SuperDVR & H.264 Series Cards
User Manual
2
CONTENTS
1.1 Summarization............................................................................................... 5
1.2 System Requirements................................................................................... 7
1.2.1 QSDT4PCRC/QSDT4PCRP Card System Requirements .............................................. 7
1.2.2 QSDT8PCRP Card System Requirements..................................................................... 8
1.2.3 QSPD4116 Card System Requirements......................................................................... 9
1.3 System Specifications.................................................................................. 10
2.1 Video Capture Card Hardware .....................................................................11
2.1.1 QSDT4PCRC Card Hardware.......................................................................................11
2.1.2 QSDT4PCRP Card Hardware...................................................................................... 12
2.1.3 QSDT8PCRP Card Hardware...................................................................................... 14
2.1.4 QSPD4116 Card Hardware.......................................................................................... 15
2.1.5 Alarm Board Hardware ................................................................................................ 17
2.1.6 Connect Audio Signal .................................................................................................. 17
2.2 Install Video Capture Card Driver................................................................ 18
3.1 Display Control Panel.................................................................................. 22
3.1.1 Display Control Panel.................................................................................................. 22
3.1.2 Display Modes............................................................................................................. 22
3.1.3 Flip Pages ................................................................................................................... 22
3.1.4 Auto Dwell Display Mode............................................................................................. 23
3.1.5 Capture ....................................................................................................................... 23
3.1.6 Urgent Record............................................................................................................. 23
3.2 Login............................................................................................................ 23
3.3 Record......................................................................................................... 24
3.3.1 Record Modes............................................................................................................. 24
3.3.2 Record Setup .............................................................................................................. 24
3.3.3 Record Status Panel.................................................................................................... 25
3.3.4 Manual Record Mode .................................................................................................. 26
3.3.5 Sensor Alarm Record Mode......................................................................................... 26
3.3.6 Motion Detection Record Mode.................................................................................... 26
3.3.7 Schedule Recording .................................................................................................... 27
3.3.8 Recycling Recordings.................................................................................................. 27
4.1 Basic Configuration..................................................................................... 28
4.2 Video Configuration..................................................................................... 30
4.3 Motion Detection Configuration................................................................... 31
4.3.2 Set Motion DetectionArea........................................................................................... 32
4.3.3 Clear Motion Detection Area........................................................................................ 32
4.4 Schedule Configuration............................................................................... 33
4.5 Motion DetectionAlarm Configuration......................................................... 34
4.5.1 Alarm Triggering Conditions Configuration ................................................................... 34
4.5.2 Alarm Record............................................................................................................... 35
4.5.3 Alarm Output ............................................................................................................... 35
4.5.4 Auto Mail Function....................................................................................................... 36
4.6 E-map Configuration.................................................................................... 38
4.6.1 Edit Map...................................................................................................................... 38
4.6.2 View Map .................................................................................................................... 39
4.7 P.T.Z Control Configuration.......................................................................... 41
4.7.1 Protocol Setup............................................................................................................. 41
4.7.2 Serial Ports Setup........................................................................................................ 42
4.8 Users Configuration..................................................................................... 43
4.8.1 Change User rights...................................................................................................... 43
4.8.2 Add User ..................................................................................................................... 44

