1 Introduction
This miniature size product adopts an advanced microwave and wireless transfer
technology developed and manufactured with 2.4GHz wireless digital receiving modules,
which has stable performance and a strong anti-interference function. This product can be
used with wireless cameras to record wireless camera signals.
2 What's included:
The following items should be included in the box. Please check that you have them all before
installation.
A One receiver
B One power adapter for the receiver
C 1camera with power adapter
D One RCA cable
E stands of camera and receiver
F screws for camera mounting
3 Main features.
3.1 Supports up to 4 cameras simultaneously.
3.2 Digital 2.4G wireless modules.
3.3 Supports A/V output from receiver
3.4 Supports AE andAWB
3.5 Supports OSD (On Screen Display) screen-controlled operation
3.6 Supports 4 Channels displayed in order
3.7 Supports automatic channel switch
3.8 Transmission distance up to 100M (Tested in open air)
3.9 M-JPEG format Compression

4
4 Buttons On Receiver
4.1 Mode switching Switch between quad mode and single channel mode
4.2 Pairing Pairing the cameras and receiver
4.3 Menu OSD menu display
4.4 Auto Scan Switching the channels automatically with set time interval
4.5 Right/CH2 Move to the Right / Switch to Channel 2
4.6 Up/CH1 Move Up / Switch to Channel 1
4.7 Manual Scan Switching the channel manually
4.8 Down/Ch3: Move Down / Switch to Channel 3
4.9 Left/CH4 Move to the Left / Switch to Channel 4
4.10 SMA Antenna SMA antenna plug in
4.11 Power LED Red Light when power on

5
5Side panel
5.1 A/v output
5.2 Power input (DC 9V)

6
6Camera Installation
6.1 Camera stand mounting screw (for ceiling mount)
6.2 Power in cable (DC 5V input)
6.3 Pairing button
6.4 SMA antenna plug
6.5 Camera stand mounting screw (for desk top mount)
6.6 Microphone

7
7Menu
Enter the Menu option to setup the main feature of this product.
Through Right/Leftbutton can adjust parameters, and through Up/Down button can
select the features to set.
7.1 Resolution (High / Low): When set to low, the image is not as clear, but it displays
more frames per second. When set to high, the image will be clearer, but it
displays fewer frames per second.
7.2 SCAN TIME：This option sets the time interval between cameras when
switching channels automatically.OFF，Scan is inactive. When on options are: 5
seconds to 20 seconds between cameras.
7.3 AUDIO VOL:Adjust the volume of the audio from 0 to 20. Use the Left/right button
to reduce/increase the volume.
7.4 BRIGHTNESS: Adjust the brightness of images, range of brightness is from 0 to 5,
use the Left/right button to adjust it.
7.5 PAIR: Use this option to pair the cameras with specific channels, press the Pair
button, use the Right/Left button to choose the channel; one channel can only pair
with one camera. After selecting the specific channel and pressing the pair button
again the window below will appear:

8
Press the Pair the button on corresponding camera and wait for a while, the
monitor connected to the receiver will display the images from the cameras
that have been matched. Pairing succeeded.
7.6 TV OUT: This option allows you to select the video format (NTSC/PAL) for video
output resources. In the United States we use NTSC format.
7.7 Channel selection keys
You may select channels by using the corresponding keys on the receiver to
manually choose channel.
Channel 1：Up
Channel 2：Right
Channel 3：Down
Channel 4：Left；
Circulation Button：Monitor screen circulates the image from Channel 1 to
Channel4 then back to Channel1. The receiver will skip the channels that do not
have cameras assigned to them.
8Troubleshooting
Symptom
Remedy
The power does not
turn on.
Check that the AC power cord is connected securely.
(In case of power failure) Check the breaker.
No image display on
monitor
Check if Monitor is on and video format (NTSC / PAL)
is correct.
Check monitor’s video cable and connections.
Confirm that the camera has power.
There is no sound. Check if the audio cable is well connected to monitor.
Interruption in
Image and Sound
If there is a microwave oven close by, turn the microwave oven
off.
You may have other units that run on the 2.4GHz signal. Move
their base away from both the transmitter and/or the receiver
Your home may have a metal frame that reduces the range of the
unit.
Poor Reception
Quality
Move the Cameras and/or the receiver around to see it reception
improves.

9
Try resetting Pairing between camera and receiver
9Technical specifications

10
10 Notes
10.1 This product can be damaged by pressure or impact.

11
10.2 Any repair of this product should only be done by Professionals.
10.3 This product should only be opened by Professionals.
10.4 This product can not be used in high temperature environments.
10.5 Replacement Parts – When replacement parts are required, be sure the service
technician has used replacement parts specified by the manufacturer or have the
same characteristics as the original part. Unauthorized substitutions may result in
fire, electric shock or other hazards.
10.6 Digital Peripheral Solutions does not accept responsibility for any illegal use of this
product by the customer.
Q-SEE PRODUCT WARRANTY
Thank you for choosing our products.
All of our product users have a conditional free warranty repair service for
hardware within 12 months starting from the purchase date, and a free
exchange service within one month (valid for manufacturing defects).
Permanent upgrading service is provided for the software.
Liability Exclusions:
(1) Equipment damage caused by improper operation
Any product malfunction, abnormalities in operation or damage caused by
the following reasons are not within the free service scope of our company.
Please select payable service.
(2) Improper environment and conditions in/on which the equipment operates,
e.g., improper power, environment temperature, humidity and lightening strike
etc. that cause equipment damage.
(3) Damage caused by acts of nature: earthquake and fire etc.
(4) Equipment damage caused by the maintenance of personnel not
authorized by our company.
(5) Product sold over 12 months ago.
In order for us to provide various services to you please complete the
registration procedure after you purchase the product. Cut off or copy User’s
Information Card and fax or mail it to us after the card is filled in. You can also
register the product by going to the www.q-see.com website and clicking on
the Register link.
Customer Information Card
User’s Name
Mr./Mrs.
Company

12
Name
Postal
Address
Postal code
Phone
Number
E-mail
Model
Number of
Product
Serial Number
of Product
Purchase
Date
Distributor
If you have questions:
Contact Us:
Mailing Address: Customer Service:
DPS Inc. Phone: [phone] x 538
8015 E. Crystal Dr Email: [e-mail]
Anaheim, CA 92807
Website: Tech Support:
http://www.q-see.com Phone: [phone] x 539
Fax: Email: [e-mail]
714-998-3509
