Python 4811P User manual

Directed is committed to delivering world class
quality products and services that excite and
delight our customers.
OWNER’S GUIDE MODEL
4811P
4816P
The company behind Python®Auto Security
Systems is Directed.
Since its inception, Directed has had one purpose, to
provide consumers with the finest vehicle security and
accessories available. The recipient of nearly 100 pat-
ents and Innovations Awards in the field of advanced
electronic technology.
Quality Directed products are sold and
serviced throughout North America and around
the world.
SECURITY FOR THE BEST®

Congratulations
Congratulations on the purchase of your remote start system. This sys-
tem has been designed to provide years of trouble-free operation. By
carefully reading this owner’s guide prior to using your system, you will
maximize the use of this system and its features.
What you get
• One 2- way, 1- button remote control
• One 1- way, 1- button remote control
• Owners Guide

Important Information
Government Regulations and Safety Information
Read the "Government Regulations" and "Warning!
Safety First" sections of this manual prior to operating this
system.
Warning! Failure to heed this information can result in
death, personal injury or property damage and may also
result in the illegal use of the system beyond its intended
purpose.
This product is designed for fuel-injected, automatic trans-
mission vehicles only. Installing it in a standard transmis-
sion vehicle is dangerous and is contrary to its intended
use.

Using Your System
Commands At a Glance
System State Press/Release Press/Hold for 3 sec.
ENGINE OFF START ENGINE CAR FINDER
ENGINE ON UNLOCK DOORS STOP ENGINE
Note: If a feature cannot be activated when performing a command
with the 2-way remote control or if the system is out of range, a fault
tone plays as an alert.
Start Engine
When the engine is OFF, press and release the remote control button
to start the engine.
See "Using Remote Start" on page 3 for more feature details.
Unlock Doors
When the engine is ON with remote start, press and release the re-
mote control button. The doors unlock, the parking lights flash, the horn
sounds (if connected) as confirmation. The 2-way remote control emits
tones.
Note: Horn honk may be an optional feature that requires additional
parts and labor.
Stop Engine
When the engine is ON with remote start, press and hold the remote
control button for three seconds. The engine stops running and the park-
ing lights turn off. The 2-way remote control emits tones.

Car Finder
When the engine is OFF, press and hold the remote control button for
three seconds. The horn sounds once (if connected) and the parking
lights flash multiple times. The 2-way remote control emits a single tone.
Using Remote Start
This feature allows you to remotely start and run your vehicle for a
programmable period of time. This makes it possible to warm up the
engine, and adjust the interior temperature of the vehicle with the cli-
mate control system. If interior heating or cooling is desired, the climate
controls must be preset, and the fan blower must be set to the desired
level prior to remote starting the vehicle.
Important! (1) Never remotely start the vehicle with the
vehicle in gear, and (2) Never remotely start the vehicle
with the key in the ignition.
Starting the Engine:
1. Make sure the parking brake is set. Press and release the remote
control button once* (or the amount of times the system has been
programmed to activate the remote start).
2. The engine will START and the parking lights will turn on. The
2-way remote will also emit tones.
The parking lights stay on as visual confirmation while the engine is
ON. The default runtime is 12 minutes and can be shortened or ex-
tended by the installer. If a remote start configuration issue prevents the
engine from starting, the parking lights flash a remote start fault report
to identify the fault. See "Remote Start Faults" on page 8.

* The factory setting is one press but this can also be programmed for
two presses (See your authorized Directed installer for the amount of
presses programmed).
Record the number of presses to activate remote start here:______
Key Takeover
When you are ready to drive the vehicle:
1. Unlock the doors.
2. Enter the vehicle. Do not step on the foot brake.
3. Insert the key into the ignition and turn it to the run (not start) posi-
tion.
4. Step on the foot brake. The remote start is disabled and the park-
ing lights turn off.
5. Disengage the parking brake and begin driving.
Note If your vehicle uses a Smart Key or PTS (Push-To-Start) system,
please refer to the vehicle specific instructions included with
the owner's guide of the interface module or consult your
authorized dealer.
Safety Features
The following safety features will disable the remote start when acti-
vated or not allow the engine to start if not properly set before starting.
• Foot Brake is depressed
• Hood is open
• Remote Start shutoff switch is OFF
•The pre-programmed run time (12, 24 or 60 minutes) has elapsed
• Remote Start activation procedure is repeated
• Parking brake is disengaged