SuperDVR & H.264 Series Cards
User Manual
Error! Use the Home tab to apply
标题
1 to the text that you want to
appear here. Error! Use the Home
tab to apply
标题
1 to the text that
you want to appear here.
3
4.8.3 Delete User ................................................................................................................. 44
5.1 P.T.Z Control ……………………………………………………………………
Error! Bookmark not defined.
6.1 Record Search............................................................................................. 50
6.2 Playing Back and Control ............................................................................ 50
6.3 Other Functions........................................................................................... 53
6.3.1 Recorded File Backup ................................................................................................. 53
6.3.2 Delete Recorded Files ................................................................................................. 54
6.3.3 Capture Pictures.......................................................................................................... 55
6.3.4 Image Zoom in/out....................................................................................................... 57
Remote Live Surveillance.................................................................................. 59
7.1 Remote Surveillance Server Configuration.................................................. 59
7.2 Setting up Router for Internet Access.......................................................... 60
7.2.1 Port Forwarding........................................................................................................... 61
7.2.2 Finding Router’s Public IP address .............................................................................. 62
7.2.3 Dynamic Domain Name Services................................................................................. 63
7.2.4 To Access through Internet Explorer............................................................................. 63
7.2.5 Unknown Publisher or Unsigned Program Error........................................................... 65
7.3 Accessing IE client....................................................................................... 65
7.4 Remote playback......................................................................................... 69
7.4.1 Record playback and control........................................................................................ 69
7.5 System setup............................................................................................... 72
7.5.1 Basic Configuration...................................................................................................... 73
7.5.2 Camera setup.............................................................................................................. 74
7.5.3 Schedule configuration ................................................................................................ 75
7.5.4 Alarm configuration...................................................................................................... 76
7.5.5 Record configuration.................................................................................................... 77
7.5.6 Motion configuration .................................................................................................... 78
7.5.7 EMAIL Configuration.................................................................................................... 79
7.5.8 P.T.Z Configuration ...................................................................................................... 81
7.6 Mobile Surveillance ..................................................................................... 83
7.6.1 Introduction to Mobile Surveillance............................................................................... 83
7.7 By Smart Phone with Win Mobile Pro or Classic Operating System............ 83
7.8 By Smart Phone with Symbian Operating System....................................... 86
Appendix1 Frequently Asked Questions ....................................................... 90
Appendix 2.1 Installation ................................................................................... 90
Appendix 2.1.1 Cannot Install the SuperDVR Driver ............................................................. 90
Appendix 2.1.2 Can’t find H.264 series Devices in Device Manager...................................... 90
Appendix 2.2 How to Use SuperDVR................................................................ 90
Appendix 2.2.1 Meanings of the indicator lights .................................................................... 90
Appendix 2.2.2 How do the different record modes work?..................................................... 90
Appendix 2.2.3 How to set recycling record mode on the system.......................................... 91
Appendix 2.2.4 How to set auto reboot function.................................................................... 91
Appendix 2.2.5 How to quickly setup the schedule record function........................................ 91
Appendix 2.2.6 What are the byte rates for different image qualities from highest to normal? 91
Appendix 2.2.7 The frame rate seems to be lower than what I set......................................... 91
Appendix 2.2.8 Why can’t I select more channels to backup?............................................... 91
Appendix 2.3 How to Use Network Function..................................................... 92
Appendix 2.3.1 How to monitor on the client-side.................................................................. 92
Appendix 2.3.2 Why can’t I download the client-side software?............................................. 92
Appendix 2.3.3 Why can’t the server be configured at the client-side? .................................. 92

Error! Use the Home tab to apply
标题
1 to the text that you want to
appear here. Error! Use the Home
tab to apply
标题
1 to the text that
you want to appear here.
SuperDVR & H.264 Series Cards
User Manual
4
Appendix 2.3.4 Why can’t I see the images?......................................................................... 92
Appendix 2.3.5 What should I do if the Internet speed is quite slow?..................................... 93
Appendix 2.3.6 Why can’t I start Webcam server or RPB server? ......................................... 93
Appendix 2.3.7 How much hard drive space do the recorded files take up?........................... 93
Appendix 2.4 Other Questions .......................................................................... 94
Appendix 2.4.1 Why doesn’t the computer display work, or why can’t I access Window system?............................................................................................................................................ 94
Appendix 2.4.2 Why I can’t find the recorded files?............................................................... 94
Appendix 2.4.3 Why is the screen’s display unstable with dithering and water-wave images?94
Appendix 2.4.4 Why does it delay playing back, and why is it slow to close and open the driver?............................................................................................................................................ 94
Appendix 2.4.5 Why can’t I play back? ................................................................................. 95
Appendix 2.4.6 Why do I see some gray blocks on time progress bar area when playing back?............................................................................................................................................ 95
Appendix 2.4.7 Why could I see some old recording sections that weren’t available for play
back?................................................................................................................................... 95
Appendix 2.4.8 Precautions on changing system time .......................................................... 95
Appendix 2.4.9 If system time must be changed, please do following preparations first......... 96
Appendix 2.4.10 How to use REPAIRDB to repair SuperDVR database................................ 96
Appendix 2.4.11 How to set power options of Microsoft VISTAsystem.................................. 96
Appendix2 Quick Start for Using................................................................. 96
Appendix 3.1 Installation Instructions................................................................ 96
Appendix 3.2 Troubleshooting........................................................................... 97
Appendix3.2.1 When opening the SuperDVR program, it says ‘ Can’t find card ’. ............... 97
Appendix 3.2.2 How to setup the web client to monitor from Internet..................................... 97
Appendix3 Function Tree............................................................................. 99
Appendix 4.1 SuperDVR Function Tree............................................................. 99
Appendix 4.2 System Configuration Tree........................................................ 100
Appendix 4.3 IE Client FunctionTree............................................................... 101
Appendix 4.4 Remote Playback Function Tree................................................ 102

