Pyronix V2GSM User manual

Speaker Microphone
RINS1322-8
GSM Speech Dialler with Automation Control
USER MANUAL

User Manual V2 GSM
Pyronix Ltd Page: 2
EASY START GUIDE
Enter 1234
This enters the user menu.
Enter 831
Enter the SMS messages for input 1.
Repeat for all other inputs if required
[831-844].
Enter 901
Program telephone number 1.
Repeat for all other numbers if
required [901-909].
Enter 931
Program the message types for the
telephone numbers. Repeat for all
other numbers if required [931-939].
Enter 999
Press the tkey to exit the user
mode.

V2 GSM User Manual
Page: 3 Pyronix Ltd
CHAPTER 1: CONTENTS PAGE
CHAPTER 1: CONTENTS PAGE ...........................................................................3
CHAPTER 2: INTRODUCTION ..............................................................................4
CHAPTER 3: HOW THE V2 GSM WORKS............................................................5
3.1 The V2 GSM Process ...............................................................................................5
CHAPTER 4: OPERATING THE KEYPAD.............................................................6
4.1 Scrolling Through MAIN Menus ..............................................................................6
4.1.1 Scrolling through main menu ...............................................................................6
4.1.2 Scrolling through sub menu .................................................................................7
4.1.3 Entering a sub menu/main menu function............................................................7
4.2 Entering Text ............................................................................................................7
CHAPTER 5: THE USER MENU ............................................................................9
5.1 Entering the user menu ...........................................................................................9
5.2 Exiting the User Menu..............................................................................................9
5.3 Call Telephone Number [600]................................................................................10
5.4 Activating The On Board 4 Outputs......................................................................10
5.5 Additional Output Control [700] ............................................................................11
5.6 Play / Record Alarm Voice Messages [800] .........................................................11
5.7 Play / Record Common Message [820].................................................................12
5.8 Write SMS Alarm Messages [830] .........................................................................12
5.9 Write SMS Restore Messages [870]......................................................................13
5.10 Program Telephone Numbers [900]....................................................................14
5.11 Message Type [930] .............................................................................................15
5.12 Call Acknowledgement Code [960].....................................................................16
5.13 Copy Acknowledgment Code 1 To All [980] ......................................................16
5.14 Set Sim-Card Secret Pin [981].............................................................................17
5.15 Test Remote Mic [982] .........................................................................................17
5.16 Test remote Speaker [983]...................................................................................17
5.17 Enable Remote Listen-In [984] ............................................................................17
5.18 View Event Log [985] ...........................................................................................18
5.19 Change User Code [986]......................................................................................18
CHAPTER 6: RECEIVING A CALL FROM THE V2 GSM ....................................19
CHAPTER 7: REMOTE CONTROL VOICE MENU ..............................................20
CHAPTER 8: SMS REMOTE TEXT COMMANDS ...............................................21
8.1 Changing a Telephone Number Via SMS .............................................................21
8.2 reading an External system status via sms.........................................................21
8.3 Reading The Input Status via sms........................................................................22
8.4 activating / Deactivating An Output Via SMS.......................................................23
CHAPTER 9: DISCLAIMER..................................................................................24
CHAPTER 10: SHORTCUT FUNCTION REFERENCE .......................................25
CHAPTER 11: INPUTS/OUTPUTS APPENDIX ...................................................26
11.1 Inputs.....................................................................................................................26
11.2 Outputs..................................................................................................................26

User Manual V2 GSM
Pyronix Ltd Page: 4
CHAPTER 2: INTRODUCTION
The V2 GSM is 2 way GSM audio communication and remote automation module.
The V2 GSM has the following features:
Call any telephone number (just like a mobile phone)
Supports 2 way speech via the built in SPK and microphone
Activate outputs (to turn on lights, open gates, etc)
oLocally via the integrated keypad
oRemotely via SMS or voice menu command
Program voice messages (Up to 14, 1 for each alarm input)
Program SMS messages (Up to 14, 1 for each alarm input)
Send SMS or voice alerts to up to 9 different user phone numbers
View the V2 event log (256 events, time and date)
Remotely operate the V2 by phone using the built in voice menu to:
oListen in
oTalk and listen
oControl output
oCheck the status of an external device that is connected to the V2 (for
example system armed or disarmed)
Remotely by SMS text commands operate the V2:
oChange telephone number
oControl outputs
oCheck the status of an external device that is connected to the V2 (for
example system armed or disarmed)
oCheck the status of an input

V2 GSM User Manual
Page: 5 Pyronix Ltd
CHAPTER 3: HOW THE V2 GSM WORKS
3.1 THE V2 GSM PROCESS
Below shows a flowchart that is a representation of how the V2 GSM operates, when an
alarm activation occurs.
Alarm
Activation
V2 GSM
Dials Number
V2 GSM Sends
SMS to
Number
User
Answers?
Message
Played. Enter
Ack. Code
Press 99 To
Enter Remote
Menu
V2 GSM
Redials the
telephone
numbers
The next
number is
dialled
SMS received
by user
BEEP
Listen / Talk /
Control
Outputs
Enter User
Code
YES
NO
UNANSWERED
ANSWERED
Press '0' to
hang up (ends
the call)