• Engine over-rev protection (Tachometer mode only)
Pit Stop and Turbo Timer Modes
This remote start can keep the engine running during short trips away
from the vehicle or to cool down turbo timers.
Enabling Pit Stop mode:
1. Park in a well ventilated area.
2. With the engine running engage the parking brake and release
the foot brake.
3. Press and release the remote control button once (or the amount
of times the system has been programmed to activate the remote
start). The parking lights turn on as confirmation.
4. Turn off the ignition and remove the key, the engine continues
running.
5. Exit the vehicle, the engine runs for the programmed runtime.
Enabling Turbo Timer mode *:
Begin by following the "Enabling Pit Stop mode" procedure. However,
in step 3, instead of pressing the remote control button, press and re-
lease the dash mounted activation button* once (or the amount of times
the system has been programmed to activate the remote start). The
engine continues running for the shorter Turbo Mode runtime. Continue
and complete the procedure steps.
* Turbo Timer mode must be turned on and an optional activation but-
ton also installed by an authorized dealer.
Note: For Manual Transmission vehicles see "Manual Transmission Ve-
hicles" on page 6.

Note If your vehicle uses a Smart Key or PTS (Push-To-Start) system,
please refer to the vehicle specific instructions included with
the owner's guide of the interface module or consult your
authorized dealer.
Manual Transmission Vehicles
Manual Transmission Mode (MTS), Pit Stop mode, Turbo Timer Mode
Enabling MTS mode
1. Park in a well ventilated area with all the doors closed.
2. With the engine running, press the foot brake and set the parking
brake.
3. Release the foot brake.
4. Press and release the remote control button, the parking lights flash
quickly five times as confirmation.
5. Turn off the ignition and remove the key, the engine continues
running.
6. Exit the vehicle.
7. When the doors are closed, the engine stops running, MTS mode
is enabled.
Note: If enabling MTS mode has failed, the parking lights flash slowly
five times, return to step 1 and repeat procedure.
Enabling Pit Stop mode:
Follow the previous Enabling MTS mode procedure, however, open a
door prior to step 4. The engine continues running for the programmed
runtime after the doors are closed.
Enabling Turbo Timer mode*:
Follow the previous Enabling MTS mode procedure, however, open a

door prior to Step 4. Then, instead of pressing the remote control but-
ton, press and release the optional dash mounted activation button*.
The engine continues running for the shorter Turbo Mode runtime after
the doors are closed.
* Turbo Timer mode must be turned on and an optional activation but-
ton also installed by an authorized dealer.
Low Runtime and Remote Start Shutdown Alerts
During remote start, the system sill send a low runtime alert to the 2-way
remote when the remote start reaches the three minute and one minute
runtime remaining point. When the remote start shuts down, the 2-way
remote will also play a descending tone to indicate that the remote
start has shutoff.
Optional Rear Defogger
If connected, the Defogger circuit automatically activates ten seconds
after remote starting the vehicle if the temperature is below 55°F
(12.8°C).
Starter Anti-Grind Circuitry
This system includes an anti-grind circuit (optional relay is required) that
can prevent damage to the starter motor if the key is turned to the start
position while the engine is ON.
Note: Anti-grind circuitry only works when the remote start system is
operating the motor and the optional relay is installed.
Disabling the Remote Start System
When the Remote Start shutoff switch is set to the OFF position, remote
engine starting is defeated. DO this when the vehicle is being serviced

or driven by someone unfamiliar with remote start system operations.
Location Of Remote Start shutoff switch: _______________________
Remote Start Faults
For user safety, the system must be properly configured or remote start
will not activate. A Remote Start Fault may be caused by any of several
configuration issues. Refer to the table below for the command type
and parking light flashes that will identify the configuration issue and
solution.
Flashes * Possible Fault Solution
5 Brake on Release foot brake
6 Hood open Close hood
7 After performing Remote Start
command - MTS not enabled Enable MTS mode
8 Toggle Switch off Turn switch on
Rapid Resume Logic
This Directed system stores its current state to non-volatile memory. If
power is lost and then reconnected the system recalls the stored state
from memory. This means if the unit is in Locked Mode and the battery
is disconnected for any reason, such as when servicing the vehicle,
when the battery is reconnected the unit maintains Locked Mode. This
applies to all states of the system.