SuperDVR & H.264 Series Cards
User Manual
Error! Use the Home tab to apply
标题
1 to the text that you want to
appear here. Error! Use the Home
tab to apply
标题
1 to the text that
you want to appear here.
5
1 Introduction
1.1 Summarization
Thank you for choosing our digital video capture cards.
4 Channel, 8 Channel and 16 Channel cards adopt H.264 compression format,
and enable a maximum of 16 channels real-time surveillance in CIF resolution.
Our cards are mature and cost-effective products that should be your ideal
choices. They enable synchronous audio and video compression and
transmission along with their powerful compression rate and network
transmission function. They are widely used in banks, intelligent communities,
traffic management units, medical systems, educational systems, armed
forces and so on.
This manual is suitable for SuperDVR 6.2, which supports QSDT4PCRC,
QSDT4PCRP, QSDT8PCRP, and QSPD4116 cards.
In this manual, you will learn how to install the hardware and driver (software),
and how to setup the systems on this range of products. Please make sure
your operations with the products are strictly in accordance with the manual,
to maintain the stability of the digital surveillance systems.
The following are standard functions of these products:
•Schedule record mode
Users can choose any period in a day to record and set up record modes,
i.e. sensor alarm record, motion detection record, manual record,
Schedule Record.
•Motion detection mode
Motion detection areas are adjustable with a maximum 16 areas for each
channel. Users can also set motion detection sensitivity for each channel.
The system begins to record only when motion is detected is detected on
the channel and after motion stops it will stop recording after a certain time
period, which is adjustable by users.
•Sensor alarm record mode
The system has an external alarm which enables the system to support
alarm input and output.
•Recycling record mode
Users can set recording storage sequence for HDD partitions. The
recording storage will automatically switch to the next partition when the
current one is full. If all the partitions are full and recycling record mode is
enabled, the oldest recorded data will be covered by new data. Users can
also set HDD minimum storage alarm. Then once the present storage

Error! Use the Home tab to apply
标题
1 to the text that you want to
appear here. Error! Use the Home
tab to apply
标题
1 to the text that
you want to appear here.
SuperDVR & H.264 Series Cards
User Manual
6
space is less then the minimum storage and recycling record mode is not
enabled, recording will automatically stop.
•P.T.Z control function
Supports a number of protocols. Users can control multiple speed domes
and integrative cameras, including pan, tilt, zoom, focus and iris
adjustment for P.T.Z devices. Supports preset points and auto scout.
•User management
Different users have different rights, user names and passwords, to
ensure system security.
•Multi-channel display
Supports different multi-channel display modes, full screen display and
auto dwell display.
•Watch dog function
The 16 Channel card has watchdog function. In case SuperDVR driver or
Windows system is frozen, the watchdog will restart the computer and
login to SuperDVR system again automatically.
•One PC can contain 1 to 4 cards of the same model, up to a total of 32
channels
•Supports 320x240 (NTSC), 352x288 (PAL) standard resolutions.
•Image color is adjustable for each channel, including contrast, brightness,
hue and saturation.
•H.264 compression format greatly reduces HDD usage.
•Powerful video playback functions, including playing back, pause, stop,
fast-forward, single-frame play and image capture.
•Supports advanced search mode. Users can search by date/time, camera,
record mode, and random combination of the three methods.
•Supports recorded file backup, delete by date/time, camera.
•Conveniently extend system functions through software upgrades.
•Supports multiple languages, including Chinese (Traditional), English,
German, Spanish, Portuguese and other customized languages.
•CPU and storage resource saving by advanced technology
•Remote Surveillance and P.T.Z control through LAN, Intranet, and
Internet.
•Supports alarm pre-record.
•Supports buzzer, email alarm out.
•Can greatly decrease fragmented files while using NTFS partition.
•User-friendly graphical user interface.

