Pyle PWMABT550 User manual

PyleAudio.com
718.535.1800 718.236.2400(fax)
1600 63rd Street, Brooklyn NY 11204
OPPERATING INSTRUCTIONS
PWMABT550
www.pyleaudio.com
8" Work site Battery Powered Rugged Speaker
w/AM/FM Radio,USB/SD,Bluetooth,120V AC Outlet

Panel design
Remote control
Rear Panel design
1.Power:on/off
2.Mode:USB/SD/FM/Aux input
3.Mute
4.Play/Pause
Previous radio station
5.EQ:equalizer
Next radio station
6.Previous:previous station/previous song
7.Next:next song/next station
8.Volume: increase
9.Volume reduce
10.0-9 USB/SD or preset radio statons selector
11.Repeat For Usb/sd
12.Auto Scan For Radio Stations
2 3 4 5
678910 1 1 12 1 3 1 4 15 1 6
1
1. Audio Output
2. Aux Input
4. BT-LED
5. Indicator Lights forBluetooth
6. Previous Radio Station
Previous Songs Selector
7. Input Selectors
DELETE function
8. Repeat
9. AM/FM Selectors
3. Display Screen
10. Next Song Selector
Next Radio Station
11. Play/pause For Usb/sd
Auto Scan For Radio Stations
12. 0-9 Selectors
13. Previous song selector
14. Repeat Function
15.Next song selector
16. Record Function
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1.
2. Indicator lights for battery power level
3. Indicator lights for battery power level
4. Indicator lights for battery power level
5. Power switch
6. Mic input
7. Audio output
8. AC 220V output
Indicator lights for Low 9. USB input for Mp3 player
10. SD/MMC card input for Mp3 player
11. ECHO controller
12. Bass volume controller
13. Treble volume controller
14. Power Plug
15. 110/240 Voltage Selector

4
3
The PA speaker can be powered when connected to main power
or using the internal 12V battery.
1.Connect the power cable to the top of the unit.
2.Connect the other end of power cable to main power.
3.Turn on the switch at the main power point.
4.The unit will automatically power on when connected to
main power.
Notes: If you wish to use the internal battery to power the unit, just
simply turn on the Battery switch located on the top of unit to ON.
Charging
Before using the PA speaker for the first time, charge the unit at
least 8 hours.
1.Connect the power cable at the top of the panel.
2.Turn off the battery switch on the top of the panel.
3.Recharge indicator light will be on when it is charging.
Notes: The internal battery will charge while the unit is being
operated and the power switch is on. It is better to charge the unit
while the power switch is off.
You can connect the wired microphone to this unit using the MIC
INPUT located on the top of control panel.
1.Turn off the unit.
2.Connect your wired microphone to the MIC INPUT located on
top of the control panel.
3.Adjust the microphone volume by tuning the MIC VOL/ECHO
knobs located on top control panel.
NOTES: You can use the wired microphone and wireless
microphone at the same time.
You can play music from USB stick or SD Card using the USB/SD
slot on the PA speaker.
1.Turn on the unit.
2. Insert your USB or SD card into the slot.
3. Once inserted the USB or SD card unit will automatically play.
4. You can use the PRE/NEXT/PLAY/PAUSE to control and play music.
NOTES: The speaker system can play the following audio file formats:
MP3,MP4,WMA.The USB/SD Card no more than 32GB. Operation may
be slower when searching large memory files. It will need several
seconds to respond when your USB/SD Card full of contents.
USB/SD Card Playback
Using the Wired Microphone
Turning ON/OFF
Note: Microphone Not Included

56
You can connect your Bluetooth phone or other device to the PA
speaker.
1. Turn on the unit.
2. Press the INPUT button which is located on top control panel, next
to the USB/SD slot.
3. The Bluetooth is on when you hear two “tone” indicator sound.
4. Use your Bluetooth phone or other device to search for the PA speaker.
It will displayed as PYLE SPEAKER.
5.Connnect your devices with PYLE SPEAKER,it will pair with unit
automatically.
6.You do not need code and get connected with unit.
7.Play music on your phone or device, sound will come from the
speaker through the BLUETOOTH wireless connection.
8.You can use the VOLUME/BASS/TREBLE to adjust the sound level for
BLUETOOTH, also you can adjust the Bluetooth music sound through
your own phone or other device.
NOTES: If there is no sound through the PA speaker during Bluetooth,
Check the volume controller both on the unit and on your phone or
other device.
BLUETOOTH playback
1.Turn on the unit.
2.Press INPUT once, to select FM Radio.
3.Press PRE/NEXT to select your desired radio station.
Ensure that you have the extended the antenna located on the rear
of the speaker. It will ensure the best possible radio quality and
signal strength.
4.When you first use the radio, press NEXT button twice, it will
auto search and store the radio stations with the strongest signal.
PyleAudio
1600 63rd St
Brooklyn, NY
11204
www.pyleaudio.com
Using the Radio
When you insert USB or SD card, insert the microphone, press
REC more than 3 seconds, you can record what you say.If you
don't want keep the recorded files, press Delete key , it will
delete the recorded files.
Long press REC button to record when AUX begins to play.
Recodring function