Remote Pairing
Your system comes with two remote controls that are already paired to
the system. An additional two remote controls can be stored in the sys-
tem's memory (for a maximum of four). However, additional or replace-
ment remote controls need to paired to the system first before use. Use
the following procedure to pair an additional or replacement remote
control to the system.
To pair a new remote control to the system:
1. Turn the ignition to the ON position.
2. Within ten seconds, press/release once and then press and hold
the control button on the system’s control center. The status LED be-
gins flashing in a sequence of single flashes and the horn sounds
(if connected) to confirm the system is ready for pairing. Release
the control center button.
3. Press and release the button on the remote control twice and then,
press and hold on the third press. The transmit LED comes on solid,
continue holding the button until the transmit LED changes its pat-
tern. Release the button and the transmit LED begins flashing as an
indication that the remote control has entered pairing mode.
4. Press and release the button on the remote control.
5. The horn (if connected) sounds as a confirmation the system has
paired with the remote control and the 2-way remote control plays
tones confirming that it has paired with the system and will auto-
matically exit pairing mode. The 1-way remote does not emit any
confirmation tones. The remote will exit programming after 30 sec-
onds or to manually exit programming, press and hold the button
on the remote. The remote emits a tone confirming exit.
6. Turn the ignition off or wait 60 seconds for the system to exit the
pairing mode, the horn will sound as confirmation.

The learn routine Exits if any of the following occurs:
• The ignition is turned off.
• There is no activity for 60 seconds.
• The control button is pressed too many times.
Programming Options
Programming options control your system's normal operational set-up.
Most options do not require additional parts, but some may require
installation labor.
The following is a list of the programmable options, with the factory
settings in bold.
•12, 24, or 60 minute run time. Your system can be programmed
to allow the vehicle to run for 12, 24, or 60 minutes when remote
started. Can be set up to minute increments by your installer.
•Parking lights flashing or constant. Your system can be pro-
grammed to flash or turn on the parking lights constantly during the
entire remote start operation.
•Ignition switch controlled door locking on or OFF. With this feature
on, the doors will lock three seconds after the ignition key is turned
on, and unlock when the key is turned off.
Important: The door lock option must be installed for this feature
to work.

Battery Information
The 1-way remote controls are powered by a single coin cell battery
(CR-2016), and the 2-way remote controls are powered by two coin
cell batteries (CR-2016) that can be purchased at most retailers. Oper-
ating range diminishes as battery charge depletes.
Low Battery Alert
When unlocking the vehicle using a remote control with a low battery
charge, the system provides a notification by emitting a third horn honk
output (if connected). If confirmation chirps are programmed off, the
system still emits one horn honk when unlocking. After performing a
command with the remote control, several beeps play to indicate the
battery/batteries need replacing. Once the alerts begin, the remote
control will remain operational for several days but the battery/batter-
ies should be replaced at the earliest opportunity or failure to control
the system may occur.
Battery Replacement
1. Unscrew the hardware on unit rear and remove from housing.
2. Use a small flat blade screwdriver and insert it into the slot located
along the bottom of the remote, near the key ring. Carefully pry
open the case.
3. Gently slide out the used battery/batteries to remove it from the
holding clip. Orient the new battery for the correct polarity and
insert into holding clip.
4. Realign the case parts and snap together by pressing firmly and
evenly on the front and back. Reinstall screw.

Battery Disposal
Directed cares about the environment. If you need to dispose
of the battery, please do so in accordance with your munici-
pal requirements for battery disposal.
Glossary of Terms
Document Terminology
Control Module The “brain” of your system. Usually hidden underneath the dash
area of the vehicle. It houses the microprocessor which monitors
your vehicle and controls all of the system’s functions.
Remote Control A hand-held, remote control which operates the various func-
tions of your system.
Status LED Transmit LED (Light Emitting Diode): A light used to indicate the
status of your system. It turns on when a button is pressed or
communication is active.
Control Center Mounted high in the vehicle usually on the windshield in a
location close to the rear view mirror. Consists of a antenna/
receiver for communicating between the control module and
remote controls and a control button with status LED for pro-
gramming system features.
Remote Start shutoff
switch
Normally located near the control module or mounted around
the dashboard, this Remote Start shutoff switch is used to dis-
able the remote start feature.

Patent Information
This product is covered by one or more of the following United States
patents:
Vehicle Security Patents
5,467,070; 5,532,670; 5,534,845; 5,563,576; 5,646,591;
5,650,774; 5,673,017; 5,712,638; 5,872,519; 5,914,667;
5,952,933; 5,945,936; 5,990,786; 6,028,505; 6,452,484
Remote Start
5,349,931; 5,872,519; 5,914,667; 5,952,933; 5,945,936;
5,990,786; 6,028,372; 6,467,448; 6,561,151; 7,191,053;
7,483,783
Other patents pending

Government Regulations
This device complies with Part 15 of FCC rules. Operation is subject to the fol-
lowing two conditions: (1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesirable operation.
This equipment has been tested and found to comply with the limits for a class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates and can radiate radio frequency ener-
gy and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television, which can
be determined by turning the equipment OFF and ON, the user is encouraged
to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
•Consult the dealer or an experienced radio / TV technician for
help.
This device complies with the Industry Canada Radio Standards Specification
RSS 210. Its use is authorized only on a no-interference, no-protection basis; in
other words, this device must not be used if it is determined that it causes harm-
ful interference to services authorized by IC. In addition, the user of this device
must accept any radio interference that may be received, even if this interference
could affect the operation of the device.
Warning: Changes or modifications not expressly approved by the party re-
sponsible for compliance could void the user’s authority to operate this device.