SuperDVR & H.264 Series Cards
User Manual
Error! Use the Home tab to apply
标题
1 to the text that you want to
appear here. Error! Use the Home
tab to apply
标题
1 to the text that
you want to appear here.
7
1.2 System Requirements
Our H.264 series cards support video cards on Windows VISTA as long as the computer that
the card is installed in supports Vista, and Vista supports the video card being used.
1.2.1 QSDT4PCRC/QSDT4PCRP Card System Requirements
Card
PC Module
QSDT4PCRC/QSDT4PCRP
CPU Intel P4 processor 2.0G minimum
HDD 100Gb minimum free space
RAM 512MB minimum
VIDEO CARDS
Supports MOST* AGP and PCI-E Video Cards
with 64MB of RAM or more with full Direct Draw support.
*Some newer PCI-E cards are not yet supported
OS (32 bit) Win2000 /WinXP /VISTA
DirectX 9.0
Table1-1 QSDT4PCRC/QSDT4PCRP System Requirements
NOTICE
1. Motherboards listed below which have passed our testing and work well with
QSDT4PCRC/QSDT4PCRP:
•Intel 865G
•GA-945PL-S3E
•GA965P-S3
•GA-K8V7890-9
•GA-8IE2004P
•ASUS P5PL2
•ASUS P5B-E
2. VGA cards listed below which have passed our testing and work well with
QSDT4PCRP:
•ATI X1600
•ATI X300
•NVIDIA GeForce 7300LE
•NVIDIA GeForce 7600GS
•
NVIDIA GeForce 8500GT
NOTE: If recorded disk partition’s format is FAT32 and the system has
run for a long time, the system will create a lot of data fragments that
may result in system running slowly. It’s recommended to run a disk
defragmenter every 10 to 30 days. We strongly suggest that you use
NTFS format for recording disk partition.

Error! Use the Home tab to apply
标题
1 to the text that you want to
appear here. Error! Use the Home
tab to apply
标题
1 to the text that
you want to appear here.
SuperDVR & H.264 Series Cards
User Manual
8
1.2.2 QSDT8PCRP Card System Requirements
Card
PC Module
QSDT8PCRP
CPU Intel P4 processor 2.0G minimum
HDD 200GB minimum free space
RAM 512M minimum
VIDEO CARDS
Supports MOST* AGP and PCI-E Video Cards
with 64MB of RAM or more with full Direct Draw support.
*Some newer PCI-E cards are not yet supported
OS (32 bit) Win2000/WinXP/VISTA
DirectX 9.0
Table1-2 QSDT8PCRP System Requirements
Motherboards and Video cards listed below have passed our testing and work
well with QSDT8PCRP in Windows XP systems:
Motherboard
Video card
COLORFUL C975X-MVP
ATI HD2400
NVIDIA GeForce 7600
NVIDIA GeForce 7300
ASUS P5LD2-X
ATI HD2400
ATI X300
ASUS P5B
ATI HD2400
NVIDIA GeForce 7600
NVIDIA GeForce 7300
ATI X300
GA-965P-S3
ATI HD2400
NVIDIA GeForce 7300
ATI X300
GA-945PL-S3E
ATI HD2400
NVIDIA GeForce 7600
ATI X300
ASUS P5L-1394
ATI HD2400
NVIDIA GeForce 7600
ATI X300
ASUS P5GD1-VM
ATI HD2400
NVIDIA GeForce 7600
ATI X300
ATI X700
Table1-3 Motherboards and Video Cards Supporting XP
Motherboards and Video cards listed below which have passed our testing
and work well with QSPD4116 in Windows VISTA systems:
Motherboard
Video card
COLORFUL C975X-MVP
ATI HD2400

