Bluetooth Devices
(iPhone, Android, Smartphone, iPad, Tablet, PC, etc.)
• Bluetooth Version: 4.0
• Bluetooth Wireless Range: 100'+ Feet
• Bluetooth Network Name: 'Pyle’
Speaker Stands:
• Eectively Elevates Speakers for Optimum Sound Performance
• Universal Speaker Compatibility (35mm Insert)
• Easy Setup and Quick Adjustment Control
• Reinforced Steel Support Construction
• Speaker Support Arm Extension
• Rugged and Reliable
• Safety Lock-in Pin
• Foldable for Quick Storage and Transport
• Rubber Capped Tripod Feet Base
• Perfect for On-Stage or Studio Use
• For Professional or Beginner Applications
• Speaker Height Adjustable: 59.1'' to 82.7''
• MAX. Load Capacity: 100 lbs. (50 kgs.) -Each
Technical Specs:
• MAX Power Output: 1000 Watt
• Amplier: Class D
• Impedance: 8 Ohm
• T.H.D.: <1%
• Magnet: 20 oz.
• Sensitivity: 92dB (+/-2dB)
• Mic Input Level: <15mV
• Line Input/Output Level: >250mV
• Frequency Response: 65-18kHz
• Digital Audio File Compatibility: MP3, WMA
• Maximum SD/USB Flash Memory Support: 32GB
• Power: 120/240V
• Single Speaker Weight: 18.08 lbs.