Warning! Safety First
Please read the safety warnings below before proceeding. Improper use
of the product may be dangerous or illegal.
Remote Start Capable
When properly installed, this system can start the vehicle via a command signal
from the remote control transmitter. Therefore, never operate the system in
an enclosed area or partially enclosed area without ventilation (such as a
garage). When parking in an enclosed or partially enclosed area or when
having the vehicle serviced, the remote start system must be disabled using
the installed menu wheel. It is the user’s sole responsibility to properly handle
and keep out of reach from children all remote control transmitters to assure that
the system does not unintentionally remote start the vehicle. THE USER MUST
INSTALL A CAR-BON MONOXIDE DETECTOR IN OR ABOUT THE LIVING
AREA ADJACENT TO THE VEHICLE. ALL DOORS LEADING FROM ADJACENT
LIVING AREAS TO THE ENCLOSED OR PARTIALLY ENCLOSED VEHICLE
STORAGE AREA MUST AT ALL TIMES REMAIN CLOSED. These precautions
are the sole responsibility of the user.
Manual Transmission Vehicles
Remote starters on manual transmission vehicles operate differently than those
with automatic transmission because you must leave your car in neutral. You
must read this Owner’s Guide to familiarize yourself with the proper procedures
regarding manual transmission remote starters.

Before remote starting a manual transmission vehicle, be sure to:
•Leave the vehicle in neutral and be sure no one is standing in front or
behind the vehicle.
• Only remote start on a flat surface
• Have the parking brake fully engaged
WARNING! It is the responsibility of the owner to ensure the parking/emer-
gency brake properly functions. Failure to do so can result in personal injury or
property damage. We recommend the owner have the parking / emergency
brake system inspected and adjusted by a qualified automotive shop biannually.
Use of this product in a manner contrary to its intended mode of operation may
result in property damage, personal injury, or death. (1) Never remotely start the
vehicle with the vehicle in gear, and (2) Never remotely start the vehicle with
the keys in the ignition. The user must also have the neutral safety feature of the
vehicle periodically checked, wherein the vehicle must not remotely start while
the car is in gear. This testing should be performed by an authorized Directed
dealer in accordance with the Safety Check outlined in the product installation
guide. If the vehicle starts in gear, cease remote start operation immediately and
consult with the authorized Directed dealer to fix the problem.
After the remote start module has been installed, contact your authorized dealer
to have him or her test the remote start module by performing the Safety Check
outlined in the product installation guide. If the vehicle starts when performing
the Neutral Safety Shutdown Circuit test, the remote start unit has not been
properly installed. The remote start module must be removed or the installer must
properly reinstall the remote start system so that the vehicle does not start in gear.
All installations must be performed by an authorized Directed dealer.
OPERATION OF THE REMOTE START MODULE IF THE VEHICLE STARTS IN
GEAR IS CONTRARY TO ITS INTENDED MODE OF OPERATION. OPERAT-

ING THE REMOTE START SYSTEM UNDER THESE CONDITIONS MAY RESULT
IN PROPERTY DAMAGE OR PERSONAL INJURY. YOU MUST IMMEDIATELY
CEASE THE USE OF THE UNIT AND SEEK THE ASSISTANCE OF AN AU-
THORIZED Directed DEALER TO REPAIR OR DISCONNECT THE INSTALLED
REMOTE START MODULE. DIRECTED WILL NOT BE HELD RESPONSIBLE OR
PAY FOR INSTALLATION OR REINSTALLATION COSTS.
This product is designed for fuel injected vehicles only. Use of this
product in a standard transmission vehicle must be in strict accordance
with this guide.
This product should not be installed in any convertible vehicles, soft or
hard top with a manual transmission. Installation in such vehicles may
pose certain risk.
Interference
All radio devices are subject to interference which could affect proper
performance.
Upgrades
Any upgrades to this product must be performed by an authorized
Directed dealer. Do not attempt to perform any unauthorized modifica-
tions to this product.
Water/Heat Resistance
This product is not designed to be water and/or heat-resistant. Please
take care to keep this product dry and away from heat sources. Any
damage from water or heat will void the warranty.