SuperDVR & H.264 Series Cards
User Manual
Error! Use the Home tab to apply
标题
1 to the text that you want to
appear here. Error! Use the Home
tab to apply
标题
1 to the text that
you want to appear here.
9
Motherboard
Video card
ASUS P5LD2-X
ATI HD2400
ATI X300
GA-965P-S3
ATI HD2400
ATI X300
ASUS P5L-1394
ATI HD2400
ATI X300
ASUS P5GD1-VM
ATI HD2400
ATI X300
ATI X700
Table1-4 Motherboards and Video Cards Support VISTA
1.2.3 QSPD4116 Card System Requirements
Card
PC Module
QSPD4116
CPU Intel P4 processor 2.0G minimum
HDD 200GB minimum free space
RAM 512MB minimum
VIDEO CARDS
Supports MOST* AGP and PCI-E Video Cards
with 128MB of RAM or more with full Direct Draw support.
*Some newer PCI-E cards are not yet supported
OS (32 bit) Windows 2000/WinXP/VISTA
DirectX 9.0
Table1-5 QSPD4116 System Requirements
Motherboards and Video cards listed below which have passed our testing
and work well with QSPD4116 in Windows XP system:
Motherboard
Video card
COLORFUL C975X-MVP
ATI HD2400
NVIDIA GeForce 7600
NVIDIA GeForce 7300
ASUS P5LD2-X
ATI HD2400
ATI X300
ASUS P5B
ATI HD2400
NVIDIA GeForce 7600
NVIDIA GeForce 7300
ATI X300
GA-965P-S3
ATI HD2400
NVIDIA GeForce 7300
ATI X300
GA-945PL-S3E
ATI HD2400
NVIDIA GeForce 7600
ATI X300
ASUS P5L-1394
ATI HD2400
NVIDIA GeForce 7600
ATI X300
ASUS P5GD1-VM
ATI HD2400
NVIDIA GeForce 7600

Error! Use the Home tab to apply
标题
1 to the text that you want to
appear here. Error! Use the Home
tab to apply
标题
1 to the text that
you want to appear here.
SuperDVR & H.264 Series Cards
User Manual
10
Motherboard
Video card
ATI X300
ATI X700
Table1-6 Motherboards and Video Cards Supporting XP
Motherboards and Video cards listed below which have passed our testing
and work well with QSPD4116 in Windows VISTA system:
Motherboard
Video card
COLORFUL C975X-MVP
ATI HD2400
ASUS P5LD2-X
ATI HD2400
ATI X300
GA-965P-S3
ATI HD2400
ATI X300
ASUS P5L-1394
ATI HD2400
ATI X300
ASUS P5GD1-VM
ATI HD2400
ATI X300
ATI X700
Table1-7 Motherboards and Video Cards Supporting VISTA
1.3 System Specifications
•Format: PAL/NTSC.
•Resolution: 320x240 (NTSC), 352x288 (PAL).
•Maximum Frame rate per channel: 25 fps (PAL), 30 ftp (NTSC). Screen
set: resolution 1024×768, color quality 16 bits or 32 bits.
•Compression code rate: 50kbps – 1.2Mbps.
•Data format: H.264.