User Manual V2 GSM
Pyronix Ltd Page: 6
CHAPTER 4: OPERATING THE KEYPAD
The V2 GSM keypad incorporates 4 output status LEDs positioned above the LCD
display. They are numbered 1 to 4 and are used to show the status of the 4 inbuilt
outputs.
4.1 SCROLLING THROUGH MAIN MENUS
4.1.1 Scrolling through main menu
TO SCROLL THROUGH MAIN MENU’S. PRESS THE [AND ]KEYS
MAIN MENU ITEMS ARE IN CAPITAL LETTERS

V2 GSM User Manual
Page: 7 Pyronix Ltd
4.1.2 Scrolling through sub menu
TO SCROLL THROUGH SUB MENU’S. PRESS THE MAND NKEYS
SUB MENU ITEMS ARE IN CAPITAL LETTERS
4.1.3 Entering a sub menu/main menu function
TO ENTER ANY FUNCTION. PRESS THE tKEY
Press xto exit a sub-menu and press xagain to return to a main menu function
(displayed in capital letters). Function numbers can also be entered to jump to a particular
menu. For example to leave the V2 GSM from any main menu or sub-menu digit [999]
that will bring you to the main menu item: ‘QUIT/EXIT PROGRAMMING’.
4.2 ENTERING TEXT
The numeric keys above are used to enter the text onto the V2 GSM (for SMS texts).
For example to enter the letter ‘Q’. The 7key needs to be pressed twice, to enter the
letter V the 8key needs to be pressed three times and so on. The 0key is used to
enter a space.

User Manual V2 GSM
Pyronix Ltd Page: 8
Keys Operation Example Display
t
Enters a function / starts a
command
x
Exits a function / stops a
command
I
Activates output 1
Enters a ‘+’ symbol before a
telephone number if required.
J
Activates output 2
Enters a ‘*’ symbol when dialling
a number if required.
K
Activates output 3
Alternates between capitals and
lower case
Enters a ‘#’ symbol when dialling
a number if required.
L
Activates output 4
Deletes the current character /
number that the cursor is on
N
Scrolls between sub-menu items
Moves the character cursor to
the end of a string
M
Scrolls between sub-menu items
Moves the character cursor to
the beginning of a string
[
Scrolls between main-menu
items
Moves the character cursor to
the left
]
Scrolls between main-menu
items
Moves the character cursor to
the right

V2 GSM User Manual
Page: 9 Pyronix Ltd
CHAPTER 5: THE USER MENU
5.1 ENTERING THE USER MENU
Using the keypad enter the user
code.
Default = 1234
‘[600] CALL TELEPHONE NUMBER’
will be displayed which indicates you
are in the user menu.
Use the [and ]keys to scroll
through the main menus.
Press tto enter a function.
NOTE: If the display shows ‘USER PROG. REQ.’ in normal mode it means that no
telephone numbers or voice/SMS messages have been programmed in the user menu
yet.
5.2 EXITING THE USER MENU
To exit the user menu, type in ‘999’ or
scroll to
“QUIT / EXIT PROGRAMMING”
Press the tkey.
NOTE: When exiting the V2 GSM user menu, the display may show the following:
Voice messages and phone numbers will need to be programmed before exiting the
user menu.

User Manual V2 GSM
Pyronix Ltd Page: 10
5.3 CALL TELEPHONE NUMBER [600]
This function allows the user to make an outgoing call as you would normally do with a
telephone. Enter the telephone number you would like to call and press tthe number
will be dialled.
Press the [or ]keys to scroll to
‘CALL TELEPHONE NUMBER’ or
enter ‘600’. Press t
Enter the telephone number to dial
and press t.
Press xto end the call.
During the call you can increase or
decrease the volume by using the
Band Tarrow keys.
For certain dialling sequences, a J
for ‘*’ or Kfor a ‘#’ symbol may
need to be used.
5.4 ACTIVATING THE ON BOARD 4 OUTPUTS
To activate the 4 onboard outputs press and hold the required number key for 2 seconds:
Press and hold Ito activate output 1.
The LED 1 output will illuminate when
turned on and extinguish when the
output has turned off.
Press and hold Jto activate output 2.
The LED 2 output will illuminate when
turned on and extinguish when the
output has turned off.
Press and hold Kto activate output 3.
The LED 3 output will illuminate when
turned on and extinguish when the
output has turned off.
Press and hold Lto activate output 4.
The LED 4 output will illuminate when
turned on and extinguish when the
output has turned off.