SuperDVR & H.264 Series Cards
User Manual
Error! Use the Home tab to apply
标题
1 to the text that you want to
appear here. Error! Use the Home
tab to apply
标题
1 to the text that
you want to appear here.
11
2 Hardware Installation
2.1 Video Capture Card Hardware
2.1.1 QSDT4PCRC Card Hardware
Figure2-1 QSDT4PCRC Video Capture Card
Pin Port
Definition
Interpret
1PIN
5V
Power Source (5V)
2PIN
ALARM_COM
Alarm COM
3PIN
ALARM_NC
Alarm Normal Close
4PIN
ALARM_IN1
Alarm Input 1
5PIN
ALARM_NO
Alarm Normal Open
6PIN
ALARM_IN2
Alarm Input 2
7PIN
GND
Ground
8PIN
ALARM_IN3
Alarm Input 3
9PIN
GND
Ground
10PIN
ALARM_IN4
Alarm Input 4
Table2-1 QSDT4PCRC Card Pins

Error! Use the Home tab to apply
标题
1 to the text that you want to
appear here. Error! Use the Home
tab to apply
标题
1 to the text that
you want to appear here.
SuperDVR & H.264 Series Cards
User Manual
12
2.1.2 QSDT4PCRP Card Hardware
Figure2-2 QSDT4PCRP Video Capture Card
PIN1
AUDIO-1
PIN2
GND
PIN3
AUDIO-2
PIN4
GND
PIN5
AUDIO-3
PIN6
GND
PIN7
AUDIO-4
PIN8
GND
Figure2-3 Definition of Audio Connector’s Pins
Figure2-4 QSDT4PCRP Video Capture Card
J5
GiL-G-8P-S3T2-
E
1
2
3
4
5
6
7
8

SuperDVR & H.264 Series Cards
User Manual
Error! Use the Home tab to apply
标题
1 to the text that you want to
appear here. Error! Use the Home
tab to apply
标题
1 to the text that
you want to appear here.
13
PIN1
VIDEO-1
PIN9
GND
PIN2
GND
PIN10
AUDIO-1
PIN3
VIDEO-2
PIN11
AUDIO-2
PIN4
GND
PIN12
AUDIO-3
PIN5
VIDEO-3
PIN13
AUDIO-4
PIN6
GND
PIN14
NULL
PIN7
VIDEO-4
PIN15
GND
PIN8
GND
Figure2-5 Definition of Audio and Video Connector’s Pins
When there are multiple QSDT4PCRP cards connected together, please
connect the lines as in the following figure:
Figure2-6 Multi-Card Connection

Error! Use the Home tab to apply
标题
1 to the text that you want to
appear here. Error! Use the Home
tab to apply
标题
1 to the text that
you want to appear here.
SuperDVR & H.264 Series Cards
User Manual
14
2.1.3 QSDT8PCRP Card Hardware
Figure2-7 QSDT8PCRP Video Capture Card
PIN1 VIDEO-1 PIN9 GND
PIN2 GND PIN10 AUDIO-1
PIN3 VIDEO-2 PIN11 AUDIO-2
PIN4 GND PIN12 AUDIO-3
PIN5 VIDEO-3 PIN13 AUDIO-4
PIN6 GND PIN14 NULL
PIN7 VIDEO-4 PIN15 GND
PIN8 GND
Figure2-8 Definition of Audio and Video Connector’s Pins

SuperDVR & H.264 Series Cards
User Manual
Error! Use the Home tab to apply
标题
1 to the text that you want to
appear here. Error! Use the Home
tab to apply
标题
1 to the text that
you want to appear here.
15
When there are multiple QSDT8PCRP cards connected together, please
connect the line as in the following figure:
Figure2-9 Multi-Card Connection
2.1.4 QSPD4116 Card Hardware
Data Line
Video Line 9-16
Video Line 1-8
Data Line
Motherboard
Accessorial board
Call Monitor
Audio Line 1-16
Figure2-10QSPD4116 Video Capture Card
The Call Monitor interface is used to connect the spot monitor.

Error! Use the Home tab to apply
标题
1 to the text that you want to
appear here. Error! Use the Home
tab to apply
标题
1 to the text that
you want to appear here.
SuperDVR & H.264 Series Cards
User Manual
16
P2
DFD202-F-26-R-T
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
28
27
PIN1
AUDIO2
PIN11
AUDIO3
PIN2
AUDIO4
PIN12
AUDIO5
PIN3
AUDIO6
PIN13
AUDIO7
PIN4 AUDIO8 PIN14 AUDIO9
PIN5
AUDIO10
PIN15
AUDIO11
PIN6
AUDIO12
PIN16
AUDIO13
PIN7 AUDIO14 PIN17
GND
PIN8 AUDIO15
/
PIN9
AUDIO16
PIN10
AUDIO1
PIN26
Figure2-11Audio Connector and Pins Definition
J1
GiL-G-8P-S3T2-E
1
2
3
4
5
6
7
8
J2
GiL-G-8P-S3T2-E
1
2
3
4
5
6
7
8
PIN1
VIN-1
PIN2
GND
PIN1
VIN-5
PIN2
GND
PIN3
VIN-2
PIN4
GND
PIN3
VIN-6
PIN4
GND
PIN5
VIN-3
PIN6
GND
PIN5
VIN-7
PIN6
GND
PIN7
VIN-4
PIN8
GND
PIN7
VIN-8
PIN8
GND
Figure2-12Video Pins Definition

SuperDVR & H.264 Series Cards
User Manual
Error! Use the Home tab to apply
标题
1 to the text that you want to
appear here. Error! Use the Home
tab to apply
标题
1 to the text that
you want to appear here.
17
2.1.5 Alarm Board Hardware
Figure2-13Alarm Board
Figure2-14Pins Definition of Alarm Board
Connect J2 to PC serial port and you can use alarm board on SuperDVR
system.
2.1.6 Connect Audio Signal
For QSDT4PCRP, connect the audio input device to the microphone
connector on the motherboard.
Before installing the Video Capture Card hardware in PCI port of the
motherboard, make sure you’ve installed Microsoft DirectX 9.0 or later. Then
turn on the computer, the system will display ‘Found new hardware’.
NOTICE: Just click ‘Cancel’ and ignore the pop-up message.
Insert the CD that contains H.264 series capture card driver into the CD tray,
and run Setup.exe program to install the driver. The default installation path is
‘C:\Program Files\SuperDVR’.

Error! Use the Home tab to apply
标题
1 to the text that you want to
appear here. Error! Use the Home
tab to apply
标题
1 to the text that
you want to appear here.
SuperDVR & H.264 Series Cards
User Manual
18
NOTICE: If you get the error message “Can’t find card” when
running the SuperDVR software, try restarting the computer.
2.2 Install Video Capture Card Driver
STEP1：Run Setup.exe, and the installation interface appears as shown
below:
Figure2-15H.264 Series Video Capture Card Installation Interface
Figure2-16 Welcome Page
STEP2：Select video system, in the US we use NTSC format, click “next”

SuperDVR & H.264 Series Cards
User Manual
Error! Use the Home tab to apply
标题
1 to the text that you want to
appear here. Error! Use the Home
tab to apply
标题
1 to the text that
you want to appear here.
19
Figure2-17Select Video Format
STEP3：Install driver first.
Figure2-18 Rate of Progress of Driver Installation
STEP4：After this process, it begins to install the application package
SuperDVR, as shown below:
Figure2-19Select Installation Folder

Error! Use the Home tab to apply
标题
1 to the text that you want to
appear here. Error! Use the Home
tab to apply
标题
1 to the text that
you want to appear here.
SuperDVR & H.264 Series Cards
User Manual
20
STEP5：Select a folder or use the default SuperDVR, and click ‘Next’.
Figure2-20Selecting program folder
STEP6：Click ‘Next’.
Figure2-21Driver and Application Installation Finished
STEP7：Click ‘Finish’.
STEP8：After all the processes are finished, it will create a shortcut on the
desktop. Restart the computer and launch the surveillance program.
Figure2-22Shortcut of SuperDVR
NOTICE: When you install the driver software on Microsoft VISTA
system, you need select the option shown below. Other steps of
